16-17 TRACTORS
AGROTRAC
5G SERIES
130 - 150 - 170
5090 - 5100 - 5110
FLEXIBLE, VERSATILE AND MANOEUVRABLE.
EXTREME VERSATILITY.
The DEUTZ-FAHR Agrotrac range is designed and built to tackle a wide spread of farm work. Because they are so productive and versatile, Agrotrac tractors are perfectly at ease with demanding open field work, even carrying implement combinations. They also excel in fast transport. A good powerto-weight ratio, correct weight distribution, and advanced technical specifications guarantee maximum efficiency under all conditions, while intelligent ergonomics and an intuitive control layout make them easy to operate from the moment you climb aboard.
DEUTZ-FAHR’s 5G Series tractors set new standards for medium power tractors, in term of styling, efficiency, productivity and comfort. These advanced machines are designed for the utmost versatility. So they offer an almost infinite range of specification options, within a package characterized by attractive, futuristic design and contours.
The Agrotrac cab offers a high visibility.
S DF Series 1000 Tier3 engine, 4 cylinder, turbo intercooler engine. THE FEATURES
Right-hand console layout.
THE FEATURES
- or 5- speeds transmission with a wide range of specification options: up to 60 speeds in each 4 direction and a top speed of 40 km/h ECO.
SDF Series 1000 Tier2 engines, 6 cylinders, aspired, turbo or turbo intercooler.
SenseClutch PowerShuttle with 5-level response modulation and Stop&Go function.
24 FWD + 12 REV synchronised gearbox and 16 FWD+12 REV with creeper.
4-wheel disc braking.
Cab available also with high visibility roof.
Equipped with SDD (Steering Double Displacement). 55 l/min or 60 l/min ECO hydraulic system.
Cab or Platform version.
4-speed power take-off: 540/540ECO/1000/1000ECO. Ground speed PTO and front PTO.
High efficiency transmission.
4-post cab: unrivalled comfort and optimized visibility for front loader.
Up to 295 litres fuel tank capacity. 7000 kg max. lifting capacity with 68 l/min pump delivery. Available also as platform version.
AGROTRAC Engine Emissions Cylinders/displacement Max. power (2000/25/CE) Power at rated engine speed Lifting capacity Wheelbase Max. weight with cab
130
n°/cc kW/HP kW/HP kg mm kg
SDF 1000.6 WT Tier2 6/6000 92.6/126 88.3/120 7000 2750 5450
150 SDF 1000.6 WTI Tier2 6/6000 114.7/156 111/151 7000 2750 5700
Stop&Go button.
170 SDF 1000.6 WTI Tier2 6/6000 126/171 118/161 7000 2750 5700
5G SERIES Engine Emissions Cylinders/displacement Max. power (2000/25/CE)
Power at rated engine speed (ECE R 120) Lifting capacity Wheelbase Max. weight
5090
5100
5110
n°/cc kW/HP
SDF 1000.4 WTI Tier3 4/4000 64.7/88
SDF 1000.4 WTI Tier3 4/4000 73.5/100
SDF 1000.4 WTI Tier3 4/4000 80.9/110
kW/HP
64.7/88
70.6/96
75/102
4525 2400 3900
4855 2400 4200
5410 2400 4300
kg mm kg
