Recycled PET Felt Material

Page 1

PET Felt The second life for PET bottles and a sustainable alternative of future product design RESEARCH 2 INT 240 F 101 DESIGN MATERIALS
Recycled
Index What is recycled PET Felt Properties Material technical details Page 4 Page 5 Page 6 DESIGN MATERIALS 2 Uses of rPET felt Page 8
DESIGN MATERIALS 3 The process Thermoforming rPET felt in product design References Page 10 Page 14 Page 16 Page 18

What is recycled PET felt?

Pet Felt is a type of material made from PET bottles residue which are turned into granulate or plastic shreds that can pressed to form sheets of a material that resembles and feels like felt, that's where the name comes from. This type of material is characterized by the great acoustic properties that it has: due to the composition and the way the fibers are compressed, sound is absorbed on the surface while also providing insulation for the different means of application.

Sustainability

Recycling PET results in a low environmental impact, it produces 75% less of CO2 emissions and requires less energy compared to virgin material production. Recycling 1k of PET corresponds to reducing CO2 emissions by 3kg. (source: The New Plastics Economy Global Commitment 2019 Progress Report).

DESIGN MATERIALS 4

Properties

There are many brands who manufacture recycled PET felt, while the properties are mostly similar, there can be a few differences depending on the usage of additives to compress the material like glue and other substances.

Féline is a family owned business based in Amsterdam, specialized in making felt fabrics by the process of using 100% recycled PET for interior design.

To view the specifications and properties of the material, refer to the next page.

DESIGN MATERIALS 5
Composition Available thickness Width
Weight
100% PET 2mm 4mm 150 150 600 1200 1 1 DESIGN MATERIALS 6 Félines Recycled PET Felt
(cm)
(gr/lm) MOQ (lm) All Féline felts are produced with respect to nature. No use of water or drying machines in the felting process. The material is made from recycled plastic bottles. PET is sustainable, easy to process and sound absorbing
DESIGN MATERIALS 7

Uses of PET Felt

Interior Design

Due to it’s acoustic properties, the most common use for Recycled PET felt is in the interior design industry. It’s a sustainable alternative to acoustic panels and it’s more durable than acoustic foam because of the compact composition of the material.

Cleaning

DESIGN MATERIALS 8

Car Industry

The car industry was the first application of recycled PET Felt in a different way from an acoustic panel. Through thermoforming, the shape for the roofs of cars can be manufactured and it is beneficial for sound absorbing and insulating on the roof.

DESIGN MATERIALS 9

The process

DESIGN MATERIALS 10
DESIGN MATERIALS 11

Recollecting plastic waste

The first step is recollecting PET bottles waste that needs to be carefully selected from recycling centers to be sorted and cleaned for use. In DeVorm's manufacturing process, they have a machine that sorts out colored plastic from transparent plastic.

Shredding

The bottles are passed to a granulator machine in which large blades shred the bottles into flakes, while a granulator removes remaining debris and waste parts.

DESIGN MATERIALS 12

Turning into fibre

The flakes are passed through a hot extruder that melts them and turns them into thin polyester fibres that resemble a wool-like texture.

Felt sheets

The material enters a felting machine which creates layers of fibres to them compress them together. Afterwards the felting begins, which means that needles stab the material in order to turn it into felt. The sheets then get pressed into the form of felt sheets

DESIGN MATERIALS 13

Thermoforming

The final and innovative way to use the recycled PET felt is in the step of thermoforming. Thermoforming is a process that works with the use of molds and heat that give thermoplastic materials a desired organic shape. In the case of recycled PET felt, the process works by thermopressing the felt sheets into an innovative shape for acustic panels, interior car parts, furniture for product design, among other possible ways.

DESIGN MATERIALS 14

See more about DeVorm's production process here: https://journal.devorm.nl/blog/from bottle-to-chair-how-we-make-petfelt

DESIGN MATERIALS 15

Recycled PET Felt in product design

LJ 1 Chair by DeVorm
DESIGN MATERIALS 16
Fost Acoustic lamp by DeVorm
DESIGN MATERIALS 17
Nobody chair by Boris Berlin for Komplot Clothing hangers by WOH

References

Minimal art Recycled PET felt MaterialDistrict. (2021, September 30). MaterialDistrict; MaterialDistrict. https://materialdistrict com/material/minim al art recycled pet felt/ Michaeloudis, C (2020) PET FELT, a plastic that’s actually good for the office. AllSfar; AllSfar. https://allsfar.com/blogs/news/a pet felt a plastic thats actually good for the office De Vorm. (2022). From Bottle to Chair: How We Make PET Felt. Devorm.nl. https://journal.devorm.nl/blog/from bottle to chair how we make pet felt PET felt | Féline | 100% recycled PET | Sustainable felt | Acoustic fabric. (2022, September 26). Féline. https://www.felinefabrics.com/feltcollections/pet felt/ Guide to Thermoforming. (2022). Guide to Thermoforming. Formlabs. https://formlabs com/blog/thermoforming/

DESIGN MATERIALS 18
DESIGN MATERIALS 19
fibre gets
new life
felt
felt/
all about recycled PET Areyour.
t all about recycled pet/#:~:text=Lower%20environmental%20i mpact%20Indeed%2C%20PET,Global%20 Commitment%202019%20Progress%20R eport Acoustic fabrics | About | Féline | Wool felt | 100% recycled PET felt |
Giovani. (2021, December 14). Barro Negro en Oaxaca: Artesanías Emblemáticas | Fabricación. Xaca.mx. https://xaca.mx/barro-negro-en-oaxaca-to. (2014) WOH WOH https://www.woh.ee/technology Polyester
a
as
Intermedius (2022, October 3) Intermedius. https://intermedius.fi/en/products/polyeste r
rPET
(2022, May 19). Areyour. https://www.areyour.org/en/2022/05/19/rpe
(2020, November 11). Féline. https://www.felinefabrics.com/feline
