We are working with Cambridge Assessment International Education towards endorsement of this title. Any references or material related to answers, grades, papers or examinations are based on the opinion of the author(s). 2 Programming constructs
PRACTICE TASK 2.3 How would Flowchart 2.3 need to be changed if the requirements for the acceptance of the new password were altered to include the following? •
The password must contain more than six characters.
•
The password must contain at least one symbol.
LE
Redraw the flowchart to include this option. You only have to include (Stage 1) general descriptions for this flowchart. You do not yet know how to program the checks required, so a general description of each check will be acceptable.
SKILLS FOCUS 2.1 COMMON FLOWCHART ERRORS
P
A system is required that will accept two numbers. The numbers must be larger than 10 and less than 20. Numbers outside of this range will be rejected and the user asked to re-input values. Once both numbers are within the range the system will output the result of adding the two numbers together. Consider the attempt at creating a flowchart for the task shown in Flowchart 2.4.
M
START
INPUT Numbers
OUTPUT "Not in range re-enter"
Calculate Result
INPUT Numbers
S
A
Check in Range 10 to 20
OUTPUT
STOP Flowchart 2.4: Flowchart attempt
31 Original material © Cambridge University Press 2021. This material is not final and is subject to further changes prior to publication.
