CONTINUED Solution
LE
START
INPUT Max Score INPUT Candidate Score
Percent ← Candidate Score / Max Score * 100
Percent >= 80
Invite to Interview
M
Send Reject Letter
TRUE
P
FALSE
STOP
Flowchart 2.2: Flowchart to output the results of an entrance examination
A
NOTE: Observe the use of the diamond symbol to indicate a decision. The criteria are Boolean expressions that will either be TRUE or FALSE. It is crucial that the TRUE/ FALSE indicators are added to show how the execution of the code will flow.
S
PRACTICE TASK 2.2
How would Flowchart 2.2 need to change if the university introduced a process where candidates who achieved more than 90% in the entrance examination are automatically offered a place at the university without the need of an interview? Redraw the flowchart to include this option.
