PROPOSED DETAIL DRAWINGS

Next Article
DEVELOPMENT

DEVELOPMENT

Detail 1: Retractable Walls

Existing ceiling. Brown oak beams support the roof structure.

Advertisement

Steel Track 98mm x 66mm

Existing ceiling. Brown oak beams support the roof structure.

Movement mechanism specified by manufacturers

Steel Track 98mm x 66mm

Bespoke element: 15mm birch plywood

Movement mechanism specified by manufacturers

Brown oak beams structure.

66mm mechanism specified by 15mm birch specified by acoustic qualities wheels for better proposed cork specified in Drawing DR - 306

Bespoke element: 15mm birch plywood

Insulation as specified by manufacturers for acoustic qualities

Insulation as specified by manufacturers for acoustic qualities

Bespoke element: wheels for better fraction against proposed cork flooring Cork flooring as specified in Drawing TB23 - CML - XX - DR - I - 306

Existing floor, assumed to be concrete

1070 Part Elevation A-A 1:20 at A2

Bespoke element: wheels for better fraction against proposed cork flooring Cork flooring as specified in Drawing TB23 - CML XX DR - 306

Existing floor, assumed to be concrete

Part Elevation A-A 1:20 at A2

Retractable Wall Plan (closed) 1:20 at A2 Retractable Wall Plan (open) 1:20 at A2

Detailed Section A-A 1:2 at A2

Detailed Section A-A

1070 Part Elevation 1:20 at A2

1:2 at A2

Specified following the system proposed by Accordial.co.uk Bespoke design manufactured off site. Please see Specification Sheet for more information.

Specified following the system proposed by Accordial.co.uk Bespoke design manufactured off site. Please see Specification Sheet for more information.

Part

Part

Sketch Up drawing illustrating different parts of the bespoke unit. The tambour slabs are introduced into the unit from the back as the tambour track has an entry slot, visible in Detail

Sketch Up drawing illustrating different parts of the bespoke unit. The tambour slabs are introduced into the unit from the back as the tambour track has an entry slot, visible in Detail

Vertical Opening Plan 1:20 at A2

Section C-C in Drawing TB23 - CML - XX - DR - I - 305. Horizontal

Section C-C in Drawing TB23 - CML - XX - DR - I - 305.

Sketch Up drawing illustrating different parts of the bespoke unit. The tambour slabs are introduced into the unit from the back as the tambour track has an entry slot, visible in Detail Section C-C in Drawing TB23 - CML - XX - DR- 305.

Detail 3: Tambour Doors

Project Name: The Building Drawing Title:

Horizontal

Same system applies as with a vertical opening. Only using this image to illustrate how it would look.
