GLASS GARDEN TOWER
The planting on the facades of the ground floor and the 2nd level provide acoustic and visual barriers to the intimidating and awe in ducing cliffs.
The circulation hugs the inner walls in a cir cular pattern, guiding people to the lookout spaces on each level, finishing at the open air space at the top of the building.
The space is lit by natural lighting as a delib erate experience for visitors.
The stained glass skylight that gives the tow er its name draws light from the open air top floor to the greenery filled second floor. The yellow stained glass light takes advantage of the positivity commonly evoked by that bright colour.
LOOKING
ALEXANDA CANAL PRECINCT MASTERPLAN
The revitalisation project is centred around the Northern end of Sydney’s Alexandra Canal. The project is guided by a three part vision: revitalising waterways to connect with Country, integrat ing significant heritage sites with newer public and private spac es, and increasing pedestrian appeal to draw people into each new human centred spaces.
This is achieved through naturalising and landscaping the Alex andra Canal with native species, creating green walkways that connect new public spaces, implementing new guidelines for the creation of resilient, sustainable and attractive enterprise and in dustrial sites, and the addition of a mixed-use development for home availability and affordability.
T T
METRES 0.5 1 2 METRES 1:20@A2 18 mm corrugated sheeting framing 40 x 60 mm spruce battens 40 mm thermal insulation 6 mm float glass 15 mm cavity 6 mm toughened safety glass aluminium window frame 40 x 60 mm spruce battens 18 mm corrugated sheeting framing 40 mm wood fibre thermal insulation 300 mm lightweight concrete 10 mm plaster 30 mm timber 300 mm lightweight concrete 40 60 mm battens 40 mm thermal insulation 40 mm thermal insulation 40 x 60 mm battens 100 mm trapezoidal profile sheeting 40 mm thermal insulation 50mm 150mm timber beam 30 mm thermal insulation aluminium guttering 42 mm trapezoidal profile sheeting waterproofing 120 mm thermal insulation vapour barrier Architects: LIN Finn Geipel, Giulia Andi, Berlin/Paris v Structural Engineer: ChristianFocken, Bad Zwischenahn Private House in Oldenburg, Germany, Date: DRAWING NO. 3 (STEEL) Draftsperson: 500587595 Completion: 2003 BDES3023: Architectural Technologies 3 300 mm lightweight concrete 10 mm plaster 30 mm aluminium window sill 40 mm thermal insulation 25 35 timber joists 10 mm plaster joists 40 mm thermal insulation 25 mm chipboard framing 15 mm wood-strip flooring 300 mm lightweight concrete 10 mm plaster 300 mm lightweight concrete 300 mm lightweight concrete 6 mm float glass 15 mm cavity 6 mm toughened safety glass aluminium frame aluminium window frame 25 mm thermal wood fibre insulation 40 mm thermal insulation lightweight concrete slab 10 mm waterproofing membrane separating layer 45 mm screed waterproofing 25 mm chipboard framing 15 mm wood-strip flooring 60 x 100 mm spruce joists 80 mm wood fibre insulation waterproofing membrane 45 mm screed 60 x 250 mm spruce joists aluminium flashing wood fibre insulation timber window piece 0.5 1 2 METRES 1:20@A2 10 mm plaster 100 mm trapezoidal profile sheeting 40 mm thermal insulation 50mm 150mm timber beam 30 mm thermal insulation aluminium guttering 42 mm trapezoidal profile sheeting waterproofing 120 mm thermal insulation vapour barrier 3 300 mm lightweight concrete 10 mm plaster 30 mm aluminium window sill 40 mm thermal insulation 25 x 35 timber joists 10 mm plaster joists 40 mm thermal insulation 25 mm chipboard framing 15 mm wood-strip flooring 300 mm lightweight concrete 10 mm plaster 300 mm lightweight concrete 300 mm lightweight concrete 6 mm float glass 15 mm cavity 6 mm toughened safety glass aluminium frame aluminium window frame 25 mm thermal wood fibre insulation 40 mm thermal insulation lightweight concrete slab 10 mm waterproofing membrane separating layer 45 mm screed waterproofing 25 mm chipboard framing 15 mm wood-strip flooring 60 100 mm spruce joists 80 mm wood fibre insulation waterproofing membrane 45 mm screed 60 x 250 mm spruce joists wood fibre insulation timber window piece
Private House in Oldenburg, Germany (2003) LIN Finn Geipel
0.5 1 METRES 1:20@A2 Architect: Beer Bembé Dellinger Housing Development in Garmisch-Partenkirchen, Germany Date: DRAWING NO. 4 (TIMBER) Draftsperson: 500587595 BDES3023: Architectural Technologies 3 60mm x 60 mm larch rail 60 mm x 40 mm notched larch upright 60 mm x 40 mm larch timber section 120 mm UPE beam 25 mm larch boarding 30 mm x 50 mm battens 30 mm 50 mm counter battens 16 mm ash parquet, glued 67 mm heated cement screed 30 mm 30 mm PS rigid foam board as footfall sound insulatin PE-foil 100 mm Perlite fill trickle protection 100 mm cross laminated timber ceiling platev 16 mm ash parquet, glued 67 mm cement screed incorporat ing heating 11 160 mm HEA steel beam 1100 mm wood fibre insulation 80 mm cross laminated timber 240 mm 30 mm spruce three-ply panel 30 mm PS rigid foam board as footfall sound insulation PE-foil 270 mm reinforced concrete slab 10 mm internal plaster 40 mm EPS thermal insulation 57.5 mm fibre cvement corrugated sheet roofing 60 mm 40 mm spruce battens 60 mm 40 mm spruce counter-battens roofing membrane 24 mm spruce boarding 2 x 1100 mm wood fibre insulation spruce rafters 80 mm cross laminated timber 11 160 mm HEA steel beam aluminium guttering 2 x 40 x 80 mm spruce batten 40 x 80 mm spruce batten aluminium flashing 175 mm reinforced concrete wall 10 mm waterproofing membrane 185 mm loose wood fibre between timber uprights as insulation 185 mm loose wood fibre between timber uprights as insulation 35 mm wood fibre insulation panel 15 mm internal plaster 30 mm 50 mm battens 30 mm x 50 mm battens 0.5 1 METRES 1:20@A2 16 mm ash parquet, glued 67 mm heated cement screed 30 mm 30 mm PS rigid foam board as footfall sound insulatin PE-foil 100 mm Perlite fill trickle protection 100 mm cross laminated timber ceiling platev 16 mm ash parquet, glued 67 mm cement screed incorporat ing heating 11 160 mm HEA steel beam 1100 mm wood fibre insulation 80 mm cross laminated timber 240 mm 30 mm spruce three-ply panel 30 mm PS rigid foam board as footfall sound insulation PE-foil 270 mm reinforced concrete slab 10 mm internal plaster 40 mm EPS thermal insulation 57.5 mm fibre cvement corrugated sheet roofing 60 mm 40 mm spruce battens 60 mm 40 mm spruce counter-battens roofing membrane 24 mm spruce boarding 2 x 1100 mm wood fibre insulation spruce rafters 80 mm cross laminated timber 11 160 mm HEA steel beam 15 mm internal plaster Housing Development in Garmisch-Partenkirchen, Germany Beer Bembé Dellinger
0.75 METRES 1.75 30 mm 40 mm corten steel rectan 40 mm 40 mm corten steel rectan 400 mm x 350 mm reinforced concrete foundation 120 mm brick wall 30 mm cement mortar 10 mm sealing waterproofing membrane 10 mm smooth cast plaster finish 50 mm polished screed 9 mm safety glass double glazed with 18 mm cavity 100 mm reinforced concrete floor slab 68 mm x 92 mm cataplpa timber window frame 270 mm x 200 mm steel box beam 10 mm corten steel sheeting 40 mm screed roof seal 300 mm steel I Section max 120 mm screed to falls 60 mm rigid-foam insulation 100 mm reinforced concrete roof slab 30 mm x 30 mm steel angles 40 mm x 40 –140 mm steel square hollow sections and rectangular hollow sections 0.25 0.75 METRES 1:10@A2 3 1.75 6 mm Corten steel sheeting 30 mm 40 mm corten steel rectan gular hollow sections 40 mm 40 mm corten steel rectan gular hollow sections 400 mm 350 mm reinforced concrete foundation 120 mm brick wall 30 mm cement mortar 10 mm sealing waterproofing membrane 10 mm smooth cast plaster finish 50 mm polished screed 9 mm safety glass double glazed with 18 mm cavity 100 mm reinforced concrete floor slab 68 mm 92 mm cataplpa timber window frame 270 mm 200 mm steel box beam 10 mm corten steel sheeting 40 mm screed roof seal 300 mm steel I Section max 120 mm screed to falls 60 mm rigid-foam insulation 100 mm reinforced concrete roof slab 30 mm x 30 mm steel angles 40 mm x 40 –140 mm steel square hollow sections and rectangular hollow sections Rockview Tea
in
Trace
House
Weihai
Architecture Office
0.5 1 METRES 1:20@A2 Architect: Alexander Reichel, KassellMunich Assistants: Johanna Reichel-Vossen, Stefan Seibert, Caroline Ossenberg-Engels. Elke Radloff Structural engineers: Habein, Kleinhans, Marx, Hochtie! AG. Kassel Mixed Office and Residential Block, Kassel, Germany, 1999 Date: DRAWING NO. 2 (CONCRETE) Draftsperson: 500587595 BDES3023: Architectural Technologies 3 30
22
200
45
40
200
slab 80
bitumenised
30
30
larch
8
precast concrete element 30 mm glass fibre facade cladding panels 50 mm mineral wool insulation 30 mm glass fibre facade cladding panels 30 mm x 40 mm larch wood cladding 30 mm glass fibre facade cladding panels 500
50
con crete beam spacers 30 mm mineral wool insulation 0.5 1 METRES 1:20@A2 2 30 mm
wool 22 mm
flooring 200
45 mm
40 mm
200 mm
slab 80 mrn
barrier bitumenised
felt 30 mm
insulation 30
insulation larch
clear
8
15
cavity precast concrete element 30 mm glass fibre facade cladding panels 50 mm mineral wool insulation 30 mm glass fibre facade cladding panels 500 mm x 50 mm precast con crete beam spacers 30 mm mineral wool insulation Mixed Office and Residential Block, Kassel, Germany (1999) Alexander Reichel, KassellMunich
mm impact sound insulation mineral wool
mm industrial quality parquet flooring
mm reinforced concrete slab (precast concrete floor planks)
mm screed polyethylene separating layer
mm reconstituted stone slabs
mm reinforced concrete
mrn mineral wool vapour barrier
roofing felt
mm mineral wool insulation
mm mineral wool insulation
wood timber window frame with clear lacquer finish
mm safety glass x 2, with 15 mm cavity
mm x
mm precast
impact sound insulation mineral
industrial quality parquet
mm reinforced concrete slab (precast concrete floor planks)
screed polyethylene separating layer
reconstituted stone slabs
reinforced concrete
mineral wool vapour
roofing
mineral wool
mm mineral wool
wood timber window frame with
lacquer finish
mm safety glass x 2, with
mm
Tennis Court
Church Street
SP2 Infrastructure
Legend.
FredrickStreet
Heritage Conservation Area
Heritage Building
Building Height Zone M (12.5m max)
Building Height Zone I (8.5m max)
Contour Lines
Setback Lines
Major Roads
Pedestrian movement
Vehicle movement
Lot Size: Minimum lot size 500sqm
Land Zoning: Low Density Residential
BoughtonStreet
Maximum Building Height: 8.5m
Maximum Floor Space Ratio (n:1): 0.7
FredrickStreet
TawaStreet
Church Street
Henry Street
RichmondAvenue
HcArchitecture + Construction TAWA STREET 3 TAWA STREET T A W A S T R E E T 1 T A W A S T D2 D3 D4 D9 4400 1665 7700 1100 9500 4100 RETAINED DRIVEWAY MASTER BEDROOM BEDROOM 2 BEDROOM RUMPUS ROOM WINDOW SEAT STONE PAVERS TIMBER DECK LAUNDRY ENSUITE W/C KITCHEN DINING LIVING 6400 2 5 0 0 O D E OBEMOVED NEW SEMI PERMEABLE BRICK FENCE TO MATCH SCALE AND STYLE OF EXISTING FENCH VEGETABLE GARDENS GARDEN SEATING GARDEN SEATING GARDEN SEATING RECYCLED BRICK GARDEN EDGING RECYCLED MASONARY WALL RECYCLED MASONARY WALL RETAINED HERITAGE STYLE EXTERIOR W4 W7 W8 W14 W17 RETAINED FRONT LAWN RETAINED FRONT LAWN EXISTING TILED PATH EXISTING TILED PORCH HALLWAY TIMBER ACCESS GATE MIN SETBACK 900m MIN SETBACK 900m MIN SETBACK 900m MIN SETBACK 900m TIMBER ACCESS GATE STORAGE SCALE BAR 1:100 5 0 10 15 20 DATE: 18/10/22 DRAWING NO:DA003 DRAWN BY: Cecilia Kent PROJECT: Tawa Street Alterations and Additions DRAWING STAGE: Final DRAWING TITLE: Proposed Floor Plans HcArchitecture Construction Architecture Construction Hc N TAWA ST 8 5m max bu d ng he gh ex s ng bu d ng he gh no change s t e b o n d a r y TAWA ST 8 5m max bu d ng he gh ex s ng bu d ng he gh no change s i e b o n d a y RL 21.9 RL 16.6 3 Tawa St 3 Tawa St RL 21.9 RL 16.6 TIMBER FRAMED WINDOW BRICK PARAPET ALUMINIUM GUTTERING W11 W12 W13 TIMBER WINDOW ABLE SHADING TIMBER FRAMED WINDOW TIMBER WINDOW ADJUST ABLE SHADING D7 RUMPUS KITCHEN EXISTING TILE ROOF EXISTING TERRACOTTA TILE ROOF SCALE BAR 1:50 10 0 1 2 3 4 5 SCALE: 1:50@A3 DATE: 18/10/22 DRAWING NO: DA008 DRAWN BY: Cecilia Kent PROJECT: Tawa Street Alterations and Additions DRAWING STAGE: Final DRAWING TITLE: Section and Elevation View 1. HcArchitecture Construction Architecture Construction Hc N TAWA STREET 3 TAWA STREET T A W A S T R E E T 1 T A W A S T W4 W6 W7 W9 EXISTING TILED PORCH HALLWAY MIN SETBACK 900m MIN SETBACK 900m MIN SETBACK 900m MIN SETBACK 900m TIMBER STORAGE Retained Existing New Roof Plan 44 0 1 65 77 0 11 0 50 100 7 0 3 00 29 0 RETAINED DRIVEWAY MASTER BEDROOM BEDROOM BEDROOM TIMBER DECK LAUNDRY ENSUITE W/C 4 4 5 0 9 0 0 1 6 5 6 9 5 0 0 1 2 0 0 m m 30 2 00 6 00 3 00 30 64 0 2 5 0 0 BOX GUTTER GARDEN SEATING GARDEN SEATING SKYLIGHT SKYLIGHT PARAPET WALL SCALE BAR 1:100 5 0 10 15 20 DATE: 18/10/22 DRAWING NO: DA004 DRAWN BY: Cecilia Kent PROJECT: Tawa Street Alterations and Additions DRAWING STAGE: Final DRAWING TITLE: Proposed Roof Plan HcArchitecture Construction Architecture Construction Hc N BOX GUTTER TERRACOTTA TILE ROOF W2 RETAINED WINDOWS RETAINED PORCH W3 W5 W7 W6 W4 W9 W10 W8 W14 HALLWAY RUMPUS ROOM TERRACOTTA TILE ROOF BE DEMOLISHED EXISTING ROOF LINE TO BE DEMOLISHED BOX GUTTER D6 RL 19.9 RL 21.9 FL 16.6 RL 21.9 FL 16.6 RL 19.9 RL 19.9 RL 21.9 FL 16.6 RL 21.9 FL 16.6 RL 19.9 FL 16.2 FL 16.2 T A W A S T T A W A S T 8 5m max bu d ng he gh s e b o n d a r y 8 5m max bu d ng he gh s i e b o n d a r y TIMBER FRAMED WINDOWS TIMBER FRAMED WINDOWS GREEN WALL SCALE BAR 1:50 10 0 1 2 3 4 5 SCALE: 1:50@A3 DATE: 18/10/22 DRAWING NO: DA009 DRAWN BY: Cecilia Kent PROJECT: Tawa Street Alterations and Additions DRAWING STAGE: Final DRAWING TITLE: Section and Elevation View 2 HcArchitecture Construction Architecture Construction Hc N ALTERATION AND ADDITION CONCEPT FOR DEVELOPMENT APPLICATION 1 TAWA ST ASHFIELD
