Established in 2012 Hunan Chendong Technology Co., Ltd (CDT) is located in the historic city of Changsha, Hunan province, where is known as Yulu Mountain, a part among Nanyue Hengshan Mountain and Yuelu Academy with a thousand years history. CDT is a hi-tech company that focuses on R&D, production and sell all kinds of aviation obstruction light and green light for airport navigation
CDT has approved by ISO9001, CAAC and ICAO owned numerous patents. And keep long terms cooperation with enterprises as ZTE, State Grid Corporation of China, China Southern Power Grid, CAH, CWAG and Hunan Airport Management Group etc.
As a pioneer in aviation obstruction light, CDT expands overseas market at the same time. We have exported to over 50 countries in Southeast Asia, Middle East, America, Africa and Oceania.
Keep a principle of improving quality and fulfill clients requirements continuously, 100% qualified CQC as quality goal, market-oriented and customer-centric marketing target, we offer 24 hours service to customers. Standing in over 100 airports in 30 provinces to offer and secure safe flight services, CDT aviation obstruction lights earns excellent reputation and customers acceptance.
CDT take innovation and factualism, honesty and trustworthiness as our operation principle, and promise to offer the most competitive price, thoughtful services and excellent products.
Now, we are dedicating to making CDT a century enterprise in aviation obstruction lights field. To become a healthier, safer and more environment friendly hi-tech company, CDT are here to serve airports throughout the world.
1.Hunan ChendongTechnology Co , Ltd (CDT) was estab ished
2.Approved by SO9001, got Independent Import & Expor Right obta ned many patents
1.CDTaviation obs ruction gh is cert f ed by CAAC
2.Product is exported o SoutheastAsia
3.Complete helipor design of world argest nd vidual bu d ng---- Wanj a nternational Fash on Mall
Moved to new self-proprietor a factory with over 3 000㎡ area And deve oped wor d f rst Meteorological target l ght
Cooperated with over 80 a rports in Ch na, Low v sibility operation ght achieve great success and got Number 1 n domestic market sales
Expor ed to over 50 countries n the wor d and cooperated with ZTE, State Grid Corporation of Ch na , PEK, CR Power , achieving more than RMB 50 mil on sales
1 Open the NorthAmerican Market;
2 Coopera e w th Heliports Pro ect
3 Researched and Developed the Rotat ng beacon
Got ICAO Certificate o TypeAHigh Intensity obstruction ights,Type B High Intensity Obstruct on lights,TypeAWhite Med um Intensity Obstruc on
ChendongTech has been exceeded 20 authorized patents , and partic pated n large foreign exhib tions in Duba (UAE),Jakarta(Indonesia) and Munich(Germany)
the number of paten s reached 33 pcs
the company has 53 paten s with sa es exceed ng 16 m lion do oars(more than 100 mil on yuan n RMB), and has become a key enterpr se in Changsha High-tech Zone
CDT will fight for a brighter and promising future!
The inspection qualified rate of product is more than 96%, final inspection qualified rate 100%, customer satisfaction more than 96 points, in the past three years increased 0 1% each year, the failure rate is lower than 0 1% during the warranty period
Improve product quality continuously to meet the customer’s demands
Work Shop
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace, helipads, iron tower chimney ports wind power plants, bridge and city high-rise buildings where require aviation warning
Usually used above 150m buildings, could use alone, also could use with Medium OBL type B and Low intensity OBL type B together.
(Low power consumpt on, easy insta at on, small size new appearance)
● The h of the ght adopts high qua ty a uminium a oy, the light emitting surface use tempered g ass, the structure is h gh strength resistance to corros on
● Use the spec al optica ref ector des gn, the visua range further angle more accurate no light po ut on
● L ght source adopts import high quality LED fespan up to 100 000 hours low power consumption energy efficiency and env ronmenta protection.
● Based on the sing e chip computer contro automat c identif cat on sync signa do not d stingu sh the main light and aux iary light and also could be contro ed by the controller
● Same power supply voltage with synchronous s gnal integrate n power supp y cable e minate the damage by error nsta ation caused
● Used the photosensitive probe f t for the natural ght spectrum curve automat c contro ght ntensity evel
● The circuit of the ght has surge protect on, so that the light is suitable for a harsh environment
● ntegra structure protect on evel of Ip66
● GPS synchronizing function s availab e
Item Parameter
Standard FAA， CAO Standard
Operat ng voltage AC220V
Power consumption ≤25W
(Other ava able)
F ashing frequency 40 60t mes/m n
L ght source White LED
L ght intensity 2000cd(±25%)
Background Luminance 20000cd(±25%)
≤50Lux
Background Luminance50～500Lux 200000cd(±25%)
Background Luminance＞500Lux)
L fespan ＞100 000hours
Em tting color White
Beam angle 90° horizontal beam ang e 3-7° vertica beam spread
Method o synchron zation Bu t- n GPS / Bui t- n Photoce as opt on)
Overall s ze(mm) 654mm×204mm×134mm
Installation size(mm) 629mm×60mm×4-M10
Ingress protection Ip66
Lightn ng protect on evel 10KA
Operat ng temperature -40℃～55℃
Net weight 11 9kg
Wind oad 240km/h
Wide y used in the A r Force, civilian airports and obstacle free airspace Mainly used in the electric power tower, the other place above the ground 150m also could use as the actual requirements accordingly.
(Low power consumption easy installation sma new appearance) s ze,
● The h of the ght adopts high qual ty a uminium a oy, the light emitting surface use tempered glass the structure is h gh strength resistance to corros on
older
● Use the spec al optica ref ector des gn the v sual range further angle more accurate no light
po ution
● L ght source adopts import h gh quality LED fespan up to 100,000 hours low power consumption, energy efficiency and env ronment protection
● Based on the single chip computer contro automat c identif cat on sync signa do not d stinguish the main light and aux ary ight and a so could be contro ed by the controller
● Same power supply vo tage w th synchronous s gnal, integrate n power supp y cable e minate the damage by error nsta at on caused
● Used the photosensit ve probe f t for the natura ght spectrum curve automat c contro ght ntens ty evel
● The c rcuit of the l ght has surge protect on so that the ight is suitab e for a harsh environment
● ntegra structure, protect on leve of Ip66
● GPS synchronizing funct on s ava lable
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC220V (Other ava able)
Power consumpt on ≤15W
Flash ng frequency 40 60times/min
Light source White LED
Light intensity 2000cd(±25%)
Structure chart
≤50Lux
(Background Luminance ) 20000cd(±25%)
(Background Luminance50～500Lux) 100000cd(±25%)
(Background Luminance＞500Lux)
Lifespan ＞100,000hours
Emitting co or White
Beam angle 90° horizontal beam angle 3-7° vert ca beam spread
Method of synchron zation Bui t- n GPS / Bu t-in Photocel as opt on)
Overall size(mm) 510mm×204mm×134mm
Installation size(mm) 485mm×70mm×4-M10
Ingress protection Ip66
Lightn ng protection evel 10KA
Operating temperature -40℃～55℃
Net weight 9 5kg
Wind oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace, helipads, iron tower chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning
Usually used above 45m and less than 150m buildings, could use alone, also could use with Medium OBL type B and Low intensity OBL type B together.
● Cover of the light adopts PC with ant -UV wh ch is h gh efficiency ght transmission up to 92% quite high mpact resistance and f ts the bad environment very we
● Ho der of the ight is made of alum num alloy and painted by spraying p ast cs the structure s high strength, res stance to corrosion
● Use the specia opt cal reflector design the v sual range further ang e more accurate, no ght pollution.
● Light source adopts mport h gh qua ty LED, lifespan up to 100,000 hours, ow power consumpt on energy eff c ency and environmental protect on
● Based on the single chip computer control, automatic dent fication sync s gnal do not dist nguish the main ght and auxil ary l ght, and a so cou d be controlled by the contro er
● Same power supp y vo tage w th synchronous signa , ntegrate in power supply cab e, el m nate the damage by error installation caused
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro light intens ty leve
● The c rcuit of the light has surge protect on so that the ght is su tab e for a harsh environment
● Integral structure, protection leve of p66
● GPS synchron z ng function is avai able
Parameter 应用领域
Item Parameter
Standard FAA， CAO Standard
Operating vo tage AC220V/DC12V/DC48V (Other availab e)
Power consumpt on ≤9W
Flash ng frequency 40 60t mes/m n
Light source White LED
Light ntens ty 2000cd(±25%)
(Background Luminance≤50Lux)
20000cd ±25%
(Background Luminance50～500Lux)
20000cd(±25%)
(Background Luminance＞500Lux)
Lifespan ＞100 000hours
Emitting co or Wh te
Beam ang e 360° hor zonta beam angle
≥3° vert cal beam spread
Method of synchronization Built-in GPS / Built-in Photoce l(as option)
Overal size(mm) Ф268mm×206mm
nsta at on size(mm) 166mm×166 mm -4×M10
ngress protect on Ip66
Lightning protection level 10KA
Operating temperature -40℃～55℃
Net we ght 5 5kg
Wind load 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports, wind power plants, bridge and c ty high-rise buildings where require aviation warning
(Low power consumption, easy installation, high br ghtness, smal size)
● Cover of the l ght adopts PC w th ant -UV wh ch is high eff ciency ght transm ss on up to 92%, qu te high impact res stance and fits the bad env ronment very we l
● Ho der of the light s made of a um num al oy and painted by spraying plastics the structure s h gh strength, resistance to corrosion
● Use the spec al optica ref ector des gn the v sual range further angle more accurate no light po ution
● L ght source adopts import h gh quality LED fespan up to 100,000 hours, low power consumption, energy efficiency and env ronmenta protect on
● Based on the single chip computer control automat c identif cation sync signa do not d stinguish the main light and aux ary ght and a so could be contro ed by the controller
● Same power supply vo tage w th synchronous s gnal integrate n power supp y cable e minate the damage by error nsta at on caused
● Used the photosensitive probe f t for the natura ght spectrum curve automat c contro ght ntens ty evel
● The circuit of the l ght has surge protect on, so that the light is suitable for a harsh environment
● ntegra structure protect on evel of Ip66
● GPS synchronizing funct on s ava able
photo Bottom Top Structure chart Parameter Structure chart
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC220V/DC12V/DC48V (Other availab e)
Power consumpt on ≤9W（day）/≤2W（n ght）
F ash ng frequency 40 60t mes/m n （day） N/A （night）
Light source Wh te/Red LED
Light intensity ＞20000cd(Wh te)/2000cd(Red)
Lifespan ＞100 000hours
Emitting co or White/Red
Beam angle 360° horizontal beam angle ≥3° vert ca beam spread
Method of synchronizat on Bu t-in GPS / Bu lt-in Photoce (as opt on)
Overall s ze(mm) Ф268mm×206mm
Installation size(mm) 166mm×166 mm -4×M10
Ingress protection Ip66
Lightn ng protection evel 10KA
Operating temperature -40℃～55℃
Net weight 5 5kg
Main
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports, wind power plants, bridge and city high-rise buildings where require aviation warning.
Usually used above 45m and less than 150m buildings, could use alone, also could use with Medium OBL type B and Low intensity OBL type B together.
(Low power consumption, easy installation, high brightness, small size)
● Cover of the light adopts PC with anti-UV which is high efficiency light transmission up to 92%, quite high impact resistance and fits the bad environment very well.
● Holder of the light is made of aluminum alloy and painted by spraying plastics, the structure is high strength, resistance to corrosion.
● Use the special optical reflector design, the visual range further, angle more accurate, no light pollution.
● Light source adopts import high quality LED, lifespan up to 100,000 hours, low power consumption, energy efficiency and environmental protection.
● Based on the single chip computer control, automatic identification sync signal, do not distinguish the main light and auxiliary light, and also could be controlled by the controller.
● Same power supply voltage with synchronous signal, integrate in power supply cable, eliminate the damage by error installation caused.
● Used the photosensitive probe fit for the natural light spectrum curve, automatic control light intensity level.
● The circuit of the light has surge protection, so that the light is suitable for a harsh environment.
● Integral structure, protection level of Ip66.
● GPS synchronizing function is available.
Item Parameter
Standard FAA，ICAO Standard
Operating voltage AC220V/DC12V/DC48V (Other available)
Power consumption ≤9W（day）/≤2W（night）
Flashing frequency 40 60times/min
Light source White/Red LED
Light intensity ＞20000cd(White)/2000cd(Red)
Lifespan ＞100,000hours
Emitting color White/Red
Beam angle 360° horizontal beam angle ≥3° vertical beam spread
Method of synchronization Built-in GPS / Built-in Photocell(as option)
Overall size(mm) Ф268mm×206mm
Installation size(mm) 166mm×166 mm -4×M10
Ingress protection Ip66
Lightning protection level 10KA
Operating temperature -40℃～55℃
Net weight 5.5kg
Wind load 240km/h.
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports, wind power plants, bridge and city high-rise buildings where require aviation warning.
Usually used above 45m and less than 150m buildings, could use alone, also could use with Medium OBL type B and Low intensity OBL type B together.
(Low power consumption, easy installation, high brightness, small size)
● Cover of the light adopts PC with anti-UV which is high efficiency light transmission up to 92%, quite high impact resistance and fits the bad environment very well.
● Holder of the light is made of aluminum alloy and painted by spraying plastics, the structure is high strength, resistance to corrosion.
● Use the special optical reflector design, the visual range further, angle more accurate, no light pollution.
● Light source adopts import high quality LED, lifespan up to 100,000 hours, low power consumption, energy efficiency and environmental protection.
● Based on the single chip computer control, automatic identification sync signal, do not distinguish the main light and auxiliary light, and also could be controlled by the controller.
● Same power supply voltage with synchronous signal, integrate in power supply cable, eliminate the damage by error installation caused.
● Used the photosensitive probe fit for the natural light spectrum curve, automatic control light intensity level.
● The circuit of the light has surge protection, so that the light is suitable for a harsh environment.
● Integral structure, protection level of Ip66.
● GPS synchronizing function is available.
Item Parameter
Standard FAA，ICAO Standard
Operating voltage AC220V/DC12V/DC24V (Other available)
Power consumption ≤30W
Flashing frequency
Light source Red LED
Light intensity 2000cd
Lifespan ＞100,000hours
Emitting color Red
Beam angle 360° horizontal beam angle ≥3° vertical beam spread
Method of synchronization
Steady burning N/A
Overall size(mm) Ф210mm×140mm
Installation size(mm) 126mm×126 mm -4×M10
Ingress protection Ip66
Lightning protection level 10KA
Light controlled sensitivity <50cd/m²
Operating temperature -40℃～55℃
Net weight 1.9kg
Wind load 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together.
(Low power consumption easy installation h gh brightness, small size)
● Cover of the ight adopts PC with anti-UV which s h gh eff c ency light transmission up to 92% quite h gh mpact res stance and fits the bad environment very well
● Holder of the ght is made of aluminum a oy and pa nted by spray ng plastics, the structure is high strength resistance to corros on
● Use the specia opt ca reflector design, the visua range further, angle more accurate no l ght pollut on
● L ght source adopts mport high qual ty LED, lifespan up to 100 000 hours ow power consumpt on energy eff ciency and env ronmental protection
● Based on the s ng e ch p computer contro , automatic identificat on sync s gnal, do not dist ngu sh the ma n ght and auxiliary light and also cou d be contro led by the control er
● Same power supply voltage with synchronous signa ntegrate in power supply cab e, elim nate the damage by error installation caused
● Used the photosens tive probe fit for the natural light spectrum curve, automatic control light intensity level
● The circu t of the ight has surge protection so that the l ght s suitable for a harsh environment
● Integral structure protection level of Ip66
● GPS synchron zing function is availab e
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC220V/DC12V/DC24V (Other ava able)
Power consumption ≤2W
F ashing frequency 20 60times/min
L ght source Red LED
L ght intensity 2000cd(±25%)
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥3° vertical beam spread
Method of synchron zat on Built- n GPS / Bu t- n Photocell(as option)
Overall s ze(mm) Ф210mm×140mm
Installation size(mm) 126mm×126 mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro led sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 1 9kg
Wind oad 240km/h
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower chimney ports wind power plants, bridge and city high-rise buildings where require aviat on warning
Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together
(Low power consumption, easy instal ation, high brightness, small size)
● Cover of the l ght adopts PC w th ant -UV wh ch is high eff ciency ght transm ss on up to 92%, qu te high impact res stance and fits the bad env ronment very we l
● Ho der of the light s made of a um num al oy and steel, painted by spray ng plastic, the structure is high strength resistance to corros on
● Use the spec al optica ref ector des gn the v sual range further angle more accurate no light po ution
● L ght source adopts import h gh quality LED fespan up to 100,000 hours, low power consumption, energy efficiency and env ronmenta protect on
● Based on the single chip computer control automat c identif cation sync signa do not d stinguish the main light and aux ary ght and a so could be contro ed by the controller
● Same power supply voltage w th synchronous s gnal integrate n power supp y cable elim nate the damage by error insta at on caused
● Used the photosensitive probe f t for the natura ght spectrum curve automat c contro ght ntens ty evel
● The circuit of the l ght has surge protect on, so that the light is suitable for a harsh
env ronment
● ntegra structure protect on evel of Ip66
● GPS synchronizing funct on s ava able
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC220V/DC12V/DC24V (Other ava able)
Power consumption ≤2W
F ashing frequency 20 60times/min
L ght source Red LED
L ght intensity 2000cd(±25%)
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° horizonta beam ang e ≥3° vertical beam spread
Method of synchron zat on Built-in GPS / Bui t- n Photocell(as option)
Overall s ze(mm) 470mm×210mm×301mm
Installation s ze(mm) Ф170 mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 7 0kg
W nd oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together.
(Low power consumption easy installation h gh brightness, small size)
● Cover of the light adopts PC with ant -UV wh ch is h gh efficiency l ght transmission up to 92%, quite h gh mpact resistance and fits the bad environment very well
● Ho der of the ight is made of alum num alloy and pa nted by spraying p ast cs the structure is high strength resistance to corros on.
● Use the specia opt cal reflector design the v sual range further ang e more accurate, no light po ution
● Light source adopts mport h gh qua ty LED, lifespan up to 100,000 hours, ow power consumpt on energy eff c ency and environmental protect on
● Based on the single chip computer control, automatic dent fication sync s gnal do not dist nguish the main ght and auxil ary l ght, and a so cou d be controlled by the contro er
● Same power supp y vo tage w th synchronous signa , ntegrate in power supply cab e, e minate the damage by error installation caused
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro l ght ntens ty evel
● The c rcuit of the light has surge protect on so that the ght is su tab e for a harsh environment
● Integral structure, protection leve of p66
● GPS synchron z ng function is avai able
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC220V/DC12V/DC24V (Other ava able)
Power consumption ≤2W
F ashing frequency 20 60times/min
L ght source Red LED
L ght intensity 2000cd(±25%)
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥3° vertical beam spread
Method of synchron zat on Built- n GPS / Bu t- n Photocell(as option)
Overall s ze(mm) Ф210mm×140mm
Installation size(mm) 126mm×126 mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 1 9kg
Wind oad 240km/h
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning.
Usually used below 45m
(Low power consumption, easy installation, high br ghtness, smal size)
● Lamp shade of the ight adopts PC with anti-UV which s h gh effic ency light transmission up to 92% qu te high impact resistance and f ts the harsh environment very well
● Holder of the light s made of a um num al oy, pa nted by spray ng p ast c the structure is h gh strength ,resistance to corrosion
● Further use reflector optica des gn visua distance ang e more accurately, thoroughly eliminate the light pollution.
● L ght source adopts LED with ong lifespan up to 100,000hrs lower power consumpt on and h gh efficiency
● Used the photosensitive probe f t for the natura ght spectrum curve automat c contro ght intensity evel
● The circuit of the l ght has surge protect on, so that the light is suitable for a harsh env ronment
Item Parameter
Standard FAA，ICAO Standard
Operat ng vo tage AC100-240V (Other ava able)
Power consumption ≤3W
F ashing frequency Steady burn ng
L ght source Red LED
L ght ntensity ≥32cd
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° hor zonta beam angle ≥10° vertica beam spread
Method of synchron zat on N/A
Overa s ze(mm) Ф150mm×234mm
Insta lation s ze(mm) Ф125mm -4×M10
Ingress protect on Ip66
L ghtning protect on leve 10KA
L ght contro ed sensit vity <50cd/m²
Operat ng temperature -40℃～55℃
Net we ght 1 0kg
W nd oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning
Usually used below 45m
(Low power consumption easy installation h gh brightness, small size)
● Lamp shade of the ght adopts PC w th anti-UV which s high eff c ency light transm ss on up to 92% quite high mpact resistance and f ts the harsh env ronment very well
● Ho der of the ight is made of alum num alloy and stee painted by spraying p ast c the structure is h gh strength ,resistance to corros on
● Further use ref ector optical design, v sual distance, angle more accurate y, thorough y
e minate the ght pollut on
● Light source adopts LED with long ifespan up to 100 000hrs, ower power consumption and high eff c ency
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro
l ght ntens ty evel
● The c rcuit of the light has surge protection so that the ght is su tab e for a harsh environment
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning. Usually used below 45m (Low power consumption, easy installation, high br ghtness, smal size)
● Lamp shade of the ight adopts PC with anti-UV which s h gh effic ency light transmission up to 92% qu te high impact resistance and f ts the harsh environment very well
● Holder of the light s made of a um num al oy and steel, painted by spray ng plastic, the structure is high strength resistance to corros on
● Further use reflector optica des gn visua distance ang e more accurately, thoroughly eliminate the light pollution.
● L ght source adopts LED with ong lifespan up to 100,000hrs lower power consumpt on and h gh efficiency
● Used the photosensitive probe f t for the natura ght spectrum curve automat c contro
ght intensity evel
● The circuit of the l ght has surge protect on, so that the light is suitable for a harsh env ronment
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC100-240V (Other availab e)
Power consumption ≤3W
F ashing frequency Steady burning
L ght source Red LED
L ght intensity ≥10cd
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥10° vertica beam spread
Method of synchron zat on N/A
Overall s ze(mm) 222mm×125mm×327mm
Installation size(mm) Ф100mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 3 0kg
Wind oad 240km/h
Item Parameter
Standard FAA，ICAO Standard
Operat ng vo tage AC100-240V (Other ava able)
Power consumption ≤3W
F ashing frequency Steady burn ng
L ght source Red LED
L ght ntensity ≥32cd
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° hor zonta beam angle ≥10° vertica beam spread
Method of synchron zat on N/A
Overa s ze(mm) Ф173mm×220mm
Insta lation s ze(mm) Ф120mm -4×M10
Ingress protect on Ip66
L ghtning protect on leve 10KA
L ght contro ed sensit vity <50cd/m²
Operat ng temperature -40℃～55℃
Net we ght 1 1kg
W nd oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning
Usually used below 45m
(Low power consumption easy installation h gh brightne small size)
● Lamp shade of the ght adopts PC w th anti-UV which s high eff c ency light transm ss on up to 92% quite high mpact resistance and f ts the harsh env ronment very well
● Ho der of the ight is made of alum num alloy and stee painted by spraying p ast c the structure is h gh strength ,resistance to corros on
● Further use ref ector optical design, v sual distance, angle more accurate y, thorough y e minate the ght pollut on
● Light source adopts LED with long ifespan up to 100 000hrs, ower power consumption and high eff c ency
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro
l ght ntens ty evel
● The c rcuit of the light has surge protection so that the ght is su tab e for a harsh environment
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning.
Usually used below 45m (Low power consumption, easy installation, high br ghtness, smal size)
● Lamp shade of the ight adopts PC with anti-UV which s h gh effic ency light transmission up to 90% qu te high impact resistance and f ts the bad env ronment very we
● The body of the light adopts SUS304 sta nless steel, House of the light is made of alum num alloy and painted by spraying p ast c the structure s high strength, res stance to corrosion
● Specia battery for solar energy, free ma ntenance and high re iab ty, lifet me more than 3 years
● Based on the single chip computer micro power control, cou d control the charge and d scharge prec sely
● M ld stee change g ass Monocrystalline sil con solar panels energy efficiency h gh (> 18%) fetime more than 20 years
● Further use reflector optica des gn visua distance ang e more accurately, thoroughly elim nate the light pollution
● L ght source adopts LED with ong lifespan up to 100,000hrs lower power consumpt on and h gh efficiency
● Used the photosensitive probe f t for the natural ght spectrum curve automat c contro ght intensity level
● The circuit of the ght has surge protect on, so that the light is suitable for a harsh env ronment
Item
Parameter
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC100-240V (Other availab e)
Power consumption ≤3W
F ashing frequency Steady burning
L ght source Red LED
L ght intensity ≥32cd
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥10° vertica beam spread
Method of synchron zat on N/A
Overall s ze(mm) 458mm×173mm×246mm
Installation size(mm) Ф130mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 3 5kg
Wind oad 240km/h
Standard FAA，ICAO Standard
Operat ng vo tage DC6V (Other availab e)
Power consumption ≤3W
F ashing frequency Steady burn ng
L ght source Red LED
L ght ntensity ≥10cd
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° hor zonta beam angle ≥10° vertica beam spread
Method of synchron zat on N/A
Overa s ze(mm) 195mm×195mm×393mm
Insta lation s ze(mm) Ф127mm -4×M10
Ingress protect on Ip66
L ghtning protect on leve 10KA
L ght contro ed sensit vity <50cd/m²
Operat ng temperature -40℃～55℃
Net we ght 8 0kg
W nd oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning
Usually used below 45m
(Low power consumption easy installation h gh brightness, small size)
● UV-resistant PC materia lampshade w th a transparency of over 90%, strong impact resistance, excellent harsh env ronment adaptab ty
● H gh structural strength, UV resistance corrosion res stance
● The ith um battery s used for energy storage, and the e ectric convers on eff c ency is high.
● The micro-power ntelligent control system ensures prec se power management and low power consumption
● Low carbon tempered g ass mono crystalline sil con so ar panels with high energy efficiency
● Further use ref ector optical design, v sual distance, angle more accurate y, thorough y e minate the ght pollut on
● Light source adopts LED with long ifespan up to 100 000hrs, lower power consumption and high eff c ency
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro l ght ntens ty evel
● The c rcuit of the light has surge protect on so that the ght is su tab e for a harsh environment
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning.
Usually used below 45m
(Low power consumption, easy installation, high br ghtness smal size)
● Lamp shade of the ight adopts PC with anti-UV which s h gh effic ency light transmission up to 92% qu te high impact resistance and f ts the bad env ronment very we
● The body of the light adopts SUS304 sta nless steel, House of the light is made of alum num alloy and painted by spraying p ast c the structure s high strength, res stance to corrosion
● Specia battery for solar energy, free ma ntenance and high re iab ty, lifet me more than 3 years
● Based on the single chip computer micro power control, cou d control the charge and d scharge prec sely
● M ld stee change g ass Monocrystalline sil con solar panels energy efficiency h gh (> 18%)
fetime more than 20 years
● Further use reflector optica des gn visua distance ang e more accurately, thoroughly elim nate the light pollution
● L ght source adopts LED with ong lifespan up to 100,000hrs lower power consumpt on and h gh efficiency
● Used the photosensitive probe f t for the natural ght spectrum curve automat c contro
ght intensity level
● The circuit of the ght has surge protect on, so that the light is suitable for a harsh env ronment
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage DC3 2V
Power consumption ≤3W
F ashing frequency Steady burning
L ght source Red LED
L ght intensity ≥10cd
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥10° vertica beam spread
Method of synchron zat on N/A
Overall s ze(mm) 167mm×167mm×162mm
Installation size(mm) 106mm×106mm -4×M6
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 1 1kg
Wind oad 240km/h
Item Parameter
Standard FAA，ICAO Standard
Operat ng vo tage DC6V (Other availab e)
Power consumption ≤3W
F ashing frequency Steady burn ng
L ght source Red LED
L ght ntensity ≥32cd
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° hor zonta beam angle ≥10° vertica beam spread
Method of synchron zat on N/A
Overa s ze(mm) 195mm×195mm×396mm
Insta lation s ze(mm) Ф127mm -4×M10
Ingress protect on Ip66
L ghtning protect on leve 10KA
L ght contro ed sensit vity <50cd/m²
Operat ng temperature -40℃～55℃
Net we ght 8 5kg
W nd oad 240km/h
So ar Pane Type: Monocrystalline
So ar Pane Dimension 241*170*4mm
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning
Usually used below 45m
(Low power consumption easy installation h gh brightness, small size)
● Lamp shade of the ght adopts PC w th anti-UV which s high eff c ency light transm ss on up to 92% quite high mpact resistance and f ts the bad environment very wel
● Ho der of the ight is made of alum num alloy and stee painted by spraying p ast c the structure is h gh strength ,resistance to corros on
● Spec al battery for so ar energy, free ma ntenance and high re ability, fetime more than 3 years
● Based on the single ch p computer m cro power contro could contro the charge and discharge prec sely
● Mi d steel change glass Monocrysta ne silicon so ar panels, energy effic ency high (> 18%) lifetime more than 20 years
● Further use ref ector optical design, v sual distance, angle more accurate y, thorough y e minate the ght pollut on
● Light source adopts LED with long ifespan up to 100 000hrs, lower power consumption and high eff c ency
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro
l ght ntens ty evel
● The c rcuit of the light has surge protect on so that the ght is su tab e for a harsh environment
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage DC3 7V
Power consumption ≤3W
F ashing frequency Steady burning
L ght source Red LED
L ght intensity ≥32cd
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥10° vertica beam spread
Method of synchron zat on N/A
Overall s ze(mm) 318mm×205mm×162mm
Installation size(mm) Ф120mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 2 4kg
Wind oad 240km/h
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning. Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together
(Low power consumption, easy installation, high br ghtness, smal size)
● Lamp shade of the ight adopts PC with anti-UV which s h gh effic ency light transmission up to 92% qu te high impact resistance and f ts the bad env ronment very we
● The body of the light adopts SUS304 sta nless steel, House of the light is made of alum num alloy and painted by spraying p ast c the structure s high strength, res stance to corrosion
● Specia battery for solar energy, free ma ntenance and high re iab ty, lifet me more than 3 years
● Based on the single chip computer micro power control, cou d control the charge and d scharge prec sely
● M ld stee change g ass Monocrystalline sil con solar panels energy efficiency h gh (> 18%) fetime more than 20 years
● Further use reflector optica des gn visua distance ang e more accurately, thoroughly elim nate the light pollution
● L ght source adopts LED with ong lifespan up to 100,000hrs lower power consumpt on and h gh efficiency
● Used the photosensitive probe f t for the natural ght spectrum curve automat c contro
ght intensity level
● The circuit of the ght has surge protect on, so that the light is suitable for a harsh env ronment
Item Parameter
Standard FAA，ICAO Standard
Operat ng vo tage DC12V
Power consumption ≤2W
F ashing frequency 20 60times/min
L ght source Red LED
L ght ntensity 2000cd(±25%)
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° hor zonta beam angle ≥3° vertical beam spread
Method of synchron zat on GPS
Overa s ze(mm) 195mm×195mm×396mm
Insta lation s ze(mm) Ф127mm -4×M10
Ingress protect on Ip66
L ghtning protect on leve 10KA
L ght contro ed sensit vity <50cd/m²
Operat ng temperature -40℃～55℃
Net we ght 17kg
W nd oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning
Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together.
(Low power consumption easy installation h gh brightness, small size)
● Lamp shade of the ght adopts PC w th anti-UV which s high eff c ency light transm ss on up to 92% quite high mpact resistance and f ts the bad environment very wel
● The body of the ght adopts SUS304 stain ess stee , House of the ght is made of aluminum a oy and pa nted by spray ng plastic, the structure is high strength resistance to corros on.
● Spec al battery for so ar energy, free ma ntenance and high re ability, fetime more than 3 years
● Based on the single ch p computer m cro power contro could contro the charge and discharge prec sely
● M d steel change glass Monocrysta ne silicon so ar panels, energy effic ency high (> 18%)
l fetime more than 20 years
● Further use ref ector optical design, v sual distance, angle more accurate y, thorough y
e minate the ght pollut on
● Light source adopts LED with long ifespan up to 100 000hrs, lower power consumption and high eff c ency
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro
l ght ntens ty evel
● The c rcuit of the light has surge protect on so that the ght is su tab e for a harsh environment
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage DC12V
Power consumption ≤2W
F ashing frequency 20～60times/min
L ght source Red LED
L ght intensity 2000cd(±25%)
L fespan ＞100,000hours
Em tting color Red
Beam angle 360° horizonta beam ang e ≥3° vertical beam spread
Method of synchron zat on GPS
Overall s ze(mm) 525mm×510mm×345mm
Installation size(mm) Ф125mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 21 5kg
Wind oad 240km/h
Widely used in various fields of the Air Force civilian airports and obstacle free airspace, helipads, iron tower, chimney, ports wind power plants, bridge and city high-rise buildings where require aviation warning. Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together
(Low power consumption, easy installation, high br ghtness, smal size)
● Lamp shade of the ight adopts PC with anti-UV which s h gh effic ency light transmission up to 92% qu te high impact resistance and f ts the bad env ronment very we
● The body of the light adopts SUS304 sta nless steel, House of the light is made of alum num alloy and painted by spraying p ast c the structure s high strength, res stance to corrosion
● Specia battery for solar energy, free ma ntenance and high re iab ty, lifet me more than 3 years
● Based on the single chip computer micro power control, cou d control the charge and d scharge prec sely
● M ld stee change g ass Monocrystalline sil con solar panels energy efficiency h gh (> 18%) fetime more than 20 years
● Further use reflector optica des gn visua distance ang e more accurately, thoroughly elim nate the light pollution
● L ght source adopts LED with ong lifespan up to 100,000hrs lower power consumpt on and h gh efficiency
● Used the photosensitive probe f t for the natural ght spectrum curve automat c contro ght intensity level
● The circuit of the ght has surge protect on, so that the light is suitable for a harsh env ronment
Item
Parameter
Standard FAA，ICAO Standard
Operat ng vo tage DC12V
Power consumption ≤2W
F ashing frequency 20 60times/min
L ght source Red LED
L ght ntensity 2000cd(±25%)
L fespan ＞100,000hours
Em tt ng color Red
Beam angle 360° hor zonta beam angle ≥3° vertical beam spread
Method of synchron zat on GPS
Overa s ze(mm) 525mm×543mm×351mm
Insta lation s ze(mm) Ф125mm -4×M10
Ingress protect on Ip66
L ghtning protect on leve 10KA
L ght contro ed sensit vity <50cd/m²
Operat ng temperature
Net we ght 25kg
W nd oad 240km/h
Widely used in various fields of the Air Force, civilian airports and obstacle free airspace helipads, iron tower, chimney, ports, wind power plants bridge and city high-rise buildings where require aviation warning
Usually used above 45m and less than 150m buildings, could use alone, also could use with Low intensity OBL type B together.
(Low power consumption easy installation h gh brightness, small size)
● Lamp shade of the ght adopts PC w th anti-UV which s high eff c ency light transm ss on up to 92% quite high mpact resistance and f ts the bad environment very wel
● Ho der of the ight is made of alum num alloy pa nted by spray ng p astic, the structure is high strength res stance to corrosion.
● Spec al battery for so ar energy, free ma ntenance and high re ability, fetime more than 3 years
● Based on the single ch p computer m cro power contro could contro the charge and discharge prec sely
● Mi d steel change glass Monocrysta ne silicon so ar panels, energy effic ency high (> 18%) lifetime more than 20 years
● Further use ref ector optical design, v sual distance, angle more accurate y, thorough y e minate the ght pollut on
● Light source adopts LED with long ifespan up to 100 000hrs, lower power consumption and high eff c ency
● Used the photosensit ve probe fit for the natura light spectrum curve automatic contro
l ght ntens ty evel
● The c rcuit of the light has surge protect on so that the ght is su tab e for a harsh environment
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage DC3 7V
Power consumption ≤2W
F ashing frequency 20 60times/min
L ght source Red LED
L ght intensity 1500cd(±25%)
L fespan ＞100,000hours
Em tting color Red
Aviation obstruction marking sphere is designed to provide daytime visual warning or night time visual warning if comes with reflective tape, for electricity transmission line and overhead wire for aircraft pilots especially cross river high voltage transmission lines
CDT power line marker ball is made of high-grade Fiberglass Reinforced Plastics(FRP), diameter of 600mm and 800mm are available to meet diff erent customers' needs
A marking sphere should be of one color such as aviation orange, white and red. Generally, the marking spheres are placed on the highest line. Where there is more than one line at the highest level, white and red, or white and orange spheres should be displayed alternately. This alternating color scheme provides the most conspicuity against all back
Key Feature
● The aviation sign ball is des gned as a hollow thin-walled spherical shape and s made of general-purpose ghtwe ght and high-strength po ycarbonate materia It has the advantages of ght weight, high strength impact res stance, corrosion resistance, and UV protection
● Super corrosion res stant character stainless stee bolts and nuts
● Alum num alloy cab e c amp guarantees good corrosion res stance
● Var ous s ze of cab e c amps are avai able fo fit for customers’ cab e conductor
● Drain ho es structure can prevent accumu ated rain water ns de the spheres
● Stack ng compatible design save storage space and freight charge
● Optiona preformed armor rods prov de better protect on against vibrat on and abras on
● Optiona reflect ve tape is more durable and econom cal so ution for n ght v s b ty
● Both sphere d ameters of 600mm and 800mm are availab e
Item Parameter Standard FAA，ICAO Standard
Co or Orange Red White, Orange/Wh te Red/Wh te
Sphere body po ycarbonate
Cable clamp Alum num
al oyBolts/nuts/washers Stainless stee 304
Diameter 600mm / 800mm
Beam angle horizonta beam ang e ≥ vertical beam spread
Method of synchron zat on GPS
Overall s ze(mm)
Installation size(mm)
360° 3° 240mm×184mm×242mm 126mm×126mm -4×M10
Ingress protection Ip66
L ghtn ng protect on evel 10KA
L ght contro ed sensit v ty <50cd/m²
Operat ng temperature -40℃～55℃
Net weight 4 1kg
Wind oad 240km/h
Weight ≤7 0KG / 9 0KG
Drain ho es Yes
Optiona Preformed Armor Rods Ref ect ve
StripVisible D stance 1200 meters
Voltage Range 35KV-1000KV
Conductor diameter 10-60 mm
Operat ng temperature
Description
● Conductor marking lights are a particular type of aircraft warning l ghts designed for overhead power lines They are visible at night, unlike overhead wire markers which rely on daylight
● Conductor marking lights increase night conspicuity of transmission line catenary wires near airports, heliports, across rivers. Lamps mark and light overhead power lines support structures (towers) as well as high voltage transmission line catenary wires.It is one assembly light with mu tiLEDS technology. Dedicated to the beaconing of high voltage lines it is a long life system (100,000 hours). Its compact design and light weight allow the quickest and easiest installation on the market.
Working Principle
Farady's Law of induction involving Magnetic Flux flowing through a circuit which powers the warning light.
The Warning light is powered by the magnetic field surrounding the power distribution wire and uses an electronic circuit integrated in a compact clamp-on warning light The operating princip e is that of a Rogowski coil, similar to a current transformer. This solution is usually intended for medium and high voltage lines up to 500 kV. However inductive coupling devices are able to work on any AC at 50 Hz or 60 Hz from 15A up to 2000A
Advantages
● Multi-LEDs
● Compact design
● Corona Extinction
● Internal Photosensor
● Easy way for mounting
● Natural stability based on specific nut
● Easy way for bulb replacement
● Light weight
● No maintenance
● 3 years warranty
● Only 1 reference for all line voltage
Features
● LED light source adopts CREE LED beads, which has high luminous eff ciency, long ife and low energy consumption
● The lampshade adopts mported ant -UV PC materia which is resistant to high temperature impact and environmenta applicability
● The frame of the clamp s made of Alloy Anodized alum num alloy
● Maintenance free. The lamp body is designed separately from the mount ng bracket and the instal at on operation s simp e
● Suitable for high-voltage wire d ameter range from 15mm-40mm in diameter
Key Feature
Main photo
● Transmission Line
● Overhead Power Line
● Low,medium and high voltage lines
Characteristics
LUMINOUS
Luminous Source LEDS
Type of Obstruction Light Low Intens ty,Type B
Color Red
Hor zontal Beam 360°
Vertical Beam 10°
Luminous Intensity
15A<Conductor Current<50A 10cd
Conductor Current >50A 32cd
Lifespan 100,000 hours
ELECTRICAL
Voltage Lines 1V to 500kV
Compatible Conductor Diameter 15mm to 40mm
Functioning Temperature -55℃ to + 65℃
HV Current 15A-2000A
Operating L ne Frequency 50Hz/60Hz
Photocell Activation 50Lux
Power Consumpt on ＜5W
Net Weight 4 1kg
WARRANTY
Warranty 3 years
MECHANICAL
Body Materia Aluminum a loy + Rubber
Lens Mater al Polycarbonate
Mounting Bolts and Nuts (Sta nless Steel)
Height 252mm
Width 215mm
Length
ENVIRONMENTAL
178mm
Humid ty 95%
Frost -60℃
Wind Speed 240Km/h
PHOTOMETRIC STANDARD COMPLIANCE
ICAO ANNEX 14, Volume I, Chap. 6
ICAO TYPE B Low intensity obstacle light
FAA AC 150/5345-43
FAA Type L-810 Low intensity obstacle light
Qual ty ISO9001;2015
For the CM-DKN aviation obstruction indoor's controller is fit for our company's all series aviation obstruction's synchronization flashing work and monitor the light's working status. This product is an indoor's type, the waterproof grade is IP43,could use for the indoor's environment directly
For the CM-DKM aviation obstruction outdoor controller is fit for our company's all series aviation obstruction's synchronization flashing work and monitor the light's working status This product is an indoor's type, the waterproof grade is IP65 could use for the outdoor environment directly
● Use the stee shell and spray coat ng techniques resistance to corros on ant -UV
● The vo tage of the power c rcuit and signal control line is same, so the connection of the wires are simple and rel able it w not cause damage to the l ghtings and contro er when connect the error ne short y
● Contro circu t use the MCU contro can simu taneously control 4000W load power / w thin 200 un ts aviation obstruct on ghts synchron zed flash ng or steady
● Contro er have 3 k nds operating modes: automatic, manual, c ose
Automat c mode automat cally shutdown during the day, turn off the av at on l ght control output automat cally turn on at night an open av at on ght contro output
Work in manual mode work status s forced open
Work c ose mode: work status s forced c osed, three operat ng modes can be switched by the user
● The controller can also customize the fau t alarm function, when one of the lights working abnorma ly controlled failed the indicator on the contro ler can be shown a so could use the dry contacts to alarm the externa environment
● The function of this av at on obstruct on light controller s very powerful performance is reliab e and safe Use and maintenance are simp e and conven ent and w th ant -surge device can be app ed to a poor work ng env ronment.
● Use the stee she and spray coating techn ques, res stance to corrosion anti-UV
● The vo tage of the power c rcuit and signa control ine is same so the connection of the w res are s mp e and re able t will not cause damage to the ghtings and contro ler when connect the error line shortly
● Control c rcuit use the MCU control can simu taneously control 2000W load power / within 100 units aviation obstruction lights synchronized f ashing or steady
● Controller have 3 kinds operating modes: automatic, manua close
Automatic mode automatically shutdown during the day, turn off the av ation ight control output automat ca ly turn on at n ght an open aviation light control output
Work n manua mode: work status s forced open
Work close mode: work status s forced closed, three operating modes can be switched by the user .
● The contro ler can a so custom ze the fault alarm funct on, when one of the ight it controlled fa ed, the nd cator on the contro er can be shown, also cou d use the dry contacts to alarm the externa enviroment
● The function of th s av at on obstruction light controller s very powerful, performance is re able and safe Use and ma ntenance are s mple and convenient; and w th anti-surge dev ce can be app ied to a poor working env ronment
Item Parameter
Standard FAA，ICAO Standard
Operat ng voltage AC220V/DC48V (Otheravailab e)
Power consumption ≤20W
Load capacity ≤4000W
F ashing frequency 20 60 times
Number of contro aux ary ight 200 units
Ingress protection p43
Controlled environment br ghtness 50~500Lux
Opt ca probe CM-12GK
Operat ng temperature -40℃～55℃
A titude ≤4500m
Wind oad 10kg
Net weight 240km/h
Overall s ze(mm) 400mm×300mm×150mm
Installation size(mm) 434mm×250-4×M8
Item Parameter
Standard FAA，ICAO Standard
Operat ng vo tage AC220V/DC48V (Other available)
Power consumption ≤10W
Load capacity ≤2000W
F ashing frequency 20~60 times
Number of contro aux ary ght 100 units
Ingress protect on p65
Contro ed env ronment br ghtness 50~500Lux
Operat ng temperature -40℃～55℃
A titude ≤4500m
W nd oad 2 5kg
Net we ght 240km/h
Overa s ze(mm) 280mm×250mm×85mm
Installation s ze(mm) 250mm×130mm-4xM4
Application bracket of vertical angle iron type
Installation Instruction
Reference as ICAO(Attachment No.14) and CAAC standard MH5001-2013 requires:
Obstruction light should be mounted three position in the tower: The top of iron tower; The lowest position of wire and cable's suspension; The medium position between the top of tower and The lowest Position of wire and cable's suspension
Obstruction Light types can be chosen as below:
Item: Mounting Bracket of Vertical AngleIron Type
Model: CM-CZZJ-TJ
Overall Size: 200*60*387mm
(Customized available)
Installation Size Wide: 80-140 Angle Iron
Material: Stainless steel
Installation: type Angle Installation
Mounting Bracket of Horizontal Angle Iron Type
Application Lamp
Item: Mounting Bracket of Horizontal Angle Iron Type
Model: CM-SPZJ-TJ
Overall Size: 160*170*341mm
(Customized available)
Installation Size Wide: 80-140 Angle Iron
Material: Stainless steel
Installation: type Angle Installation
Installation Instruction
Bracket
Vertical Type Mounting Bracket
Item: Vertical Type Mounting Bracket
Model: CM-ZLZJ-TJ
Overall Size: Ø210mm*240mm
(Customized available)
Installation Size: Ø120mm-4*M10
Material: Stainless steel
Installation: typeHorizontal installion
Side of Vertical Type Mounting Bracket
Installation
Item: Side of Vertical Type Mounting Bracket
Model: CM-CLZJ-TJ
Overall Size: 290*160*120mm
(Customized available)
Installation Size: 80*46mm-4*M10
Material: Stainless steel
Installation: type Horizontal installion
Anchorear Type Mounting Bracket
Installation Instruction
Item: Anchorear Type Mounting Bracket
Model: CM-BKZJ-TJ
Overall Size: 160*60*330mm
(Customized available)
Installation Size : Ф40-60mm
Material: Stainless steel
Installation: type Cylindrical installation
Curtain Wall Type Mounting Bracket
Item: Curtain Wall Type Mounting Bracket
Model:CM-MQZJ-TJ
Overall Size: 160*160*480mm
(Customized available)
Installation Size: 8*M6
Material: Stainless steel
Installation: type Curtain Wall Installation
beacon
Heliport ight is a white f ashing ght, as a distance visua gu dance. It s so mportant especially when the ambient ght makes t d fficu t to see there s a he port Accord ng to ICAO, every he port shou d have at least one light beacon. It shou d be nstalled above or near the he port, it w l be better if it is nstalled n an eleva ed place P ease make sure it w not et the pi ot feel glaring in short d stance
Key Feature
● The amp cover adopts PC material w th excellent impact resistance (IZOD notch impact strength: 90) thermal stab ty (service temperature can be 130℃) great transparency (ava able w th a light transmission of up to 92%), auto-UV resistance aging resistance and f ammability rating in UL94V0
● The house of the ght adopts a uminum alloy and stain ess steel SUS304 on the surface use the oxidation treatment the product features are ght we ght water t ghtness seism c and corrosion resistance
● L ght source adopts imported LED featuring high ght (100Lm/W) light source life for f ashing reach ng 100 000 000 t mes. Wide y used in the domest c and nternational aviat on field
● The ght with surge protection device ( n 7 5KA/5 t mes, max 15KA) can be used n the harsh environment
Heliport per meter light s a constant green upr ght installing light. Em ting omnid rectional green light at night or in the day me w th ow vis bility to ind cate the perime er of heliport take o f and land area, to ndica e the safe and ng area for the helicopter pilot. It s controlled by a sw tch n the he port control cabinet
● The amp cover adopts PC material w th excellent impact resistance ( ZOD notch impact strength: 90), thermal stab lity (service temperature can be 130℃) great transparency (ava able w th a light transmiss on of up to 90%) auto-UV resistance aging resistance and flammability rat ng n UL94V0
● The house of the ght adopts a uminum alloy, the product features are light weight water tightness, se smic and corros on res stance
● L ght source adopts the nternat onal advanced LED featur ng ow power consumpt on, h gh efficiency and ght source fespan reaching 100,000 hr
● The ght with surge protection device ( n 7 5KA/5 t mes, Imax 15KA) can be used n the harsh environment.
(Other available)
Green/Blue/Yellow/White
Structure chart
Structure chart
FATO Helipad a m point Land ng light s a steady burning white nset installing light. Em tting Omnidirect ona white light at night or n the dayt me w h ow visib ity to show the accurate oad ng place for loading helicop er. It s controlled by a sw tch n the he port control cabinet
TLOF Helipad aim point Landing light s a cons an green upright insta ng light
Em tt ng omn directional green light at night or n he daytime w th ow visibility to indicate the per meter of heliport take off and and area, to ind cate the safe landing area for the helicopter p ot. It s controlled by a switch n the he port con rol cabinet
● Adopt toughened opt cal glass with h gh strength good abras on resistance strong mpact resistance and ght transmittance of more than 95%
● The upper cover of the light is made of high qua ty aluminum alloy w th good mechan cal properties strong bear ng capac ty and impact resistance
● The light body is made of corrosion-resistant alum num and the surface s anodized All fasteners are made of sta n ess steel, which can be used n various environments
● The light surface s smooth and no acute ang es to ensure the safety of the heliport tires.
● The light source LED adopts the imported internat onal advanced long-life low power consumption, and high-eff ciency ch p package ( fetime exceeds 100 000 hours) Strict LED co or management to ensure the cons stency of ght color
● The power factor is greater than 0 9, which can min m ze the interference to the power gr d
● The power line of the ght is equ pped with anti-surge device (10KV / 5KA surge protection), wh ch can be applied to harsh c mate environment
● The dust-proof and waterproof grade can reach IP68 and the power supply adopts glue sealing technology
● Adopt toughened optica g ass w th high strength,good abrasion resistance,strong impact res stance and light transmittance of more than 95%
● The upper cover of the light is made of high quality aluminum alloy with good mechanica properties, strong bearing capacity and impact resistance
● The light body is made of corros on-resistant aluminum and the surface is anod zed A fasteners are made of stainless steel, which can be used in various environments
● The light surface is smooth and no acute angles to ensure the safety of the heliport tires
● The light source LED adopts the mported internationa advanced long-life low power consumption, and high-effic ency chip package (lifet me exceeds 100,000 hours) Strict LED color management to ensure the consistency of light co or
● The power factor is greater than 0 9 which can minimize the nterference to the power grid
● The power line of the light is equipped with anti-surge device (10KV / 5KA surge protection) which can be app ed to harsh climate environment
● The dust-proof and waterproof grade can reach IP68, and the power supply adopts g ue sea ng techno ogy
Parameter
Mode
Operating voltage
Power Consumpt on
Light Intensity
Light Source
L ght Lifespan
Emitting Color
Ingress Protect on
Environment Humid ty A
Environment Temperature
CM-HT12/CQ AC220V/6.6A (Other available)
≤7W
30cd
Green/Blue/Yellow LED
100,000 Hours
Green/Blue/Yellow Ip68 ≤2500m
-40℃～55℃ 240km/h
7.3kg
Ø220mm×160mm
(mm)
Ø220mm×156mm
He port f ood light s a ground surface insta at on l ght. It's used to lighten the surface of
the hel port, ensuring the he port surface illum nat on no less than 10 Lux mak ng the heliport sign easy to see and giving the landing heliport accurate gu dance Un form lumination of the he iport make the pilot to reduce eye g are as much as possible n short d stance
The Heliport Rotating Beacon is used primarily for night operations at heliports as an dentification and location marker.
● All-aluminum alloy case, ght we ght, h gh structura strength, corrosion resistance and excellent heat diss pat on
● Imported LED ght source, ong life low power consumption and high brightness
● The glazing surface is tempered g ass, which has exce ent impact resistance, good thermal stab ty (500 ° C temperature resistance), good ght transmission (light transmittance up to 95%), UV resistance and aging resistance
● The amp holder s made of alum num a oy liquid casting and the surface s oxid zed, which has the character st cs of fu sealing waterproof and corrosion resistance
● Reflector based on the princ ple of reflection the light utilization rate s over 92% and the ght ex t angle can be more accurate, the v sible distance is farther, and the ght pollution is completely e m nated
● The ght source is a white LED which adopts internationa advanced long-life low-power h gh eff ciency chip package (lifetime over 100,000 hours) and color temperature of 5000K
● The complete set of amps and anterns adopts full packaging technology, which is res stant to impact v bration and corrosion and can be used n harsh environments for a long time The structure is ght and firm and the installation is simp e
● Light ntensity and ght color meet the requ rements.
● Sophisticated optica control light utilization high brightness, outstanding optical performance
● Lamps shape is handsome, good thermal performance well-designed
● The amp uses a sp t structure reducing impur ties and moisture nto the amp,improving the service life of amp opt cs reduc ng the number of maintenance operat ons.
● The main body of the lamp is made of a uminum alloy The fastener s made of stain ess steel, and the ant -corros on performance is good
● Adopts h gh-prec sion machine tool process ng, ensuring a full range of lamps quality and accuracy
A titude below 2500 meters
Outdoor: -40 ℃ - +55 ℃
Re ative humidity 95%; (+ 24 5 ℃), the maximum humidity can be greater than 100%
Rain snow ice, water
Corrosive salt spray
Halogen lamp3*150W
Lamp Us ng Life ≥1000 hours
Wh te,Green Yellow Color
Lamp angle can be ad usted;
12 RPM, 36 times per m nute f ash
304 Stee cab net with powder layer Voltage
The SAGA(System ofAz muth Gu dance orApproach) provides a combined signal of approach az muth guidance and thresho d den ficat on
Lamp
Power supp y
Electrical consumption
Visual range
Operat on angular sector
Axis accuracy
Delay between f ashes
“Flashes” frequency
F n sh
One 12 Vac 105 W pre-focused halogen reflector lamp
110V-230 Vac 50/60 Hz
Less than 250 W for the SAGA system and 240 W maximum for the heating resistors
10 nautical miles in standard visibility conditions
15 degrees on both side of the approach axis +/- 0.45 degree in azimuth
From 60 to 300 ms
0.5 Hz
Body Cap and Support are in aluminium alloy,phosphated and painted in aviation yellow All fixingsand fastenings are stainless steel. The IP 65 – 20Joules Power Supply Box is made of reinfor polyester
FAA type:
L-854 Radio Receiver/Decoder, Air- to-ground,Type 1,Style A
ETL Certified to:
FAA AC 150/5345-49C
Our L-854 FM radio receiver/decoder is designed to provide p lots direct, unassisted air-to-ground control of airfield lighting systems This field tunable rad o allows p lots to activate airfie d ighting w th a series of 3 5, or 7 microphone clicks in a 5 second period. An integrated selectable t mer shuts airf eld lights off after 1, 15, 30, or 60 minutes of illumination Our L-854 receiver s particular y useful for small to mid-sized airfields where cont nuous night time illumination is unnecessary and expensive. The un t s a virtual necessity for remote sites where the volume of qualified on-site control personnel may be limited. Our rugged, solid state design w ll provide years of service and is the perfect replacement for aging “crystal” based units
Item
Power supply
Working temperature
AC90V-264V, 50HZ – 60HZ
Outdoor -40° - 55°, indoor -20° - 55°
118.000HZ – 135.975HZ, channel spacing
Work ng temperature
Remote CMS
From -40°C to +50°C
Remote control from 48 Vdc. Monitoring feed back signal using two dry contacts (Contact capacity = 250 V / 1A maximum).
The System of Azimuth Guidance for Approach will comply with ICAO recommendations Annex 14, VolumeI paragraph 5.3 4 and French STAC.
It will compr se of 2 “Flashing” Units (master and slave) located symmetrically on both s des of the runway (or TLOF for he port) threshold
Receiving frequency
25000Hz channel GMS frequency band:
850MHZ, 900MHZ, 1800,1900MHz
Sensit vity
Signa output frequency
Four outputs
Waterproof rat ng
Size
5 microvolts, adjustable.
> 50HZ
RA, R3, R5, R7
IP54
186mm * 134mm * 60mm
Applied for civil or military airport precision approach path indicator system.
● Us ng precision angle sensor to detect the tiny change of the nc nation ang e of each unit (precision 0 6 minute) and the real t me data is showed on the LED d gita tube disp ay at the back of each indicator When the ang e deviate more than the sett ng value (normally not exceeding 15 minutes) the system will shut off itself, and a ert the contro center
● The specia opt cal strengthened filters have high transmiss on factor and good thermal resistance and with no discoloration
● Structure des gn ensures very good water-tightness and protection against corrosion, and ensures the e ectronic components not affected by the heat from the lamps The structure has gotten application patent (Pat No:ZL201320196674 4)
● The unit is mounted n standard on three egs, each eg has a unit zed structure wh ch compr ses three mental components for ad usting the ang e The structure has gotten application patent (Pat. No:ZL201320196153.9)
● Easy s t adjustment by us ng a clinometer
● Red to white transit on s accurate with value not exceed ng 3 minutes
● Excellent frangibility w thout sacr fice of any stab ty
● Easy maintenance replacement of main e ements does not requ re e ther unit adjustment or any special tools
● Front g ass protect ng enses aga nst sad wind, and eng ne b ast
● Very easy access to a components by removing the cover
CM-HT12/F Windsock can be used as a sign n a l kinds o airpor to observe the w nd power and wind direct on n both dayt me and n gh
On the top nsta ed one red LED obstruction light, provide the obstac e h n for the pilot at night
On the upper of the po e nstal ed a l gh sta n ess w nd sleeve frame and one 360°rotat on gear.
Ins de of the windsock frame instal ed one waterproof LED spot ght, it will turn with the windsock, cou d light the w ndsock directly, not like the o d outside flood light, then e iminate the power consumption and against the eye flare
On the windsock frame nsta ed one w ndsock which s made o corrosion-residen and high-temperature-resident ny on ant -UV materia , and ifetime is ong The co or is red(orange) and white, have 5 sect ons, he s art color s red(orange) The w ndsock inc uding 3 dimensions according to the pole s height
1 The d ameter is 300mm, the diameter at sma end is 150mm and the leng h is 1 2m
2 The d ameter is 600mm, the diameter at sma end is 300mm and he leng h is 2 4m
3 The d ameter is 900mm, the diameter at sma end is 450mm and he leng h is 3 6m
How o choose the w ndsock?
Be ow 4m use the first type; be ween 4m to 6m, use the second type above 6m, use the third type
On the bottom of the pole, it has a contro box, you could choose he w nd vane w th the photosw tch; the power supp y cab e n o the contro box directly
The pole and the base a use he SUS304 sta n ess The w ndsock he gh cou d be 2m,3m 4m,5m,6m or as buyer s requ rements; when the total height more than 9m, you cou d add the stay wire n order to ncrease the stabi y; when the windsock he ght more than 4m, you could choose the hinges base so that could ins a l more s eady
Th s product comp ies w th he ConsultationAnnouncemen AC150 5345-27C and L-806
o U S Federa Av ationAdmin stra on (FAA),Append x 14-A rport of Internat ona C vi Av ation Organization (ICAO) and the specifications n Part Four ofA rport Des gn draf ed by CAO
The max des gned wind speed s 260kph. But if he area w nd speed or Ultrav olet strength s too h gh, w l shorten the wind sleeve s lifespan Connect the w re in the bottom and 2 5mm w re term nal is avai able
Heliport Windsock is to indicate the wind direction of the final approach and take-off, it can make a general indication to the wind speed. According to the ICAO provisions for each airport must be set at least one wind vane. Its installation location must not interference by nearby objects or the airflow blowed by the rotor, and must be guaranteed the helicopter can be clearly identified at least in 200 meters away Structure chart
TheA rport Rotat on Beacon dentifiies the ocat on of an a rport from a distance and is designed for use at commercial and reg ona a rports and he ports
CM-HT12/G is a heliport outdoor light contro er, suits all k nds of hel port ligh on/off controller. t contro s and shows a the heliport navigation lights' work statu This product s outdoor type, and ingress protect on s IP65, can be used in the outdoor directly
● The house is made of stee painted by spraying p ast c finish which is corros on res stance and anti-UV
● Meet FAA specification AC150/5345-12 L801A
● Operat ng temperature -40℃～55℃
● High re ability
● Hous ng in aluminium alloy coated in ye ow.
● Lamp heads in a uminium alloy
● Four lamp heads for airport
● Wh te LED 150W*2 Green LED 30w*2,LED Lamp
● Power supp y:220V,50 or 60Hz
● It has 6 c rcuits of output, and it can be changed according to requirement There a Auto Manua and Remote three modes for user's choice
● Th s controller is powerful reliab e safe, easy to use and maintain, convenient
Bangda Iron Tower Project Tibet
Turkey Transmission Tower Project
Yanghu Iron Tower Project,Tibet
Henan Telecom Tower Project
Shanxi Telecom Towe Project
Henan GSM Tower Project
2018 & 2019 Airport Show in Dubai & Germany
2019 Clients Visiting in Indonesia & Germany & Italy & Poland
