Casey Li Architectural Portfolio

WOULD YOU PLEASE LOOK AT ARCHITECTURE PORTFOLIO 2019 CASEY

LI

CONTENTS

Letter of Recommendation

01

Academic Moss Park Community Center Fishog Lake Boathouse Multicultural Center Construction

02 12 22

Work Experience Qihe Wetland Park Universal Business Park Hentong

30 36

Design Build Winterlude Installation Vision Media Conference Signage Fraktur Installation

38 40 42

北京土人景观与建筑设计规划研究院 T URE N SC AP E I NT E R N AT IO N AL LIM IT ED

Recommendation Letter Dear Sir / Madam, I have been a Director and an Architect at Turenscape International Limited, where I had the privilege of working with Casey Li. It is my pleasure to write a letter of recommendation for Casey in support of her future endeavors.

I have known Casey for over two months at Turenscape. The work produced by her as a intern architect demonstrates her through understanding of architectural design, organization skills and planning skills.

Working at a company with over five hundred professionals in four areas of focus (architecture, landscape architecture, environmental design, and urban planning and design), Casey was able to benefit from the opportunity to collaborate with professionals of various backgrounds and strengths. Her design ideas align with Turenscape’s philosophy which prioritizes unifying nature and man in a harmonious way through sustainable design.

Over the term from June 1st till August 11th 2017, Casey took on the responsibility of an intern architect for several national design projects. She was an asset to projects such as the Xiamen Waterfront Masterplan and the Beijing Universal Business Park presentation. Additionally, one of her main responsibilities was the schematic design of buildings for the Qihe National Wetland Park. For this project she made significant contributions to the design of a wetland museum and private villas for the park. She also worked well with her colleagues, offering suggestions and assistance to others whenever possible.

Her dedication and competence show through her persistence to improve and refine designs, and I can attest that she has a professional attitude and great potential in the industry.

Casey's combination of motivation and hard work in the architectural field make her an ideal candidate for her future prospects. I believe that she has the potential for a career as an architect and will be a great asset to any firm.

Sincerely,

Stanley Lung B.Arch, M.Arch Turenscape Director & Associate International Studio, Design Architect

Dr. Kongjian Yu Turenscape Principal, Turenscape International Limited Room 401 Innovation Centre, Peking University Science Park, 127-1, Zhongguancun North Street Haidian District, Beijing P.R. China 100080

01

MOSS PARK COMMUNITY CENTER

Academic Studio

Moss Park Community Center

Academic Studio 2017 Lucy Yang, Casey Li

N

Moss Park Site 02

Ground Floor Render

Located at the corner of Queen St. and Jarvis St., Moss Park is one of many parks available to the communities in the core of downtown Toronto. The intent of the Moss Park Community Center would be to provide a space for the services most needed by the community as well as center to direct users to facilities available close by. The community center would be a location for

all residents to easily access multiple amenities, and hopefully become a central place for all people in the area to build a community. The Moss Park area is surrounded by several services available to the Aboriginal and First Nations community, and one of the primary facilities in the community center would be to become a center of operations and communication for the

services in the area, helping to direct community members to services along with providing additional resources in the center itself. Other facilities to help serve the community also include a Service Canada center, a daycare, a multipurpose hall, a community kitchen, and a library.

03

PROPOSED 8 STOREY RESIDENTIAL CO-OP

1

2

PROPOSED 8 STOREY RESIDENTIAL CO-OP

3

4

5

6

LANEWAY

7

A A DW REF. 1

VALVE ROOM

LOADING/ GARBAGE ROOM

ELECTRICAL ROOM

DW REF.

4

COMMUNITY KITCHEN

B

UP

TELECOM ROOM

STORAGE

WORKSHOP ROOMS

STORAGE

YOUTH ROOM

B

C

2 4

DAYCARE LOBBY MEETING ROOMS

COMM. CENTRE OFFICE

B

RECEPTION

MECHANICAL ROOM

MULTI-PURPOSE ROOM

PERFORMANCE/ ART DISPLAY PLATFORM

D

WAITING AREA

FEDERAL DISPLAY

ABORIGINAL DISPLAY

FEDERAL OFFICES

FEDERAL RECEPTION UP

UP

E

UP

ARTIST STUDIO

TEMPORARY ART DISPLAY

LIBRARY

TEMPORARY ART DISPLAY

F

15 1

QUEEN STREET EAST

1

Level 1 1 : 100

A Ground Floor Plan

Academic Studio

Moss Park Community Center

N

Section AA

04

1

2

3

4

5

6

7

A A 1 4

B SENIORS CENTRE

DN

DAY CARE OUTDOOR TERRACE

OPEN TO BELOW

C

2 4

B

EATING AREA

DW REF.

OPEN TO BELOW

KITCHEN CHANGE AREA REF. DW

STAFF ROOM

D DAYROOM

DW REF.

B

DAYROOM INDOOR PLAY AREA

ABORIGINAL LEARNING CENTRE

STAFF ROOM

DN

DAYROOM

DAYROOM

DAYROOM

DAYROOM

OPEN OFFICE

E

DN

LOUNGE/ WAITING AREA

DAY CARE OUTDOOR TERRACE

CONSULTING ROOMS

FORMAL MEETING ROOM

F

N

1

Level 2 1 : 100

A Second Floor Plan

Section BB

05

Academic Studio

Moss Park Community Center

Sectional Perspectives

Ground Floor Render 06

South Elevation

East Elevation

Southern Exterior Perspective

Eastern Exterior Perspective 07

Parapet Axonometric

SLOPED BLOCK PARAPET CAP 5

51

10

150

15 40

51

30

PARAPET CONSTRUCTION

CANT STRIP

90 24 46

• • • • PARALLEL FLANGE CHANNEL

I BEAM WELDED TO COLUMN

OPEN WEB STEEL JOIST

08

30mm WOOD CLADDING 51mm AIRSPACE BETWEEN WOOD STUD 40mm RIGID INSULATION AIR VAPOUR MEMBRANE 15mm PLYWOOD SHEATHING 150mm BATT INSULATION BETWEEN STEEL STUD

FRAMING 10 mm GYPSUM BOARD 1mm AIR BARRIER 51mm RIGID INSULATION 5mm FLASHING

ROOF ASSEMBLY

400

Academic Studio

Moss Park Community Center

76

6

50

• • • • • •

10

150

15 40

51

30

• • • • • • •

50mm CALCAREOUS TUFA SLAB 10mm ROOF MEMBRANE 180mm RIGID INSULATION AIR VAPOUR MEMBRANE 24mm ROOF SHEATHING 46mm STEEL DECK OPEN WEB STEEL JOIST

Parapet Detail

Second Floor Atrium Render

09

Academic Studio

Moss Park Community Center

Second Floor Atrium Model

Rail to Floor Condition Model 10

Exterior Facade Model

11

FISHOG LAKE BOATHOUSE Academic Studio 2018 Casey Li

12

Academic Studio

Fishog Lake Boathouse

Fishog Lake Bathymetry 1969

Cafe Render

Just north of the Kwartha Lakes of Ontario lies the Queen Elizabeth II Wildlands Provincial Park, a park of over thirty thousand hectares containing more than one hundred different habitats and the plethora of flora and fauna that call it home. Close to the southern border of the Wildlands is Fishog Lake, just over two kilometers at its longest and over two hundred acres of smooth water surrounded by trees and wildlife. Located on the protrusion that splits

Canoe Rental Render

the lake, is the Fishog Lake Boathouse, a stepping stone for beginner water sports lovers and a stop on the portage trail for canoe and backpacking enthusiasts alike. Guests will be able to rent canoes or kayaks for the day and explore either side of the lake, as well as have a place to wash up and relax after the day is done. Likewise, seasoned outdoorsmen can take a break from their journey and have a quick bite or stock up on supplies at the cafe and

store.

The Boathouse consists of several smaller structures that descend along with the land towards the lake. As guests move between the facilities of the Boathouse, the division between interior and exterior is softened, with structures that open onto the site, allowing for omni directional views and circulation. Guests can meander from space to space, moving through the trees within the site and towards the lake to cast off.

13

B

Roof Plan

A

Academic Studio

Fishog Lake Boathouse

Fishog Lake Bathymetry

N

Fishog Lake B 14

A

N

Ground Floor Plan

15

16

Academic Studio

Fishog Lake Boathouse

Section AA

Section BB

Methods of Arrival to Site 17

Roof Panel

Spruce Joists

Cedar Deck Boards

Spruce Studs Wall Panel

Glazing

Spruce Joists

18

Concrete Footing Academic Studio

Fishog Lake Boathouse

Glulam Column

Structure Axonometric

Construction Axonometric

19

20

Academic Studio

Fishog Lake Boathouse

Sectional Perspectives Approaching Lake

21

MULTICULTURAL CENTER CONSTRUCTION Academic Studio 2018 Florence Chu, Shirley Li, Clarice Medina, Juan Jabile, Lucy Yang, Casey Li

contained plans, building sections, wall sections, elevations, details, and schedules that would relate the specifications of the design. Over the course of the project, the capabilities of Building Information

Modelling were utilized to create a cohesive and integrated model that could display information on how the project would be constructed.

Academic Studio

Multicultural Center Construction

Based on the preliminary designs of a multi-cultural center, detailed construction documents were produced that would comply with Ontario Building Code requirements. The completed package

Site Plan

22

Site Plan

23

24

Academic Studio

Multicultural Center Construction

Ground Floor Plan - North Section

25

26

Academic Studio

Multicultural Center Construction

Ground Floor Plan - South Section

27

28

Academic Studio

Multicultural Center Construction

Longitudinal Section - 1

Transverse Section - 2

29

30

Academic Studio

Multicultural Center Construction

Zinc Cladding to Curtainwall 1-10

Curtain Wall at Grade 1-10

Window and Wall Schedule

31

QIHE WETLAND PARK

Turenscape Student Intern Work

Qihe Wetland Park

Turenscape Student Intern Work

32 Wetland Museum Render

Wetland Museum Render

In the Eastern province of Shandong, China, is the growing city of Qihe, one of many cities in China striving to become an ecocity in addition to becoming a recognized eco-tourist destination.

The Qihe Wetland Park is a project commissioned by the city, wherein Turenscape would design and collaborate with other consultants to produce working drawings for the master plan of the park. Spanning over ten kilometers, and multiple

ecosystems, the Wetland Park will include facilities for visitors to delve into the wetlands areas, stay in different accommodations, and enjoy contemporary facilities throughout the park.

Structures proposed for the park would include welcome centers, commercial spaces, and different lodging residences.

A wetland conservation museum would be located in the northern section of the park which would

give visitors a chance to learn more in-depth about the flora, fauna, and ecosystems inside the park as well as the importance of wetland habitats and wetland conservation. The museum would coalesce indoor and outdoor structures to create spaces that are educational and experiential, all featuring highlighted components of wetland ecosystems.

33

N

34

Qihe Wetland Park Master Plan Site

Turenscape Student Intern Work

Qihe Wetland Park

Welcome Center Render

Wetland Museum Site

Retail Street Render

Outdoor Facilities Render Cabin and Lodging Site

35

36

Schematic Wetland Museum Sections

Turenscape Student Intern Work

Qihe Wetland Park

Museum Program: 1.

2.

3.

4.

5.

6.

7.

6.

7.

Box Office and Welcoming Center Theater Uses of Wetlands Exhibit Wetland Flora Exhibit Wetland Fauna Exhibit Cafe Wetland Conservation Exhibit

5.

3.

4.

2.

1.

N

Schematic Wetland Museum Plan

7.

6.

2.

5.

1.

3.

4.

37 Schematic Wetland Museum Axonometric

UNIVERSAL BUSINESS PARK HENTONG

Turenscape Student Intern Work

Universal Business Park Hutong

Turenscape Student Intern Work

UBP Hentong Park Render 38

UBP Hentong Site Render

UBP Landscaping Render

The Universal Business Park located in the northwest sector of Beijing City is a building complex of low to mid rise buildings home to many international enterprises’ business offices. The Park is currently expanding to include new buildings and facilities, as well as improve on the current landscaping and urban planning of the site.

Turenscape’s proposal for the development of future structures and landscaping additionally involve creating distinguishable points of entry into the business park, creating structured circulation pathways for vehicles and pedestrians, along with making meaningful spaces from designated parklettes. Signage within

the Business Park would be updated to distinctive markers that would allow visitors a simple means of navigation within the Park, and park amenities would be updated to be more easily accessible. Parkettes would have seasonal fauna displayed, visually engaging hardscapes, as well as pavilions for public use.

39

FROZEN SEASONS Winterlude Festival Installation Designers: Victor Huynh, Tim Melnichuck Installation: Agnes Yuen, Casey Li

Installation

Frozen Seasons

Acrylic Panel Axonometric

40 Installation Photos

“Canada is well known for its natural landscape and with each season brings a new life and beauty. Frozen Seasons is designed to embrace the cold weather as well as showcase the seasonal changes that occur throughout the year.

An abstracted tree appears within the crystal structure.

As time progresses, the tree emits seasonal colours bringing the sculpture to life.” Abstract from 325

Magazine 2016.

published

in

Displayed at the annual Winterlude Festival held in Ottawa, the installation was situated inside Major’s Hill Park where guests could wander across the snow covered paths to look at the various installations and sculptures as well as take part in the festivities.

The appearance of the installation would differ

depending on the time of day as well as the immediate weather conditions. During the sunny midmorning, the acrylic panels could be easily seen though revealing the structure and tree motif within, but as the sun set and snow began to fall, the panels would become opaque, screening the tree and emitting a muted light in the darkness.

41

VISION MEDIA CONFERENCE SIGNAGE Commissioned Design Build in Partnership with DFZ Team: Devin Rochussen, Jessica Feng, Kierstyn Marlow, Rhea Mazgaonkar, Tanya Estrina, Casey Li

42

Commissioned Design Build

Vision Media Conference Signage

The signage was designed in collaboration with Ryerson University’s Digital Fabrication Zone (DFZ) for the Vision Media Conference, an event organized by the Faculty of Communication and Design. This conference was a one-day creative learning experience where students could find the tools, processes, and

inspiration necessary to pursue their goals and create change in the media industry. Produced by a design team including architecture and interior design students and led

by DFZ mentor Duncan Sabiston, the team worked with the event organizers to design a sign that would that could be easily transported to multiple

conference locations and would be clearly recognizable to guests.

The final design was constructed from a wire cut foam piece bisected by an acrylic panel, with led lighting hidden in the wooden base, to create dynamic views from multiple angles and achieve what the clients had envisioned.

Vision Media Conference

Signage Photos

43

FRAKTUR Installation for Come Up to My Room 2019 Adrian Chiu, Henry Mai, Arnel Espanol, Casey Li, Monika Mitic, Nan Xiao, Martina Cepic

44

Installation

Fraktur

Framed within the backdrop of the historic 130-year-old Gladstone Hotel, ‘Come Up To My Room’ invites artists and designers to create immersive installations that stimulate the imagination and encourage discussion and dialogue between contributors and visitors alike.

The inspiration for the living wall came from wanting to create an installation that was not only interactive but had the ability to be a different experience based on multiple visits. Looking at how humans interact with systems in nature such as coral reefs, we wanted to create something that could invoke the feeling of encroaching on a living

creatures and their defense mechanisms. Depending on if you go in alone or with a crowd of others, one can experience the installation as a dark alcove with only a peculiar murmur to indicate its active state, or see the installation come to life when it senses the presence of others and begins to swell, skin cracking open as it evolves.

Installation Photos

Installation Walkthrough

Panel Construction Components: • • • • • • • •

Plywood Shelf 20 in Fan Plastic Film LED Strip connected to Arduino Plywood Frame Mesh Fabric Paper Tiles Ultrasonic Sensor 45

THANK FOR

YOU YOUR

CONSIDERATION

ARCHITECTURE PORTFOLIO 2019 CASEY

LI
