SITE PLAN HOUSE TYPES
BLOCK TERRACED
PRIVATE LANDSCAPE
DETAILS RENOVATION
01
.2 .3 .6 .8 .9 .10
BROOKVIEWCOURT BROOKVIEW
Over-run Over-run Over-run Over-run 122.596 SteelFence SteelFence SteelFence SteelFence SteelFence SteelFence SteelFence SteelFence SteelFence PalisadeFence LS LS LS Car Park
RISE
UND Line Luas Luas Line Luas Luas Luas Line Luas Line Luas LuasLine Luas Line Luas Line Steel Citywest Citywest Grass margin 107.70 PHASE 02 Please Refer to Drawing No. 23001-AKM-XXXX-XX-DR-A01-000001 BZ02 BZ03 BZ04 BZ05 BZ06 BZ01 H3BB H3BA H3BB H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3BA H3BB H3BA H3BB H3BA H3BB H4BB H3CB H3CA H3CA H3CB H3CB H3CA H3CA H3CB H3CB H3CB H3CA H3CB H3CA H4CA H4CB H4AA H4BB H4BA H4BB H4BA H4BB H4BA H3BB H3BA H3BA H3BB H3BA H3BB H3BA A1EB D3AB A1FB D3BB A1FA D3BA A1FB D3BB A1FA D3BA A1FB D3AA A1DB A1CB A1EB A1FB A1FA A1FB A1FA A1EA D3AB D3BB D3BA D3BB D3BA D3AA D3AB D3BB D3BA D3BB D3BA D3AA A1FB A1FA A1EA A1EB A1FB A1FA A1FB A1FA A1DA A1CA H3AB H3AA H3AB H3AA H3AB H3AA 1 BT01 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 H3BB H3BA H3BB H3CB H3CA H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3CB H3CA H3BA H3BB H3BA H3BB H3BA 01 02 03 04 05 06 07 08 09 10 05 04 03 02 01 06 12 13 14 15 16 17 18 11 09 08 07 06 05 04 03 02 01 10 11 12 13 14 15 16 17 18 19 20 02 03 04 05 06 07 08 09 10 01 07 06 05 04 03 02 01 08 07 06 05 04 03 02 01 08 09 10 11 12 13 The Mews The Cresent The Drive The Close The Way TheAvenue The Avenue TheBoulevard 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 46 47 44 45 42 43 40 41 38 39 36 37 34 35 32 33 30 31 28 29 26 27 24 25 22 23 20 21 ThePark ThePark ThePark BT01 BT04 BT01 BT01 BT08 BT07 BT10 BT02 A1BA A1AA A1EA D3AA D3BB D3BA A1FB A1FA A1FA D3BB D3BA D3BA A1BB A1AB A1CA A1DA D3BA D3BB D3BA D3BB D3BA D3AA A1AA A1BA A1FA A1FB A1FA A1FB A1FA A1EA D3AB D3BB D3BA D3BB D3BA D3AA A1EB A1FB A1FA A1FB A1FA A1EA BT06 BT09 BT05 BT03 18 17 16 15 14 13 12 11 19 0+44.50 108.223 0+00.00 108.603 0+10.00 108.518 0+20.00 108.432 0+30.00 108.347 0+40.00 108.262 0+59.44 108.075 0+00.00 107.575 0+10.00 107.659 0+20.00 107.743 0+30.00 107.828 0+40.00 107.912 0+50.00 107.996 6+24.46 ??? 0+00.00 107.852 0+10.00 108.129 0+20.00 108.471 0+30.00 108.631 0+40.00 108.581 0+50.00 108.541 0+60.00 108.563 0+70.00 108.613 0+80.00 108.663 0+90.00 108.684 1+00.00 108.632 1+10.00 108.581 1+20.00 108.529 1+30.00 108.477 1+40.00 108.426 1+50.00 108.384 1+60.00 108.375 1+70.00 108.400 1+80.00 108.450 1+90.00 108.501 2+00.00 108.496 2+10.00 108.433 2+20.00 108.369 2+30.00 108.305 2+40.00 108.241 2+50.00 108.227 2+60.00 108.310 2+70.00 108.410 2+80.00 108.497 2+90.00 108.543 3+00.00 108.546 3+10.00 108.506 4+00.00 108.041 4+10.00 108.050 4+20.00 108.093 4+30.00 108.128 4+40.00 108.148 4+50.00 108.154 4+60.00 108.145 4+70.00 108.122 4+80.00 108.085 4+90.00 108.033 5+00.00 107.968 5+10.00 107.882 5+20.00 107.770 5+30.00 107.631 5+40.00 107.466 5+50.00 107.274 5+60.00 107.055 5+70.00 106.821 5+80.00 106.587 5+90.00 106.353 6+00.00 106.119 6+10.00 105.885 6+20.00 105.636 1+62.50 108.683 0+10.00 108.387 0+20.00 108.420 0+30.00 108.385 0+40.00 108.326 0+50.00 108.267 0+60.00 108.243 0+70.00 108.301 0+80.00 108.409 0+90.00 108.387 1+00.00 108.436 1+10.00 108.496 1+20.00 108.555 1+30.00 108.512 1+40.00 108.498 1+50.00 108.574 1+60.00 108.661 0+00.00 108.347 0+10.00 108.400 0+20.00 108.433 0+30.00 108.433 0+40.00 108.400 0+50.00 108.349 0+60.00 108.297 0+70.00 108.246 0+80.00 108.216 0+90.00 108.222 1+00.00 0+00.00 108.250 0+10.00 108.305 0+20.00 108.354 0+30.00 108.325 0+40.00 108.274 0+50.00 108.231 0+60.00 108.258 0+70.00 0+00.00 108.534 0+10.00 108.566 0+20.00 108.450 0+30.00 108.433 0+40.00 108.493 0+50.00 108.538 0+60.00 108.462 0+70.00 108.242 0+90.91 108.471 0+10.00 108.463 0+20.00 108.516 0+30.00 108.531 0+40.00 108.480 0+50.00 108.426 0+60.00 108.372 0+70.00 108.364 0+80.00 108.414 0+90.00 108.467 BT01 No. 04 TOTAL Block Type H3CA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3CB BT02 No. 01 H3CA H2AB H2AA H2AB H2AA H3CB BT03 No. 01 H3AA H2AB H2AA H2AB H3CB BT04 No. 01 H4AA H2AB H2AA H2AB H2AA H2AB H2AA H3AB BT05 No. 01 H4CA H4BB H4BA H4BB H4BA H4BB H4BA H4BB H4CB BT06 No. 01 H3CA H2AB H2AA H2AB H2AA H2AB H2AA H2AB H2AA H3AB BT07 No. 01 H3CA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3AB BT08 No. 01 H3AA H3BB H3BA H3BB H3BA H3BB H3BA H3BB H3BA H3CB BT09 No. 01 H3AA H3BB H3BA H3BB H3BA H3BB H3BA H3CB BT10 No. 01 H3CA H2AB H2AA H2AB H2AA H2AB H2AA H3CB BZ01 No. 01 TOTAL Block Type A1CA A1DA D3BA D3BB D3BA D3BB D3BA D3AA BZ02 No. 01 BZ03 No. 01 BZ04 No. 01 BZ05 No. 01 BZ06 No. 01 A1AA A1BA A1FA A1FB A1FA A1FB A1FA A1EA D3AB D3BB D3BA D3BB D3BA D3AA A1EB A1FB A1FA A1FB A1FA A1EA D3AB D3BB D3BA D3BB D3BA D3AA A1DB A1CB A1EB A1FB A1FA A1FB A1FA A1FB A1BB A1AB A1EB A1FB A1FA A1FB A1FA A1EA D3AB D3BB D3BA D3BB D3BA D3AA A1CA A1DA D3BA D3BB D3BA D3BB D3BA D3AA A1AA A1BA A1FA A1FB A1FA A1FB A1FA A1EA A1EB A1FB A1FA A1FB A1FA A1EA D3AB D3BB D3BA D3BB D3BA D3AA H3BB H3BA H3CA H3CB H2AB H2AA H3AB H3AA H4BB H4CA H4CB H4BA H4AA Bed Mid-Terrace Area 77.7 sqm No. 13 TOTAL House Type No. 14 No. 3 No. 3 No. 27 No. 27 No. 8 No. 9 No. 1 No. 3 No. 4 No. 1 No. 1 Bed Mid-Terrace Area77.7 sqm Bed End Terrace Area 102 sqm Bed End Terrace Area 102 sqm Bed Mid-Terrace Area 93.5 sqm Bed Mid-Terrace Area 93.5 sqm Bed End-Terrace Area 116 sqm Bed End-Terrace Area 116 sqm Bed End Terrace Area 137 sqm Bed Mid-Terrace Area 167 sqm Bed Mid-Terrace Area 167 sqm bed End Terrace Area 171 sqm Bed End Terrace Area 171 sqm North Proposed Site Layout Plan 1:1000@A1 DRAFT ALL DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED DIMENSIONS ONLY. ALL DISCREPANCIES TO BE REPORTED NOTES: 21026-AKM-XXXX-XX-DR-A01-100001 DOCUMENT NO: S3 FOR REVIEW AND COMMENT STAGE: 02
BROOKVIEWWALK
– DUPLEXES/MAISONNETS
Site Plan
SITE PLAN 114 HOUSES 6 BLOCKS
4 BLOCKS - APARTMENTS
H2AA GROUND FLOOR PLAN SCALE 1:50
HOUSE
GROUND FLOOR
• LIVING ROOM
• KITCHEN/DINNING
• UTILITY
• ACCESSIBLE WC
FIRST FLOOR
• BED 01
• ENSUITE
• BED 02
• ENSUITE
• HP
2 BEDROOM MID TERRACE HOUSE 78 SQM
EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS
EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS
H2AA FIRST FLOOR PLAN SCALE 1:50
18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing GT 300.0 HEAT PUMP 300.0
18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing CL CL CL CL Note: Restricted Head Room Radon Outlet W01 DW 4204 1140 2014 1860 1050 3610 KITCHEN/DINING 12.1m² LIVING ROOM 18.4m² Stringer required on both sides stairs Radon Sump Ceiling Vent Ceiling Vent WC UTILITY/ST. 2.6m² SVP 950 950 D01 1022.5 ENT.800 W02 1810.0 665.0 4612.5 1022.5 440.0 1810.0 685.0 WALL VENT aco drain Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° Min. 1200x750mm Clear area within cubicle 900 2340 925 TAP BIGT WALL VENT 3 no. 50mm Comms Ducts Additional 35mm service batten fitted to inside face of 35mm service batten to allow for ducts 3053 950 WM DR Ceiling Vent 10 11 12 13 09 Disabled (Part M) ramp and 1200 x1200 clear flat area (slope 1:50) at door. Vertical DPCs to All Opes 1600 4204 1050 HALL 6172 D02 Traditional newel post and balustrade is NOT required. Stairs is to fit within allowed opening and is to be fitted with a handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part & I.S.EN 1991-1-1 the Irish National Annex incl. NA.4. Vertical DPCs to All Opes 1294 2013 CHARCOAL FILTERS FOR KITCHEN HOB 2950 Additional 35mm service batten fitted to inside face of 35mm service batten 925 ESB Duct Radiator location zone 450 HP 877 925 2085 2200 900 LANDING BED 1 14.63m² Reduced height wall 1.0m 900 W05 1810.0 572.5 890.0 1810.0 800 WALL VENT 925 2129 2076 pull down attic access 6 11 13 3085 3085 1299 1885 Vertical DPCs to All Opes Vertical DPCs to All Opes 2485 715 3457 4194 BED 2 11.64m² Ceiling Vent 2460 SVP 1000 SVP 850 ENSUITE 900 W03 4612.5 W04 1970 WALL VENT 925 10 12 09 3645 2140 1000 715 ENSUITE Traditional newel post and balustrade is NOT required. Stairs is to fit within allowed opening and to be fitted with a handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part & I.S.EN 1991-1-1 & the Irish National Annex incl. NA.4. 850 777.5 W06 572.5 Ceiling Vent 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing H2AA GROUND FLOOR PLAN SCALE 1:50 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing GT 300.0 HEAT PUMP 300.0 H2AA FIRST
PLAN
1:50 Movement Joint Flexible Polyethylene Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing L CL CL CL Note: Restricted Head Room Radon Outlet W01 DW 4204 1140 2014 1860 1050 3610 KITCHEN/DINING 12.1m² LIVING ROOM 18.4m² Stringer required on both sides of stairs Radon Sump Ceiling Vent Ceiling Vent WC UTILITY/ST. 2.6m² SVP 950 950 D01 1022.5 ENT.800 W02 1810.0 665.0 4612.5 1022.5 440.0 1810.0 685.0 WALL VENT aco drain Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° Min. 1200x750mm Clear area within cubicle 900 2340 925 TAP BIGT WALL VENT no. 50mm Comms Ducts Additional 35mm service batten fitted to inside face of 35mm service batten allow for ducts 3053 950 WM DR Ceiling Vent 4 10 11 12 13 09 Disabled (Part M) ramp and 1200 x1200 clear flat area (slope 1:50) at door. Vertical DPCs to All Opes 1600 4204 1050 HALL 6172 D02 Traditional newel post and balustrade is NOT required. Stairs is to fit within allowed opening and is to be fitted with handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part K I.S.EN 1991-1-1 & the Irish National Annex incl. NA.4. Vertical DPCs to All Opes 1294 2013 CHARCOAL FILTERS FOR KITCHEN HOB 2950 Additional 35mm service batten fitted to inside face of 35mm service batten 925 ESB Duct Radiator location zone 450 HP 877 925 2085 2200 900 LANDING BED 1 14.63m² Reduced height wall 1.0m 900 W05 1810.0 572.5 890.0 1810.0 800 WALL VENT 925 2129 2076 pull down attic access 11 13 3085 3085 1299 1885 Vertical DPCs to All Opes Vertical DPCs to All Opes 2485 715 3457 4194 BED 2 11.64m² Ceiling Vent 2460 SVP 1000 SVP 850 ENSUITE 900 W03 4612.5 W04 1970 WALL VENT 925 5 8 10 12 09 3645 2140 1000 715 ENSUITE Traditional newel post and balustrade is NOT required. Stairs to fit within allowed opening and is to be fitted with handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part K & I.S.EN 1991-1-1 the Irish National Annex incl. NA.4. 850 777.5 W06 572.5 Ceiling Vent 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing Joint Polyethylene
FLOOR
SCALE
03 CL CL CL CL FRONT ELEVATION SCALE 1:100 REAR ELEVATION SCALE 1:100 500 (Min. 500mm) 818 818 W01 D02 W04 W06A 500 (Min.500mm) W06 HEAT PUMP ACCESS PIPES 818 818 W04 D04
GFL.+0.000 FFL.+2.787 DH HEAD.+2.250 WIN HEAD.+4.875 UNDERSIDE OF CILL.+3.600 UNDERSIDE OF CILL.+0.975 2088.0 DPC DPC DPC DPC Note: Insulation Continue Through Joists 2500 Top of Deck to U/S Rafter 2518 Top of Joist To U/S Rafter 2450 Top of Deck to Ceiling Slab Note: Insulation to Continue Through Joists DPC 10 11 12 13 1000.0 2088.0 Slab to Top of Joists 2769.0 Slab to Underside of Joist 2465.0 Slab to Ceiling Slab 2450.0 Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° DPC DPC DPC 888.0 1200.0 2250.0 1050.0 1200.0 888.0 1200.0 2787.0 600.0 1650.0 2250.0 08 09 UNDERSIDE OF ROOF +8.587 ATTIC Fire smoke alarm to be installed. 32.0° 32.0° LIVING ROOM KITCHEN DINING BED 02 BED 01 x 12.5mm Type A Plasterboard 1 x 15mm Type A Plasterboard UTILITY LANDING SECTION
SCALE
DOCUMENT NO: PROJECT TITLE: 23047-AKM-E5-ZZ-DR-A01-100016
CL CL CL CL FRONT ELEVATION SCALE 1:100 REAR ELEVATION SCALE 1:100 500 (Min. 500mm) 818 818 W01 D02 W04 W06A 500 (Min.500mm) W06 HEAT PUMP ACCESS PIPES 818 818 W04 D04
AA
1:100
E5
GFL.+0.000 FFL.+2.787 DH HEAD.+2.250 WIN HEAD.+4.875 UNDERSIDE OF CILL.+3.600 UNDERSIDE OF CILL.+0.975 2088.0 DPC DPC DPC DPC Note: Insulation to Continue Through Joists 2500 Top of Deck to U/S Rafter 2518 Top of Joist To U/S Rafter 2450 Top of Deck to Ceiling Slab Note: Insulation to Continue Through Joists DPC 10 11 12 13 1000.0 2088.0 Slab to Top of Joists 2769.0 Slab to Underside of Joist 2465.0 Slab to Ceiling Slab 2450.0 Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° DPC DPC DPC 888.0 1200.0 2250.0 1050.0 1200.0 888.0 1200.0 2787.0 600.0 1650.0 2250.0 08 09 UNDERSIDE OF CILL.+0.525 ROOF +8.587 ATTIC Fire & smoke alarm to be installed. 32.0° 32.0° LIVING ROOM KITCHEN DINING BED 02 BED 01 1 x 12.5mm Type A Plasterboard x 15mm Type A Plasterboard UTILITY LANDING SECTION
SCALE 1:100 DOCUMENT NO: DRAWN BY: PROJECT TITLE: STAGE: 23047-AKM-E5-ZZ-DR-A01-100016 S2-SUITABLE HOUSE E5
AA
2 2 A1
HOUSE D2
HOUSE D2
HOUSE D2
GROUND FLOOR
• LIVING ROOM
• KITCHEN/DINNING
• UTILITY/HP
• ACCESSIBLE WC
FIRST FLOOR
• BED 01 -DOUBLE
• ENSUITE
• BED 02 - SINGLE
• BED 03 - SINGLE
• SOCIAL BATHROOM
3 BEDROOM MID TERRACE HOUSE 93 SQM 2 3 A1
EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS
EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS
EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS
CL CL CL CL GT 300.0 HEAT PUMP 300.0 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing H3BA GROUND FLOOR PLAN SCALE 1:50 H3BA FIRST FLOOR PLAN SCALE 1:50 925 2710.0 1022.5 1115.0 1360.0 5400.0 TAP BIGT aco drain D01 1022.5 W01 ENT.800 WALL VENT 8 10 11 12 13 Ceiling Vent WM LIVING ROOM 22.16 m² Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° 1575 2222 950 KITCHEN / DINING 15.50m² W.C. Transfer pipe 1480 1590 Ceiling Vent 1050 950 DW Min. 1200x750mm Clear area within cubicle Note: Restricted Head Room 3815 4992 Stringer required on both sides of stairs SVP SVP 950 6550 3612 Radon Sump Radon Outlet UT/ST 3.50m² DR 1085 Disabled (Part M) ramp and 1200 x1200 clear flat area (slope 1:50) at door. Vertical DPCs to All Opes no. 50mm Comms Ducts Additional 35mm service batten fitted to inside face of 35mm service batten to allow for ducts WALL VENT BEAM TO T/F DETAIL Traditional newel post and balustrade is NOT required. Stairs is to fit within allowed opening and to be fitted with a handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part & I.S.EN 1991-1-1 & the Irish National Annex incl. NA.4. D02 CHARCOAL FILTERS FOR KITCHEN HOB Additional 35mm service batten fitted to inside face of 35mm service batten 1934 2222 Vertical DPCs to All Opes 2909 ESB & Utilities 337.5 337.5 1340.0 4992 338 ESB Duct Radiator location zone Radiator location zone 405 HP Ceiling Vent 112.5 5400.0 685.0 1902.5 1360.0 W02 W04 W05 WALL VENT WALL VENT WALL VENT 10 11 12 13 SVP BED 3 7.15 m² BED 2 8.33 m² LANDING BATHROOM Ceiling Vent 2622 2320 1575 1595 1468 3119 1510 925 pull down attic access 2250 Reduced height wall 1.0m SVP 3850 3177 3177 BATHROOM/ EN SUITE FLOORS: Plywood Sheets on Bathroom/ En Suite Floors to be Screwed Down Only. Nailing will NOT be Accepted. BED 1 13.94 m² ENSUITE 1027 850 Ceiling Vent 900 850 2045 3362 964 09 900 Vertical DPCs to All Opes Vertical DPCs to All Opes Vertical DPCs to All Opes 1360.0 665.0 1360.0 W03 1880 1753 2035 Traditional newel post and balustrade is NOT required. Stairs to fit within allowed opening and is to be fitted with handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part K & I.S.EN 1991-1-1 & the Irish National Annex incl. NA.4. 900 08 Vertical DPCs to All Opes 07 06 05 04 03 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing
04 CL CL CL CL GT 300.0 HEAT PUMP 300.0 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing H3BA GROUND FLOOR PLAN SCALE 1:50 H3BA FIRST FLOOR PLAN SCALE 1:50 925 2710.0 1022.5 1115.0 1360.0 5400.0 TAP BIGT aco drain D01 1022.5 W01 ENT.800 WALL VENT 10 11 12 13 Ceiling Vent WM LIVING ROOM 22.16 m² Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° 1575 2222 950 KITCHEN / DINING 15.50m² W.C. Transfer pipe 1480 1590 Ceiling Vent 1050 950 DW Min. 1200x750mm Clear area within cubicle Note: Restricted Head Room 3815 4992 Stringer required on both sides of stairs SVP SVP 950 6550 3612 Radon Sump Radon Outlet UT/ST 3.50m² DR 1085 Disabled (Part M) ramp and 1200 x1200 clear flat area (slope 1:50) at door. Vertical DPCs to All Opes no. 50mm Comms Ducts Additional 35mm service batten fitted to inside face 35mm service batten to allow for ducts WALL VENT BEAM TO T/F DETAIL Traditional newel post and balustrade is NOT required. Stairs is to fit within allowed opening and is to be fitted with handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part K I.S.EN 1991-1-1 & the Irish National Annex incl. NA.4. D02 CHARCOAL FILTERS FOR KITCHEN HOB Additional 35mm service batten fitted to inside face of 35mm service batten 1934 2222 Vertical DPCs to All Opes 2909 ESB & Utilities 337.5 337.5 1340.0 4992 338 ESB Duct Radiator location zone Radiator location zone 405 HP Ceiling Vent 112.5 5400.0 685.0 1902.5 1360.0 W02 W04 W05 WALL VENT WALL VENT WALL VENT 10 11 12 13 SVP BED 3 7.15 m² BED 2 8.33 m² LANDING BATHROOM Ceiling Vent 2622 2320 1575 1595 1468 3119 1510 925 pull down attic access 2250 Reduced height wall 1.0m SVP 3850 3177 3177 BATHROOM/ EN SUITE FLOORS: Plywood Sheets on Bathroom/ En Suite Floors to be Screwed Down Only. Nailing will NOT be Accepted. BED 1 13.94 m² ENSUITE 1027 850 Ceiling Vent 900 850 2045 3362 964 09 900 Vertical DPCs to All Opes Vertical DPCs to All Opes Vertical DPCs to All Opes 1360.0 665.0 1360.0 W03 1880 1753 2035 Traditional newel post and balustrade is NOT required. Stairs is to fit within allowed opening and is to be fitted with a handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be in accordance with Part & I.S.EN 1991-1-1 the Irish National Annex incl. NA.4. 900 08 Vertical DPCs to All Opes 07 06 05 04 03 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing
500 (Min. 500mm) 1212 1212 W06a W04 W01 D02 500 (Min. 500mm) HEAT PUMP ACCESS PIPES 1043 1381 W05 W05 D03 REAR ELEVATION SCALE 1:100 FRONT ELEVATION SCALE 1:100 CL CL CL CL 5400.0 KITCHEN DINING BED 2 ENSUITE LIVING ROOM 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 1x15mm Type A Plasterboard 1x15mm Type A Plasterboard
Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° 2450 Slab to Ceiling Slab 2088.0 2088.0 2500 Top of Deck to U/S Rafter 2518 Top of Joist To U/S Rafter 2450 Top of Deck to Ceiling Slab BATHROOM DPC DPC Note: Insulation to Continue Through Joists DPC DPC DPC Note: Insulation to Continue Through Joists DPC 888.0 1200.0 888.0 1200.0 GFL.+0.000 DR HEAD.+2.250 WIN HEAD.+4.875 FFL.+2.787 UNDERSIDE OF CILL.+3.600 2565.0 BED 1 Fire smoke alarm to be installed. 32° ROOF +8.587 SECTION AA SCALE 1:100
500 (Min. 500mm) 1212 1212 W06a W04 W01 D02 500 (Min. 500mm) HEAT PUMP ACCESS PIPES 1043 1381 W05 W05 D03 REAR ELEVATION SCALE 1:100 FRONT ELEVATION SCALE 1:100 CL CL CL CL 5400.0 KITCHEN / DINING BED 2 ENSUITE LIVING ROOM 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 1x15mm Type A Plasterboard 1x15mm Type A Plasterboard
Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° 2450 Slab to Ceiling Slab 2088.0 2088.0 2500 Top of Deck to U/S Rafter 2518 Top of Joist To U/S Rafter 2450 Top of Deck to Ceiling Slab BATHROOM DPC DPC Note: Insulation to Continue Through Joists DPC 888.0 1200.0 888.0 1200.0 GFL.+0.000 DR HEAD.+2.250 WIN HEAD.+4.875 FFL.+2.787 UNDERSIDE OF CILL.+3.600 BED 1 Fire & smoke alarm to be installed. 32° ROOF +8.587 SECTION AA SCALE 1:100
500 (Min. 500mm) 1212 1212 W06a W04 W01 D02 500 (Min. 500mm) HEAT PUMP ACCESS PIPES 1043 1381 W05 W05 D03 REAR ELEVATION SCALE 1:100 FRONT ELEVATION SCALE 1:100 CL CL CL CL 5400.0 KITCHEN DINING BED 2 ENSUITE LIVING ROOM 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 1x15mm Type A Plasterboard 1x15mm Type A Plasterboard
Stair Gr. to 1st 13 No. Risers Going: 240mm Rise: 214.38mm Pitch: 41.8° 2450 Slab to Ceiling Slab 2088.0 2088.0 2500 Top of Deck to U/S Rafter 2518 Top of Joist To U/S Rafter 2450 Top of Deck to Ceiling Slab BATHROOM DPC DPC Note: Insulation to Continue Through Joists DPC DPC DPC Note: Insulation to Continue Through Joists DPC 888.0 1200.0 888.0 1200.0 GFL.+0.000 DR HEAD.+2.250 WIN HEAD.+4.875 FFL.+2.787 UNDERSIDE OF CILL.+3.600 2565.0 BED 1 Fire smoke alarm to be installed. 32° ROOF +8.587 SECTION
SCALE 1:100
AA
GROUND FLOOR
• LIVING ROOM
• KITCHEN/DINNING
• UTILITY/ST
• ACCESSIBLE WC
FIRST FLOOR
• BED 02-DOUBLE
• ENSUITE
• BED 03-DOUBLE
• SOCIAL BATHROOM
• STUDY ROOM
• HOT PRESS
SECOND FLOOR
• BED 01-MASTER
• ENSUITE
• STORAGE
• BED 04-DOUBLE
• ENSUITE
HOUSE B1
HOUSE B1
HOUSE B1
• SOCIAL BATHROOM
4 BEDROOM MID TERRACE HOUSE 167 SQM 2 4 A1 1
800.0 GT 300.0 HEAT PUMP 300.0 Traditional newel post and balustrade is NOT required. Stairs is to within allowed opening and be fitted with a handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength stair guarding to be accordance with Part I.S.EN 1991-1-1 & the Irish National Annex incl. NA.4. 4635 pull down attic access 900 900 850 BED 1 19.7m² BED 4 11.6m² ENSUITE 3019 Vertical DPCs to All Opes BATHROOM/ EN SUITE FLOORS Plywood Sheets on Bathroom Floors to be Screwed Down Only. Nailing will NOT be Accepted 1460 4480 Reduced height walls 1.00m 1220 453.5 1214.0 1360.0 685.0 1980 16 17 18 19 Wall Vent Vertical DPCs to All Opes 5442 3695 800 20 21 22 23 24 25 26 5850.0 1091 W07 W08 W09 2260.0 Wall Vent 925 950 27 2172 28 Stair Gr. 1st 14 No. Risers Going: 230mm Rise: 199.07mm Pitch: 41° 5850.0 1372 FD30 FD30 925 LANDING 2231 Ceiling Vent 2231 3211 850 ST 2.3m² ENSUITE 3150 2172 850 Ceiling Vent SVP 800 SVP 1220 1431 800 Traditional newel post and balustrade NOT required. Stairs is to within allowed opening and be fitted with handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding to be accordance with Part I.S.EN 1991-1-1 the Irish National Annex incl. NA.4. BEAM TO TIMBER FRAME DETAIL FOR TIMBER FRAME AND MASONRY SUPPORT 10 11 12 13 15 17 18 19 SVP Vertical DPCs to All Opes Vertical DPCs to All Opes Vertical DPCs to All Opes Wall Vent ENSUITE BATHROOM LANDING 1710 3266 2240 5582 2350 2972 Ceiling Vent Ceiling Vent 1633 BATHROOM/ EN SUITE FLOORS Plywood Sheets on Bathroom Floors to be Screwed Down Only. Nailing will NOT be Accepted SVP BED 3 11.6m² STUDY 7.1m² 900 906 1633 850 900 850 2056 900 975 900 Reduced height walls 1.00m W03 14 BED 2 16.8m² 5850.0 1360.0 337.5 1810.0 1002.5 W04 Wall Vent 3019 3214 1289 552.5 1115.0 1360.0 685.0 4610 925 3545 UP 1269 W05 W06 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing Wall Vent Stair Gr. to 1st 14 No. Risers Going: 230mm Rise: 199.07mm Pitch: 41° 5850.0 FD30 2056 FD30 FD30 FD30 FD30 925 16 2005 1425 HP/ST 0.7m² 1220 5442 4060 1500 1460 1647 3227 3364 5164 1500 W.C. UT./ST 2.5m² WM ST. 1.3sqm LIVING ROOM 17.98m² Vertical DPCs to All Opes SVP KITCHEN DINING 21.16m² Min. 1200x750mm Clear area within cubicle Radon Sump DW Vertical DPCs to All Opes Vertical DPCs to All Opes Wall Vent Ceiling Vent Ceiling Vent Vertical DPCs to All Opes 950 950 950 950 850 1517 1050 Stringer required on both sides of stairs 925 DR 1050 3805 Ceiling Vent Note: Restricted Head Room 1 3165 3180 CHARCOAL FILTERS FOR KITCHEN HOB 2 3 4 5 6 7 8 9 10 11 12 13 14 1810.0 1115.0 1360.0 1360.0 1002.5 1810.0 aco drain Disabled (Part M) ramp and 1200 x1200 clear flat area (slope 1:50) at door. 1125.0 Radon Outlet W01 D02 W02 BIGT/ TAP D01 1022.5 ENT.800 Traditional newel post and balustrade NOT required. Stairs is fit within allowed opening and to be fitted with handrail located between 900 1000mm above the pitch line and between 900 1000mm above landing. Strength of stair guarding be in accordance with Part K & I.S.EN 1991-1-1 the Irish National Annex incl. NA.4. 5850.0 337.5 Additional 35mm service batten fitted to inside face 35mm service batten 925 1100 1100 no. 50mm Comms Ducts Additional 35mm service batten fitted to inside face 35mm service batten allow for ducts ESB Duct Wall Vent 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 5850.0 Stair Gr. to 1st 14 No. Risers Going: 230mm Rise: 199.07mm Pitch: 41° FD30 FD30 FD30 FD30 405 SVP Half wall follow pitch of stairs @950mm above Transfer pipe H4BA GROUND FLOOR PLAN SCALE 1:50 H4BA FIRST FLOOR PLAN SCALE 1:50 H4BA SECOND FLOOR PLAN SCALE 1:50 CL CL CL CL CL CL 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing
05 500 (Min. 500mm) 1437 1437 W01 W05 W09 D01 W10 W05 500 (Min. 500mm) HEAT PUMP PIPES ACCESS 1437 1437 W05 W07 W06a W06a D04 FRONT ELEVATION SCALE 1:100 REAR ELEVATION SCALE 1:100 CL CL CL CL ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY DO NOT TAKE FINISHES FROM SECTION DRAWINGS 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2610 Slab to Top of Joist 2510 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2x12.5mm Type Plasterboard ATTIC Fire smoke alarm to be installed. 41.0° 41.0° KITCHEN BED 1x15mm Type Plasterboard 876.0 1200.0 UNDERSIDE OF CILL .+6.375 1x15mm Type Plasterboard DPC Note: Insulation Continue Through Joists DPC DPC DPC Note: Insulation to Continue Through Joists 2250.0 2787 2787 DPC UT/ STORE LIVING ROOM BED ENSUITE ENSUITE BED BED 600.0 1650.0 DPC DPC DR HEAD.+2.250 238.0 1850.0 1038.0 810.0 228.0 1038.0 238.0 1850.0 Note: Insulation Continue Through UNDERSIDE OF CILL .+2.925 FFL .+2.787 2076.0 2088.0 2250.0 600.0 1650.0 UNDERSIDE OF CILL .+0.525 2076.0 SMALL PITCHED Grey Bullnose by Condron 50x38mm Approved 2x200mm above and 35mm Roof details @600c/c 15mm Type on35x50mm 15mm Type SECTION AA SCALE 1:100 DOCUMENT NO: PROJECT TITLE: 23047-AKM-B1-ZZ-DR-A01-100002
500 (Min. 500mm) 1437 1437 W01 W05 W09 D01 W10 W05 500 (Min. 500mm) HEAT PUMP PIPES ACCESS 1437 1437 W05 W07 W06a W06a D04 FRONT ELEVATION SCALE 1:100 REAR ELEVATION SCALE 1:100 CL CL CL CL ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS ROOF.+12.800 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2610 Slab to Top of Joist 2510 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2x12.5mm Type F Plasterboard ATTIC Fire smoke alarm be installed. 41.0° 41.0° KITCHEN BED 1x15mm Type A Plasterboard UNDERSIDE OF CILL .+6.375 1x15mm Type A Plasterboard DPC Note: Insulation to Continue Through Joists DPC DPC DPC Note: Insulation to Continue Through Joists WIN HEAD.+4.875 WIN HEAD.+7.650 FFL .+5.574 FFL .+2.787 DR HEAD.+2.250 GFL.+0.000 2250.0 2787 2787 DPC UT/ STORE LIVING ROOM BED ENSUITE ENSUITE BED BED 600.0 1650.0 DPC DPC DR HEAD.+2.250 238.0 1850.0 UNDERSIDE OF CILL .+2.925 UNDERSIDE OF CILL .+6.375 UNDERSIDE OF CILL .+0.525 810.0 228.0 810.0 228.0 1038.0 Note: Insulation Continue Through Joists UNDERSIDE OF CILL .+2.925 FFL .+2.787 2076.0 600.0 1650.0 UNDERSIDE OF CILL .+0.525 876.0 1200.0 2076.0 SMALL PITCHED ROOF: Grey Bullnose Flat Concrete Roof Tile by Condron Concrete On 50x38mm Treated Timber Battens on Approved Breather Membrane on 2x200mm Mineral Wool (0.044W/m2K) above and between trusses 35mm Roof trusses to Timber Frame details @600c/c 15mm Type F Plasterboard on35x50mm Timber Battens 15mm Type F Plasterboard SECTION AA SCALE 1:100 DOCUMENT NO: DRAWN BY: PROJECT TITLE: STAGE: PROJECT 23047-AKM-B1-ZZ-DR-A01-100002 S2-SUITABLE FOR
500 (Min. 500mm) 1437 1437 W01 W05 W09 D01 W10 W05 500 (Min. 500mm) HEAT PUMP PIPES ACCESS 1437 1437 W05 W07 W06a W06a D04 FRONT ELEVATION SCALE 1:100 REAR ELEVATION SCALE 1:100 CL CL CL CL ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 EXTERNAL FINISHES MUST BE TAKEN FROM ELEVATIONS AND FINISHES SCHEDULE ONLY - DO NOT TAKE FINISHES FROM SECTION DRAWINGS ROOF.+12.800 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2787 Slab to Top of Deck 2465 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2610 Slab to Top of Joist 2510 Slab to Underside of Joist 2450 Slab to Ceiling Slab 2x12.5mm Type F Plasterboard ATTIC Fire smoke alarm be installed. 41.0° 41.0° KITCHEN BED 1x15mm Type A Plasterboard 876.0 1200.0 UNDERSIDE OF CILL .+6.375 1x15mm Type A Plasterboard DPC Note: Insulation to Continue Through Joists DPC DPC DPC Note: Insulation to Continue Through Joists WIN HEAD.+4.875 WIN HEAD.+7.650 FFL .+5.574 FFL .+2.787 DR HEAD.+2.250 GFL.+0.000 2250.0 2787 2787 DPC UT/ STORE LIVING ROOM BED ENSUITE ENSUITE BED BED DPC DPC DR HEAD.+2.250 238.0 1850.0 UNDERSIDE CILL .+2.925 UNDERSIDE CILL .+6.375 UNDERSIDE CILL .+0.525 810.0 228.0 1038.0 1038.0 Note: Insulation Continue Through Joists UNDERSIDE OF CILL .+2.925 FFL .+2.787 2076.0 2088.0 2250.0 600.0 1650.0 UNDERSIDE OF CILL .+0.525 876.0 1200.0 2076.0 SMALL PITCHED ROOF: Grey Bullnose Flat Concrete Roof by Condron Concrete On 50x38mm Treated Timber Battens Approved Breather Membrane on 2x200mm Mineral Wool (0.044W/m2K) above and between trusses 35mm Roof trusses to Timber Frame details @600c/c 15mm Type Plasterboard on35x50mm Timber Battens 15mm Type Plasterboard SECTION AA SCALE 1:100 DOCUMENT NO: DRAWN PROJECT TITLE: STAGE: 23047-AKM-B1-ZZ-DR-A01-100002 S2-SUITABLE
BT03 H3AA SIDE ELEVATION SCALE 1:50 ESB EV 450.0 Grey uPVC Fascia Soffit Rainwater Goods Grey Bullnose Flat Concrete Roof Tiles by Condron Concrete selected roofing underlay laid in accordance with SR 82:2017 Slating Tiling Code Practice. Sever exposure zone to be assumed unless otherwise specified. Compatible dry verge to be installed to manufacturer's details. All ventilation tiles to be compatible with selected roof tiles. Each Tile to be Nailed and Cliped Dry-Fix Ridge System by Condron Concrete laid accordance with manufacturer's details. Where the ceiling follows the pitch line or room is located within attic, ventilation must be provided at least equal strip 5mm wide. 1m Min. 1.2m Max. 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing W06a GFL.+0.000 FFL.+2.787 ROOF +9.355 WIN HEAD.+4.875 UNDERSIDE OF CILL.+3.600 ROOF +7.098 GFL.+0.000 500 (Min. 500mm) 500 (Min. 500mm) uPVC Double Glazed Windows by Selected Supplier Concrete Sills 40mm High Front Facing Edge Composite Front Door with Double Glazed Vision Panel by Selected Supplier Grey uPVC Fascia Soffit Rainwater Goods Grey Bullnose Flat Concrete Roof Tiles by Condron Concrete & selected roofing underlay laid in accordance with SR 82:2017 Slating Tiling Code of Practice. Sever exposure zone to be assumed unless otherwise specified. Compatible dry verge be installed to manufacturer's details. All ventilation tiles be compatible with selected roof tiles. Each Tile to be Nailed and Cliped Dry-Fix Ridge System by Condron Concrete laid accordance with manufacturer's details. Where the ceiling follows the pitch line or room is located within attic, ventilation must be provided at least equal to strip of 5mm wide. Selected proprietary eaves soffit ventilator provide at least equal to a 10mm continuous strip (allow 25mm where ceiling follows pitch line/room located attic). Install proprietary rafter ventilator ensure 50mm gap insulation. Zinc Canopy Finish Monorex One Coat Through Coloured Weather Resistant Render. Colour Code G00 47.5° FFL.+2.787 WIN HEAD.+4.875 UNDERSIDE OF CILL.+3.600 ROOF +7.592 ROOF +8.820 DR HEAD. +2.250 UNDERSIDE OF CILL.+0.525 Selected Brick ROOF +9.355 W04 W04 W05 W01 W03 W01 D02 BT03 H3CB SIDE ELEVATION SCALE 1:50 ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 Window or Door Type Floor D-01 D-03 W-01 Ground W-04 W-05 Notes: All steel lintels have 250mm bearing or construction. All precast concrete lintels have minimum 2.0m. All precast concrete lintels greater than 1.2m All precast concrete lintels are be placed No stepped DPC cavity tray be placed Where plaster banding shown around windows Ground W-06a First Concrete Ground First First Concrete Concrete Concrete Steel Steel Window or Door Type Floor D-02 D-04 W-01 Ground W-04-Front W-04-Back Notes: All steel lintels have 250mm bearing or construction. All precast concrete lintels have minimum 2.0m. All precast concrete lintels greater than 1.2m All precast concrete lintels are be placed No stepped DPC cavity tray be placed Where plaster banding shown around windows Ground W06a-Front First Ground First First Concrete Steel Concrete Steel W-06 Concrete Ground W06a-Back First Concrete Steel Steel Window or Door Type Floor D-02 D-04 W-01 Ground W-04-Front W-04-Back Notes: All steel lintels have 250mm bearing or construction. All precast concrete lintels have minimum 2.0m. All precast concrete lintels greater than 1.2m All precast concrete lintels are be placed No stepped DPC cavity tray be placed Where plaster banding shown around windows Ground W06a-Front First Ground First First Concrete Steel Concrete Steel W-06 Concrete Ground W06a-Back First Concrete Steel Steel Window or Door Type Floor D-02 D-04 W-01 Ground W-04-Front W-04-Back Notes: All steel lintels have 250mm bearing or construction. All precast concrete lintels have minimum 2.0m. All precast concrete lintels greater than 1.2m All precast concrete lintels are be placed No stepped DPC cavity tray be placed Where plaster banding shown around windows Ground W06a-Front First Ground First First Concrete Steel Concrete Steel W-06 Concrete Ground W06a-Back First Concrete Steel Steel Window or Door Type Floor D-02 D-04 W-01 Ground W-04 W-05 Notes: All steel lintels have 250mm bearing or construction. All precast concrete lintels have minimum 2.0m. All precast concrete lintels greater than 1.2m All precast concrete lintels are be placed No stepped DPC cavity tray be placed Where plaster banding shown around windows W-03-Right W-03-Left & Front Steel Ground Steel W-06 Steel W-06a First Steel Ground Ground Concrete Ground Concrete Concrete Steel First First First Concrete DOCUMENT NO: CLIENT: DRAWING TITLE: PROJECT TITLE: AKM NO. DESCRIPTION DATE REVISIONS Architecture Planning Engineering Architecture Planning Engineering Building Surveying Development Consultants AKM Design Unit 6, Kingswood Business Centre, 4075 Kingswood Business Centre, Citywest Business Campus D24 A068 T: 353 1 4796234 E: info@akmdesign.ie INITIALS Block BT03 (H3AA-H2AB-H2AA-H3CB) Elevations GLENVEAGH HOMES 21026-AKM-BT03-XX-DR-A01-200031 21026 BROWNSBARN 1.01 00 ISSUED FOR REVIEW AND COMMENT 19/05/23 CT ALL DRAWINGS TO BE READ IN CONJUNCTION WITH STRUCTURAL ENGINEERS & MECHANICAL ENGINEERS AND ALL OTHER DETAILS. NOTE: REFER TO STRUCTURAL ENGINEERS DRAWINGS FOR ALL EXTERNAL DRAINAGE LAYOUTS.REFER TO M&E DRAWINGS FOR ALL INTERNAL DRAINAGE LAYOUTS. ALL DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED DIMENSIONS ONLY. ALL DISCREPANCIES TO BE REPORTED TO AKM CONSULTANTS IMMEDIATELY. NOTES: REFER TO TIMBER FRAME DETAILS BOOKLET DETAILS. ALL DISCREPANCIES TO BE REPORTED TO THIS OFFICE. CONTACT THIS OFFICE PRIOR TO COMMENCEMENT FOR CLARITY IF YOU ARE UNCLEAR ON A DETAIL. 01 ISSUED FOR CONSTRUCTION 28/06/23 CT dB nT,w nT,w 58 (max) Impact Sound Insulation 53 (min) 53 (min) Note: For Works Protected Structure, Refer TDG Paragraph 1.1.3 Floors (Including Stairs With Separating Function) Airborne Sound Insulation Walls Sound Performance Levels (Par.1.1.1) TGD E: TABLE MECHANICAL VENTILATION (litres per second time overrun) PROPRIETARY CAVITY CLOSERS DPC OS IS MAINS POWERED IONISATION SMOKE DETECTOR INTERCONNECTABLE TYPE TO I.S.3218 IF NOT INDICATED REFER TO M&E DRAWINGS CARBON MONOXIDE DECTOR TO I.S. EN 50291 1:2010/A1:2012. REFER TO TGD 2019 1.5 HEAT DETECTOR INTERCONNECTABLE TYPE TO I.S.3218 IF NOT INDICATED REFER TO M&E DRAWINGS HD LEGEND: RADON SUMP CONNECTED TO 110mm PVC PIPE LINKED TO 'EASI-SUMP' CAP-LINK 30 MINUTE FIRE RESISTING CONSTRUCTION 60 MINUTE FIRE RESISTING CONSTRUCTION ES MAINS POWERED OPTICAL SMOKE DETECTOR INTERCONNECTABLE TYPE TO I.S.3218 IF NOT INDICATED REFER TO M&E DRAWINGS SURFACE LININGS TGD PART VOL: PAR: 2.4 & TABLE A5 (a) CLASS D s3, d2 (EUROPEAN CLASS) or CLASS (NATIONAL CLASS) IN BATHROOMS, TOILETS AND SHOWER ROOMS (b) CLASS C s3, d2 (EUROPEAN CLASS) or CLASS (NATIONAL CLASS) IN OTHER ROOMS (c) CLASS C s3, d2 (EUROPEAN CLASS) or CLASS (NATIONAL CLASS) IN CIRCULATION SPACES WITHIN DWELLINGS <5m3/(h.m2) REFER TO M SPECIFICATION AND DRAWINGS AIR TO WATER HEAT PUMP MIN. STANDARD CYLINDER INSULATION CONTROLS THERMAL BRIDGING SPACE HEATING AIR PERMABILITY LOW ENERGY LIGHTING 100% PART L SPECIFICATION (TGD 2021) (B) nT,wdB nT,wdBIMPACT SOUND INSULATION 53 (min) ESCAPE WINDOW SELF-CLOSING FIRE DOOR WITH 30 MINUTE FIRE RESISTANCE (E30) 53 (min) Note: For Works to Protected Structure, Refer to TDG Paragraph 1.1.3 FLOORS (Including Stairs With Separating Function) AIRBORNE SOUND INSULATION WALLS SEPARATING CONSTRUCTION Sound Performance Levels (Par.1.1.1) TGD E: TABLE Note: Single Coursing to Party Walls Only BUILDING ELEMENTS Floor Details PART L SPECIFICATION (TGD L 2021) (A) TYPE GROUND FLOOR SOLID DESCRIPTION CONCRETE SLAB BUILDING ELEMENTS Roof Details TYPE DESCRIPTION U-VALUE [W/m2K] PITCHED ROOF ATTIC INSULATION PITCHED ROOF SLOPED CEILING 400MM MINERAL WOOL INSULATION OR SIMILAR OR EQUAL APPROVED U-VALUE [W/m2K] BUILDING ELEMENTS Wall Details TYPE DESCRIPTION U-VALUE [W/m2K] TIMBERFRAME Walls BUILDING ELEMENTS Door Details uPVC U-Value [W/m2K] DOUBLE-GLAZED, ARGON FILLED (LOW-E, EN=0.05, SOFT COAT) BUILDING ELEMENTS Window Details TIMBER FRAME U-VALUE [W/m2K] FRONT DOOR 150MM INSULATION BETWEEN RAFTERS 50MM PIR INSULATION BELOW. RAD NEW RADIATORS (location indicative/Radiators to be sized by plumber/ Location to be agreed with client) CALCULATED HEAT LOSS OR THESE DEFAULT YFACTORS: Y=0.08 WITH ACD'S APPENDIX Y=0.15 OTHERWISE (TGD 1.3.3.3) ADOPT ACDS, CERTIFIED DETAILS THAT ARE SUITABLY ASSESSED OR ACCEPTABLE ALTERNATIVES (TGD L 1.3.3.2) DPM/ RADON BARRIER VAPOUR CONTROL BARRIER ENT.800 SWAJ STORM WATER ACCESS JUNCTION FWAJ FOUL WATER ACCESS JUNCTION STORM WATER DRAIN FOUL WATER DRAIN bigt BACK INLET GULLY TRAP RWP GT WALL VENT REFER TO M&E DRAWINGS ALLOWANCE IN (W/m2K) REFER TO M SPECIFICATION AND DRAWINGS REFER TO M SPEC. DWGS. DEAP WALL VENT ELEVATION- RENDER WALL VENT ELEVATION- BRICK MIN. CLEAR WIDTH TO FRONT DOOR Ceiling Vent CEILING VENT REFER TO M&E DRAWNGS CEILING VENT REFER TO M&E DRAWNGS 0.170 0.110 0.160 0.140 1.400 1.400 75MM DIA RAIN WATER PIPE WITH GULLY TRAP (Min. 500mm) 818 818 W01 D02 W04 W06a 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing CL CL 500 (Min. 500mm) 818 818 W01 D02 W04 W06a 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing CL CL BT03 H3AA H2AB H2AA H2AB - H3CB FRONT ELEVATION SCALE 1:50 ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 500 (Min. 500mm) 3724 W01 W04 D01 W06a GFL.+0.000 DR HEAD.+2.250 WIN HEAD.+4.875 UNDERSIDE OF CILL .+0.375 FFL.+2.787 ROOF +9.355 ROOF +7.098 UNDERSIDE OF CILL.+3.600 B C D A (Min. 500mm) 818 818 W01 D02 W04 W06a 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 47.5° W06 W06a W03 W03 ETU uPVC Double Glazed Windows by Selected Supplier Concrete Sills 40mm High Front Facing Edge Grey uPVC Fascia Soffit Rainwater Goods Grey Bullnose Flat Concrete Roof Tiles by Condron Concrete selected roofing underlay laid in accordance with SR 82:2017 Slating Tiling Code of Practice. Sever exposure zone to be assumed unless otherwise specified. Compatible dry verge to be installed to manufacturer's details. All ventilation tiles to be compatible with selected roof tiles. Each Tile to be Nailed and Cliped Dry-Fix Ridge System by Condron Concrete laid accordance with manufacturer's details. Where the ceiling follows the pitch line or room is located within attic, ventilation must be provided at least equal strip 5mm wide. Selected proprietary eaves soffit ventilator to provide at least equal to 10mm continuous strip (allow 25mm where ceiling follows pitch line/room located attic). Install proprietary rafter ventilator to ensure 50mm gap at insulation. Selected Brick (Min.500mm) W06 HEAT PUMP ACCESS PIPES 818 818 W04 D04 W06a (Min.500mm) W06 HEAT PUMP ACCESS PIPES 818 818 W04 D04 W06a 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing CL CL CL BT03 H3CB H2AB - H2AA H2AB H3CA REAR ELEVATION SCALE 1:50 500 (Min.500mm) W06 HEAT PUMP ACCESS PIPES 818 818 W04 D04 W06a HEAT PUMP PIPES ACCESS 47.5° 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing ESB D04 W03 GFL.+0.000 UNDERSIDE OF CILL. +0.525 FFL.+2.787 WIN HEAD.+4.875 ROOF+7.592 ROOF.+8.820 UNDERSIDE OF CILL.+3.600 WIN HEAD.+2.250 ROOF.+9.355 CL ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 HEAT PUMP ACCESS PIPES 500 (Min.500mm) 2732 D03 W05 W05 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing B C D A Grey uPVC Fascia Soffit & Rainwater Goods Grey Bullnose Flat Concrete Roof Tiles by Condron Concrete selected roofing underlay laid in accordance with SR 82:2017 Slating & Tiling Code of Practice. Sever exposure zone to be assumed unless otherwise specified. Compatible dry verge to be installed to manufacturer's details. All ventilation tiles to be compatible with selected roof tiles. Each Tile to be Nailed and Cliped Dry-Fix Ridge System by Condron Concrete laid in accordance with manufacturer's details. Where the ceiling follows the pitch line or room located within attic, ventilation must be provided at least equal to strip of 5mm wide. Selected proprietary eaves soffit ventilator to provide at least equal to 10mm continuous strip (allow 25mm where ceiling follows pitch line/room located in attic). Install proprietary rafter ventilator to ensure 50mm gap at insulation. Monorex One Coat Through Coloured Weather Resistant Render. Colour Code G00 UNDERSIDE OF CILL. +0.975 DOCUMENT NO: STAGE: NOTES: 21026-AKM-BT03-XX-DR-A01-200030 S4-SUITABLE FOR CONSTRUCTION BT03 H3AA SIDE ELEVATION SCALE 1:50 ESB EV 450.0 Grey uPVC Fascia Soffit Rainwater Goods Grey Bullnose Flat Concrete Roof Tiles by Condron Concrete selected roofing underlay laid in accordance with SR 82:2017 Slating Tiling Code of Practice. Sever exposure zone to be assumed unless otherwise specified. Compatible dry verge to be installed to manufacturer's details. All ventilation tiles to be compatible with selected roof tiles. Each Tile to be Nailed and Cliped Dry-Fix Ridge System by Condron Concrete laid accordance with manufacturer's details. Where the ceiling follows the pitch line or room is located within attic, ventilation must be provided at least equal strip 5mm wide. 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing 18mm Movement Joint Filled with Flexible Closed Cell Polyethylene with Mastic Pointing W06a GFL.+0.000 FFL.+2.787 ROOF +9.355 WIN HEAD.+4.875 UNDERSIDE OF CILL.+3.600 ROOF +7.098 GFL.+0.000 500 (Min. 500mm) 500 (Min. 500mm) uPVC Double Glazed Windows by Selected Supplier Concrete Sills 40mm High Front Facing Edge Composite Front Door with Double Glazed Vision Panel by Selected Supplier Grey uPVC Fascia Soffit Rainwater Goods Grey Bullnose Flat Concrete Roof Tiles by Condron Concrete & selected roofing underlay laid in accordance with SR 82:2017 Slating Tiling Code of Practice. Sever exposure zone to be assumed unless otherwise specified. Compatible dry verge to be installed manufacturer's details. All ventilation tiles to be compatible with selected roof tiles. Each Tile to be Nailed and Cliped Dry-Fix Ridge System by Condron Concrete laid accordance with manufacturer's details. Where the ceiling follows the pitch line or room is located within attic, ventilation must be provided at least equal to strip 5mm wide. Selected proprietary eaves soffit ventilator provide at least equal to 10mm continuous strip (allow 25mm where ceiling follows pitch line/room located attic). Install proprietary rafter ventilator to ensure 50mm gap insulation. Zinc Canopy Finish Monorex One Coat Through Coloured Weather Resistant Render. Colour Code G00 47.5° FFL.+2.787 WIN HEAD.+4.875 UNDERSIDE OF CILL.+3.600 ROOF +7.592 ROOF +8.820 DR HEAD. +2.250 UNDERSIDE OF CILL.+0.525 Selected Brick ROOF +9.355 W04 W04 W05 W01 W03 W01 D02 BT03 H3CB SIDE ELEVATION SCALE 1:50 ***PV Panels:*** Location of PV Panels as Shown is Indicative Only! For Quantity and Orientation of PV Panels Refer to PV Panel Schedule 21026-CCE-XXXX-XX-SH-E01-000001 Window or Door Type Floor Manuf. D-01 D-03 W-01 Ground W-04 W-05 Notes: steel lintels have 250mm bearing or as specified by lintel construction. precast concrete lintels have minimum bearing of 150mm 2.0m. precast concrete lintels greater than 1.2m span propped precast concrete lintels are to be placed with rough side facing No stepped DPC cavity tray be placed between the precast Where plaster banding is shown around windows on brick facades Ground LINTEL SCHEDULE W-06a First TYPE H3AA Concrete killeshal Ground First First Concrete killeshal Concrete killeshal Concrete killeshal Steel keystone Steel keystone Window or Door Type Floor Manuf. D-02 D-04 W-01 Ground W-04-Front W-04-Back Notes: steel lintels have 250mm bearing or as specified by lintel construction. precast concrete lintels have minimum bearing of 150mm 2.0m. precast concrete lintels greater than 1.2m span propped precast concrete lintels are to be placed with rough side facing No stepped DPC cavity tray be placed between the precast Where plaster banding is shown around windows on brick facades Ground LINTEL SCHEDULE W06a-Front First TYPE H2AB killeshal Ground First First Concrete killeshal Steel keystone Concrete Steel keystone W-06 killeshal Concrete Ground W06a-Back First Concrete killeshal Steel keystone Steel keystone Window or Door Type Floor Manuf. D-02 D-04 W-01 Ground W-04-Front W-04-Back Notes: steel lintels have 250mm bearing or as specified by lintel construction. precast concrete lintels have minimum bearing of 150mm 2.0m. precast concrete lintels greater than 1.2m span propped precast concrete lintels are to be placed with rough side facing No stepped DPC cavity tray be placed between the precast Where plaster banding is shown around windows on brick facades Ground LINTEL SCHEDULE W06a-Front First TYPE H2AA killeshal Ground First First Concrete killeshal Steel keystone Concrete Steel keystone W-06 killeshal Concrete Ground W06a-Back First Concrete killeshal Steel keystone Steel keystone Window or Door Type Floor Manuf. D-02 D-04 W-01 Ground W-04-Front W-04-Back Notes: steel lintels have 250mm bearing or as specified by lintel construction. precast concrete lintels have minimum bearing of 150mm 2.0m. precast concrete lintels greater than 1.2m span propped precast concrete lintels are to be placed with rough side facing No stepped DPC cavity tray be placed between the precast Where plaster banding is shown around windows on brick facades Ground LINTEL SCHEDULE W06a-Front First TYPE H2AB killeshal Ground First First Concrete killeshal Steel keystone Concrete Steel keystone W-06 killeshal Concrete Ground W06a-Back First Concrete killeshal Steel keystone Steel keystone Window or Door Type Floor Manuf. D-02 D-04 W-01 Ground W-04 W-05 Notes: steel lintels have 250mm bearing or as specified by lintel construction. precast concrete lintels have minimum bearing of 150mm 2.0m. precast concrete lintels greater than 1.2m span propped precast concrete lintels are to be placed with rough side facing No stepped DPC cavity tray be placed between the precast Where plaster banding is shown around windows on brick facades W-03-Right W-03-Left & Front Steel Ground keystone LINTEL SCHEDULE Steel keystone W-06 Steel keystone W-06a First Steel keystone Ground Ground TYPE H3CB Concrete killeshal Ground Concrete killeshal Concrete killeshal Steel keystone First First First Concrete killeshal DOCUMENT NO: CLIENT: DRAWING TITLE: PROJECT TITLE: AKM NO. DESCRIPTION DATE REVISIONS Architecture Planning Engineering Architecture Planning Engineering Building Surveying Development Consultants AKM Design Unit 6, Kingswood Business Centre, 4075 Kingswood Business Centre, Citywest Business Campus D24 A068 T: 353 1 4796234 E: info@akmdesign.ie INITIALS Block BT03 (H3AA-H2AB-H2AA-H3CB) Elevations Sides GLENVEAGH HOMES 21026-AKM-BT03-XX-DR-A01-200031 21026 - BROWNSBARN 1.01 00 ISSUED FOR REVIEW AND COMMENT 19/05/23 CT ALL DRAWINGS TO BE READ IN CONJUNCTION WITH STRUCTURAL ENGINEERS & MECHANICAL ENGINEERS AND ALL OTHER DETAILS. NOTE: REFER TO STRUCTURAL ENGINEERS DRAWINGS FOR ALL EXTERNAL DRAINAGE LAYOUTS.REFER TO M&E DRAWINGS FOR ALL INTERNAL DRAINAGE LAYOUTS. ALL DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED DIMENSIONS ONLY. ALL DISCREPANCIES TO BE REPORTED TO AKM CONSULTANTS IMMEDIATELY. NOTES: REFER TO TIMBER FRAME DETAILS BOOKLET DETAILS. ALL DISCREPANCIES TO BE REPORTED TO THIS OFFICE. CONTACT THIS OFFICE PRIOR TO COMMENCEMENT FOR CLARITY IF YOU ARE UNCLEAR ON A DETAIL. 01 ISSUED FOR CONSTRUCTION 28/06/23 CT BTO5 07
MATERIALS KEY - REAR GARDEN
HARD LANDSCAPING - Gravel Strip
Lose Gravel type approved by GVH.
Gravel stones - 10mm Donegal Quartz from McMonagle Stone or similar approved
To be laid to manufacturers Details & Specifications.
SOFT LANDSCAPING - Planting
Planting species to landscape architect
HARD LANDSCAPING - Paving/ Driveway
Kilsaran or similar approved by GVH
HARD LANDSCAPING - FOOTPATH
Kilsaran or similar approved by GVH.
In-situ Concrete Footpath with Isolation joints are installed to allow expansion and to avoid cracking. The paths are to have a brush finish to increase slip resistance. B7
PLANTING KEY
REAR GARDEN-
Topsoiled and Seeded for Grass
PUBLIC REALM PLANTING LIST -
Refer to Landscape Architects Specification & Details B12
PUBLIC FOOTPATH HEAT PUMP REFER TO BOUNDARY TREATMENT PLAN FOR BOUNDARY TYPE REFER TO BOUNDARY TREATMENT PLAN FOR BOUNDARY TYPE HEAT PUMP REFER TO BOUNDARY TREATMENT PLAN FOR BOUNDARY TYPE REFER TO BOUNDARY TREATMENT PLAN FOR BOUNDARY TYPE HEAT PUMP HEAT PUMP PUBLIC FOOTPATH HEDGE HEDGE B3 B1 B1 B1 B4 B11 B11 B11 B11 B4 B7 B7 B7 B7 B5 B5 B5 B4 B3 B3 B2 B12 B4 B2 B2 B5 B5 B10 B2 B2 B3 B4 B4 B3 B10 B3 B4 NO LAMPOST TO BE LOCATED HERE INSPECTION CHAMBERS INSPECTION CHAMBERS TYPICAL PRIVATE LANDSCAPING LAYOUT - BT08 TERRACE *Refer to Boundary Treatment Plan for Boundary Type ALL DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED Chamfer EDGE KERB Kilsaran or similar approved by GVH. MATERIALS KEY - FRONT GARDEN HARD LANDSCAPING - Paving/ Driveway Kilsaran or similar approved by GVH. Permeable paving blocks with min. 6mm joints filled with graded 6.3-2.0mm grit to BS EN 13242:2002 to suppliers specification or similar approved 60mm Lismore Curragh Gold or similar approved HARD LANDSCAPING - Paving Border Kilsaran or similar approved by GVH. Permeable paving blocks with min. 6mm joints filled with graded 6.3-2.0mm grit to BS EN 13242:2002
B2 B1 B3
B5
to suppliers specification or similar approved Charcoal Trim Border 200mm width or similar approved
B4
B11
B10
PRIVATE LANDSCAPE 08
Bin Storage
Gossip Wall
09 1012.5 MIN 1.0m MAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 PLAN SCALE: 1:20 440 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING DPC INSTALLED AS PER ESB DETAIL SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAIL 1950 UTILITIES BOXES AS PER PROVIDERS DETAILS EV ESB 1950 GALVANISED LINTEL OVER ESB METER CABINET WITH DPC ESB METER BOX TO BE INSTALLED AS PER DPC INSTALLED AS PER ESB DETAIL 1012.5 327.5 ESB METER BOX TO SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB 1012.5 440 DWELLING SECTION AA SCALE: 1:20 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION 440 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING GOSSIP WALL TYPE 02 GOSSIP WALL TYPE 01 MIN 1.0m MAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 440 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING 2565 EV ESB 2565 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION 440 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING
WALL
03 DWELLING (FOR H3BA/H3BB) DWELLING 327.5 1200 102.5 GL.+0.00 SELECTED BRICK FINISH TO MATCH CHARACTER AREA FOLDING TIMBER DOORS BIN STORE DETAIL 2 BIN STORAGE GROUND FLOOR PLAN SCALE: 1:20 BIN STORAGE ROOF PLAN SCALE: 1:20 BIN STORAGE FRONT ELEVATION SCALE: 1:20 FOLDS FIXED ZINC CANOPY FINISH SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA TOP OF WALL +1.200 FOLDS 4490 215 1002.5 FOLDS BIN STORE 1.65m² FIXED FOLDS NO. 240L BIN NO. 120 BIN 240L BIN 240L BIN 120L BIN 1922.5 215 1922.5 BIN STORE 1.65m² FIXED 240L BIN 240L BIN 120L BIN NO. 240L BIN 1 NO. 120 BIN 4490 1002.5 1200 102.5 GL.+0.00 SELECTED BRICK FINISH TO MATCH CHARACTER AREA FOLDING TIMBER DOORS BIN STORAGE REAR ELEVATION SCALE: 1:20 FOLDS FIXED ZINC CANOPY FINISH SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA TOP OF WALL +1.200 FOLDS 102.5 BIN STORAGE SIDE ELEVATION SCALE: 1:20 GL.+0.00 TOP OF WALL +1.200 SELECTED BRICK FINISH TO MATCH CHARACTER AREA 1200 102.5 SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA BIN STORAGE SIDE ELEVATION SCALE: 1:20 GL.+0.00 TOP OF WALL +1.200 SELECTED BRICK FINISH TO MATCH CHARACTER AREA 1200 102.5 SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA 1200 102.5 BIN STORAGE SECTION A-A SCALE: 1:20 TOP OF WALL +1.200 FOUNDATIONS AND ASSOCIATED WORKS AS PER ENGINEERS SPECIFICATIONS SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA FOLDING TIMBER DOORS 215 2352.5 1922.5 215 102.5 ALL DRAWINGS TO BE READ IN CONJUNCTION WITH STRUCTURAL ENGINEERS MECHANICAL ENGINEERS AND ALL OTHER DETAILS. NOTE: REFER TO STRUCTURAL ENGINEERS DRAWINGS FOR ALL EXTERNAL DRAINAGE LAYOUTS.REFER TO M&E DRAWINGS FOR ALL INTERNAL DRAINAGE LAYOUTS. DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED DIMENSIONS ONLY. ALL DISCREPANCIES TO BE REPORTED AKM CONSULTANTS IMMEDIATELY. NOTES: REFER TO TIMBER FRAME DETAILS BOOKLET DETAILS. ALL DISCREPANCIES TO BE REPORTED TO THIS OFFICE. CONTACT THIS OFFICE PRIOR TO COMMENCEMENT FOR CLARITY IF YOU ARE UNCLEAR ON DETAIL. 00 00 ISSUED FOR CONSTRUCTION 07/07/23 CT 1. All boundaries, dimensions and levels are be checked on site before construction and any discrepancies are to be reported to the Architect. Partial Service: Any discrepancies with site or other information is to be advised to the Architect and direction or approval is to be sought before the implementation of the detail. Block and site plans are reproduced under license from the Ordnance Survey. Do not scale this drawing. 5. For the purpose of coordination, all relevant parties must check this information prior to implementation and report any discrepancies to the Architect. DOCUMENT NO: AKM JOB NO.: SCALE: DATE: DRAWN BY: REVISION: CLIENT: DRAWING TITLE: PROJECT TITLE: SEQUENCE NUMBER: ROLES CODE: DOCUMENT CODE: LEVEL: STAGE: DEPARTMENT CODE: ORGANISATION CODE: PROJECT CODE: AKM NO. DESCRIPTION DATE REVISIONS Architecture Planning - Engineering Architecture Planning Engineering Building Surveying Development Consultants AKM Design Unit 6, Kingswood Business Centre, 4075 Kingswood Business Centre, Citywest Business Campus D24 A068 T: 353 1 4796234 E: info@akmdesign.ie INITIALS 1:20@A1 JUL'23 NA AKM Bin Store Detail 2 Houses GLENVEAGH HOMES A01 DR XX 21026-AKM-XXXX-XX-DR-A01-000111 21026 - BROWNSBARN 1.01 22008 000111 21026 S4-SUITABLE FOR CONSTRUCTION C.T. DETAILS 1012.5 MIN 1.0mMAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 PLAN SCALE: 1:20 440 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING DPC INSTALLED AS PER ESB DETAIL SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAIL 1950 UTILITIES BOXES AS PER PROVIDERS DETAILS EV ESB 1950 GALVANISED LINTEL OVER ESB METER CABINET WITH DPC SELECTED BLOCK WITH RENDER FINISH TO MATCH THE HOUSE ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS 1012.5 MIN 1.0m MAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 327.5 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING 1950 EV ESB 1950 1012.5 440 DWELLING DPC INSTALLED AS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING 1012.5 SECTION AA SCALE: 1:20 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION 440 REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING
GOSSIP
TYPE
GOSSIP WALL TYPE 02
MIN 1.0m MAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 PLAN SCALE: 1:20 440 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING 2565 EV ESB 2565 440 SECTION AA SCALE: 1:20 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION 440 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING GOSSIP WALL TYPE 03 1340 DPC INSTALLED AS PER ESB DETAIL SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS DWELLING DWELLING (FOR H3BA/H3BB) DWELLING 327.5 1012.5 MIN 1.0mMAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 PLAN SCALE: 1:20 440 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING DPC INSTALLED AS PER ESB DETAIL SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAIL 1950 UTILITIES BOXES AS PER PROVIDERS DETAILS EV ESB 1950 SECTION AA SCALE: 1:20 GALVANISED LINTEL OVER ESB METER CABINET WITH DPC SELECTED BLOCK WITH RENDER FINISH TO MATCH THE HOUSE ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS 1012.5 MIN 1.0mMAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 327.5 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING 1950 EV ESB 1950 1012.5 440 DWELLING PLAN SCALE: 1:20 DPC INSTALLED AS PER ESB DETAIL SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS 1012.5 337.5 SECTION AA SCALE: 1:20 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION 440 REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING DWELLING
GOSSIP WALL TYPE 01
GOSSIP WALL TYPE 02
MIN 1.0mMAX 1.2m METER CABNET ELEVATION SCALE: 1:20 END ELEVATION SCALE: 1:20 PLAN SCALE: 1:20 440 ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS UTILITIES BOXES AS PER PROVIDERS DETAILS SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING 2565 EV ESB 2565 440 SECTION AA SCALE: 1:20 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAILS "HOCKEY STICK" TO BE INSTALLED AS PER ESB DETAILS DPC INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS REFER TO STRUCTURAL ENG. DETAIL FOR GOSSIP WALL FOUNDATION 440 SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING GOSSIP WALL TYPE 03 1340 DPC INSTALLED AS PER ESB DETAIL SELECTED BLOCK WITH RENDER FINISH TO MATCH THE DWELLING ESB METER BOX TO BE INSTALLED AS PER ESB DETAIL UTILITIES BOXES AS PER PROVIDERS DETAILS DWELLING DWELLING (FOR H3BA/H3BB) DWELLING 327.5 ALL DRAWINGS TO BE READ IN CONJUNCTION WITH STRUCTURAL ENGINEERS & MECHANICAL ENGINEERS AND ALL OTHER DETAILS. NOTE: REFER TO STRUCTURAL ENGINEERS DRAWINGS FOR ALL ALL DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED DIMENSIONS ONLY. ALL DISCREPANCIES TO BE REPORTED TO AKM CONSULTANTS IMMEDIATELY. NOTES: REFER TO TIMBER FRAME DETAILS BOOKLET DETAILS. ALL DISCREPANCIES TO BE REPORTED TO THIS OFFICE. CONTACT THIS OFFICE PRIOR TO 00 ISSUED FOR CONSTRUCTION 07/07/23 CT 1. All boundaries, dimensions and levels are to be checked on site before construction and any discrepancies are to be reported to the Architect. 2. Partial Service: Any discrepancies with site or other information is to be advised to the Architect and direction or approval is to be sought before the implementation of the detail. 3. Block and site plans are reproduced under license from the Ordnance Survey. 4. Do not scale this drawing. 5. For the purpose of coordination, all relevant parties must check this information prior to implementation and report any discrepancies to the Architect. DOCUMENT NO: SCALE: DRAWN BY: REVISION: DRAWING TITLE: PROJECT TITLE: SEQUENCE NUMBER: DOCUMENT CODE: LEVEL: STAGE: ORGANISATION CODE: PROJECT CODE: NO. DESCRIPTION DATE REVISIONS Architecture - Planning - Engineering AKM Design INITIALS XX 21026-AKM-XXXX-XX-DR-A01-000100 21026 - BROWNSBARN 1.01 000100 21026 S4-SUITABLE FOR CONSTRUCTION C.T. 01 ADDITIONAL GOSSIP WALL TYPE 17/07/23 CT GL.+0.00 SELECTED BRICK FINISH TO MATCH CHARACTER AREA FOLDING TIMBER DOORS BIN STORAGE GROUND FLOOR PLAN SCALE: 1:20 BIN STORAGE ROOF PLAN SCALE: 1:20 BIN STORAGE FRONT ELEVATION SCALE: 1:20 FOLDS FIXED ZINC CANOPY FINISH SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA TOP OF WALL +1.200 FOLDS 1002.5 FOLDS BIN STORE 1.65m² FIXED 240L BIN 240L BIN 120L BIN BIN STORE 1.65m² 240L BIN 240L BIN 120L BIN 1002.5 1200 102.5 GL.+0.00 SELECTED BRICK FINISH TO MATCH CHARACTER AREA FOLDING TIMBER DOORS BIN STORAGE REAR ELEVATION SCALE: 1:20 FOLDS FIXED ZINC CANOPY FINISH SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA TOP OF WALL +1.200 FOLDS 102.5 BIN STORAGE SIDE ELEVATION SCALE: 1:20 GL.+0.00 TOP OF WALL +1.200 SELECTED BRICK FINISH TO MATCH CHARACTER AREA 1200 102.5 SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA BIN STORAGE SIDE ELEVATION SCALE: 1:20 GL.+0.00 TOP OF WALL +1.200 SELECTED BRICK FINISH TO MATCH CHARACTER AREA 1200 102.5 SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA BIN STORAGE - SECTION A-A SCALE: 1:20 TOP OF WALL +1.200 FOUNDATIONS AND ASSOCIATED WORKS AS PER ENGINEERS SPECIFICATIONS SELECTED BRICK COURSE FINISH TO MATCH CHARACTER AREA FOLDING TIMBER DOORS 215 2352.5 1922.5 102.5 ALL DRAWINGS TO BE READ IN CONJUNCTION WITH STRUCTURAL ENGINEERS & MECHANICAL ENGINEERS AND ALL OTHER DETAILS. NOTE: REFER TO STRUCTURAL ENGINEERS DRAWINGS FOR ALL EXTERNAL DRAINAGE LAYOUTS.REFER TO M&E DRAWINGS FOR ALL INTERNAL DRAINAGE LAYOUTS. ALL DIMENSIONS TO BE CHECKED ON SITE BY MAIN CONTRACTOR PRIOR TO CONSTRUCTION. MAIN CONTRACTOR RESPONSIBLE FOR SET-OUT. COPYRIGHT RESERVED. DO NOT SCALE DRAWING. USE FIGURED DIMENSIONS ONLY. ALL DISCREPANCIES TO BE REPORTED TO AKM CONSULTANTS IMMEDIATELY. NOTES: REFER TO TIMBER FRAME DETAILS BOOKLET DETAILS. ALL DISCREPANCIES TO BE REPORTED TO THIS OFFICE. CONTACT THIS OFFICE PRIOR TO COMMENCEMENT FOR CLARITY IF YOU ARE UNCLEAR ON A DETAIL. 00 ISSUED FOR CONSTRUCTION 07/07/23 CT 1. All boundaries, dimensions and levels are to be checked on site discrepancies are to be reported to the Architect. 2. Partial Service: Any discrepancies with site or other information direction or approval is to be sought before the implementation of 3. Block and site plans are reproduced under license from the Ordnance 4. Do not scale this drawing. 5. For the purpose of coordination, all relevant parties must check implementation and report any discrepancies to the Architect. DOCUMENT NO: SCALE: DATE: DRAWN BY: CLIENT: DRAWING TITLE: PROJECT TITLE: ROLES CODE: DOCUMENT LEVEL: STAGE: DEPARTMENT CODE: ORGANISATION CODE: PROJECT CODE: AKM NO. DESCRIPTION DATE REVISIONS Architecture Planning Engineering Architecture Planning Engineering Building Surveying Development Consultants AKM Design Unit 6, Kingswood Business Centre, 4075 Kingswood Business Centre, Citywest Business Campus D24 A068 T: 353 4796234 E: info@akmdesign.ie INITIALS 1:20@A1 JUL'23 NA AKM Bin Store Detail Houses GLENVEAGH HOMES A01 DR XX 21026-AKM-XXXX-XX-DR-A01-000111 21026 - BROWNSBARN 1.01 21026 S4-SUITABLE FOR CONSTRUCTION C.T.
GOSSIP WALL TYPE 01
