BrakelAtmosphere2015 english

01

edition

2015/2016

BrakelAtmosphere

Foreword

Fortunately, our sector is on the verge of recovery after a difficult period. This type of period involves negative issues, but especially also wonderful innovations. Because one thing is certain, a crisis brings efficiency back to a sector.

Brakel has translated this into acceleration not only of product development, but also in the field of modelling and calculations. This not only produces benefits in terms of comfort and safety in the field of daylight and natural (fire) ventilation, it also highlight savings possibilities for you.

In this first international edition of the BrakelAtmosphere you will find various example projects that we have completed in cooperation with our worldwide partner network.

We hope that this will inspire and challenge you to participate with us in the dialogue on daylight penetration, natural ventilation and fire ventilation in your building.

Enjoy reading this newsletter and please do not hesitate to contact us or our partners, completely free of obligation.

Ton van Gerwen Managing director Brakel

1

BrakelAtmosphere

7

9

11

13

15

16

17

19

21

23

24

25

Content

Brakel Brakel international

3

Advice & Design

5

Product developments 2015

39

27

29

31

32

33

35

37

39

Projects Queens Square, United Kingdom

7

Moresport, South Africa

9

Bavaria, the Netherlands

11

Voestalpine, Austria

13

Royal College of General Practitioners, United Kingdom

15

Melesi, Italy

16

DHL, the Netherlands

17

Olivomundo, Portugal

19

Marchetti Viaduct, Italy

21

Eurospuma, Portugal

23

Jaguar Land Rover, United Kingdom

24

Dutch Flower Group, the Netherlands

25

Bloemfontein, South Africa

27

VS Mรถbel, Germany

29

Decor workshop, the Netherlands

31

Dairymaster, Ireland

32

Cups4you, the Netherlands

33

Recheio, Portugal

35

Centurion, South Africa

37

BrakelAtmosphere

2

Brakel: international brand with the power of nature as its source of inspiration 37 years of experience in both industry and utility Brakel is a leading European company/brand in the field of glass

constructions, ventilation and fire safety systems. Brakel has

Products

a turnover of more than 50 million Euros and 300 employees.

When it comes to light, air and safety, Brakel brings the

Brakel uses a certified partner network to create a pleasant, safe

best of nature indoors. We have set up the Green

indoor climate in all sectors.

Building Program in order to guarantee the quality of

the nature – our most important source. Here, we

Optimum use of daylight and air

assign priority to the development of energy-efficient,

Brakel regards making an important contribution to sustainable

sustainable concepts, systems and products. Our

construction as its task. We strongly believe in the use of the natural

sustainable products are classified as Green Building

elements of daylight and air to create functional and sustainable

Products.

solutions for a comfortable and safe indoor climate.

Team work with our local partners Our local partners create fire safe and pleasant buildings in collaboration with architects, principals and contractors. Environments in which people live, learn, work and relax with pleasure. At Brakel we think that this is the most natural thing in the world.

3

Green Building Program/Green Building

BrakelAtmosphere

Lidl Aco Székesfehérvár, Hungary

Voest Alpine Linz, Austria

Palacio de Comunicaciones Madrid, Spain

Swarovski Triessen, Austria

Fontestad Valencia, Spain

Smiths Medical Wijchen, the Netherlands

BrakelAtmosphere

4

Advice & Design

Advice & Design: translu in cold stores?

Do energy savings outweigh extra initial and cooling costs?

Together with local partners, Brakel offers you application advice

Large cold stores operate continuously, 24 hours x 365 days per

based on 37 years of experience. Advice substantiated by many

year. Their construction usually consists of a large insulated box

case studies and benchmarks in individual industries.

supported by a steel superstructure, the roof being clad with ribbed steel roof sheeting. Usually the interior is lit with artificial

Simulation models

lighting. Brakel Certified Partner Quality Power researched the

By means of Brakel® simulation models, insight is given into the effect

possibility of using translucent glass blades in the thermally

that applications in the area of daylight access and ventilation have on

separated Brakel® Optima ventilator enabling daylight to enter

the indoor climate, maintenance costs, productivity, energy consump-

the building. Do energy savings on artificial lighting outweigh the

tion and comfort of your building.

addition initial and cooling costs?

The input of these simulations enables Brakel partners to provide a substantiated design for daylight and natural ventilation.

Fire Safety Engineering As smoke ventilation is strictly bound to the EN 12101-2 regulations, supplemented with local legislation, the design of natural smoke ventilation is highly regulated. However, as there is a lot of variation in fire load and use of buildings, Brakel will provide you on request with insights in the expected smoke and temperature behaviour in case of fire by means of CFD modelling (Computational Fluid Dynamics).

In this way you will be able to make well-founded decisions based on clear data.

Calculations show positive results In-depth Calculations proved that using translucent glass blades and bringing daylight inside the cold store would be profitable despite extra costs with regard to material and the removal of extra heat. The company wanted to substantiate these calculations with practice tests.

Empirical research After considering various methods of measurement, Quality Power decided that the best empirical results would be achieved by exposing a significant mass of water and recording the rate of rise of temperature.

Two identical glass boxes were made, exactly fitting into the internal frame of the aluminum and glass versions of the Optima louvered vent with low ‘e’ Stopsol solar reduction glass. The boxes were insulated with 60 mm of polystyrene to limit heat loss during the experiment to extremely low levels.

Service and Maintenance After commissioning a project the reliability of systems depends entirely on professional maintenance. Brakel partners offer you tailormade maintenance programs to extend the lifecycle of the applied products.

5

BrakelAtmosphere

ucent blades possible

“From the test results and calculations regarding energy costs can be concluded that the use of glass blades in the Optima louvered vents is profitable.�

The heat source chosen was 400 Watt metal halide

The graph above shows four results. The two top lines are the surface

luminaires because they generate an electromagnetic spectrum

temperatures directly below the luminaire on top of the ventilator sam-

most similar to sunlight. This allowed the experiment to be conducted

ple. As expected the higher temperatures are obtained on the glass

indoors with a steady and controlled source of energy and avoided the

as it absorbs heat well, whilst the lower line is on the aluminium blade

constantly changing level of sunlight, due to time of day, cloud cover

which reflects the radiation.

and other environmental factors, all factors which could introduce

The interesting results are the two lower lines about the water tempe-

errors into the results.

rature. The tanks each contain 42 litres of water. The mass of water is

The identical glass tanks were painted matt black, to maximize the ab-

relatively large compared to the heat source in order to provide a well

sorption of the radiation. Also two identical new metal halide luminaires

damped and steady increase in temperature. After 15 hours the water

from the same manufacturing batch were produced for the experiment.

temperature was unaffected.

Lux level

Case proven

Lux meter indicated exactly the same level of illumination: 53,600 lux.

From the test results and calculations regarding energy costs can be

Three matters were recorded:

concluded that the use of glass blades in the Optima louvered vents is

1. The surface temperature of the louvre blades

profitable. The larger initial costs (glass instead of aluminum blades),

2. The ambient temperature on the exterior of the insulated tank

the low extra costs because of the increase in heat do not outweigh

3. The water temperature

the benefits in cost reductions on artificial lighting.

Interested in the complete research report?

If you are interested in the complete research report with figures and detailed test results, please contact us.

BrakelAtmosphere

6

44 Brakel® Inova ventilation windows

Queens Square: attractive shopping centre again after refurbishment Comfortable, fire safe environment due to natural ventilation and day lighting Built in 1971 Queens Square turned from an attractive mall into a

Reduced energy costs

shopping centre with a declining number of visitors and moving

By using the smoke ventilation system for environmental/comfort

key brands. This due to overdue maintenance and investment

cooling the need for a mechanical ventilation system was reduced.

freeze. In 2010 a new Property and Asset Management was ap-

Furthermore the electrical control also offers additional energy and

pointed. The result: an appealing shopping centre with an annual

maintenance cost reductions.

footfall of 4,600,000. Important reason: Queens Square turned into a comfortable shopping place with a pleasant inner climate

More skylights for daylight

and a lot of daylight. Brakel Airvent was responsible for the nat-

A significant improvement to natural day lighting was provided by in-

ural (fire) ventilation system and skylights.

stalling transparent skylights. Brakel Airvent installed 36 glass Brakel® Duralite skylights throughout the shopping centre.

Smoke control It goes without saying that a reliable fire safety system is essential in

Maintenance

a shopping centre with so many visitors. The old smoke ventilation

After the installation of the ventilation system and skylights, Brakel

installation was old, difficult to maintain and pneumatically operated.

Airvent has been retained for the ongoing annual service support of

Brakel Airvent replaced it by an electrical more easy to maintain

the new installation. To ensure many years of trouble free perfor-

aesthetical system consisting of 91 Ventria en 44 Inova ventilation

mance and to assist central management with their compliance

windows.

obligations under Government Fire Safety Legislation. “Brakel Airvent met all requirements concerning natural ventilation, fire strategy and

Kill two birds with one stone: natural ventilation

maintenance” says Melvin Glasby, Property and Asset Management

This smoke and heat extraction system is a dual system as it is also

Queens Square.

used for daily, natural ventilation. This by using natural updraft to extract warm air through the ventilation windows. In order to influence

Satisfied shopkeepers and happy visitors

air movement and comfort, the natural ventilation is thermostatically

Melvin Glasby continues: “Queens Square in West Bromwich has

controlled and fitted with incorporated temperature, wind and rain

an annual footfall of 4,600,000, 38% of our shoppers visit us more

sensors.

than once a week, current retail turnover is estimated to exceed £ 25 Million and the income to the local economy is in excess of £ 1.2 Million. Furthermore there are plans to commence on a new leisure and restaurant quarter which will see Queens Square be able to offer restaurant and entertainment opportunities.” So: Queens Square is back in business!

7

BrakelAtmosphere

91 Brakel® Ventria ventilation windows

M. Glasby, Queens Square

“Brakel Airvent met all requirements concerning natural ventilation, fire strategy and maintenance”

36 Brakel® Duralite rooflights

BrakelAtmosphere

8

42 Brakel速 Eura smoke vents

9

BrakelAtmosphere

New distribution centre Moresport Cape Town fire safe With EN 12101 smoke ventilation Moresport is a successful chain of specialist Sportwear and

“Besides the fact that the

Camping equipment retailers. In order to assure that stores in

smoke ventilation system

the Western Cape region are well stocked at all times, a new

satisfies the local government

10.000 m² distribution centre was built. South African building

requirement it also offers

regulations stipulate smoke ventilation which has to be in

a functional, cost effective

compliance with EN 12101. Engineering company Aurecon and

solution.”

Certified Brakel Partner Quality Power provided a solution that meets requirements and that is functional and cost effective.

P. Gräbe, Aurecon

Mr Pieter Gräbe, consulting engineer at engineering service company Aurecon, states: “Fire safety is taken seriously by the city of Cape Town. That is why we provided a solution that would offer a safe and compliant solution to Moresport.“ Flammable goods in high rack storage

Added value: natural ventilation

Pieter Gräbe continues “Moresport distribution centre requires high

“Besides the fact that the smoke ventilation system satisfies the local

rack storage for their highly flammable products. Local fire regulations

government requirement it also offers a functional, cost effective

stipulate that sprinkler fire protection as well as smoke ventilation is

solution. The 42 Brakel® Eura vents have daily added value because

required”.

they are also used for natural ventilation”, Peter Gräbe adds. Staff members utilise the manual opening features of the vents in summer

Safe escape and good visibility fire fighters

to provide cooling effect through natural ventilation.

Although the warehouse is occupied by a small number of people who are familiar with the escape routes, proper smoke ventilation is essential

Cooperation Aurecon and Quality Power

as it houses a large quantity of flammable goods. The clear layer was

Pieter: “Quality Power offered a working solution and we are satisfied

specified at one meter above the height of the racks which is 12 metres.

with the quality and certification of the Brakel® Eura products. Further-

Fire fighters will have good visibility on arrival in case of a fire incident,

more I am satisfied with the service from Quality Power.”

in order to effectively extinguish the fire. The building was divided into six zones and smoke vents had to be installed to extract smoke.

BrakelAtmosphere

10

Bavaria makes work of CSR and a pleasant indoor climate Modern combination of natural ventilation and a SHEV installation

The Swinkels family has been brewing Bavaria beer in Lieshout

Fresh view on climate control

since 1719. This makes the company the oldest independent

Bavaria’s production takes place largely in Lieshout. The expansion of

beer brewer in the Netherlands. The oldest and possibly the

the bottling plant with a new palletising centre prompted the examination

most modern. Because Bavaria has developed into a world-

of the smoke and heat extraction systems (SHEV) and the ventilation

wide player that exports 65% of its production to more than 120

systems. “A great deal of expansion and addition has taken place over

countries. Moreover, it was the first brewery in the world to be

the years. Some SHEV systems and ventilation systems are becoming

certified in accordance with ISO 26000, the standard for sustai-

obsolete. This was the time to ask ourselves whether we should replace

nable business. Fabienne van Thiel-Swinkels, building agency

systems one-to-one or implement improvements.”

architect and manager, explains why Bavaria attaches so much value to fire safety, a pleasant working climate and CSR (corpor-

Research: conditioning or natural ventilation?

ate social responsibility).

The buildings have become ever larger. “This makes it more difficult to get air deep into the buildings. Moreover, the number of machines has

“We take responsibility for the environment and for the people who live

increased, which means that ever more heat is being produced. That

in the vicinity of the brewery. For example, we purify our own water and

means that the demand for ventilation and cooling has also increased.”

return it to the surface water. We also generate our own energy with a

Bavaria invited parties to investigate the situation. “We studied natural

combined heat and power station. CSR influences the way we brew.

ventilation with Brakel Atmos and studied air conditioning with a different

Moreover, we screen our suppliers in relation to their CSR efforts.”

party.” Natural ventilation is preferred in principle, explains Van Thiel-

Taking responsibility for your own employees is just a part of this: “We

Swinkels: “With natural ventilation a building stays cleaner and you have

want to create a healthy workplace for our people, with the right tempera-

less maintenance. And you need less energy because you use thermals.

ture, without draughts and with daylight and a view. This helps people to

Naturally, this is what we support. There was just the question of whether

function better. ”

there was sufficient wall surface area to supply sufficient air and whether it was possible to get this air far enough into the building. Brakel Atmos executed simulations in order to answer this question.”

11

BrakelAtmosphere

F. van Thiel-Swinkels and H. Nabuurs, Bavaria

Brakel® Eura louvered ventilator for smoke and heat extraction

SHEV installation Brakel Atmos engineered and produced the smoke and heat extraction installations in the new palletising centre and the expansion of the bottling plant. They consist of Eura louvered ventilators in the roof for smoke and heat extraction and Estra wall grills for air intake. “The bottom louvered ventilators provide the air supply for the SHEV installation. The louvered ventilators that are placed higher provide better ventilation at the top of the building and also allow more daylight to enter. All of the louvres are made from glass, which means that there is a view and that light can enter.” The SHEV installation is also used for daily ventilation.

Fire screens and smoke curtains “Fire screens that only close in the case of fire in order to prevent Brakel® Estra glass facade louvers for air supply

the fire spreading are used between the different production rooms”, adds Henny Nabuurs, Architectural Project Manager & Maintenance Coordinator at Bavaria. “In the palletising hall there is a smoke curtain in the ceiling for the compartmentation of visible rising smoke.”

Simulation models

Naturally, fire safety systems must work correctly. “This is why their

Brakel Atmos created simulation models for the first part of the bot-

seals are tested every year and they are carefully maintained.”

tling plant and the new palletising hall. Result: natural ventilation is possible. “Of course, the simulation models involved making assumptions. However, the results were such that we chose to use natural ventilation again.”

The natural ventilation is connected to a regulation system that determines which ventilation grills must be opened or closed on the basis of factors such as the indoor and outdoor temperature, wind and precipitation. It creates a better/more pleasant indoor climate without draughts.”

Fire safety: The safety of people, operational reliability and inside attack Bavaria also specified stringent demands in relation to the new fire safety installation. “The legal requirements in relation to fire safety are geared to allowing people to leave the building safely. However, we

Fire screen to prevent fire spreading

also look at the operational reliability. The fire service must be able to enter the building in order to fight the fire. The fire must remain

A pleasant, safe workplace benefits performance

controllable and may not spread to other rooms or buildings. This

Fabienne van Thiel-Swinkels finds the new fire safety and ventilation

means that rapid detection is extremely important. The sooner fire is

systems an asset. “The same applies to the people in production as

detected, the smaller it stays and the easier it is to extinguish.”

the people in the office: it is important for daylight to enter and for the climate to be good. We are convinced – contact with the outside world makes people feel and perform better!”

BrakelAtmosphere

12

Voe fire

Brakel collaboration for smoke and heat extraction (SHEV) and natural ventilation The worldwide voestalpine Group is a steel based technology and industrial goods company. The company is, for example, one of the leading partners of the European automotive industry and household appliance industry, as well as the global oil and gas industry. During the casting of the steel for a renovation, voestalpine worked together with Brakel to put in an SHEV system and natural ventilation. Mr Edwin HĂśtzenegger, Technical Infrastructure Project Engineer - Industrial Building Technology, talks about the renovation.

Renovation of the steel framework, frontage and roof The problem was the age of the hall (which was built in 1940). The steel framework of the building had already been heavily affected by corrosion

BrakelÂŽ Eura-R

in some places and required renovation. At the same time, the frontage and the roof were also renovated, which gave us the opportunity to install natural ventilation and an SHEV system.

1940: no valid SHEV standards and guidelines The hall was built back in 1940. Back then there were no standards or guidelines for SHEV yet. There were only a few windows which could be opened for ventilation purposes.

The challenge: Renovating the building during operation The biggest challenge was, and still is, renovating the building during operation. The renovation work was not allowed to cause any production losses or disruptions. The time schedule was specified precisely in advance, together with the production team and project team, and must be adhered to exactly.

Foundry

13

BrakelAtmosphere

estalpine steel company: Importance of protection and air conditioning E. Hötzenegger, Voestalpine

Renovation takes over 5 years The renovation is spread out over 5 years (2014-2018), as the hall’s production may not be negatively influenced by the work and we can only ever open the frontage in the summer months, i.e. in warm weather.

Fire protection: key to the company Fire protection plays a central role in the company and is adhered to accordingly by all employees. In order to minimise the risk of fire and to continuously improve safety for both people and facilities, as well as the availability thereof, the group “Preventative fire protection” has been created, which is involved in all newly constructed buildings and renovations at the site in Linz. For this purpose, tailor-made fire protection solutions are being created – also for the SHEV system.

Brakel® Estra

The solution: Important criteria for the functionality and aesthetics of the SHEV system The solution: On the one hand, the SHEV system has to be functional. On the other hand, we also want an aesthetically-pleasing solution. Together with our design committee (architects), we decided on transparent louvered ventilators, Brakel® Estra and Brakel® Eura.

SHEV system also for daily ventilation In the foundry, as well as in almost all other halls, the SHEV system is also used for natural ventilation. Some ventilators are controlled manually, however several are already automatic, which takes energy efficiency into account. This is very important in our company.

Natural ventilation: Waste heat and improved working conditions The substantial amount of waste heat created in the production halls needs to be diverted in a targeted way. A natural ventilation system of

Brakel® Eura

appropriate dimensions also has an indirect positive effect on production and the operational lifespan of a system (e.g. the electrics). Moreover, this also creates improved working conditions for our colleagues.

Collaboration with Brakel Brakel has already provided us with fantastic support during the basic planning stage. Neither the various construction sizes, nor the coating of the ventilators in our preferred RAL colour were a problem for Brakel. In this way, the design committee’s guidelines could be fully adhered to.

In addition, throughout the installation process, Brakel proved to be, along with the implementing company (SCE), a reliable partner who is always on-site, delivers punctually and consistently deals with problems in a solution-oriented, quick and uncomplicated way.

BrakelAtmosphere

14

Atrium Royal College of General Practitioners London full of daylight and fresh air Due to glass ventilation windows in near-flat structural glass roof A pleasant day-to-day ventilation, sufficient daylight and an adequate smoke and heat extraction system (SHEV) was essential for the headquarters of The Royal College of General Practitioners in London. Certified Brakel Partner Delta Ventilation provided a solution using the Brakel® Lumera ventilator meeting all of the design and aesthetical requirements.

Ventilation window for structural skylights For smoke and natural ventilation purposes, the building required glass ventilation windows which had to be installed in a near flat structural glass roof. Delta Ventilation’s team designed the resulting scheme using Brakel® Lumera ventilators linked to the building BMS. Satisfied client The result: an open, pleasant building with a nice inner climate. The client is “delighted with the final solution”.

28 Brakel® Lumera ventilation windows

15

BrakelAtmosphere

Natural ventilation ideal solution for warehouse steel company Melesi Italy Smoke control and humidity problems solved Italian company Melesi is an international market leader in the

Mechanical ventilation impossible due to size of building

production of forgings. Its flanges and forged components are

The large dimensions of the building – 40 x 30 m, height 16 m – make

part of the main oil & gas projects. The natural ventilation sys-

the cooling of air via air conditioning or forced ventilation impossible.

tem installed by Brakel partner Bovema Italia proved the perfect

That is why Bovema proposed an entirely natural ventilation system,

solution for the new completely automated warehouse for inten-

based on thorough calculations.

sive storage of steel products. Why? It reduces the presence of humidity to prevent harmful oxidation processes as required ánd takes care of smoke control in case of fire.

“All-weather solution” based on surrounding conditions In Bovema’s study the building was put in context with respect to external weather conditions, prevalent wind directions, average winter and summer temperature. The building lies in a hilly environment, close to a stream and in a valley rich with vegetation, and thus with a high rate of evaporation-transpiration. Thus, In a context where the humidity generally tends to be high. In this respect continuous ventilation was needed.

Louvered ventilators with rain-proof side blades Brakel® Eura-R 14 Brakel® Eura-R louvered vents

The solution was found in a system based on natural updrafts. The systems consists of louvered ventilators in the façade for air inlet and louvered ventilators with rain proof side blades on the roof for the outlet of air. With this system ventilation is covered under all weather conditions.

Controlled ventilation The natural ventilation system is controlled by a rain-anemometer which regulates opening and closing of the central blades in case of wind, rain and snow.

Satisfied customer Melesi is very satisfied with the solution. It proves to be an efficient climate system, it saves energy and it is a good fire prevention system at the same time.

BrakelAtmosphere

16

DHL Express gives fire safety high priority In connection with the safety of employees and customers

DHL is a worldwide market leader in logistics. The company

Good maintenance generates low costs

offers solutions in international, express, air and ocean freight,

DHL Express must be able to rely on the optimum functioning of fire

road and rail transportation, contract logistics and international

safety systems, and therefore handles maintenance with care. More-

postal services. The fast delivery of packages and documents is

over, good maintenance generates low costs. Fire safety systems are

the specialism of the DHL Express division.

extremely durable if you keep them up-to-date.

Certification regulations play an important role in this because they

DHL Express manages 22 sorting centres in the Netherlands, varying in size from 10,000 m² to 44,000 m². A total of approximately 3500 people work at these centres. Eindhoven is the largest sorting centre, with 220 docks. Trucks gather at a sorting centre. Packages are collected and resorted, after which everything is transported again, within or outside the Netherlands.

Fire has an enormous impact Speed and reliability of delivery are crucial for a business like DHL Express. This is why the company has fire safety as a high priority. Due to the safety of its employees and the relationship with its customers.

DHL transports goods owned by others, and they must, of course, be handled carefully. In addition, a fire would have an enormous impact on the business process. After all, customers expect DHL to deliver in accordance with the agreement.

17

BrakelAtmosphere

ensure that effective maintenance will be carried out.

The fire safety facilities of DHL Express Brakel Atmos is responsible for the fire safety facilities in almost all of the DHL Express sorting centres in the Netherlands, from installation to and including maintenance of detection and SHEV (smoke and heat extraction) systems. DHL expects Brakel Atmos to work pro-actively in this respect – participation in the thought process and providing timely notification in relation to changes in regulations.

Detection Beams have been installed in a great many sheds. The packages are transported on exceptionally long conveyor belts. A beam is able to detect over extreme lengths. Traditional smoke alarms are not suitable for this purpose. A package that is located between two smoke alarms can burn for a long time before the fire is detected. Detection takes too long. DHL does work with traditional detection systems in its offices.

Smoke and heat extraction (SHEV) DHL Express believes that the safety of people is extremely important. If a fire is detected they must be able to leave the building in good time. The SHEV installations in the sorting centres make this possible.

SHEV, daily ventilation and night cooling The majority of sorting centres are operational 6 days per week, 24 hours per day. When it is warm in a shed, DHL opens the louvres – also occasionally at night – in order to provide cooling.

BrakelAtmosphere

18

19

BrakelAtmosphere

Louvered vents: a good solution for the production facility Smoke extraction, natural ventilation and daylight Olivomundo in Portugal specializes in the production of olive oil and aqua vitae. Products that are either sold to other companies as ingredients or exported. Olivomundo wanted a sustainable, energy saving solution for its new production facility. Certified Brakel Partner Cottes advised a system which meets all fire safety, indoor climate and daylight demands. “We are really satisfied with the ventilation system, it works well”, states Mrs Paula Silva from the Olivomundo maintenance department.

Natural ventilation in dry climate Olivomundo is located in a very dry climate region. Therefore it is essential to remove warm air from the building. The natural ventilation system, consisting of Brakel® Eura louvered vents, takes care of this by using natural updrafts to warm air from the building.

Fire safety and daylight The louvered vents also meet fire safety requirements as they extract smoke from the building in case of fire.

Furthermore, daylight enters the building through the louvers which provides a very pleasant atmosphere.

The result: satisfied employees that work in a pleasant working environment.

6 Brakel® Eura louvered vents

“We are really satisfied with the ventilation system, it works well!”

Paula Silva, Olivomundo

BrakelAtmosphere

20

New robust Marchetti Viaduct necessary after serious floods Natural ventilation prevents condensation inside bridge

Natural ventilation: a sustainable solution to prevent condensation inside the steel box structure of the bridge

The need to create a new “Marchetti Viaduct”, on the A4/5

problem. There is historical knowledge of the fact that one of the

Ivrea‑Santhia motorway link became necessary following the

most critical issues in metal structures of this kind consists in the

floods in October 2000. On that occasion, a large portion of

accumulation of condensation inside the girders, due to the thermal

this motorway link, was completely swept away by the mass of

and hygrometric imbalance between the air contained in the girders

water which smashed into the motorway link next to a modest

and the air outside. Consequently, it was of fundamental importance

construction which was unable to cope with such a catastrophic

to find a way of preventing the formation of condensation and the

event. Just rebuilding was not an option. Specific studies had to

subsequent corrosion of the steel in order to extend the useful life of

be carried out to ensure a solid bridge/viaduct in future. Bovema

the object for as long as possible. The solution proposed was studied

Italy, Certified Brakel Partner, advised a sustainable solution

in order to make the best possible use of the geometric and structural

to prevent condensation inside the steel box structure of the

conformation of the viaduct; an operation designed as part of the

bridge: natural ventilation.

design/construction of the metallic structural carpentry. The whole system was sized to ensure that the speed of the removal of excess

Two important factors for safety

water vapour would prevent the formation of condensation on the in-

• Efficiency and functionality had to be guaranteed for this important

ner walls under normal working conditions or at least to allow its swift

motorway providing access to and from France.

removal to minimise corrosion.

• The current hydraulic risk had to be reduced.

Natural ventilation system meets requirements Arched bridge with sufficient height and span of 250 m

The natural ventilation system consists of:

The need to build a single-span viaduct narrowed down the choice to

• 13 natural vents made of nautical aluminium, for the constant

just a few design solutions, so an arched bridge has been envisaged,

extraction of air from inside the chain girder, and four performing

built to prestigious design and in a light grey colour to put it into a bet-

a similar job along the arch, installed at the top of upper band. For

ter context within a surrounding visual cone. The viaduct is made with

each one, round holes are envisaged to supply the minimum sur-

a single-arch bridge with the road running at low level, with a span of

face calculated to extract the air from inside.

250 m.

• A system of 22 groups of four round holes arranged in line, on the lower band of the chain girder, to allow the entrance of fresh air.

Unique solution Bovema Italia

A system of four groups of three round holes arranged in a square

For the load‑bearing components of the viaduct, made with closed

on the side walls of the arch where it joins with the chain girder, to

steel bodies, a natural ventilation system was envisaged. This is a

allow the entrance of fresh air.

highly innovative application, used for the first time in a metal bridge and proposed by Bovema Italia. It is a new solution to a well‑known

21

BrakelAtmosphere

“This innovative system provides a further demonstration of the versatility of natural ventilation: a technique in principle simple, already applied in a pragmatic way by the ancients. Today we have calculation models that can predict the performance and this technique is suitable for a wide range of applications, embracing many human activities and providing a practical response to the problems of energy saving and environmental protection. It is a promising path, which must be developed in a systematic way.”

Pierenrico Varuzza, Bovema Italy

To prevent the lateral entrance of rainwater, the round holes will be

Self regulating system based on natural updrafts

covered by louvers.

Higher performances are envisaged in the arch. This is due mainly to

• A grating measuring approximately 1000 x 1000 mm housed in each

the fact that the air uptake height is much higher. However, this rate

of the two service entrance doors at the two ends of the chain gir-

of exchange is considered adequate, taking into account the finer

der, to provide an additional fresh air entrance for the ventilation of

section and the presence of the ladders inside. Under these condi-

the arch.

tions, their air flow is choked and, in certain cases, might not locally conserve the laminar characteristics.

Bird guards are fitted in each of the openings envisaged.

The forecast quantity of water vapour removed per unit of time has been calculated, considering a guaranteed average rate of exchange, Sustainable solution prevents corrosion

in relation to the change in air density and the quantity of water

The ventilation system in question does not have moving mechanical

vapour corresponding to the dew point. The system also confirms its

parts to pressurise the air inside the girders. All air movements will

self‑regulating characteristic with the forecast water vapour capacity,

be generated by the thermodynamic values naturally present inside

in that the higher extraction capacity corresponds to the warm sea-

and around the volumes considered. Thermo‑convection will force hot

son, when the air saturation point is higher.

air upwards. Large amounts of air and hot vapours are disposed of through natural vents. The system works without consuming energy.

Result: solid and durable Marchetti Viaduct that

Ventilation is accentuated by the wind’s action on the cover. The

guarantees vehicle passage

modular self‑supporting structure easily covers the holes in the roof.

These innovative technical solutions have been implemented in order

The forecasts assume natural laminar movements. Even in the worst

to ensure that the Marchetti Viaduct will have adequate operational

conditions for the chain girder, with an air uptake height of just 7.6

characteristics, solidity and durability. Not only does it have to span

m, at least 1.6 volumetric air changes an hour are guaranteed. It is

the riverbed of the Ribes - a usually small watercourse for which a

considered that this hourly capacity, combined with a normal painting

250‑metre viaduct might seem somewhat oversized - it also has to

cycle, can prevent corrosion triggered by condensation in the internal

guarantee the vehicle passage and safety of the motorway if excep-

volumes. This forecast is backed up by the fact that the system

tional weather conditions transform the modest stream into a raging

presents self‑regulating characteristics. In the warm season, when

river, as happened during the floods of 2000.

the atmospheric humidity is higher, the volumetric rate of exchange exceeds two volumes an hour.

BrakelAtmosphere

22

106 louvered BrakelÂŽ Eura smoke vents

Natural ventilation ideal for Eurospuma: manufacturer of polyurethane foams Portuguese company pleased with controllable smoke ventilation and daylight Eurospuma is a manufacturer of high-quality polyurethane foams and high bulk nonwovens. In this industry people work in large production facilities with machinery that produces a lot of warmth. That is why temperature control is essential. Certified Brakel Partner Cottes advised a controlled natural ventilation system with translucent louvres. The result: a pleasant interior climate with lots of daylight. An energy saving, silent solution which also meets all fire safety requirements.

Smoke extraction: 14 smoke zones Regulation requires 14 smoke zones in the Eurospuma production plant. In case of fire, 106 louvered BrakelÂŽ Eura smoke vents are going to take care of the extraction of smoke from the building.

Mechanical smoke system has limitations The client chose for natural smoke vents because a mechanical system cannot anticipate on the temperature chances intrinsic to the production process. Controlled natural ventilation can. The control system decides how far open certain ventilation grills should be at any given time. The system calculates this on the basis of the indoor and outdoor temperature, wind direction, wind speed and rainfall. The ventilation level set and optimum distribution of air are key to this.

Furthermore, a natural ventilation system is based on natural updraft and therefore doesn’t use energy. A good choice for sustainable as well as cost saving reasons.

Translucent louvres: access of daylight The 106 new translucent Eura louvred vents replaced the old fixed skylights which had low thermic value. This meant no extra constructional holes in the roof, a reduction in energy costs due to improvement in thermic value and the entry of much daylight. Eurospuma is very satisfied with this.

23

BrakelAtmosphere

Comfortable, durable and fire safe inner climate Jaguar Land Rover UK Thanks to 244 BrakelÂŽ Eura smoke vents Brakel Airvent installed 244 Eura smoke vents in the Jaguar Land Rover production facility in Solihull (near Birmingham) for smoke and heat extraction.

As Jaguar Land Rover gives high priority to sustainability, the company chose Eura smoke vents with enhanced insulated 25 mm louvres having a good U value.

Durable day-to-day ventilation The system is mainly used for daily ventilation and heat cooling. This results in a pleasant indoor climate based on natural updraughts. This is a silent, energy saving solution that also saves maintenance costs.

Smoke vent Initially the ventilation system is meant for smoke clearance in case of fire. The production facility in Solihull is split into 7 large smoke clearance zones. Eura smoke vents with enhanced insulated 25 mm louvres are used especially for smoke clearance. So in case of fire, the louvered ventilators ensure that smoke is effectively extracted via the roof. This means that anyone present in the premises can evacuate quickly and safely. Also the fire service can quickly localize the source of a fire – because it is not hampered by smoke.

BrakelAtmosphere

24

Dutch Flower Group focuses on efficient and sustainable energy management Saving energy costs with natural ventilation and daylight

Dutch Flower Group, a family of 30 companies trading in flowers,

Natural ventilation contributes to lower energy

bouquets, decorative floral arrangements and plants, is an

consumption

international supplier for importing wholesalers and large scale

The fact that energy consumption is a major cost centre means that

retailers. Flowers, bouquets and plants find their way from the

Dutch Flower Group is focussing on effective energy management.

processing rooms in the DFG companies in the Westland and

Energy consumption at the business locations is monitored con-

Aalsmeer to customers who count on reliable delivery and

stantly. “I use a special computer programme for this that registers

optimum quality. A great deal of care and attention is therefore

the exact quantity of energy consumed. I can use the programme to

devoted to the storage and processing of the fresh products.

compare the data from different production halls. If necessary, we can

Fire safety, ventilation and the entry of daylight play an important

rapidly make corrections by applying cooling or heating. Here, it is

role in the production rooms. This means that efficient energy

necessary for the Brakel Atmos ventilation systems to communicate

management is essential, says Jean Paul Herrie, technical man-

effectively with my climate management system.”

ager at Dutch Flower Group. “Energy consumption is a major cost centre for us.”

(Night) cooling Herrie explains how natural ventilation contributes to the energy

Fire means losing customers

management. “Plants and especially flowers may not be allowed

“If a fire breaks out we have a major problem immediately”, continues

to become too warm. This is why cooling is important. At night, the

Herrie. “If we cannot supply for a day, we lose customers. So good

cooling is switched off and the Brakel Atmos air extraction grills are

fire safety facilities are essential for our production. We test whether

opened. This allows warm air to be extracted naturally. As soon as the

the systems still work correctly every month. We have smoke detec-

temperature drops below 12° C, the grills close. This works effectively.

tors everywhere. In the cooling cells for our cut flowers and bouquets

It allows us to make significant savings in terms of cooling costs and

we are testing the effectiveness of both LIST cable detection and

also contributes to making our energy consumption more sustainable.

beams. Moisture in the cooling cells can cause normal detection to produce false reports. Moreover, every cooling cell is different and we have to adjust the detection system appropriately.”

25

BrakelAtmosphere

“Constant monitoring of energy consumption is a daily task for me” J.P. Herrie, Dutch Flower Group

Daylight, for a pleasant, healthy workplace The entry of daylight is an important aspect of the work environment in which a significant number of people are involved in checking, storing and arranging the products and preparing them for shipment. “We used to lease a lot of rooms, where we worked like moles in the dark.

Then when Dutch Flower Group started building in 2001 we were able

(Night) cooling is sustainable and saves costs

to ensure that sufficient daylight could enter the new building. This is very important for the job satisfaction and motivation of our employees! For the same reason we also work – if possible – with shed roofs or skylights. Our colleagues enjoy their work more when these glass constructions are used.”

Energy management in new buildings Insulation: glass instead of polycarbonate

Herrie keeps his finger on the pulse every day. “Constant monitoring

Glass constructions also play a role in energy management. Attention

of energy consumption is a daily task for me.” The data registered

is devoted to the insulating properties of the systems because this

by the computer programme proves its worth not only in existing

can produce a significant amount of profit. “Where you used to

situations, but also in new construction projects. “For example, I can

choose polycarbonate, now you choose glass. This insulates much

see how a glass skylight affects energy consumption in a room in

better and is also more reliable. A successful example of insulation is

comparison with a plastic skylight. This information helps us to make

our plant specialist company Hamiplant in Honselersdijk, where the

the right choices in projects.”

heat requirement has been reduced by more than half: from 1000

Dutch Flower Group cooperates with HD Project Management on new

kW to 400 kW. The application of glass in louvred ventilators or hung

construction projects.

windows can produce a great deal of profit, on condition that you

“They are familiar with all of the architectural ins and outs. We indi-

combine it with effective ventilation management. It can get hotter in

cate what we want in terms of daylight and air. HD Project Manage-

summer. You earn the extra investment that this requires back soon

ment then contacts Brakel Atmos for this specialisation, which then

enough.”

rapidly provides solutions and answers. That works nicely!”

BrakelAtmosphere

26

Smoke ventilators efficient solution refrigerated warehouse Bloemfontein Brakel® Optima performs well in hygienic environment The refrigerated warehouse in Bloemfontein stores fruit and vegetables produced on farms in Orange Free State and had to be extended because it had reached capacity. Architect Francois du Toit from FD/A was asked to provide a professional architectural solution that met the clients’requirement. For fire safety FD/A teamed up with Sutherland Engineers and Certified Brakel Partner Quality Power. This proved to be a fruitful cooperation.

Fire safety most important aspect Francois du Toit: “Fire safety is the most important aspect when designing a building occupied by a large number of people. Lives depend on a well-designed and rational building. The smoke extraction to the cold rooms was of paramount importance. Sutherland Engineers, together with Quality Power’s Brakel smoke ventilators, provided a very cost effective and efficient solution to what could be a very complicated and cumbersome one.”

Food industry and Quality Power Francois continues: “The fire installation had to comply with the high hygienic standards inherent in food storage. We have a good track record with Quality Power, dating back many years. We knew they could deliver a product that performs well in a hygienic environment; to keep rainwater, dust, insects and birds out of the building, while allowing smoke to exit the internal spaces.”

Why thermally broken Optima in ceiling void?

“We chose large size thermally broken Brakel® Optima ventilators in the ceiling void. As the cold rooms operate between 0-10°C, we were concerned that we could end up with a cold bridge between the cold room and the roof void”, explains the architect. “This would have compromised the required even room temperature and in turn, increased the loading on our cooling plant. Thus, we opted for an insulated ceiling ventilator. This ventilator also negates condensation on the top side of the ventilator, which can cause a constant dripping inside the building, especially during the summer months”.

Software model and ventilation system Quality Power used Brakel’s visual software model to prove the noncondensation aspect. The Optima ventilator’s control panel is connected to the building’s fire alarm in order to trigger them to open in case of a fire being detected. When the Optimas open, smoke is allowed to rise from the cold store, through the Optimas into the ceiling void. From there it will extract through six Eura ventilators into the roof.

27

BrakelAtmosphere

F. du Toit, FD/A

“Brakel smoke ventilators, provided a very cost effective and efficient solution to what could be a very complicated Brakel® Optima ventilator

and cumbersome one.”

Reduction maintenance costs Francois ends the interview by referring to maintenance. “Maintenance is always an issue in buildings. Maintenance is necessary. The air and water tight ventilators installed on the roof, reduce the need to clean the roof void on a regular basis. The roof void carries a great number of sensitive fire and electrical services that could be compromised by dust and water ingress. The customer is satisfied with the solution.”

BrakelAtmosphere

28

School and office furniture manufacturer VS Möbel has decided on natural solutions Light, constructional fire protection, and natural ventilation/extraction in one system VS Möbel is a one-stop provider of custom-made school and office furniture. The company has 1000 employees and considers a pleasant work environment in its production areas to be important. This also applies to the new hall, where approximately 50 employees are involved in final assembly of tables. Mr Georg Benz, of VS Möbel, turned to certified Brakel partners Rothe and Poth for ensuring smoke and heat extracting properties, natural

G. Benz, VS Möbel

ventilation/extraction, and provision of daylight in the new hall.

“For us, it is important to use natural thermionics”, stated Mr Benz.

Fire protection as a requirement

“We prefer to work with normal daylight and natural ventilation as well

Certain fire protection regulations must be observed for building

as constructional fire protection, so we have decided to use skylight

approval to be granted. Amongst other things, it means the use of a

strips with integrated ventilation systems in the new 7000 m² hall. Our

smoke and heat extraction system with integrated air intake system

new building is long and narrow, 210 m x 32 m, and varies between

for the new hall.

5.5 and 8.5 m in height.”

Brakel® Eura-R for air extraction

29

BrakelAtmosphere

Continuous rainproof ventilation This smoke and heat extraction system consists of Brakel® Eura-R louvre vents with rainproof side flaps for air extraction. We always have ventilation with this system, even when it rains - then we just open the side flaps. We only close everything during holidays and in winter.

Brakel® Eura louvre vents are integrated in the façade for the air supply. These louvre vents are, just like the roof systems, designed to be transparent so that daylight can get in.

Daylight gets in via skylight strips The building is divided into a 6 m grid in a longitudinal direction. A 10 m long by 2 m wide skylight strip is installed at 12 m intervals, with louvre vents mounted at the ends. This means a total of 17 skylight strips with 34 2 m x 2 m louvre vent systems for the new hall.

Brakel® Eura for air supply

Collaboration VS-Möbel and Georg Benz have worked together with Rothe and Poth for many years. R&P also installed ventilation in an existing hall where a production process was used which released a lot of heat. The louvre vents are positioned such that the warm air is quickly and efficiently moved away, directly over the source of heat. R&P also carries out maintenance work on the systems. Their clients are completely satisfied with the work.

“We prefer to work with normal daylight and natural ventilation as well as constructional fire protection.”

Georg Benz, VS Möbel BrakelAtmosphere

30

Brakel® Optima chosen for the renovation of a Decor workshop The most sustainable solution for smoke and heat exhaust and ventilation

Smoke vents without condensation “It was pointed out to us during the renovation that the smoke vents were the coldest part of the roof and so threatened to become a source of condensation. That would be no good at all, as cultural heritage is stored here. This is decor that has been made together with famous artists which we keep when the productions are finished.

To prevent condensation, Brakel Atmos advised installing the Brakel® Optima. This new type of smoke vent is energy-efficient and is able to deliver the required insulation value.”

The Dutch National Opera Decor workshop is situated in the Bijl-

Daily ventilation and daylight

mer in Amsterdam. As the roof of the building urgently required

The Decor workshop also uses the smoke vents for daily ventilation.

renovation, a futuristic solution was looked for. Because of the

“We still have to discover how to use this properly, as they are group-

equivalence requirement set by the fire brigade, the old Brakel

driven. But it is certainly pleasant on hot days.”

smoke vents had to be replaced. As valuable decor is made and

In the spaces where the decor is stored, daylight is only admitted spar-

stored in the building, the formation of condensation had to be

ingly. On the other hand, there are also work areas where daylight

completely excluded. Brakel Atmos therefore recommended the

access is desirable. “For instance the painting department, where our

application of the Brakel® Optima: the most sustainable, ther-

people have to be able to see the colours properly. In these spaces

mally separated louvered ventilator.

the smoke vents have been fitted with glass flaps.”

The Decor workshop had very green ambitions for the renovation,

Nice building

says Rolf Hauser, the Decor workshop administrator. “Due to lack

The renovated building represents an enormous step forwards, thinks

of funds we have unfortunately had to make concessions, however

Hauser. “We are very satisfied. And as for the smoke vents, we have

improving the insulation was retained. The amount of energy needed

had little trouble with the old Brakel Atmos system for the last 28

to heat the whole building has been significantly reduced.”

years, so we expect the same from the new systems.”

“To prevent condensation, Brakel Atmos advised installing the Brakel® Optima. This new type of smoke vent is energyefficient and is able to deliver the insulation value.”

Rolf Hauser, Decor workshop

31

BrakelAtmosphere

Dairymaster’s global manufacturing facility equipped with Brakel® smoke vents Certified Brakel Partner Williaam Cox advises and installs

Dairymaster is a world leader in dairy equipment manufacturing.

Smoke extraction system: 49 m² Brakel® Eura ventilators

Its head office – with 200 employees - is located in Causeway,

In order to minimise the number of cut outs on the roof, large AOVs

Co. Kerry Ireland. Dairymaster has a wide innovative product

(Automatic Opening Ventilators) were required. The answer was

range including milking equipment, automatic scrapers, auto-

found in the design & installations of the Eura louvered ventilator to

matic feeders, milk cooling tanks and heat detection systems.

provide the free area required and achieve Fire Certificate.

“Fire safety is important to us” states John Fleming, design Maintenance

engineer at Dairymaster.

“Maintenance is essential to us because we have to rely on the Dairymaster contacted Certified Brakel Partner Williaam Cox to

system. Low maintenance is important because the smoke vents,

advise on a turnkey project for the Requirement for Smoke Ventilation

by nature, are difficult to access. Persons accessing the vents

in the extension to the Plant.

require MEWP’s (Mobile Elevating Work Platforms). That’s why low maintenance for this type of equipment is desirable” says Fleming.

Expansion production area: need for smoke vents

Dairymaster concluded a maintenance contract with Williaam Cox so

The continued growth of the Dairymaster brand worldwide and the

that professional maintenance is guaranteed.

increased demand for Dairymaster equipment caused the need for expansion. An additional fabrication area was added to the current factory. John Fleming: “Of course the safety of the people working in our factory is important. It is also essential to minimize the damage to the building in case of a fire. That is why smoke vents were also required on the new building.

“Of course the safety of the people working in our factory

In 2008 Williaam Cox already designed & installed smoke vents

to the building in case of a fire. That is why smoke vents

is important. It is also essential to minimize the damage

in other areas of our Plant. We are satisfied with the cooperation

were also required on the new building.”

with Williaam Cox that is why we contacted them again for the new

John Fleming, Dairymaster

building.”

40 Eura smoke vents

BrakelAtmosphere

32

33

BrakelAtmosphere

The best “workshop” is one with natural ventilation Effective heat extraction very important for packaging specialist Cups4you Cups4you in Oss manufactures injection moulded packaging mainly for companies in the food industry, such as Johma, Campina and Haribo. The manufacturing process involves the injection of synthetic material. All machines heat up to temperatures between 200 and 240 degrees, making the manufacturing area very hot. And this heat needs to be properly extracted. Ron Vogels, Technical Manager at Cups4you, says that the hall having natural ventilation has the most pleasant working climate.

“Contrary to expectations perhaps, but the hall with natural ventilation has the best climate.”

Cups4you, formerly Vadeal Plastics, has been operating since 1969 and, besides synthetic packaging, also produces bottle caps for both glass and PET bottles. These are manufactured 24 hours a day, 7 days a week.

The company engineers its own robots and has 72 employees.

Extremely hot “The manufacturing process makes it extremely hot in the hall, which is a nuisance. Indoors it is at least 5 degrees warmer than outside, even in the summer months. So it is important to extract the heat properly to the outside air”, says Vogels.

Natural ventilation works better than mechanical “We have three halls on site. One hall is mechanically ventilated. In practice this means that outside air is blown in, which is then discharged via the roof. However, this does not provide a uniform temperature gradient; somehow the heat is not extracted. Contrary to expectations perhaps, but the hall with natural ventilation has the best climate. There the hatches, at the top of the hall, are opened opposite each other when it is hot. This

R. Vogels, Cups4you

automatically draws the heat out of the hall. The natural ventilation is controlled by the wind direction, but to be honest I sometimes open the flaps manually to get it a little cooler. That works perfectly.”

Sustainability “Natural ventilation is an energy-efficient system, and that is of course a nice bonus. However, our machines are the big energy guzzlers. A lot more could be saved in this respect, so we are focusing on that most of all. To limit the energy consumption of the machines, we cool using outside air, we use a closed cooling system and any heat released is blown into areas that are already cool, such as the warehouse.”

Maintenance “Of course, just like our machines, our ventilation systems also require periodic maintenance. So we have a service contract with Brakel Atmos.

That works well: we are contacted in good time and maintenance is carried out properly.”

BrakelAtmosphere

34

Brakel速 Eura

35

BrakelAtmosphere

Brakel速 Eura-R

Fresh air, fire safety and daylight important to Recheio Leader Cash & Carry sector Portugal takes sustainability seriously With 36 cash and carry stores and 3 food service platforms,

Two-in-one: daily ventilation and smoke and heat

Recheio is an important player in the food industry distribution

extraction

sector in Portugal. Recheio is the first HACCP certified food dis-

The natural ventilation systems installed at the several sites of

tribution company. The company takes sustainability seriously.

Jer贸nimo Martins Group, including Recheio Cash& Carry, have an-

This is also reflected in the way it deals with the renovation and

other important advantage: the efficient extraction of smoke and heat.

extension of its buildings. According to Brakel Certified Partner

This so-called Smoke and Heat Extraction (SHEV) system discharges

Cottes Group, Recheio chooses energy-efficient solutions when

smoke and heat quickly through the roof. In case of fire this enables

it comes to fire safety, ventilation and lighting.

people to escape safely, the size of fire is limited and the fire service can extinguish the fire in an efficient manner.

Energy-saving solutions

This client kills two birds with one stone with natural vents.

Recheio is part of the Jer贸nimo Martins Group. The Cottes Group has been involved in 2 renovations of Recheio distribution centres located

Plus daylight

in Loures and Valen莽a do Minho.

The natural smoke ventilation installed by Cottes Group in the

In both cases, Recheio opted for energy-saving natural smoke and

Recheio buildings consists of louvered systems. Using translucent

heat ventilation.

blades allows daylight to enter the buildings. This has two advantages.

Pleasant environment for people

Firstly, as natural daylight has a positive effect on mood, it makes

Sustainability, however, is not the only issue that is important to the

people feel and concentrate better.

company. It also gives high priority to realizing a comfortable environ-

Secondly, it saves energy (costs) because considerably less artificial

ment for both clients and employees. One way of doing this is by

lighting is necessary.

implementing building installations that contribute to a pleasant atmosphere. This is why Cottes recommended the use of energy-

The result: comfortable, healthy and (fire) safe indoor climates in

efficient, on-demand, natural ventilation that works using natural up-

which people feel more comfortable and perform better.

drafts and creates effective, silent and energy-efficient climate control.

BrakelAtmosphere

36

Thermally broken Brakel速 Optima smoke ventilators

37

BrakelAtmosphere

Unusual solution for refrigerated warehouse Centurion South Africa Non guided smoke ventilation A massive distribution facility in Centurion had to be extended

from the refrigerated space through the roof void and then out of the

with a -28°C area (3500 m²) and a 1°C area (7000 m²). Consulting

building. At this cold store only one smoke ventilator – type Brakel

engineers WSP teamed up with Brakel Certified Partner Quality

Optima which is rated for large temperature differences - was instal-

Power. This led to an unusual, sustainable and cost saving

led. The refrigerated space is therefore extended right up to the roof

solution for the 1°C area. Jan Eager, consulting engineer at WSP

sheet level.”

explains.

Customer satisfied with this solution “We worked together with Quality Power because Quality Power

Jan Eager continues: “Compared with previous systems installed,

conducted the necessary market research and code requirements

there is a vast difference in customer satisfaction. There is no prob-

to secure that we offered certifiable roof ventilators that comply with

lem with leaking roof ventilators and associated condensation inside

South African regulations.”

the refrigerated space.”

1°C area:

-28°C area: openings drastically reduced

refrigerated area extended right up to roof sheet level

“Due to the problematic nature of openings through freezer panels

Quality Power proposed a configuration which surpasses the general-

and icing problems, smoke vent openings had to be minimized.

ly implemented method in South Africa. Normally, insulated ventilators

Through the use of mechanical extraction, openings could be drastic-

are fitted onto the ceiling, allowing smoke to rise into the ceiling from

ally reduced compared with other areas of the building.”

where it is ventilated outside of the building via controllable louvered

Fans were installed inside shafts of the ceiling void. To minimize heat

ventilators. Jan Eager states: “What is not normal for South African

transfer between the cold area below and the void which can reach

installations is that smoke extracted from the building is not guided

temperatures up to 40°C in summer, Brakel® Duo Therma flap ventilators were fitted onto the ceiling. Brakel® Eura louvered ventilators were fitted above the fans in order to prevent rain ingress through the roof.

Future buildings: Optima louvered vents with glass blades?

It was remarkable how much daylight entered the building through the thermally broken Optima vents when they were open. Since cold stores are 100% illuminated with artificial lighting, Quality Power investigated the feasibility of installing glass blades in the louvered ventilators since the artificial lighting could be reduced during daylight hours. What would be the heating effect?

Financial value and heating influence Calculations show that daylight entering the cold store will have a

Brakel® Eura ventilators above the fans

financial effect only if the artificial lighting can be reduced during hours of daylight.

But what about the heating effect during daylight? Empirical tests were done to see what effect daylight would have on the temperature inside the building.

The results: there was much to be gained by using translucent blades. There was an additional load but that did not outweigh the cost reduction in artificial lighting.

“There is no problem with leaking roof ventilators and associated condensation inside the refrigerated space.”

Brakel® Duo Therma flap ventilator

Jan Eager, consulting engineer WSP BrakelAtmosphere

38

Latest product developments 2015 Brakel is constantly developing and improving products. This involves us to listen carefully to our clients’ requests. In 2015, this resulted in the development of the Brakel© Fumetica and Brakel® Eura Exellent and the improvement of the Brakel® Optima and Brakel© Microlab.

Brakel® Fumetica Louvered ventilator for large spaces: Large smoke ventilation capacity for a competitive price!

This new louvered ventilator with a large exhaust capacity was developed especially for distribution centres, storage halls and production environments. Features of Fumetica: • Maximum (smoke) extraction: 7.5 m² • ± 28% cheaper • Performance guarantee • 100% silicone-free

Brakel® Eura Excellent Highly insulating louvered ventilator The Eura Excellent is based on the Eura louvered ventilator, which has been used for decades. Application of new materials and techniques has enabled us to achieve a 56% improvement in the U value. Features of the Eura Excellent: • Highly insulating louvered ventilator • To 9.37m2 (geom.) certified • Fall-through safe • Insulation value increased by 56%

39

BrakelAtmosphere

Brakel® Optima The most sustainable louvered ventilator on the market The Optima is the most energy-efficient louvered ventilator for smoke extraction and ventilation. In contrast to other louvered ventilators, the Optima is completely thermally separated. Features of the Optima: • Completely thermally separated • Suitable for air supply and smoke and heat extraction • Energy-efficient natural ventilator • Optional weather-independent ventilation setting

Brakel® Microlab Plus Continuous natural air extraction The labyrinth construction Microlab is a maintenance-friendly, natural roof ventilator that prevents the ingress of rain that was designed especially for industrial spaces where permanent high internal heat loads must be extracted. Features of the Microlab: • Weather-independent ventilation • Slanted louver structure: Cv value: without crosswind effect : Cvw = 0.28 with crosswind effect

: Cvw = 0.52

• (Sealable) labyrinth construction • Longitudinally linkable

BrakelAtmosphere

40

Brakel partners with nature to create a sustainable interior climate Brakel believes in utilizing the elements of nature (daylight and air) to provide people safety and comfort in their private habitat and workplace environment. Everything we do is in congruence with our belief, resulting in an extensive product range in daylight, natural ventilation and smoke ventilation. These products form the basis to configure project proposals, meeting your requirements, wishes and functional solutions.

Brakel Aluminium b.v. • Uden, The Netherlands • T +31 (0)413 - 338 360 • www.brakel.com

Daylight

Ventilation

Fire safety

maintenance
