RESIDENTIAL SOLAR GALLERY
Browse examples of the most common solar systems and additional features.
A R C H S O L A R . C O M
ROOF MOUNT SYSTEMS
GARAGES WORK TOO!
WHY PEOPLE CHOOSE ROOF MOUNTED SYSTEMS
Roof-mounted systems can be more cost-effective since your meter is closer to the array.
You have a typical property footprint to work with and you’d like to save money on energy bills for the next 30 years.
You are proud of your solar and want to show it off to everyone!
GROUND MOUNT SYSTEMS
TRENCHING & POST POUNDING
A ground mount system requires a unique mix of construction and engineering.
To hold the modules, we pound steel beams into the ground, u machine
In addition to pounding posts, we also trench the ground to run wire through metal conduit up to the meter of your home.
WHY PEOPLE CHOOSE GROUND MOUNTED SYSTEMS
If you don’t have enough roof space to accommodate the number of panels needed for your electrical offset. You don’t want solar on your house or garage for aesthetic consideration. You have property and want to use it for an investment that gives you a strong ROI.
OTHER CONSIDERATIONS
CONDUIT
Conduit is the metal tube we use to pull wires through.
This weatherproofs the wires and allows us to run wiring from your meter to the solar panels.
Conduit
Internal
External
SOFFIT PENETRATION
SOFFIT WRAP AROUND
CRITTER GUARD
WE ENERGIES METERS
Overhead Meter
Pedestal MeterMG&E METERS
Overhead Meter
Pedestal Meter
ALLIANT METERS
Pedestal Meter
COMBINER & DISCONNECT
Combiner Disconnect
MICROINVERTERS
STRING INVERTERS
RACKING
HUG ATTACHMENT: THE HALO CASTALUMINUM FOUNDATION
SURROUNDS THE BASE A FOAM-BACKED SEAL COMBINATION THAT PREVENTS WATER INTRUSION BY ADHERING AND SEALING WITH THE SHINGLE SURFACE.
RACKING
BATTERY STORAGE
TESLA POWERWALL
BATTERY STORAGE FRANKLIN WHOLE HOME
BATTERY STORAGE BATTERY ROOM
EV CHARGING SPAN SMART PANEL
