archjtecture part 1 portfolio

jay earnshaw

part 1 architecture graduate

a firm believer that architecture is the best way too represent people, with a particular interest in working with listed buildings. a hard-working, creative individual with a strong sense of design, who is looking to create his own mark on the world.

education

bachelors of architecture (hons.)

2020 - 2023

nottingham trent university second class honours

studying at nottingham trent, over three years gaining the core skills required for the rest of my career, culminating in a thesis project, creating a new cycling hub for the city of nottingham.

awards

aia student charlette 2022 winner

october 2022

winner of a one day student architecture competition, ran by the aia in london. working in a small team, we created a “west end wonderland”; transforming a small cobbled crescent of london’s west end into a new hybrid space, which could act as both a water fountain or a small performance space.

skills

3d modelling and bim

sketchup pro and environmental simulation software such as sefaria. autodesk revit, and rendering softwares, such as lumion, v-ray and enscape.

ai rendering and prototyping

sketchup prototyping with veras ai, craiyon ai

graphics

autodesk autocad and revit, hand drafting, sketching, adobe creative cloud suite, especially photoshop and illustrator.

contact

iamjaydanielearnshaw@gmail.com

instagram portfolio

@archjtecture

employment history

momentum instore

august 2021 - september 2022 merchandiser

overnight replenishment role within sainsbury’s around the united kingdom, requiring working with a rotating team, in a fast paced environment.

debenhams

october 2018 - january 2020 sales assistant

working alongside my a-levels, in a small team working to fulfil the personal requirements of shoppers.

annabelle tugby architects

june 2018 work internship

a week long work internship, in a small architecture firm, working on a residential project. also completed a similar intership with bdp. in 2016.

hobbies/ interests

film production

a long term hobby, which has involved working on small independent film’s, and as a freelance video editor in the past.

cycling

a major interest and preferred sport which directly influenced my thesis project at university.

civic laboaratories of change

nottingham cycle centre

meadow lane lock, nottingham

a chord of connection

nottingham cycle hub aims too create a new chord and place of connection for the wider city of nottingham. exploring the site through a fluid chord and undulating structures, the idea of a dynamic spaces for people to visit and travel through is created.

celebrating the past, whilst building the future

this aim for this project is to celebrate nottingham’s cycling heritage within its museum and archive facilities. these facilities are then built upon with spaces for quick bike repairs, and classes teaching the importance of self repair, rather than purchasing and buying new.

roof membrane timber roof sheathing insulation beween the glulam structure vapour control layer plywood sheeting

thermally isolated glulam beam steel mount connecting the glulam beam to the concrete structure

flexible movement joint

insultation strip

internal insulation parapet closing insulated cavity cover

in situ cast stainless steel reinforced concrete walls waterproof membrane

cladding mouted using stainless steel mounts

insulation mechanically fixed to substrate sealant pre-cast concrete cladding panel

double glazed windows

sill overhang sealant strip insulation under sill insulated cavity closer pre-cast concrete cladding panel waterproof membrane

insulation mechanically fixed to substrate

concrete floor finish rigid insulation screed atop precast concrete planks precast concrete planks

gypsm based board fixed to counter batterns

junction closed off with sealant if required

in situ cast stainless steel reinforced concrete walls plasterboard skirting board window head insulated cavity closer insulated flashing with sealant to cladding pannel

in situ cast stainless steel reinforced concrete walls

damp proof course 150mm above ground level flashing lapped with dpc extruded polystyrene insulation below dpc level waterproof render below dpc level in situ stainless steel reinforced concrete floor, with an exposed floor finish, using raft foundations to support the larger walls screed hardcore

pillar foundations in specific locations to support the collumns above

DETAIL B @ 1:10

DETAIL C @ 1:10

museum of the whale transformer

new way ghaut, whitby

the essence of the ocean

inspired with the movement and forms of the ocean, the museum of the whale aims to adapt an existing listed building of whitby’s rowing club, and transform the spaces into a new museum. a new steel and glass structure has been creating a permanent encapsulation of a wave hitting the walls of whitby harbour.

exploration of ai

within this project, was an exploration of ai, as a device that can be used to iterate, through the use of quick rendering, which proved to be a useful tool in exploring materiality and chaotic forms. ai was also used to help generate renders exploring the idea of the movement of the ocean and water crashing in on the user.

st philips marsh, bristol

masterplanning

part of creating a redeveloped area for bristol involved master planning in line with the principles presented in the book soft city. in particular a large area of development was placed in exploring how a new area can be curated for pedestrians, as well as how the safe and pleasant spaces are created through smart urban planning.

urban housing

further developing the lessons of soft city, urban housing focuses on creating a large residency with a large focus on creating different atmospheres within private and public areas. inspired heavily by the “hundertwasserhaus” in vienna this design is a way of keeping the public street areas well lit and safe below, whilst still allowing residents to feel a sense of privacy

a softer city sites of hybridity

urban farm

the growth of nine twins

high pavement, nottingham

growing nottinghamshire

through growing the produced of the nine cities and towns twinned with nottingham from around the world this urban farm not only provides a series of unique farming produce and environment, but also symbolically represents nottingham’s place in the wider world. consisting of farming facilities on three levels with a small residency atop, this structure manages to blend seamlessly into the nottinghamshire landscape and creates a new attraction for the cities centre.

habitat

posenenske house

arbouretum, nottingham

habitat for an artist

inspired by the artwork of charlotte posenenske, this home is designed to be a true encapsulation of the style of work she has produced throughout her career. this house, is inspired by her industrial minimalist sculptures, with an architectural focus on utilising light strategically to give each space its own atmosphere, based off the purpose of the space.
