66
FEATURES
1
Ventilation
Shell Construction CFC
Shell Construction PB-CLC
Carbon Fibre Composite Exclusive technology developed internally by Arai for the GP-6RC F-1 helmet utilizes carbon fibre found in the latest generation of commercial airlines, and is bonded with Arai´s proprietary resins and is reinforced with a band of incredibly super fibre belt specifically oriented to disperse energy loads laterally across the shell surface. In the forehead area, this band increases shell strength without adding thickness or weight, and allows the use of a thinner EPS liner which greatly enhances the upward field of view – especially appreciated in a full racing tuck!
Peripherally Belted Complex Laminate Construction Arai’s proprietary (super fibre belt) Peripheral Belt, borrowed from our F-1 technology, greatly increases shell strength and flexibility while maintaining low weight and a lower centre of gravity. Positioned across the top of the eye port, this band contributes to the use of a thinner EPS liner which greatly enhances the upward field of view. A specially designed “mechanically expanded fibre mat”, sandwiched between the inner and outer layers of Arai’s proprietary Super Fibre Laminates, is used to reinforce and bond these two Super Fibre layers without adding significant weight to the helmet.
3
Free Flow System (FFS)
Creates airflow under the helmet that reduces wind noise and turbulence while increasing the exhaust of hot air.
Peripherally Belted Structural Net Composite Arai´s proprietary (super fibre belt) Peripheral Belt, borrowed from our F-1 technology, maximizes shell strength and flexibility while maintaining low weight. Positioned across the top of the eye port, this band allows the use of a thinner EPS liner which greatly enhances the upward field of view – especially appreciated in a full racing tuck! The Structural Net Composite adds a physical bond to the resin bond of the many layers of fibres and reinforcing materials within the shell.
Shell Construction SCLC Super Complex Laminate Construction The latest aerospace fibres, with 30% more strength in extension & bending resistance than standard fiberglass comprises the majority of the SCLC shell. While considerably more expensive than most fiberglass (and in fact more than many Carbon Fibre materials), this “Super Fibre” provides incredible flexibility and strength, which maximizes shell integrity. A specially designed “mechanically expanded fibre mat,” sandwiched between the inner and outer layers of Arai´s proprietary Super Fibre Laminates, is used to reinforce and bond these two Super Fibre layers without adding significant weight to the helmet.
Eyeport air channel
Enhanced air exhaust from the eye port area, pulled through dedicated air channel to side ducts, improving efficiency and reducing noise.
Front Ventilation 5
Center Top Vent
The new Top Vent provides 11% more airflow than the previous Vent. The new bigger switch makes opening and closing easier. The new Top Vent has three positions; closed, half open and fully open to adjust the airflow and prevent water intrusion when fully closed.
Shell Construction PB-SNC2
4
8
Brow vents
Fresh air can enter directly to the forehead area without the need for holes in this critical area of the shell and impact absorbing liner. For specific models the ventilation is extended to the temple area.
Shell Construction SFL Special Fibre Laminate Strict quality controlled construction using special fibre layers, crowded with fibres right to the shell surfaces and bonded with special resins formulated by Arai, to disperse impact energy over the widest possible area – the shell’s main job – through strength, structural integrity and impact flexibility.
6
Dual intake
Designed for increased airflow and lower noise level, guiding fresh, cool air into the interior.
9
Three-position chin vent
Three-position chin vent helps in demisting the visor and offering fresh, cool air to the rider.
2
Variable Axis System (VAS) With VAS, the visor mounting position is lowered, yielding an average of an additional 24mm across both temple areas, in pursuit of the ideal smoother shape that increases the ability of glancing off energy. As a result, this has made it possible for more of the shell to be smoother along and above the test line of the Snell standard.
Virtual Axis Track
7
Diffuser system
The new diffusers are 20mm longer and straightened for improved aerodynamics, working together with the Air Wing to improve stability. Compared to the previous diffusers, the efficiency of the intake scoops of the new diffusers has increased by 19%. The new air intake vents not only have more adjustability with three positions; closed, half open and fully open but also help to improve sealing that decreases wind noise and water intrusion.
10
Inner chin (bar) vent shutter
Open and close the chin bar vents from the inside to prevent debris coming into the helmet in dusty riding conditions.
