GENERAL RANGE, CAPITAL WORKSHOP EQUIPMENT & LUBE SYSTEMS MASTER PRICE LIST MAY 2024

RANGE, CAPITAL WORKSHOP EQUIPMENT & LUBE SYSTEMS

MASTER PRICE LIST MAY 2024

ALEMLUBE IS A PROGRESSIVE, INNOVATIVE, CUSTOMER CENTRIC AND 100% AUSTRALIAN FAMILY OWNED COMPANY

Alemlube was established in 1970 and now more than ever we are looking for new and better ways to service the needs and requirements of lubrication equipment, refuelling, hose storage, fluid management and vehicle servicing users from Invercargill in the south of New Zealand to Port Hedland in the north west of Australia.

The team at Alemlube understands that we need to be looking to evolve and change as the market constantly changes and moves.

Whilst the cornerstones of our business will not change, namely an ever expanding & improving product range, quality products sourced from market leading manufacturers, a company structure that delivers efficiencies and consistency and a company culture that engages our suppliers, our team and our valued customers, our focus in the future will be bringing more to the table at an ever increasing rate.

Today, we look to our suppliers, both existing and new, and our Branch, Division and Department Managers and their respective teams to bring new ideas, new approaches, new solutions and new energy to capitalise on new opportunities.

If we can engage our suppliers, our team and our customers to do things better and more quickly and to address micro challenges and to take macro opportunities that come our way, we are confident that we can grow and evolve in the years ahead as we have done successfully since starting out from humble beginnings in 1970.

Thank you for your support, and the confidence you have placed in our business to date; we sincerely hope that you will be and will choose to be part of the Alemlube journey well into the future.

GENERAL RANGE, CAPITAL WORKSHOP EQUIPMENT & LUBE SYSTEMS

CONTENTS GENERAL RANGE, CAPITAL WORKSHOP EQUIPMENT &

7.20

GENERAL RANGE, CAPITAL WORKSHOP EQUIPMENT & LUBE SYSTEMS

GREASE NIPPLES AND SINGLE & MULTI POINT GREASE LUBRICATORS

OILERS & LUBRICATORS

6.

AUTOMATIC LUBRICATION SYSTEMS

6. DUAL LINE METERING VALVES

7. MINING & INDUSTRIAL CABINETS

8. VOLUME INJECTORS & MANIFOLD KITS

9. TUBE, HOSE

CONTENTS

DISTRIBUTOR SUPPORT & PRODUCT MERCHANDISING

GENERAL RANGE & CAPITAL WORKSHOP EQUIPMENT

LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER

SECTION

SECTION 1 LUBRICATION & GREASE TRANSFER

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION

SECTION 1 LUBRICATION & GREASE TRANSFER

SECTION

SECTION 1 LUBRICATION & GREASE TRANSFER EQUIPMENT

SECTION 1 LUBRICATION & GREASE TRANSFER

DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER &

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER &

SECTION 2 DIESEL STORAGE, TRANSFER

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 2 DIESEL STORAGE,

SECTION 2 DIESEL STORAGE, TRANSFER

SECTION

SECTION 2 DIESEL STORAGE, TRANSFER & METERING EQUIPMENT

PETROL AND AVGAS TRANSFER & METERING EQUIPMENT

OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

4.2 OIL SUCTION GUNS

4.3 OIL GUNS

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

4.7 OIL UTILITY PUMP

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 4 OIL STORAGE,

OIL

SECTION 4 OIL STORAGE, TRANSFER & METERING

317825-8

317825-10

317825-20

317825-30

317825-40

317825-50

Alemlube 12mm ID R1 oil hose – 2.4m long

Alemlube 12mm ID R1 oil hose – 3m long

Alemlube 12mm ID R1 oil hose – 6m long

Alemlube 12mm ID R1 oil hose – 10m long

Alemlube 12mm ID R1 oil hose – 13m long

Alemlube 12mm ID R1 oil hose – 15m long

Alemlube 19mm ID R1 oil hose – 2.4m long

Alemlube 19mm ID R1 oil hose – 3m long

Alemlube 19mm ID R1 oil hose – 6m long

Alemlube 19mm ID R1 oil

Alemlube 19mm ID R1

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

SECTION 4 OIL STORAGE, TRANSFER & METERING EQUIPMENT

ALL ON WALL SERIES 3D WHEEL ALIGNER

The All On Wall series allows you to have all that is necessary for performing wheel alignment operations to be placed on a convenient wall-mounted panel, in this way freeing up useful space in the workshop. All alignment activities can be controlled from a 10" tablet that the operator can carry with him or place on the lifter during adjustment thanks to the built-in magnets. The aligner boasts a well-tested measuring head technology with HD cameras and Real 3D target that is fully wireless with Bluetooth transmission.

Wall mounted console supports measuring heads, batteries & tablet

Set of 4 self-centring 3-point clamps requiring no compensation

No console, or tower taking up valuable workshop space

Batteries & Tablet are charged on wall mounted console

Wall mounted brackets support wheel clamps & targets when not in use

• Long lasting batteries with 8 hours use

• Wi-Fi tablet controlled 3D wheel aligner

Totally PC free

Fully wireless

Manufactured in Italy

AIR, WATER AND WELDING GAS TRANSFER & METERING

SECTION 5

SECTION 5 AIR, WATER AND WELDING GAS TRANSFER &

SECTION

SECTION 5

AIR, WATER AND WELDING GAS TRANSFER &

SECTION

HOSE REEL HOSE STOPS

SECTION 5

SECTION 5

AIR, WATER AND WELDING GAS TRANSFER &

SECTION

ADBLUE ® AND FLUID TRANSFER & METERING EQUIPMENT

SECTION 6

ADBLUE® AND FLUID TRANSFER & METERING

SECTION 6

SECTION 6

FLUID

SECTION 6

ADBLUE® AND FLUID TRANSFER & METERING EQUIPMENT

WASTE OIL HANDLING, DRUM STORAGE, SPILL CONTAINMENT & FILTER CRUSHERS

INDUSTRIAL FUME EXTRACTION EQUIPMENT

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

ALEMLUBE

LARGE PORTABLE & LOCKABLE DIESEL REFUELLING PODS

• Australian made, heavy duty, robustly constructed polyethylene tank

• Flow rates of up to 80L/min on the high flow models

• Flow rates of up to 40L/min on the standard flow models

• Dispensing kits consists of a Piusi 12V pump, 4m antistatic fuel delivery hose, 2m battery cables & automatic shut off fuel nozzle

• Self-priming Piusi 12V electric pump with on/off switch & 2 year warranty

• Internal baffles aid tank stability

• Forklift lift points & tie down capability

• Suitable for storing & dispensing diesel fuel only

• Metered options also available

Dimensions

L1200: 1,700mm (W) x 1,100mm (H) x 999mm (D)

L1000: 1,700mm (W) x 950mm (H) x 999mm (D)

L800: 1,420mm (W) x 950mm (H) x 999mm (D)

CAPITAL WORKSHOP EQUIPMENT

SECTION 9

CAPITAL WORKSHOP EQUIPMENT

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

SECTION 9

CAPITAL WORKSHOP EQUIPMENT

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

SECTION 9

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

SECTION 9

CAPITAL WORKSHOP EQUIPMENT

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

SECTION 9 CAPITAL WORKSHOP EQUIPMENT

9.15 BEAD BREAKER

UNDERGROUND COAL MINE EQUIPMENT

SECTION 10 UNDERGROUND COAL MINE EQUIPMENT

SECTION 10

UNDERGROUND COAL MINE EQUIPMENT

SECTION 10 UNDERGROUND COAL MINE EQUIPMENT

COXREELS HOSE REELS

SECTION 11

SECTION 11. COXREELS HOSE REELS

COXREELS HOSE REELS

HOSE

SERIES

SECTION 11. COXREELS HOSE REELS

SLP LOW PRESSURE SERIES SECTION 11 COXREELS HOSE REELS

TWO BRAID HOSE

Maximum pressure up to 300psi.

Consult Factory For Reels With Hose

*These models are supplied with fuel hose

SLP & SMP SERIES

SECTION 11

SECTION 11. COXREELS HOSE REELS

COXREELS HOSE REELS

1125, 1175, 1185 & 1195 SERIES GEARED CRANK – MOTOR REELS

1125-4-100

1125-4-200

1125-4-325 1125-4-450

1125-5-50 1125-5-100 1125-5-175

1125-6-35 1125-6-50 1125-6-75 1125-6-100

1185-1124

$2,958.00 $2,958.00 $3,059.00 $3,754.00 $3,157.00

$3,211.00 $3,211.00 $3,323.00 $3,291.00 $3,537.00 $3,171.00 $3,171.00 $3,291.00 $3,291.00 $3,368.00

$3,930.00 $4,005.00 $4,005.00 $4,005.00

$5,524.00 $4,712.00 $5,000.00 $5,000.00 $5,000.00

$5,441.00 $5,441.00 $5,441.00

SECTION 11. COXREELS HOSE REELS SECTION 11 COXREELS HOSE REELS

ELECTRIC MOTOR ADD ONS

FOR ED MOTOR - SUFFIX ED (EXPLOSION PROOF) FOR AC MOTOR - SUFFIX EA (EXPLOSION PROOF) FOR 24V MOTOR - SUFFIX E

NOTE: Add electric motor price to the “Suffix E” list price

1125 STACKING BRACKET

SECTION 11

SECTION 11. COXREELS HOSE REELS

COXREELS HOSE REELS

11.3 HAND & POWER REWIND HOSE REELS DIMENSIONS

CHALLENGER & SWIVEL MOUNT HOSE REELS

1125 SERIES HAND CRANK & POWER REWIND HOSE REELS

SECTION

1175 SERIES

HAND CRANK & POWER REWIND HOSE REELS

100 SERIES SM SERIES

1125 & 1175 SERIES

CRANK ELECT. AIR

SECTION 11

COXREELS HOSE REELS

1185 SERIES

1195 SERIES

SECTION 11. COXREELS HOSE REELS

SECTION 11 COXREELS HOSE REELS

SECTION 11

SECTION 11. COXREELS HOSE REELS

COXREELS HOSE REELS

SERIES P, MP & SH

GREASE NIPPLES AND SINGLE & MULTIPOINT GREASE LUBRICATORS

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

SECTION 1

GREASE NIPPLES

SECTION 1 GREASE NIPPLES

GREASE NIPPLE ACCESSORIES & HEADER BLOCKS

ALEMLUBE IN ACTION AGRICULTURE

Agriculture today is a 24 hours per day business. Fast, efficient and timely operations are critical to success, hence the huge investments in seeders, sprayers, harvesters and other ag machines to ensure that crops are planted, nurtured and harvested at the optimum times.

Many agricultural machines have 50 to 100 grease points and work in extreme conditions, day and night. Keeping up with hand greasing can be extremely difficult because of the large numbers of grease points required to be

GREASE TUBE, HOSE & FITTINGS

SECTION 3

GREASE TUBE, HOSE & FITTINGS

SECTION 3 GREASE TUBE, HOSE & FITTINGS

SECTION 3

GREASE TUBE, HOSE & FITTINGS

SECTION 3 GREASE TUBE, HOSE & FITTINGS

SECTION 3

GREASE TUBE, HOSE & FITTINGS

3.6 PUSH IN HOSE TAILS

GREASE LUBRICATORS

& CUPS

SECTION 4

GREASE LUBRICATORS & CUPS

SECTION 4 GREASE LUBRICATORS

SECTION 4

GREASE LUBRICATORS & CUPS

SECTION 4

GREASE LUBRICATORS & CUPS

SECTION 4 GREASE LUBRICATORS & CUPS

4.16 MOUNTING ADAPTORS – IMPERIAL THREADS

SECTION 4

ALEMLUBE INHOUSE DESIGN, LIGHT ENGINEERING AND FABRICATION FACILITIES

Alemlube’s first class fabrication facilities are managed by highly qualified industry professionals with the right expertise and industrial design experience.

Specialities include workshop benches to any specification of height and width and special consideration in accommodating unique equipment or workshop accessories.

Bespoke requirements can be designed and included in the manufacturing, be it powder coated or stainless steel and inclusive of any corporate colour identity. Additionally, storage tanks for grease, oil and waste oil are consistently being manufactured to any specification and are completely compliant with all WHS regulations.

OIL NIPPLES

SECTION 5 OIL NIPPLES

RELIEF VALVES & AIR VENTS

SECTION 6 RELIEF VALVES & AIR VENTS

6.2 AIR VENTS

OILERS & LUBRICATORS

CONSTANT LEVEL OILERS

SECTION 1 CONSTANT LEVEL OILERS

Constant level oilers are used on a variety of applications, principally on pumps, and have proved very effective over many years. Adams is the largest manufacturer of constant level oilers in Europe, producing an extensive range of both fixed and variable constant level oilers.

Made in steel, zinc plated for protection, reservoirs are made from transparent impact resistant acetate mouldings so oil levels can be checked at a glance.

FINISH: Zinc Plate

MATERIAL: Steel or Aluminium Body, Plastic Bottle

SECTION 1

CONSTANT LEVEL OILERS

Steel construction, zinc plated for protection, the oil level on these units can be adapted to 3/8”. All models are fitted with glass reservoirs up to 500cc capacity designed for ease of replacement in the event of accidental damage. Side and base entry models with BSP and NPT connections to meet the widest range of applications.

SIGHT GRAVITY DRIP FEED OILERS

SECTION 2

SIGHT GRAVITY DRIP FEED OILERS

Sight gravity feed oilers are widely used as reservoirs for small gravity fed continuous or brush lubrication systems.

Sight gravity feed oilers are widely used as reservoirs for small gravity fed continuous or brush lubrication systems.

SECTION 2 SIGHT GRAVITY DRIP FEED OILERS

These oilers have shut off needle valve oil feed adjustment features. An acrylic sight tube in shank is provided so that the operator can adjust the feed to the proper volume. This type of oiler is especially adapted where regulation of the oil feed is required and we recommend this streamlined model because of its attractive appearance and the unbreakable feature. Max temp 65°C

Maximum operating temperature – 80ºC Electrical rating – 12VA IP 20 (DIN 40050)

In regard to the drip feed oilers listed in Sections 4.4 and 4.5, the following voltages are available; 12V DC, 24V DC, 110V-50Hz, 230V-50Hz, 415V-50Hz. When ordering, please state voltage required.

SIGHT GRAVITY DRIP FEED OILERS

Provides accurate control of flow rate from bulk reservoir to the bearing. Sight window provides visual flow indication.

SECTION 2 SIGHT GRAVITY DRIP FEED OILERS

OIL LEVEL SIGHT GAUGES

SECTION 3 OIL LEVER SIGHT GAUGES

The sight-window permits the direct observation of oil flow.

Machined to permit generous oil passage, the glass is held between oil sealing washers by an independent locking nut.

SECTION 3

OIL LEVER SIGHT GAUGES

OIL LEVEL WINDOWS

The “Adams” Steel/Glass Window Nut provides a most convenient form of inspection window for oil, fluid level indication, or similar applications. They are machined to a high degree of accuracy and fitted with a clear toughened glass window.

SECTION 4. OIL LEVEL WINDOWS

SECTION 4 OIL LEVER WINDOWS

4.2 SCREW IN – BRASS – WITH OR WITHOUT REFLECTOR

Fitted with Perspex Window

Suffix “R” means “With Reflector ”

Fitted with Toughened Glass Window

Suffix “R” means “With Reflector ”

These window nuts are machined from solid brass and fitted with either perspex or toughened glass. Recommended for transmissions and gear cases of all kinds.

Maximum working pressure – 100psi. Maximum working temperature – 70°C (Perspex).

Maximum working temperature – 100°C (Toughened Glass)

4.3 SCREW IN – PLASTIC – WITH REFLECTOR

Plastic oil level windows are moulded in a high tensile plastic and are fully resistant to weather and sunlight. All sizes supplied with oil resistant seals. The design of the rear white disc ensures that no liquid can remain in the indicator when the level falls below it.

Material – Plexiglass. Maximum working pressure – 42psi. Maximum working temperature – 80°C A

SECTION 4

SECTION 4. OIL LEVEL WINDOWS

OIL LEVER WINDOWS

Maximum working pressure – 10psi

Maximum temperature – 70ºC with 3psi

Suffix ‘A’ means “Oil Level” and line is engraved on window.

This Oil Window is eminently suitable for indicating, oil level and flow in reservoir, etc. It is a self-contained one piece unit, constructed of Plated Steel with a window of clear unbreakable plastic. This window is held in place by a special oil proof synthetic gasket.

Installation is extremely simple – the unit is pressed into a reamed hole in the wall of the reservoir. To ensure wall tightness the surface of the hole should be covered with a thin coat of hermatite or other oil-proof sealing material.

• Heavy duty full metal double pedestal construction

• No external aluminium components

• FRAS compliant hose assembly

• Hose capacity: 15m x 19mm ID

• 1,500psi (103bar) hose pressure rating

• 3/4"(f) inlet; 3/4"(f) outlet threads

• Manufactured using 4mm gauge steel

• Epoxy coated for increased wear resistance

• Weight of 38kg

• Suitable for air, water & fuel

SPRING LID & BALL CLOSING OIL HOLE COVERS

SECTION 5

SPRING LID & BALL CLOSING OIL HOLE COVERS

Visible oil supply always and no danger of breaking. Automatic feed positive and dependable. Style “SWF” is an Oiler which automatically feeds oil to the bearing allowing the oil reserve to be constantly visible. No adjustment is necessary and they are particularly recommended for machines which operate continuously. Maximum operating temperature of 65ºC

KEEN SPACE

CUSTOMISABLE ITALIAN MADE WORK AND STORAGE BENCHES

The new Keen Space range of benches, cabinets and storage modules available from Alemlube offers multiple solutions for your workshop needs and the combinations are countless. Thanks to its modularity, the Keen Space workbench is not just a bench, its wide range of combinations give you the ability to be able to organise your workspace at its best with everything you need right where it should be, easy to reach.

PRODUCT SPECIFICATIONS, FEATURES AND BENEFITS

• Customisable Bench Modules with storage – various work bench sizes, compositions ranging from 1,020mm to 2,000mm wide

• Worktop with ABS cover

• Drawer chest available with option for waste collection [ecological bin for differentiated waste]

• Central key locking systems & adjustable feet

• Open shelf kit options from 1,000mm x 1,500mm wide

• Front & side skirting options available

• Lighting kits available – distribution module for compressed air and power available

SECTION 5 SPRING LID & BALL CLOSING OIL HOLE COVERS

GENERAL USE

Is a widely used, drive-in oil hole cover particularly suited to applications where a flush fitting is essential. They will drive into die-castings without danger of cracking the metal.

CONSTRUCTION

All style A oilers are made with exact uniform drive shanks to very close limits. Due to their rigid construction these oilers may be driven into position without the danger of collapsing and loss in assembly is reduced to a minimum. The spout of an oil can can be inserted into these oilers very easily. They are self-closing and dirt and grit cannot reach and damage the bearings equipped with these oilers.

Zinc plate

Steel

Made from steel, the style BS oil hole covers are designed for a drive fit into a drilled hole. The shoulder permits insertion to a predetermined depth.

The large size oilers in the range make an effective filler cap on oil reservoirs where their self-closing lids ensure the filling orifice is adequately covered.

Nickel Plate

Steel

STYLE "A"

5.3 BALL CLOSING OIL HOLE COVERS – DRIVE IN

5.4

SECTION 5

SPRING LID & BALL CLOSING OIL HOLE COVERS

CONSTRUCTION

Style B oil hole covers are known as a plain drive-in type. The shanks are of exact uniform size and generous oil passage is provided. Equipped with a spring hinged lid, easily opened with an oil can spout and is self-closing. The cover is notched to hide the spring end ensuring a smooth surface. Wiping waste cannot catch on the spring nor can the operator’s hands be injured. These oilers are all steel construction and may be driven into position without danger of crushing and loss in assembling is reduced to a minimum. They also drive into die castings without danger of cracking the metal. Like the style BS oil hole covers, the larger sizes can be used as filler caps for reservoirs. Mesh strainers can be supplied to trap foreign bodies so the oil in the reservoir is free of debris.

B1604

STYLE "B"

B1625

5.5 DRIVE – VERTICAL – PLAIN

SECTION 5 SPRING LID & BALL CLOSING OIL HOLE COVERS

A two piece construction thus providing an alternative to style LS and allowing a wide choice of shank lengths for special applications.

FINISH: Nickel Plate

Body - Brass, Filler - Steel

5.7 SCREW-IN – VERTICAL – MISCELLANEOUS THREADS

CONSTRUCTION

The body is one piece and turned from solid bar stock. Provided with a generous oil passage. Threads are die cut and accurate. Equipped with patented spring hinge lid, easily opened with an oil can spout and is self-closing. The cover is notched to hide end of spring, causing a smooth surface. Wiping waste cannot catch on spring end, nor can the operators hands be injured in handling.

FINISH: Nickel Plate

-

-

STYLE "C"

C1740

SECTION 5

SPRING LID & BALL CLOSING OIL HOLE COVERS

GUIDES FOR OILING

STYLE "F"

Dirt and grit cannot reach and injure bearings equipped with these oil hole covers. The cover sits above the bearing, is quickly noticed and naturally not overlooked during the process of oiling.

Nickel Plate

*With wick feed and syphon tube.

CONSTRUCTION

STYLE "L"

Body - Brass, Filler - Steel

The body of style LS is formed in one piece from hot brass stampings and carefully drilled to cause a generous oil passage. This particular oil cup is used extensively on small motors and machinery where side oiling is necessary. Threaded shanks are die cut and accurate. Drive shanks are machined to exact uniform sizes.

FINISH:

CONSTRUCTION AND USE

Brass body and Anodised Aluminium Caps. Features a knurled screw top which is chained to body to prevent loss. This is a dust proof oil filler cap and has many applications. Caps attached to adaptors by internal chain.

5.8 SCREW IN – 90º – MISCELLANEOUS THREADS

5.9 OIL FILLER CAPS & ADAPTORS

SECTION 5 SPRING LID & BALL CLOSING OIL HOLE COVERS

CONSTRUCTION AND USE

Style D oil hole covers are equipped with patented spring hinge lid, easily opened with oil can spout and self-closing. The cover is notched to hide end of spring causing a smooth surface. Wiping waste cannot catch on spring end, nor can hands be injured in handling.

STYLE "D"

The upright prominent appearance of this oiler causes it to be instantly recognised as an oil cup and naturally it is not overlooked during the process of oiling.

SECTION 5

SPRING LID & BALL CLOSING OIL HOLE COVERS

CONSTRUCTION AND USE

Style M is a very popular oil cup where side oiling is necessary. It is substantially made, the cup drawn from heavy gauge steel is pierced and plunged to form a reliable fixing for the hexagon shank, which is machined from the solid bar stock and is driven in and copper brazed to ensure a leak proof connection. Equipped with spring hinge lid, easily opened with an oil can spout and is selfclosing. The cover is notched to hide end of spring, causing a smooth surface. Wiping waste cannot catch on end of spring, nor can hands be injured in handling.

SPECIAL NOTE

The letters WF following the part numbers denote they have syphon tube and wick fitted.

RETARD OIL FEED

A syphon tube and wick can be fitted in the bowl to feed the oil gradually at a small additional cost.

DISTANT BEARINGS

These oil cups can be supplied with a female shank for connecting a pipe or nipple to reach distant bearings or reservoirs.

LOW PRESSURE OIL SYSTEMS

SECTION 6 LOW PRESSURE OIL SYSTEMS

Suitable to be used with the metered flow units indicated in Section 6.2, these 240 volt electric piston pumps can generate a working pressure of up to 42psi. Supplied standard with a low level control, all pumps have a 1 litre reservoir.

Other specifications include: delivery rates: 1 to 3 cm3, inbuilt control: fixed pause times, lubricant type: up to 250 cst max, low level control: included, outlet: 4mm tube.

Contact our Lubrication Systems Department who can recommend the right pump for your application.

SECTION 6 LOW PRESSURE OIL SYSTEMS

AUTOMATIC LUBRICATION SYSTEMS

ALEMLUBE PROGRESSIVE SYSTEM PUMPS

SECTION 1. ELECTRIC PUMPS

SECTION 1 PROGRESSIVE SYSTEM ILC MAX PUMPS

1.1 PUMPS WITHOUT TIMERS

4K.Z01082.012

4K.Z01082.014

4K.Z01082.015

APPLICATIONS

For use in system with pre-existing or built in timers, or for applications for control by PLC.

SPECIFICATIONS

Voltage: 24VDC

Max current draw at 300 Bar: 2.5 amps (24VDC)

Lubricant type: Up to Grease NLGI2

Reservoir sizes: 4kg, 8kg LP, 16kg all with low level switch standard

No of outlets: Maximum of 3

Delivery per pump element: Fixed element – 3.52cm 3 (24VDC)

Adjustable element – 0.92 to 3.52cm 3 (24VDC)

Pressure Relief Valve: 280 Bar fitted to each pump element Outlet size: 1/4"BSP

ELECTRIC PUMPS

4K.Z01082.012

4K.Z01082.013

Alemlube 24VDC pump with 4kg reservoir, with low level switch, 1 x fixed pump element with relief valve $3,264.00

Alemlube 24VDC pump with 8kg reservoir, with low level switch, 1 x fixed pump element with relief valve $3,737.00 *4K.Z01082.014

Alemlube 24VDC pump with 8kg LP reservoir with low level switch, 1 x fixed pump

*4K.Z01082.015

Alemlube 24VDC pump with 16kg LP reservoir with low level switch , 1 x fixed pump element $4,380.00

1.2 PUMPS WITH BUILT IN FULL FUNCTION CONTROLLERS

APPLICATIONS

For use in transport, agriculture, construction & mining, industry and can be programmed for full monitoring.

4K.16.24DC.FCT.G

SPECIFICATIONS

Voltage: 12VDC, 24VDC, 240VAC

Max current draw at 300 Bar: 5 amps (12VDC) or 2.5 amps (24VDC) or 1 amp (240VAC)

Lubricant type: Up to Grease NLGI2

Reservoir sizes: 4kg, 8kg LP, 16kg all with low level switch standard

No of outlets: Maximum of 3

Delivery per pump element: Fixed element – 3.68cm 3 (12VDC) or 3.52cm 3 (24VDC) or 4.64cm 3 (240VAC)

Adjustable element – 0.93 to 3.68cm 3 (12VDC) or 0.92 to 3.52cm 3 (24VDC) or 0.99 to 4.64cm 3 (240VAC)

Pressure Relief Valve: 280 Bar fitted to each pump element

Outlet size: 1/4"BSP

Controller adjustment: On time – Digital - adjustable in minutes and seconds

Off time – Digital - adjustable in minutes and hours

Controller operating modes: Lubrication by time and pause by time (standard)

Lubrication by time and pause machine counts (selectable)

Lubrication by divider cycles and pause by time (selectable)

Prelube is selectable

Alarm modes:

Low level alarm (standard)

High pressure alarm (optional with addition of HP switch)

Cycle alarm (optional with addition of proximity on divider)

4K.4.12DC.FCT.G

4K.2.12DC.FCT.G

4K.2.24DC.FCT.G

4K.2.230.FCT.G

4K.8.24DC.FCT.G

4K.4.12DC.FCT.G

Alemlube 12VDC pump with 2kg reservoir, with controller, with low level switch, 1 x fixed pump element with relief valve $2,880.00

Alemlube 24VDC pump with 2kg reservoir, with controller, with low level switch, 1 x fixed pump element with relief valve $2,880.00

Alemlube 240VAC pump with 2kg reservoir, with controller, with low level switch, 1 x fixed pump element with relief valve $3,384.00

Alemlube 12VDC pump with 4kg reservoir, with controller, with low level switch, 1 x fixed pump element with relief valve $3,456.00

4K.4.24DC.FCT.G

Alemlube 24VDC pump with 4kg reservoir, with controller, with low level switch, 1 x fixed pump element with relief valve $3,456.00 4K.4.230.FCT.G

240VAC pump with 4kg reservoir, with controller, with low level switch, 1 x fixed pump element with relief valve $3,961.00

4K.8.12DC.FCT.G

SECTION 1. ELECTRIC PUMPS

SECTION 1 PROGRESSIVE SYSTEM ILC MAX PUMPS

TRITON PUMP

APPLICATIONS

The Alemlube TRITON pump is suited to mining and heavy duty operating conditions. With a 25kg capacity reservoir designed for high speed filling and built in fill shut off, the Alemlube TRITON is both efficient and environmentally friendly.

Designed to supply progressive systems on excavators, dozers, wheel loaders and other high production machines, the Alemlube TRITON is built to withstand vibration and harsh conditions.

FEATURES

• 280Bar operating pressure

• 25kg capacity

• Auto fill shut off

• Powder coated steel construction

• 300 micron high pressure fill point strainer

• 12VDC or 24VDC with built in controller

• Flow rate – 3.68cm 3 per minute (12VDC), 3.52cm 3 per minute (24VDC)

• Built in low level monitoring

• Available with optional full cycle monitoring

Alemlube 24VDC pump station with 25kg bulk fill reservoir, low level and high pressure alarms. Auto shut-off fill system

APPLICATIONS

For use in transport, agriculture, construction & mining, industry and can be programmed for full monitoring.

SPECIFICATIONS

Voltage: 12VDC, 24VDC

Max current draw at 200 Bar: 7.5 amps (12VDC) or 3.8 amps (24VDC)

Lubricant type: Up to Grease NLGI2

Reservoir sizes: 1kg with low level switch standard

No of outlets:

Maximum of 2 large and 8 small outlets

Delivery per pump element: Fixed element – 2.4cm 3

Adjustable element – 0.3 to 2.4cm 3

Small elements – 0.1cm 3 to 1cm 3

Pressure Relief Valve: 280 Bar fitted to each pump element

Outlet size: 1/4"BSP

Controller adjustment: On time – Dipper switch – adjustable from 2 sec to 32 min Off time – Dipper switch - adjustable from 2 min to 32 hours

Controller operating modes: Lubrication by time and pause by time (standard) Lubrication by divider cycle count and pause by time (selectable) Prelube is selectable

Alarm modes: Low level alarm (standard) Cycle alarm (optional with addition of proximity on divider)

3K.12TL.F

SECTION 1. ELECTRIC PUMPS

SECTION 1 PROGRESSIVE SYSTEM ILC MAX PUMPS

•

PROGRESSIVE SYSTEM & MULTILINE INDUSTRIAL PUMPS

SECTION 2 PROGRESSIVE SYSTEM & MULTILINE INDUSTRIAL PUMPS

APPLICATIONS

The PEG-5/10N pumps are ideal for all types of small to medium industrial lubrication applications feeding to DMX and /or DPX progressive dividers.

SPECIFICATIONS

Number of outlets: 1 to 3

Flow rate per revolution with fixed pumping element: 0.16cc

Flow rate per revolution with adjustable pumping element: 0.01 - 0.16cc

Suitable lubricants: Grease up to a maximum consistency of NLGI 2 Mineral oils 50-1500 cSt

Maximum operating pressure: 4,200psi (300bar)

Reservoir capacity: 5kg or 10kg (PEG), 5L or 10L (PEO)

Temperature: -30°C – +80°C

Outlet size: 1/4"BSP

Delivery fitting: 1/4"G

PEG Electric Levels

Power supply voltage: 250V AC, 125V DC

Absorption: 5A (250V AC), 0.4A (125V DC)

Protection rating IP65

PEG-5N 230VAC, 5kg grease reser, with low level sw, 1:80 ratio, 17 RPM, 1 x adjustable pump

PEG-10N 415VAC, 10kg grease reser, with low level sw, 1:80 ratio, 17

NOTE: Additional pump elements (fixed & adjustable) can be purchased - up to 3 maximum Gear reduction ratios of 1:30 & 1:50 are available for higher flow rates if required - POA

Other voltage motors available - POA

Pumps suitable for oil are also available - POA

SECTION 2 PROGRESSIVE SYSTEM & MULTILINE INDUSTRIAL PUMPS

APPLICATIONS

The PEG-250N (grease) pumps are ideal for applications with up to 15 lubrication points, directly supplied from the pump without divider valves. Alternatively, up to 15 secondary dividers can be connected to the pump, each with its own pump element.

SPECIFICATIONS

Number of outlets: 1 to 15

Flow rate per cycle with fixed pumping element: 0.16cc / rev

Flow rate per cycle with adjustable pumping element: 0.01 - 0.16cc / rev

Suitable lubricants: Grease up to a maximum consistency of NLGI 2

Maximum operating pressure: 5,082psi (350bar)

Tank capacity: 25kg

Electric level with capacitive sensor: 10-30V DC <200mA maximum

*90.930.4.230

*90.930.4.415

PEG-250N 230VAC, 25kg grease reser, with low level sw, 1:80 ratio, 17 RPM, 1 x adjustable pump element

$7,504.00

PEG-250N 415VAC, 25kg grease reser, with low level sw, 1:80 ratio, 17 RPM, 1 x adjustable pump element $7,504.00

NOTE: Additional pump elements (fixed and adjustanble) can be purchased - up to 15 maximum Gear reduction ratios of 1:30 and 1:50 are available for higher flow rates if requited - POA

Other voltage motors available - POA

Pumps suitable for oil are also available - POA

DUAL LINE PUMPS

SECTION 3

DUAL LINE PUMPS

APPLICATIONS

Mini Twin-Pump available with a 10kg or 30kg reservoir, have a maximum operating pressure of 350bar and a 25cc/min flow rate. They are suitable for small to medium sized dual line systems. Pumps are provided with relief valve, check valve, lubricant filter, pressure gauge and robust metal base. Pumps are designed on a modular basis and they can be configured with different types of reversing valves.

SPECIFICATIONS

Maximum operating pressure: 5,000psi (350bar)

Lubricant output: 25cm 3 minute

Safety valve:

Adjustable from 50 to 400bar, default set to 300bar

Main line connection: 3/8" BSP

Reversing valve:

Electric, Pneumatic or Hydraulic

Protection class: IP-65

Drive motor: 0,18Kw

Mini-Twin 415VAC, 30kg grease reser, with ultrasonic low level, without reversing valve, with metal mounting base

$12,779.00

APPLICATIONS

TWIN-2 dual line pump is available with 30kg or 100kg reservoir, with flow rates of 200cc/min or 400cc/ min. Maximum operating pressure of 400bar. They are suitable for medium to large sized dual line systems. Pumps are provided with relief valve, check valve, lubricant filter, pressure gauge and robust metal base. Pumps are designed on a modular basis and they can be matched with different types of reversing valves.

SPECIFICATIONS

Maximum operating pressure: 5,800psi (400bar)

Lubricant output: 200cc/min or 400cc/min

Safety valve: Adjustable from 50 to 400bar, calibrated as standard at 350bar

Main line connection: 3/8" BSP

Reversing valve: Electric, Pneumatic or Hydraulic Protection class: IP-65 Drive

TWIN-2 415VAC, 100kg grease reser, 400cc/min, with ultrasonic high/low level, without reversing valve, with metal mounting base

NOTE: Add reversing valve if required from the sections below

Other voltage motors available - POA

Other reservoir level monitoring options available - POA

Pumps suitable for oil are also available - POA

$21,110.00

3.2 TWIN-2 DUAL LINE PUMP

DPX PROGRESSIVE METERING VALVES

SECTION 4 DPX PROGRESSIVE METERING VALVES

APPLICATIONS A compact, high quality progressive divider for all applications.

“QUICK QUOTE” VALVE PRICES FOR FULLY ASSEMBLED AND TESTED BLOCKS (A $10.00 charge is included for assembly and testing before despach.)

SPECIFICATIONS Standard

Nickel Plated Steel (ZnNi) Maximum Pressure:

bar (4500 psi) Lubricant Type: Oil or Grease to NLGI 2

Minimum and Maximum Displacement Per Outlet: 25mm3 to 210mm3

Maximum Operating Temperature: 100°C

ASSEMBLED DIVIDERS

SECTION 4 DPX PROGRESSIVE METERING VALVES

DPX INLET SECTIONS

DPX CENTRE SECTIONS

SECTION 4 DPX PROGRESSIVE METERING VALVES

4.5 VALVE ASSEMBLY TIE RODS

SECTION 4 DPX PROGRESSIVE METERING VALVES

DMX INDUSTRIAL PROGRESSIVE METERING VALVES

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING VALVES

APPLICATIONS

The DMX modular system consists of two main parts: Base (divided into initial base, intermediate base and final base) and the Metering Elements (available in different outputs).

The system can be easily extended and its modularity allows a low cost component replacement. The assembled base can be installed and connected without Modular Metering elements to make easier the Tube tracking process. Metering elements can be installed later.

SPECIFICATIONS

Working pressure

Lubricants [at minimum working temperature]

Minimum 15Bar – Maximum 5,800psi (400bar)

Mineral oil with minimum viscosity of 15 cSt at fluid working temperature.

Grease consistency NLGI-2 maximum

Working temperature From -40 °C to + 120 °C

Output for outlet (mm 3)

Inlet

Available piston size 40/ 80 / 160 / 250 / 350 / 400 / 500 / 650

1/4" BSP

Outlet 1/8" BSP

Number of elements From 3 to 20

Cycles/min

Gasket

Parts protective coating

Maximum 500

O-Ring Viton 90sh

Zinc-Nickel 800 hour salt spray tested

Material Steel, Zn-Ni plated (free of Cr-V) or SS316L

Metering element

Supplied with screw

Element: initial base Supplied with screw and O-Ring

Element: intermediate base Supplied with screw, adapter screw and O-Ring

Element: final base Supplied with screw

Metering valves interchangeability Graco MSP - Bijur series M2500G - Dropsa series SMX

Bridge element

By-pass element

Supplied with adapter screw. Screw replace junctions bridge in order to convey the output of one or more output into the next one.

Supplied with screw. They are used as a reserve for additional points or for metering valves replacement in case of output reduction

Monitoring options Cycle pin or inductive switch

Air purge 2 valves included in the final base

Torque tightening (base) 8 Nm

Torque tightening (elements) 15 Nm

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING VALVES

NOTE: Alemlube dividers are flow tested before dispatch

Pre-assembled DMX bases save time & money

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING

5.3 DMX BASE SECTIONS

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING VALVES

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING VALVES

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING VALVES

SECTION 5 DMX INDUSTRIAL PROGRESSIVE METERING VALVES

The DMX-A model is designed to send a flow of air/oil to specific lubrication points. The continuous supply of a mixed air stream, besides lubricating, it also has a cooling effect.

Air exiting the lubrication point prevents the ingress of moisture and contamination. The air/oil system does not produce oil mist and therefore does not produce fogging. The constant air flux helps lubricant advancement along the internal walls. When the lubricant reaches the final point it is spread in particles.

Aqpplications are high speed rotating element bearings, chains, gears, slideways, points that can only be reached by a spray

DUAL LINE METERING VALVES

SECTION 6 DUAL LINE METERING VALVES

SPECIFICATIONS

Construction: Fully modular

Material: Zinc Nickel (Zn-Ni) plated steel

Maximum working pressure: 5,600psi (400bar)

Lubricant Type: Oil or Grease to NGLI#2

Displacement:

DR3 – 0.15 to 3.0cc adjustable DR5 – 0.5 to 24cc adjustable

-30ºC to +80ºC

SECTION 6 DUAL LINE METERING VALVES

MINING & INDUSTRIAL CABINETS

SECTION 7 MINING & INDUSTRIAL CABINETS

• Alemlube prebuilt cabinet lubrication systems are ideal for industrial, mining and mineral processing fixed plant applications.

• Alemlube's ALS team can design the divider configuration to suit the lube requirements, and add monitoring systems to suit the applications needs.

• The cabinet systems can be utilised as complete fully tested stand alone systems, or they can act as the pump/master divider combination for much larger systems with secondary dividers installed downstream.

• The Medium and Large Mining/Industrial cabinets have outlets on the side gland plates which can be engraved with the lubrication points names.

• The medium and large cabinet systems are based on Australian made heavy duty custom designed cabinets designed to take the stress and vibration of mining and mineral processing plant applications.

• All cabinets are pre-wired and fully checked and pressure tested before dispatch to ensure easy leak free installation on site.

INDUSTRIAL CABINETS - WITH 4KG ALS PUMP & DPX DIVIDERS - WITH BUILT IN CONTROLLER

• Heavy duty Australian made cabinet 600h x 500w x 300d with ALS 24vdc 4kg pump, with timer, with DPX divider installed with 6mm bulkhead outlets on left and right.

• Includes grease point enabling manual lubrication or priming of the system.

• For connection to bearings with 6mm tube fittings.

• Pump is standard with low level alarm and red flashing LED beacon on top wired to terminal strip inside the cabinet.

• Includes compact 150 micron fill point strainer.

• The standard pump controller can be configured to work with a divider cycle switch to accurately monitor lubricant flow and provide a cycle fault alarm in addition to the standard low level alarm

SMALL CABINET 4KG 24DC PUMP WITH CONTROLLER, WITH LOW LEVEL ALARM CONTROLLED BY THE PUMP

SMALL CABINET 4KG 24DC PUMP WITH CONTROLLER, WITH CONTROL BY CYCLES & LOW LEVEL ALARM CONTROLLED BY THE PUMP

SMALL CABINET 4KG 24DC PUMP WITHOUT CONTROLLER , FOR CONTROL BY SITE PLC WITH CYCLE SWITCH & LOW LEVEL SWITCH

SECTION 7 MINING & INDUSTRIAL CABINETS

CABINETS - WITH 8KG ALS PUMP & DMX DIVIDERS - WITH BUILT IN CONTROLLER

• Super duty Australian made cabinet with dust cover over the door 800h x 600w x 300d with ALS 24vdc 8kg pump, with timer, with DMX divider installed and tubed to 7/16"JICM bulkheads on the left and right gland plates.

• Includes outlet grease filter, pressure gauge and grease point enabling manual lubrication or priming of the system.

• All outlets include 150 Bar pop out pressure indicator for easy troubleshooting.

• For connection to bearings with 7/16"JIC hose ends.

• Pump is standard with low level alarm and red flashing LED beacon on top wired to terminal strip inside the cabinet.

• Pump includes fill point filter and fill coupling.

• The standard pump controller can be configured to work with a divider cycle switch to accurately monitor lubricant flow and provide a cycle fault alarm in addition to the standard low level alarm

MEDIUM CABINET 8KG 24DC PUMP WITH CONTROLLER, WITH LOW LEVEL ALARM CONTROLLED BY THE PUMP

MEDIUM CABINET 8KG 24DC PUMP WITH CONTROLLER, WITH CONTROL BY CYCLES & LOW LEVEL ALARM CONTROLLED BY THE PUMP

MEDIUM CABINET 8KG 24DC PUMP WITHOUT CONTROLLER , FOR CONTROL BY SITE PLC WITH CYCLE SWITCH & LOW LEVEL SWITCH

2

3

4

SECTION 7 MINING & INDUSTRIAL CABINETS

MINING/INDUSTRIAL CABINETS - WITH 16KG ALS PUMP & DMX DIVIDERS - WITH BUILT IN CONTROLLER

• Super duty Australian made cabinet with dust cover over the door 1,000h x 800w x 400d with ALS 24vdc 16kg pump, with timer, with DMX divider installed and tubed to 7/16"JICM bulkheads on the left and right gland plates.

• Includes outlet grease filter, pressure gauge and grease point enabling manual lubrication or priming of the system.

• All outlets include 150 Bar pop out pressure indicator for easy troubleshooting.

• For connection to bearings with 7/16"JIC hose ends.

• Pump is standard with low level alarm and red flashing LED beacon on top wired to terminal strip inside the cabinet.

• Pump includes fill point filter and fill coupling.

• The standard pump controller can be configured to work with a divider cycle switch to accurately monitor lubricant flow and provide a cycle fault alarm in addition to the standard low level alarm

L*ARGE C*ABINET 16KG 24DC PUMP WITH CONTROLLER, WITH LOW LEVEL *AL*ARM CONTROLLED BY THE PUMP

L*ARGE C*ABINET 16KG 24DC PUMP WITH CONTROLLER, WITH CONTROL BY CYCLES & LOW LEVEL *AL*ARM CONTROLLED BY THE PUMP

L*ARGE C*ABINET 16KG 24DC PUMP WITHOUT CONTROLLER , FOR CONTROL BY SITE PLC WITH CYCLE SWITCH & LOW LEVEL SWITCH

3

4

5

VOLUME INJECTORS & MANIFOLD KITS

SECTION

•

•

TUBE, HOSE FITTINGS & HEADER BLOCKS

SECTION 9 TUBE, HOSE FITTINGS & HEADER BLOCKS

SECTION 9 TUBE, HOSE FITTINGS & HEADER BLOCKS

WASTE OIL HANDLING

Alemlube supplies all necessary equipment for the safe, clean and efficient management of waste oil from cars, light commercial and commercial vehicles. Mobile waste oil drainer/evacuators, fixed hose reels and diaphragm pumps have been specifically designed & manufactured for the collection of motor oil, gear oil and other non-aggressive oils.

SECTION 9 TUBE, HOSE FITTINGS & HEADER BLOCKS

SECTION 9 TUBE, HOSE FITTINGS & HEADER BLOCKS

9.9 PUSH IN TUBE UNION

9.10 DUST COVER FOR PUSH IN FITTINGS

DISTRIBUTOR SUPPORT

Alemlube has available a wide range of countermats,

AGRICULTURE

TRADE SHOW SUPPORT

Alemlube is consistently represented at Trade Shows and Field Days in metropolitan and regional districts throughout Australia and New Zealand.

Showcasing a wide and comprehensive range of general workshop and specialised equipment marketing directly to the industrial, automotive, mining, agricultural, transport and food& beverage sectors, Alemlube’s team of professional experts in their respective fields is always on hand to present the latest in product development and advancement to offer the end user reliable, efficient and cost effective solutions to deliver improved productivity.

PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

• Displays 6 x Alemlube quick connect grease gun couplers

• Features grease gun coupler, flexible hose and grease nipple for hands on demonstrations

• Free

•

showroom display stand or pegboard wall mounting options

with Alemlube branding

• Displays 6 x Alemlube lock on air chucks

• Features lock on air chucks, flexible hose and grease nipple for hands on demonstrations

• Free standing showroom display stand or pegboard wall mounting options

• Steel construction with Alemlube branding

SECTION 1 PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

SECTION 1 PRODUCT MERCHANDISING

1.10 TRADE SHOW TABLET & COUNTER DISPLAYS

The unique Alemlube Tablet Displays have been designed and manufactured to showcase specific Alemlube product information at Trade Shows, Field Days and Exhibitions.

Three individually branded designs are dedicated to represent Alemlube General Range products, the Alemlube Automotive workshop equipment range and the Italian made Ravaglioli workshop equipment range.

PULSARLUBE SINGLE POINT AND MULTI POINT GREASE LUBRICATOR COUNTER DISPLAYS

The Pulsarlube Single and Multi Point Grease Lubricator Counter display units provide an informative and concise means of marketing the features and benefits of these versatile lubricators, right at your sales counter. Requiring very little space, each unit displays the actual product allowing the customer to accurately gauge the size and potential applications of the grease lubricators and to be aware of their functions, features and full specifications.

AATSTD0617 Alemlube Automotive Trade Show Tablet Display 1

RTSTD0617 Ravaglioli Trade Show Tablet Display 1

SECTION 1 PRODUCT MERCHANDISING

Dimensions:

The Alemlube Lube Systems Construction Machine demo board provides a point of sale marketing tool to promote lubrication systems sales.

Compact design enables the demo board to fit in almost any available space and presents the look and feel of the Alemlube Lube Systems with a pump and divider valve with the actual hose and fittings used on typical installations. Below the lubrication system components concise bullet points on why lubrication systems should be considered and key performance information have been listed.

Holders for business cards and brochures are also included to make the display complete.

550mm(W) x 600mm(D) x 1,950mm(H) 1.11 337700CMN LUBRICATION SYSTEMS – CONSTRUCTION MACHINES

SECTION 1 PRODUCT MERCHANDISING

Dimensions:

The Alemlube Lube Systems Truck and Trailer demo board provides a point of sale marketing tool to promote lubrication systems sales.

Compact design enables the demo board to fit in almost any available space and presents the look and feel of the Alemlube Lube Systems with a pump and divider valve with the actual hose and fittings used on typical installations. Below the lubrication system components concise bullet points on why lubrication systems should be considered and key performance information have been listed.

Holders for business cards and brochures are also included to make the display complete.

550mm(W) x 600mm(D) x 1,950mm(H)

1.12 337700TATN LUBRICATION SYSTEMS – TRUCK & TRAILER

SECTION 1 PRODUCT MERCHANDISING

Dimensions: 550mm(W) x 600mm(D) x 1,950mm(H)

The Alemlube Lube Systems Agriculture demo board provides a point of sale marketing tool to promote lubrication systems sales.

Compact design enables the demo board to fit in almost any available space and presents the look and feel of the Alemlube Lube Systems with a pump and divider valve with the actual hose and fittings used on typical installations. Below the lubrication system components concise bullet points on why lubrication systems should be considered and key performance information have been listed.

Holders for business cards and brochures are also included to make the display complete.

INDEX

MODEL PAGE

01.190.1 253

253

253

253 01.190.5 253 01.190.6 253 01-1614 216 01A12LM 42 01N12LM 94 02.940.1.G 253 02.940.1.G.01 253 02.940.1.G.02 253 02.940.1.G.03 253 02.940.1.G.04 253 02.940.1.G.05 253

02.940.1.G.06 253 04.052.0 235 06.052.0 235 07.270.5 242 07.270.6 242 09.600.3 234 09.600.4 234 09.710.4 241 09.710.5 241 09.710.7 241

001007 59, 60 001007-6 59

001007-12 59 001007-25 59 001014 59, 60

001014-6 59 001014-12 59

001014-25 59 001014-PU 59 001014-ST 59

001021 59, 60 001021-6 59 001021-12 59 001021-25 59 001021-PU 59 001021-ST 59 001045 59 001083 60 001090 60 001106 60 001113 60 001120 60 001137 60 001373 59 001380 59 001397 59 001520 60 001530 60 097127 223 1 1x1/8 185 1x1/8BR 184 112-3-100 147, 148

MODEL PAGE

112-3-150 147, 148

117-3-250 147, 148

117-3-400 147, 148

117-3-550 147

112-3-100-CM 147

112-3-100-CM 147

112-3-150-CM 147

117-4-225-CM 147

112-3-150 147, 148

112-3-150-CM 147

112-4-75 147, 148

117-4-225 147, 148

117-4-350 147, 148

117-5-100 147

112W-1-100 92

117-3-200-DM 147

117-4-225-DM 147

117-3-250 147, 148

117-3-400 147, 148

117-3-550 147, 148

117-4-225 147, 148

117-4-225-CM 147

117-4-225-DM 147

117-4-350 147, 148

117-5-100 147

117-5-100-SS 92

117W-1-200 92

1000MFN 60

1000-OB 61

1125-4-100

142, 146, 148

1125-4-200 146, 148

1125-4-325 146, 148

1125-4-450 146, 148

1125-4-500 146, 148

1125-5-50 48, 146, 148

1125-5-100

142, 146, 148

1125-5-175 146, 148

1125-5-200 146, 148

1125-5-250 146, 148

1125-6-35 47, 146, 148

1125-6-35C 46

1125-6-50 146, 148

1125-6-75 142, 146, 148

1125-6-100 146, 148 1167S 168 1169S 168

1175-6-50 47, 146, 149

1175-6-200 146 1175-6-100

142, 146, 149

1175-6-125 146, 149

1175-6-150 146, 149

1175-6-200 146, 149

1175-8-50 149

1175-8-75 149

1175-8-100 149

1175-8-125 149

1175-8-150 149

MODEL PAGE

1185-1124 46, 146, 150 1185-3328 146 1185-1524 146, 150 1185-2024 146, 150 1185-2028 146, 150 1185-2528 146, 150 1185-3324 146, 150 1185-3328 146, 150

1195-932 146, 150 1195-3228 146 1195-1332 146, 150 1195-1728 146, 150 1195-2032 146, 150 1195-2428 146, 150 1195-3228 146, 150 1195-3328 146

1250MD-2 183 1250MD-3 183 1250MD-4 183 1250MD-5 183 1250MD-6 183 1250MD-7 183 1250MD-8 183

1250RC-1 183 1250RO-1 198 1250RO-2 198 1250RO-3 198 1250RO-4 198 1266S 168 1316S 168 1336S 168 1346S 168 1347S 168 1349S 168 1366S 168 1367S 168 1369S 168 1376S 168 1377S 168 1379S 168 1386S 168 1387S 168 1389S 169

98

2.TR.05 233

2.TR.06 233 2.TR.07 233

102

102 108000 16 108100 16 108501 22 131000 190 147610 100 186311 73, 140

1000272 178, 186, 260 1000295 178, 260 1000571 177, 259 1000685 258 1000686 258 1000696 177, 186, 259 1000708 241 1000770 257 1000771 257 1000773 257 1000774 257 1000833 177, 258 1001029 234

1001050G 178, 261 1001054G 178, 261

1001058G 178, 261 1001062G 178, 261 100120200-0704 177, 258

2

2.A.025.D.1N.M10 232

2.A.045.D.1N.M10 232

2.A.075.D.1N.M10 232

2.A.105.D.1N.M10 232

2.B.025.D.1N 232

2.B.045.D.1N 232

2.B.045.D.2V 232

2.B.045.D.3I.M12 232

2.B.075.D.1N 232

2.B.075.D.2V 233

2.B.075.D.3I.M12 232

2.B.105.D.1N 232

2.B.105.D.2V 233

2.B.105.D.3I.M12 232

2.C.025.D.1N.M10 233

2.C.045.D.1N.M10 233

2.C.045.D.3I.M10.M12 233

2.C.075.D.1N.M10 233

2.C.075.D.3I.M10.M12 233

2.C.105.D.1N.M10 233

2.C.105.D.3I.M10.M12 233

2.TR.03 233

2.TR.04 233

2.TR.08 234 2.TR.09 234 2.TR.10 234

2.TR.11 234 2.TR.12 234

2x1/4 185 2x1/4BR 184 2x1/8 185 2x1/8BR 184 200A 15

200ACB 15 201S 139, 141, 142 208S 168 211S 168 220A 15 220ACB 15 225 106 280-SGS 184 2000MFN 60 2002G 64

105

96

96

96 2501 184 2502 184 2503 184 20011 130 20033 130 20040PA 52 20045P 52 20049GA 51 20055 130 20055TS 130 20056G 51 20066N2 130 20068PA 51 20077 130 20080P 51 20084N 130 20088 130 20215 93 20216 93 21040 58 21041 58 22585 115 29304 78 29304-504C 78 29304-506C

3

03.355.5 242

03.355.8 242

3.DMX.03 238

3.DMX.04 238

3.DMX.004.D.1N 239

3.DMX.05 238

3.DMX.06 238

3.DMX.07 238

3.DMX.08 239

3.DMX.008.D.1N 239

3.DMX.008.D.2V 240

3.DMX.008.D.3I.12 240

3.DMX.09 239

3.DMX.10 239

3.DMX.016.D.1N 239

3.DMX.016.D.2V 240

3.DMX.016.D.3I.12 240

3.DMX.025.D.1N 239

3.DMX.025.D.2V 240

3.DMX.025.D.3I.12 240

3.DMX.035.D.1N 239

3.DMX.035.D.2V 240

3.DMX.035.D.3I.12 240

3.DMX.040.D.1N 239

3.DMX.040.D.2V 240

3.DMX.040.D.3I.12 240

3.DMX.050.D.1N 239

3.DMX.050.D.2V 240

3.DMX.050.D.3I.12 240

3.DMX.060.D.1N 239

3.DMX.060.D.2V 240

3.DMX.060.D.3I.12 241

3.DMX.065.D.1N 239

3.DMX.065.D.2V 240

3.DMX.065.D.3I.12 241

3.DMX.A 239, 243

3.DMX.A.A

3.DMX.A.B

3.DMX.A.C

3.DMX.B

3.DMX.C

3.DMX.L

317925-30

4K.2.12DC.FCT.G 221

4K.2.24DC.FCT.G 221

4K.2.230.FCT.G 221

4K.4.12DC.FCT.G 221

4K.4.24DC.FCT.G 221

4K.4.230.FCT.G 221

4K.8.12DC.FCT.G 221

4K.8.24DC.FCT.G 221

4K.8.230.FCT.G 221

*4K.8F.12DC.FCT.G 221

4K.8F.12DC.FCT.G 221

4K.8F.24DC.FCT.G 221

4K.16.24DC.FCT.G 220, 221

4K.Z01082.012 220

4K.Z01082.013 220

4K.Z01082.014 220

4K.Z01082.015 220

4x1/4 185

4x1/4BR 184 4x1/8 185

4x1/8BR 184

40.CBL.5.10.AK 223

40.CPC.4.06 223 400A 15, 138 401A 105 401A-20 105 410A 15 430A

216

217

217

217

5N.F3.BD.ICS 246

5N.G.BB.B.BSP 245

5N.ICS.03 246

5N.PC.SB 246

5N.R1.BD.ICS 246

5N.R3.BD 246

5N.R3.BD.ICS 246

5N.R5.BD 246

5x1/4 185

5x1/4BR 184 5x3/8 185

55.IEM10.24DC 229 55.ISP10 229

57.G.03.SS.X.C.X.A.X 229

58.G.10.SS.X.1.A.1.X 229

15

61

61 500S 20

35

35, 54

15 599F 16

60

60

35 5040 35 5060AN 35, 54 5080AN 35,

5N.BB.A.BSP 245

5N.BB.B.BSP 245

5N.BB.C.BSP 245

5N.F1.BD 246

5N.F1.BD.ICS 246

5N.F3.BD 246

598020P 39

598030 39

598030P 39

599040 39

5100372 175, 256

5100433 174, 256

5100641 175, 256

5100652 175, 256

5100668 256

5115478-10 175, 256

5115478-50 175, 256

5115480-50 175, 257

5115481-10 175, 256

5115481-50 175, 256

5116734 178, 259

5116752 178, 260

5116753 178, 259

5116763 177, 259

5116796 178, 186, 260

5116881 176, 257

5116883 176, 257

5125622-20 175, 256

5125622-100 175, 256

5125623-20 175, 256

5125623-100 175, 256

5126044 178, 186, 260

5126046 178, 186, 260

5126797 178, 186, 260

5128787 176, 257

5128982 177, 259

5152997 176, 257

5500085 176, 257

5500099 176, 257

5500134 176, 257

5500136 176, 257

5500152 176, 258

5500156 176, 257

5500216 176, 257

5500247 176, 257

5500304G 178, 261

5500344 176, 257

5500832 176, 258 5901017 178, 260

6

6x1/4 185

6x1/4BR 184

6x3/8 185

600A 14

600ACB 14

600AF 14

600AFQRC 14

600AS 138

610A 14

630A 15, 224

630A-BA 15

650A 15, 223

660AN 14

660ANCB 14

660ANK1 17

660ANK2 17

660ANK3 17

660ANK4 17

660ANK5 17

660ANP 17

660ANP5 18

660ANQRC 14, 18

660AS 138

670AN6 15, 15

670AN6-SKIN 15

680AN 14

6000 167

6131 172, 259

6132 172, 259

6133 172, 259 6134 172, 259

6135 172, 259

6136 172, 259

6138 172, 259

6239 21

6268-2 19

6278 21 6279 21

6320-3 31, 138

6320-A 31 6336N 22 6438 31

6598-B 32

6603A 87 6604 95 6606 95 6608 95 6664 103 6665 103 6709-B4 32 6778 21

6820HDN 48

6820HDS 48

60040PA 51

60045P 51

60049GA 51

60056G 51

60068PA 51

60080P 51

66880SN 138

609007 84

609013 84

611000 70

611010 44, 56

611020 44, 56

611030 44

611040 44

611100 44, 56

611110 44, 56

611200 44, 56

611210 44

611410 103

611410C 103

619032 100

619032-MTA 100

619040 100

630010 109, 141 656110N 77

6093003 243

6101047 174, 255

6101048 174, 235, 255

6101086 174, 255

6103736 174, 255

6103767 174, 255 6103768 174, 255 6105688 177, 258 6116803 234 6129403 174, 255

6400081 174, 255 6400120 255 6400140 174, 255 6400236 255 6400298 174, 256

6600332 255 7

7x3/8 185 733 105

741-A 188 7149-A4 23, 138, 23 7216-4 67, 108, 109 7216-20 66, 109 7216-SS 108 7320 58 7330 58 7337 22 7340 28, 138 7340A 58 7341 48, 71 7342 47, 71 7346 46 7370 28 7371 71

7480-12 147 7480-18 147 7480-24 147 7480-28 147 7498-A 72 7498-C 73 7520EAN 102 7520HAS 102 7531-A4 22 7540EDN 48

8700-A 25

8820N 63

8826N 63

8826S 139

8828N2 63 8828SN 139 8848N 87 8870N 63

8876N 63

8878N 63 80082 62

80096 62 80100 62

80180 62 80205 62 80364 114 80365 114 8125003 217 8169033 217 9

90.898.1.230 226

90.898.1.415 226

90.900.0 223, 227, 223

90.900.3 223, 227, 223 90.900.7 227

90.923.1.230 226

90.923.1.415 226

90.930.4.230 227

90.930.4.415 227 925 106

925-005 106 925-006 106

925-007 106

925-008 106

925-20 106

925V 106

925V-20 106

933N 105 950 106 950-20 106 950V 106 950V-20 106

9611HS 138

9617-BS 139

9619-BS 139

9668S 139 9669-BS 139

9679HS 138 9910H 23 9910T 23 9911H 23 9911-R1 25

9911T 23

9916-A 68 9917-B 67 9918-A 68 9926 63

9949 26

9950-1 25 9950-20 25 9950-C1 25, 27 9950-D1 26 9968 67 9969-B 67 9970 67

9971-B 67 9976 63 9978 63 9979D 24 9979H 24 9979T 24 914900A 70 935900 70 9900089 178, 186 9900153 177, 186, 259 9900417 178, 186, 260 A

A-11-B 185 A-12-B 185

A-14-B 185 A-15-B 185

A51.087096 242

A53.114116 242 A70.093229 234 A70.093679 243 A70.093688 242 A70.0931053 243

A83.120870 246 A92.087058 242 A200 13 A336 167 A336B 167 A359 167 A359B 167 A1184 166 A1184B 166 A1186 166 A1186B 166 A1188 166 A1188B 166 A1190 166 A1190B 166 A1401 209 A1402 209 A1403 209 A1404

AA30PJBN 129 AA35MRS 128 AA35S 128

AA35S-240V 128

AA40CF2P 126

AA40CF2P-240V 126

AA40FB2P 126

AA40FB2P-240V 126

AA45LPAS 127, 129

AA50CF2PN 125

AA101P 126

AA108 132

AA201 134

AA205-2DG 78

AA205-3DG 78

AA221A 134 AA226A 134

AA236A 133

AA290-240V 133 AA296 133

AA402-240V 126

AA454PAN 127, 129 AA476 134

AA500-1C-GN 79

AA500-1C-GN-EL 79

AA579 132

AA820 132

AA828 132

AA850 132

AA1000-2C-GN 79

79

81 AAP-104-28-22 81 AAP-104-35-28 81 AAP-104-42-28 81 AAP-105-22xRp3/4 81 AAP-105-28xRp1 81

81 AAP-106-28xRp1 81 AAP-106-35xRp11/4 82 AAP-106-42xRp11/2 82

AAP-107-22xRp1/2 82

AAP-107-22xRp3/4 82

AAP-107-28xRp1 82

AAP-107-28xRp3/4 82

AAP-107-35xRp1 82

AAP-107-42xRp11/2 82

AAP-108-22xRp1/2 82

AAP-108-22xRp3/4 82

AAP-108-28xRp1 82

AAP-108-28xRp3/4 82

AAP-108-35xRp1 82

AAP-108-35xRp11/2 82

AAP-108-42xRp11/2 83

AAP200.000.400A 132

AAP204.001.400A 132

AAP206.005.400A 132

AAP280.010.589A 132

AAP280.010.818A 132

AAP280.090.002A 132

AAP1000 123

AAP2000 123

AAP3000 123

AAP5000R 123

AAP47070A 123

AAP-ACLP-1-0 83

AAP-ACLP-1-2 83

AAP-ACLP-1-14 83

AAP-ACLP-3-4 83

AAPBL9000 123

AAP-BV-SS-1-0 83

AAP-BV-SS-1-2 83

AAP-BV-SS-3-4 84

AAP-CF-5E 135

AAP-CF-6E 135

AAP-CF-7E 135

AAP-DP30403 83

AAP-DP30404 83

AAP-DP30405 83

AAP-DP30406 83

AAPDT-800M 130

AAP-FT2212 83

AAP-FT2812 83

AAP-FT2834 83

AAP-FT3534 83

AAP-FT4234 83

AAPKA24 135

AAPKA30 135

AAP-SF-4E 135

AAPTC26HA 133

AAPTWA 130

AAPTWBP2 132

AAP-UNI-40-40-5.8M 84

AAPWA3D 131

AAPWA8CCD 131

AAPWAT6CCD 131

AAPWB220 132

AAPWB220V 132

AATSTD0617 273

AB5017M 102

AB80005 98

AB80010 98

AB80015 98

AB80020 99

AB80025 99

AB80030 99

AB80035 99

AB80045 100

AB80050N 103

AB80055 99

AB80060 101

ABH1 103

ABH075 103

ABL7528 193

ABL7538 193

AB-PA01 95

AB-PA03 94

AB-PA05 94

AB-PD100 94

AB-PD100A 95

AB-PD100B 95

AB-PD100C 95

AB-PD101 94

AB-PD101A 95

AB-PD101B 95

AB-PD101C 95

AB-PD102 94

AB-PD102A 95

AB-PD102B 95

AB-PD102C 95

AB-PX100 94

AB-PX101 94

AB-PX102 94

ACL7563 193

ACL7567 193

ACL7568 193

ACL7572 193

ACL7573 193

ACL7577 193

ACL7578 193

ACL7595 193

ACL7596 193

ACON0820-MAK 17

ACON0820-MIK 17

AH2182 212 AL29 155 AL48 155

AL161 155 AL162 155 AL185 155 AL200 155 ALA34 155

ALA44 155 ALA52 155

ALA60 155 ALA165 155 ALA168 155 ALA169 155

ALA172 155

ALA187 155

ALA189 155

ALA203 155

ALA204 155

ALE-5FPT 107

ALE-15BST 107

ALE-15FPH

38, 69, 87, 100, 107, 113

ALE-15FVT 107

ALE-20BAH 38, 69, 87,

ALE-20BPS 107

ALE-20BST 107

ALE-25BAH 38, 69, 87

ALE-25BPS 107

ALE-25BST 107

ALE-40BAH 38, 69, 87

ALE-40BPS 107

ALE-40BST 107

ALE-50BAH 38, 69, 87

ALE-50BPS 107

ALE-80BAH 38, 69, 87, 112

ALEM-9V 45

ALEM-2020 45

ALEM-4000-240 45

ALEM-5020 45

ALS.C4.24.CE.2.C 248

ALS.C4.24.CE.3.C 248

ALS.C4.24.CE.4.C 248

ALS.C4.24.CE.5.C 248

ALS.C4.24.CE.6.C 248

ALS.C4.24.CE.7.C 248

ALS.C4.24.CE.8.C 248

ALS.C4.24.CE.9.C 248

ALS.C4.24.CE.10.C 248

ALS.C4.24.CE.11.C 248

ALS.C4.24.CE.12.C 248

ALS.C4.24.CE.13.C 248

ALS.C4.24.CE.14.C 248

ALS.C4.24.CT.2 248

ALS.C4.24.CT.2.C 248

ALS.C4.24.CT.3 248

ALS.C4.24.CT.3.C 248

ALS.C4.24.CT.4 248

ALS.C4.24.CT.4.C 248

ALS.C4.24.CT.5 248

ALS.C4.24.CT.5.C 248

ALS.C4.24.CT.6 248

ALS.C4.24.CT.6.C 248

ALS.C4.24.CT.7 248

ALS.C4.24.CT.7.C 248

ALS.C4.24.CT.8 248

ALS.C4.24.CT.8.C 248

ALS.C4.24.CT.9 248

ALS.C4.24.CT.9.C 248

ALS.C4.24.CT.10 248

ALS.C4.24.CT.10.C 248

ALS.C4.24.CT.11 248

ALS.C4.24.CT.11.C 248

ALS.C4.24.CT.12 248

ALS.C4.24.CT.12.C 248

ALS.C4.24.CT.13 248

ALS.C4.24.CT.13.C 248

ALS.C4.24.CT.14 248

ALS.C4.24.CT.14.C 248

ALS.C8.24.CE.2.C 249

ALS.C8.24.CE.3.C 249

ALS.C8.24.CE.4.C 249

ALS.C8.24.CE.5.C 249

ALS.C8.24.CE.6.C 249

ALS.C8.24.CE.7.C 249

ALS.C8.24.CE.8.C 249

ALS.C8.24.CE.9.C 249

ALS.C8.24.CE.10.C 249

ALS.C8.24.CE.11.C 249

ALS.C8.24.CE.12.C 249

ALS.C8.24.CT.2 249

ALS.C8.24.CT.2.C 249

ALS.C8.24.CT.3 249

ALS.C8.24.CT.3.C 249

ALS.C8.24.CT.4 249

ALS.C8.24.CT.4.C 249

ALS.C8.24.CT.5 249

ALS.C8.24.CT.5.C 249

ALS.C8.24.CT.6 249

ALS.C8.24.CT.6.C 249

ALS.C8.24.CT.7 249

ALS.C8.24.CT.7.C 249

ALS.C8.24.CT.8 249

ALS.C8.24.CT.8.C 249

ALS.C8.24.CT.9 249

ALS.C8.24.CT.9.C 249

ALS.C8.24.CT.10 249

ALS.C8.24.CT.10.C 249

ALS.C8.24.CT.11 249

ALS.C8.24.CT.11.C 249

ALS.C8.24.CT.12 249

ALS.C8.24.CT.12.C 249

ALS.C16.24.CE.2.C 250

ALS.C16.24.CE.3.C 250

ALS.C16.24.CE.4.C 250

ALS.C16.24.CE.5.C 250

ALS.C16.24.CE.6.C 250

ALS.C16.24.CE.7.C 250

ALS.C16.24.CE.8.C 250

ALS.C16.24.CE.9.C 250

ALS.C16.24.CE.10.C 250

ALS.C16.24.CE.11.C 250

ALS.C16.24.CE.12.C 250

ALS.C16.24.CE.13.C 250

ALS.C16.24.CE.14.C 250

ALS.C16.24.CE.15.C 250

ALS.C16.24.CE.16.C 250

ALS.C16.24.CE.17.C 250

ALS.C16.24.CE.18.C 250

ALS.C16.24.CE.19.C 250

ALS.C16.24.CE.20.C 250

ALS.C16.24.CE.21.C 250

ALS.C16.24.CE.22.C 250

ALS.C16.24.CE.23.C 250

ALS.C16.24.CE.24.C 250

ALS.C16.24.CT.2 250

ALS.C16.24.CT.2.C 250

ALS.C16.24.CT.3 250

ALS.C16.24.CT.3.C 250

ALS.C16.24.CT.4 250

ALS.C16.24.CT.4.C 250

ALS.C16.24.CT.5 250

ALS.C16.24.CT.5.C 250

ALS.C16.24.CT.6 250

ALS.C16.24.CT.6.C 250

ALS.C16.24.CT.7 250

ALS.C16.24.CT.7.C 250

ALS.C16.24.CT.8 250

ALS.C16.24.CT.8.C 250

ALS.C16.24.CT.9 250

ALS.C16.24.CT.9.C 250

ALS.C16.24.CT.10 250

ALS.C16.24.CT.10.C 250

ALS.C16.24.CT.11 250

ALS.C16.24.CT.11.C 250

ALS.C16.24.CT.12 250

ALS.C16.24.CT.12.C 250

ALS.C16.24.CT.13 250

ALS.C16.24.CT.13.C 250

ALS.C16.24.CT.14 250

ALS.C16.24.CT.14.C 250

ALS.C16.24.CT.15 250

ALS.C16.24.CT.15.C 250

ALS.C16.24.CT.16 250

ALS.C16.24.CT.16.C 250

ALS.C16.24.CT.17 250

ALS.C16.24.CT.17.C 250

ALS.C16.24.CT.18 250

ALS.C16.24.CT.18.C 250

ALS.C16.24.CT.19 250

ALS.C16.24.CT.19.C 250

ALS.C16.24.CT.20 250

ALS.C16.24.CT.20.C 250

ALS.C16.24.CT.21 250

ALS.C16.24.CT.21.C 250

ALS.C16.24.CT.22 250

ALS.C16.24.CT.22.C 250

ALS.C16.24.CT.23 250

ALS.C16.24.CT.23.C 250

ALS.C16.24.CT.24 250

ALS.C16.24.CT.24.C 250

ALSSR-25MM 257

ALSTRITON25 222

AM-050 41

AOGM-25E 41

AOGM-25M 41

AOGM-40E 41

AOGM-40M 41

AOGM-50E 41

AOGM-50M 41

AP609 90

AP1009 90

AP1220 90

AQCCDS1118N 268

AS1090 89

ASL-1A-000-HO 252

ASL-1A-000-R5 252

ASL-M1A-000-HO 252

ASL-M1A-000-R5 252

ASL-M2A-000-HO 252

ASL-M2A-000-R5 252

ASL-M3A-000-HO 252

ASL-M3A-000-R5 252

ASL-M4A-000-HO 252

ASL-M4A-000-R5 252

ASL-M5A-000-HO 252

ASL-M5A-000-R5 252

ASL-M6A-000-HO 252

ASL-M6A-000-R5 252

ATAT0820-MAK 17

ATAT0820-MIK 17

ATSTD0617 273

AW30090 89

AWP809 90, 141

AWP1014 90, 140

AWP1215 90, 140

AWS815 90, 141

B

B200 20

B203 21

B1604 210

B1614 210

B1623 210

B1625 210

B1741-A 184

B6304-B 13, 19

B6509-D 13, 19

B6783 13, 20

B306740 16

B308730 13

B322610 16

B336770 13, 20

BC110010 87

BC110020 87

BR50010D 118

BR50020C 119

BRP5216C 119

BRP5216D 118

BS1511 209

BS1512 209

BS1513 209

BS1516 209

BS1521 209

BS1523 209

BS1536 209

BS1555 210

BS1556 210

BS1560 210

BS1574 210

BT60/MAIN 182

BT60/PL1 182

BT120/MAIN 182

BT120/PL1 182

BT240/MAIN 182

BT240/PL1 182

BT0544 177, 258

BT0544S 177, 258

BT0566 177, 258

BW4040P 205

BW4040TG 205

BW4041P 205

BW4041PR 205

BW4041TGR 205

BWS4042 204

BWS4042R 204

BWS4043 204

BWS4043R 204

BWS4044 204

BWS4044R 204

BWS4045 204

BWS4045R 204

BWS4046 204

BWS4046R 204

BWS4047 204

BWS4047R 204

BWS4052 204

BWS4052R 204

BWS4053R 204

BWS4054 204

BWS4054R 204

BWS4055 204

BWS4055R 204

C

C030 198 C69 166 C1730 211 C1732 211 C1733 211 C1736 211 C1740 211 C1743 211 C1748 211

C1749 211 C1763 211 C1787 211

CE6B18 174

CE6M6 174

CE6M8 174

CE6M10 174 CO32 198

CR30050 130

CR30060 129

CS6B18 174

CS6M6 174

CS6M8 174

CS6M10 174 D D50 40

DMX9-17

DMX9-18 238

DMX10-19 238

DMX10-20 238

DP70015 38, 69, 88, 113

DP70020 38, 69, 87

DP70025 38, 69, 87, 113 DP70040 38, 69, 87

DP70050 38, 69, 87

DPDS0220 272

DPX3-2

DPX3-3

DPX3-5

DPX3-6

DPX4-7

DPX4-8

DPX5-9

DPX5-10

DPX6-11

DPX6-12

DPX7-13 231

DPX7-14 231

DPX8-15 231

DPX8-16 231

DPX9-17 231

DPX9-18

DPX10-19 232

DPX10-20 232

DR31-2 245

DR32-4 245

DR33-6 245

DR34-8 245

DR35-10 245

DR36-12 245

DR37-14 245

DW4061 206

DW4061A 206

DW4062 206

DW4062A 206

DW4063 206

DW4063A 206

DW4064A 206

E

E60/EMPTY 180

E60/PL1 180

E120/EMPTY 180

E120/PL1 180

E240/EMPTY 180

E240/PL1 180

EB111D0FA 42

ECRP24025 130

EPL-240SP 24

ESOC875E 77, 113, 117

EVRP2405 129

EXP240/MAIN 182

EXP480/MAIN 182

F

F2141 212

F20010 34

F20020N 37

F20025 43

F20030 43

F20030U 55

F20040 43

F20050 35

F20050N 35

F20060 35

FA2 44, 56

FAVSS8404 258

FF01-0132 61

FF03-0140 61

FGB280 202

FGB2100 202

FGB2125 202

FGB2150 202

FGB2175 202

FGB2200 202

FGB2250 202

FGB2300 202

FGM160 201

FGM280 201

FGM2100 201

FGM2125 201

FGM2150 201

FGM2175 201

FGM2200 201

FGM2250 201

FGM2300 201

FGV280 202

FGV2100 202

FGV2125 202

FGV2150 202

FGV2175 202

FGV2200 202

FGV2250 202

FGV2300 202

FM300HL 108

FTH1 45

FTH1-3M 45

FTH1-3M1 45

FTH1-3M2 45

FTH1-5M2 45

FTH1P 56

FTH15 45

G

G2.121RFM 131

G2S05IQ9LMA 108

G2S15IQ9LMA 108

G2S20IQ9LMA 108

G3.150 131

G3.150WS 131

G4.140WS 131

G96N 133

G1250.30PLUSIT 133

G8945ITV.26S 133

G9156.11 133

G10010N 14

G10010NP 18

G10010NP5 18

G10020N 14

G10030 14

G10040N 15

G10042 15

G10044N 16

G10050N 18

G10051 18

G10051-GC 18

G10060 19

G10070 21

G10080 22

G10090 16, 165

G14500CK 17, 20

G30090 30

G100100SS 17, 165

G100110 25

G100120 23

GAR325 134

GEM1 67

GEM2 65

GEM3

GGADS0518

GGDS0617

GMR10010

GMRF10010 124

GMS1755 124

GMS1755-240V 124

GMS-AU150T7 124

GON-100IG 124

GON-100IGR 124

GRNG-160100 124

GROLLY 125

GROLLY-M 125

GROLLY-GTP12510 125

GRS926 133

GRS926-240V 133

GRS926.MOVI 133

GRS2150 197

GSA0.5-GMR 124

GSA1.5 124

GSA2 124

GSF130 196

GSF239 196

GSF240 196

GSF250 196

GSF360 196

GSF368 196

GSF468 196

GSF480 196

GSF4100 196

GSI-1.5 125

GT2-10040 125

GTA12244560 37

GTL2.120RC 131

GTL4.140RC 132

GTP12244560 38

GYG-10010010 125

GYNMA-GON100 125

H

H0010031 260

H10120 88

H0010130 260 H10300 88

H0010530 260 H0010630 260 H12060 88 H12220 88 H0040031 260 H0040130 260 H0040530 260 H0040630 260 H0080031 261 H0080032 261 H0080130 260 H0080530 261

HC1-YE-YE 118

HP8.3E-50

J30PX 129

J30X 129

J40PKL 129

J50PHA 129

JBFR65 119

JBFR75 119

JBWE70 119

JBXE83 119

JP-140-PP-HC-1000 104

JP-140-PP-HC-1000 104

JP-140-PP-HC-1200 104

JP-140-PP-HC-1200 104

JP-140-PVDF-HC-1000 104

JP-140-PVDF-HC-1000 104

JP-140-PVDF-HC-1200 104

JP-140-PVDF-HC-1200 104

JP-180-PP-HC-1000 104

JP-180-PP-HC-1000 104

JP-180-PP-HC-1200 104

JP-180-PP-HC-1200 104

JP-180-PVDF-HC-1000 104

JP-180-PVDF-HC-1000 104

JP-180-PVDF-HC-1200 104

JP-180-PVDF-HC-1200 104

JP-280-ALU-HC-1000 64

JP-280-ALU-HC-1200 64

JP-280-PP-HC-1000 104

JP-280-PP-HC-1200 105

JP-280-PP-HC-1200 105

JP-280-PVDF-HC-1000 104

JP-280-PVDF-HC-1200 105

JP-280-PVDF-HC-1200 105

JP-440EX-SS-SS-1000 104

JP-440EX-SS-SS-1200 105

JP-440EX-SS-SS-1200 105

JP-480EX-SS-SS-1000 104

JP-480EX-SS-SS-1200 105

JP-480EX-SS-SS-1200 105

JS20PR 129

JS30PR 129

K

K200 70

K600/4 42

K600N/3F 42

K600N/3O 69

K700 41

K900 41

KIT102 117

KP118NP 128

KP118P 128

KP118PY 128

KP442NE 126

KPH350.45 125

KPH370.32R 126

KPH370.45 125, 126

KPH370.45-240V 126

KPH370.45LIK-A 125

KPH370.45LIKA 125

KPH370.55LIKTA 125

KPL-24EX 24

KPN349WEK 126

KPX32 126

KPX337LWR 126

L

L1 156, 161

L2 156, 161

L12 156, 161

L13 156, 161

L15 156, 163

L28 156, 162

L29 156, 160

L29-LH 156, 160

L30 156, 160

L31 156, 161

L47 157, 162

L48 157, 160

L77 157, 164

L78 157, 164

L79 157, 164

L80 157, 164

L89 160

L113 157, 161

L114-U 157, 162

L119 157, 163

L123 157, 162

L128 158, 162

L143 158, 164

L161 158, 163

L162 158, 163

L163 158, 164

L185 158, 162

L190 158, 162

L195 158, 162

L200 158, 163

L201 158, 164

L201-L 159, 164

L202 159, 164

L205 159, 163

L310 159, 164

L311 159, 164

L508 159, 163

L645 159, 164

L652 159, 162

L971 159, 164

L981 159, 164

L1020 159, 162

L2511 211

L2531 211

L2601 212

L2603 212

L4674 16, 165

L4675 16, 165

L4676 16, 165

L4679 16, 165

L4680 17, 165

L4785-13 160, 166

L4785-18 160, 166

L4788-1 160, 166

L6075 160, 163

L10040PA 50

L10040PAM 50

L20040PA 50

L20040PAM 50

L40040PA 50

L40040PAM 50

L40049GA 50

L40049GAM 50

L40068PA 50

L40068PAM 50

L45040PA 50

L45040PAM 49

L60040PA 49

L60040PAM 49

L80040PA 49

L80040PAM 49

L80080PA 49

L100040PA 49

L100040PAM 49

L100080PA 49

L120040PA 49

L120040PAM 49

L120080PA 49

L400504017AAM 52, 102

LA5 156, 161

LA6 156, 161

LA8 156, 161

LA9 156, 161

LA10 156, 161

LA11 156, 161

LA16 156, 161

LA19 156, 163

LA20 156, 161

LA24 156, 161

LA27 156, 163

LA34 156, 160

LA35 156, 161

LA37 157, 162

LA39 157, 160

LA41 157, 161

LA43

LA44

LA51

LA168 158, 163

LA169 158, 163

LA172 158, 163

LA187 158, 162

LA188 158, 162

LA189 158, 162

LA192 158, 162

LA193 158, 162

LA194 158, 162

LA197 158, 163

LA198 158, 163

LA199 158, 163

LA203 159, 163

LA204 159, 163

LA206 159, 163

LA207 159,

LT46 157, 165

LT52 157, 165

LT210 159, 165

LT320 159, 165

LT324 159, 165

LT325 159, 165

LT326 159, 165

LT610 166

LT810 166

LT1010 166

LT1015 159, 166

LT3403 160, 168

LT3455 160, 168

LT8125 160, 166

M30 42

M60/MAIN 180

M60/PL1 180

M125/MAIN 180

M125/PL1 180

M150S 34

M150SA 34

M240S 34

M240SA 34

M250/MAIN 180

M250/PL1 180 M336 169

M500/MAIN 180

M500/PL1 180

M3011 214

M3017WF 214 M3024 214

M3024WF 214

M3025 214

M3025WF 214

M3041WF 214 M3042 214

M3130-AL 35

M3130-ML 35

M0160030 261

Mi60/MAIN 181

Mi125/MAIN 181

Mi250/MAIN 181

MPL-N-350-SS 152

MPL-N-450-SS 152

MP-N-450 140

MP-N-450S 140

MSP250-VAC/MAIN 181

MSP500-VAC/MAIN 181

MSPOL500-VAC/MAIN 198

O

O30010N 63

O30020 74

O30030 67

O30040 64

O30050 64

O30060 75

O30070 75

O30080 73

O30090 72

O300100 65

O300110 76

O300120 68

O300130 68

O300140 67

O300160 95

O300161 96

OL500 198

OL4281 201

OL4283 201

OL4285 201

OM025A001-211QPN 41

OM025P001-811R4 103

OM025P001-811R4 103, 108

OP20L 85

OR7708 208

OR7714 208

OR7724 208

OR7730 208

OS615 92

OS3471 198

OS3472 198

P

P40 41

P50 40

P200H-TAP 108

PF10 44, 56

PH50 40

PLC120/MAIN 181

PLC240/MAIN 181

PLC480/MAIN 181

P-LPL-335-SS 152

P-LPL-425-SS 152

PM40 41

PPDS0518 266 PR50 40

PR80 40

PR-1125-12 147

PR-1175-11 147

PRP-1125-12 147 PRP-1175-11 147

PSF130 196

PSF240 196

PSF250 196

PSF360 196

PSF368 196

PSF480 196

PSF4100 196

PW4210 205

PW4211 205

PW4212 205

PW4213 205

PW4214 205

PW4215 205

Q

QDC-04 224 QDP-04 224

R

R80-04F 224

R80-04M 224

RAV3D2.OWALL3S 131

RAV232NL-AF 128

RAV241-AF 128

RAV305H.4WS 128

RAV307H.4WS 128

RAV308H.4WS 128

RAV518NL 128

RAV535 128

RAV540 127

RAV640N.2I 127

RAV650N.2.55I 127

RAV825.10I 127

RAV1450N 128

RAV4401 127

RAV4402 127

RAV4501L 127

RAV4502L 127

RAV4651L 127

RAV4652L 126

RAV4800R 126

RAV4802-R 126

RAV4802R 126

RAVTD3200HPR.3 130

RAVTD3200SP.3 131

RAVTD8060TWSR 131

RAVTD8060/

VARCOMBOAV 131

RF15 183

RF30N 183

RF40 183

RSMN80 199

RT141D0FM 42

RT401D0FA 42

RT406D0FM 42

RTSTD0617 273

S

S100/Empty 183

S100/PL1 183

S600NA11 127

S600NA14 127

S600NA19 127

S600NA21 127

S800A12 127

SA300N 90, 140

SA400N 90, 140

SA400SN 140

SA630 93

SAW100 90, 141

SAW200 90, 140

SB325 98, 100

SB325M 100

SB325MA 100

SB325-MK 100

SB501 183

SBA315 121

SBA415 121

SBA515 121

SC60040 115

SC60040IWC 115

SC60050 115

SC60050IWC 115

SC60080 116

SC60090 116

SCK60 118

SCK120 118

SCK240 118

SG800 30

SJ-100-051 116

SJ-100-061 116 SJ-110-006 116

SJ-200-002 117

SJ-510-001 115

SLPF-750 46, 144

SLPF-825 144

SLPF-835 46, 144

SLPF-850 46, 144

SLPL-550 144, 145 SLPL-575 144, 145

SLPL-625 144, 145

SLPL-650 144, 145

SLPL-675 144, 145 SLPL-725 144, 145

SLPL-750 46, 144, 145 SLPL-825 144, 145

SLPL-835 46, 144, 145

SLPL-850 46, 144

SLPL-4100 144, 145

SLPL-5100 144, 145

SM12-3-100 147

SM12-3-100 147

SM17-3-250 147

SM17-4-125 147

SM17-3-250 147

SM17-4-125 147

SMK-202 147

SMOBIPLUS-M 121

SMP-550 144

SMP-575 144

SMP-625 144

SMP-650 144

SMP-675 144

SMP-4100 144

SMP-5100 144

SMPL-550 144

SMPL-575 144

SMPL-625 144

SMPL-650 144

SMPL-675 144

SMPL-4100 144

SMPL-5100 144 SO600 92

SO640 92

SOI700 72, 75

SOI700S 140

SOP620 92 SP610 93

SP100010 108

SP100020 108

SP100030 108

SP100040 108

SPFN57 199

SPRBC16 199 SPRBC25 199

SPRNC6.5 199

SPRNC16 199 SPRNC25 199

SPRNC30 199

ST1-10-YE-BK 116

ST1-30 117

ST1-30C 116

ST1-60 117

ST1-60C 116

ST1-100 116

ST1-100C 116

ST2-60-YE-BK 116 ST200 37

ST200DC 37

SV60/PL1 182

SV125/PL1 182

SV250/PL1 182

SV502/PL1 182

SW500N 91, 141

SWF7701 208

SWF7706 208

SWF7712 208 SWF7717 208

T TM05 94

TM07 94 TM10 94

TM20 94 TM40 94

TN6E-100 175

TN6GF-100 175

TSHF-N-635 56

TSHL-N-550-SS 152

TSHL-N-4100-SS 152

U

USF7402 197 USF7403 197

USF7409 197

USF7410 197

USF7416 197

USF7417 197

USF7431 197

USF7432 197 USF7438 197 USF7439 197

V

V25-012AD 34

V25-012MD 34

V25-024AD 34

V25-024MD 34

VABL7973 194

VABL7974 194 VABL7976 194 VABL7977 194

VABL7979 194

VABL7982 194 VABL7983 194

VABL7985 194 VABL7986 194

VABL7988 194

VABL7989 194 VB942 20 W

WO50010 58 WP1290 91, 141 WT200N 92 Z

Z737 20 ZZZ100-208 223

ALEMLUBE WARRANTY POLICY

Your Alemlube product is warranted to the original user against defects in workmanship or materials under normal use for a period of twenty four months after purchase date. Any product which is determined to be defective in material and workmanship and returned to Alemlube P/L, shipping costs prepaid, will be repaired or replaced at Alemlube’s option.

This warranty also covers parts that are subject to wear such as O rings, packings, seals, springs, electronic and even electrical components. The warranty does not cover damage or failure which in the judgement of Alemlube arises from misuse, abrasion, corrosion, negligence, accidental damage, faulty installation or tampering. If Alemlube inspection discloses no defect in material or workmanship, repair or replacement and return will be made at customary charges.

Alemlube has made a diligent effort to accurately illustrate and describe its product in all its literature. However, such illustrations and descriptions are not a warranty.

The above express warranty is in lieu of and excludes all other warranties, express or implied, including, without limitation, merchantability or fitness for a particular purpose. The purchaser shall give written notice of any claim to Alemlube within ten days after discovery of any alleged defect.

Alemlube shall not be liable for consequential damages, losses, delays, labour costs or any other expense directly or indirectly arising from use of the product, its liability being expressly limited on the replacement or repair of any defective product or an allowance of credit therefore.

The remedy and recovery of the purchaser on any claim against Alemlube, whether based on contract of this warranty or any alleged negligence shall be as stated and limited herein and shall be exclusive.

Alemlube warranty on Automatic Lubrication Systems, Vehicle Hoists, Wheel Service Equipment and other products installed by Alemlube is twenty four months after purchase date, unless otherwise stated at the time of purchase.

Proof of purchase including the pump/product serial number will be required to initiate a warranty claim. Claims relating to damage or wear and tear of Alemlube installed products and/or installation materials will be assessed by Alemlube taking into account the actual working conditions and reasonable care and maintenance on behalf of the purchaser.

Warranty is void if any alterations, modifications or repairs are attempted without the express permission of Alemlube.

* For inclusions and exclusions please visit our website to confirm details.

Head Office

22 Green Street

Brookvale NSW 2100

Phone: 02 9938 2999

Fax: 02 9938 6605

New South Wales / ACT

8 Grevillea Street

Eastern Creek NSW 2766

Phone: 02 9677 1555

Fax: 02 9675 1155

Workshop Equipment

Head Office

57-61 Smeaton Ave

Dandenong VIC 3175

Phone: 03 8768 8011

Fax: 03 8787 8266

Victoria / Tasmania

57-61 Smeaton Ave

Dandenong VIC 3175

Phone: 03 8787 8288

Fax: 03 8787 8266

Queensland / PNG 21 Chrome Court

Burpengary QLD 4505

Phone: 07 3491 2600

Fax: 07 3491 2699

South Australia / NT 3 Nucera Court

Greenfields SA 5107

Phone: 08 8241 7111

Fax: 08 8241 7011

Western Australia 9 Kalinga Way

Landsdale WA 6065

Phone: 08 9302 4199

Fax: 08 9303 2095

New Zealand Unit 1/43

William Pickering Drive

Albany Auckland NZ 0632

Phone: 64 9 447 1007

www.alemlube.com.au info@alemlube.com.au www.alemlube.co.nz info@alemlube.co.nz
