3 Table of Contents 04 Community Canopies - Williamsburg, PA Expressway Succession - Baltimore, MD Design Implementation - State College, PA Internships and Construction - NJ and CT Millennium Science Complex - State College, PA Spring Creek Watershed - Centre County, PA 10 14 20 24 28

Community Canopy

Community Design Studio

Date: Fall 2022

Location: Williamsburg, Pennsylvania

Project Size: 256 Acres

The Williamsburg, Pennsylvania is rural small town community that has historically relied on manufacturing and agriculture as its main economic outputs. In recent years, businesses have left rural America including Williamsburg creating an economic void for its residents. This studio focuses

on how residents can capitalize on The Lower Trail which runs through Blair and Huntingdon Counties and will become an assets with its placement along the 9/11 Memorial Trail. Through interventions in the downtown area and in Riverside Park, Williamsburg has the potential to became a destination for many.

Regional Trail System Analysis

Spatial Analysis

United States Route 22

Blair/Huntingdon County Line

The Lower Trail Juniata River and Assorted Streams

Proposed Huntington to Hollidaysburg Trail System

Huntington to Hollidaysburg Trail System Signage

Rural Stops Smaller Communities Larger Communities

Educational Trail Signage

Community Amenities

Regional Trail Map

Community History

Hollidaysburg Williamsburg Cove Dale Mount Etna Huntingdon Alexandria

Proposed Goals

1. 2. 3.

Enhance Riverside Park for increased accessibility and flood mitigation

Rerouting the Lower Trail through integrating historical context

Creating street hierarchy with vegetation while managing storm water

1 2

Riverside Park Interventions

8 1 2 3 4 5

Seasonal Color Palette ADA Accessible Riverfront Existing Vegetation Rain Meadow Turf Area Football Field Juniata River 1. ADA Accessible River Access 2. Rain Meadows for Flooding 3. Rerouting the Lower Trail 4. Enhanced Parking Lot

Spring Summer Fall

5. Green Streets Scale: NTS

East First Street

Deciduous Trees

High Street Bio-retention

East Second Street

Native Perennials

Standard Curb

2” River Stone

Sandy/Loam Soil

6” River Stone

Perforated NDS Piping

High Street Interventions

9 1 2 3

Town Hall Pocket Park 1. Historic Town Diamond 2. Green Streets and Bio-retention 3. Community Pocket Park

Spring Creek Watershed

Geo-spatial Analysis Studio

Date: Spring 2021

Location: Centre County, Pennsylvania

Project Size: 93,000 Acres

The Spring Creek Watershed is diverse region with its urban/rural dynamics including being home to the Pennsylvania State University. In recent years, there has been an increased need for emergency medical services (EMS) to serve all of the county’s residents, especially it’s older populations further away from its only hospital, Mount Nittany Medical Center. Through

an initial inventory of the Watershed, several proposals were designed to not only make healthcare more accessible but take proactive measure to decrease the needs for EMS services along with make health centric public spaces more readily available for all residents within the Watershed.

GIS Analysis of Watershed EMS and Population

Regional EMS Services Analysis

Response Times (Primary Service Area)

Centre LifeLink: 5 - 10 Minutes

Pleasant Gap FD and Bellefonte EMS: 10 - 20 Minutes

Penns Valley EMS: 15 - 30 Minutes

EMS Call Types

General Trauma (ex. General Falls and Injuries): 45%

Medical (ex. Cardiac and Respiratory Difficulties): 40%

Serious Traumas (ex. Vehicle Accidents and Severe Bleeding): 15%

Staffing Composition

Paid Staff: 85%

Volunteer: 15% Source: PGFD and EMS

GIS Analysis of Watershed Community Definitions

Median Age 18 - 24 years old Urban Context 25 - 1.5K People

Park spaces within 1 mile of municipal center

Bellefonte EMS Pleasant Gap Fire Co. Centre LifeLink Penns Valley EMS 10 - minute response time 24 - 32 47 - 50 32 - 42 Mixed Context 1.5K - 3.5K Quarries 50 - 58 Rural Context 3.5K - 5.5K Agricultural Land 5.5K - 10K Developed 10K - 92K Natural Land

Existing Parks

EMS Coverage

Population Density

Proposed Regional Interventions

13 Enhanced EMS in Rural Communities Increased Trail and Bike Infrastructure Health Centric Park Spaces Safer Roads And Highways

College

State

Centre Hall Pleasant Gap Bellefonte

Expressway Succession

Urban Design Studio

Date: Spring 2022

Location: Baltimore, Maryland

Project Size: 16 Acres

The Franklin Mulberry Expressway is an abandoned infrastructure project from the 1960’s that never came to fruition that has fragmented four different communities in Baltimore. The Expressway in various sections is 40 feet below grade along with having large amounts of cement. The concept derived through this design process explores how

abandoned infrastructure can be repurosed for a fraction of the cost as opposed to building a new public space from scratch. The design capitalizes on the existing vegetation growing on site through the phased integration of native species while cultivating a new public space for Baltimore residents.

Fragmented Communities

Neighborhood Boundary Neighborhood Barrier Caused By Site

Lateral Community Movement

Franklin Mulberry Expressway

Former Roads

Accessible Green Space and Important Roads

Concept Alignment - Enhancing Current Proposals

Existing Walls

Rather than removing all the concrete, some of the concrete walls can be removed to enable large scale site access

5 Minute Walking Radius to Park

Vegetation that is already found onsite can be left (besides large invasives) to create a more natural plant palette that will be evident during the early phases

Past History

Current vegetation Community Spaces

By keeping the highway infrastructure, landscape features such as plants growing through the cracks resemble the community’s comeback from systemic racism. Using existing public spaces with specific intentions will enable these neighborhoods to unite together as one larger community

Harlem Park Franklin Square Poppleton

MLK Jr. Blvd.

N. Fremont Ave. Midtown Edmond

Community Engagement Timeline

2022 Community Engagement and Conceptual Design

2027

Refined Design is Developed by Community

2035

Final Phases are Installed with Community

2025 Concrete Demolition and Initial Planting

Succession Framework

Demolition

Concrete and stone is removed and an amended soil mix is installed

Primary Succession

Native and invasive plants grow in the soil. Minimal maintenance of beds

2030 Phase 1 Succession and Additional Construction

2040 Phase 2 Succession and Maintenance

Secondary Succession

Invasive are more aggressively removed and native vegetation takes hold

Maintained Planting

Planting is naturally managed with minimal maintenance from community

Section A A1 A2

B2 B1

Section B Wall regraded with crushed concrete steps for increased access Cut out planting spaces ADA walkways Larger openings for community activities

A perspective rendering representing how some of the retaining walls are demolished to enabled access to the site. Different areas of the site are left more open for the community to hold events such as festivals and markets.

A perspective rendering that helps exhibit how the cut out concrete within the site enables vegetation to grow. These cut-outs provide aesthetic and functional benefits to those who visit the site and for those who live in the surrounding neighborhoods.

Millennium Science Complex

Technical Planting Design Course

Date: Fall 2021

Location: University Park, Pennsylvania

Project Size: 5.5 Acres

The Complex’s planting design incorporates many of the most modern planting design techniques to better facilitate biological activity. Through this semester long exercise, the Complex was able to get redesigned with the use of pollinator gardens. All phases of the project use almost all native plants to aid in educating

the site’s visitors. Through the design of the pollinator garden, there was an emphasis on engaging visitors with natural activities found within the garden. Different nodes are created to see how pollination occurs and the plethora of plants that help preserve a dwindling pollinator population.

Pollinator Education Types

1. Plants that are native to Pennsylvania

2. Plants with bright visual interest

3. Plants that attract bees and butterflies

4. Prairie meadow/pollinator garden

A perspective rendering illustrating the different heights of planting material chosen. This study helps identify whether certain species are in the right areas along with whether the garden is visually appealing to those walking through. A perspective rendering of the view walking towards the Millennium Science Complex. Native vegetation and grasses creates intimacy for visitors through the use of ornamental grasses, flowering perennials, and deciduous trees.

Grasses:

purpurea

Eupatorium maculatum

Eupatorium purpureum

Geranium maculatum

Hepatica acutiloba

Hibiscus mosheutos

Iris prismatica

Lobelia cardinallis

Lilium philadelphicum

Lupinus perennus

Liatris spicata

White Snakeroot

Butterfly Weed

Blue False Indigo

Purple Conelfower

Spotted Joe - Pye Weed

Sweet Joe - Pye Weed

Wild Geranium

Sharp Lobed Hepatica

Rose Mallow Hibiscus

Slender Blue Flag

Cardinal Flower

Wood Lily

Blue Lupine

Blazing Star

Oswego Tea

Hairy Beardtongue

Summer Phlox

False Dragonhead

Symphyotrichum novi - belgii New York Aster

Solidago canadensis

Solidago caesia

Solidago flexicaulis

Andropogon gerardii

Juncus effusus

Spartina pectinata

Cornus sericea

Ilex Montana

Spirea tomentosa

Physocarpus opulifolius

Potentilla fruticosa

Vibernum acerfolium

Cornus florida

1 Magnolia tripetala

1 Malus coronaria

Prunus pensylvanica

Canada Goldenrod

Blue-Stemmed Goldenrod

Zig - Zag Goldenrod

Big Bluestem

Softrush

Prairie Cord Grass

Red Twig Dogwood

Mountain Holly

Meadowsweet Spirea

Ninebark

Shrubby cinquefoil

Mapleleaf Viburnum

Flowering Dogwood

Umbrella Magnolia

Wild Sweet Crabapple

3' - 0"

4' - 0" Hgt. 2' -

2' - 0" Hgt.

3' - 0" Hgt.

#SP4 #SP4 #SP5 #SP4 #1

Diagonally planted; groups of 3 & 5; 14" O.C.

pot

Diagonally planted; 24" O.C.

Diagonally planted; groups of 3 & 5; 10" O.C.

Diagonally planted; groups of 3 & 5; 14" O.C.

Diagonally planted; groups of 3 & 5; 8" O.C.

Diagonally planted; groups of 3 & 5; 14" O.C.

Diagonally planted; groups of 3 & 5; 10" O.C.

Diagonally planted; groups of 3 & 5; 14" O.C.

Diagonally planted; groups of 3 & 5; 18" O.C.

Diagonally planted; groups of 3 & 5; 14" O.C.

Diagonally planted; 24" O.C.

Diagonally planted; 18" O.C.

Diagonally planted; 24" O.C.

Diagonally planted; 36" O.C.

Diagonally planted; 24" O.C.

Diagonally planted; 18" O.C.

Diagonally planted; 36" O.C.

Select low branched

Pre - selected by Landscape Architect

Select low branched

Single Stem

23 (3) ST (42) AA (42) EP (42) HAc (4) IM (5) CS (41) LS (41) MD (41) SF (5) HM (29) LC (29) LS (29) SCe (3) ST (4) SP (2) CS (33) IP (33) PP (33) SF (1) PP (3) PO (3) AG (1) MT (55) AA (55) MD (55) SCa (3) JE (2) PF (2) ST (1) CF (16) LC (16) LS (16) SCe (3) PF (1) PO (5) AG (53) BA (53) LC (53) SN (17) GM (17) HAc (17) SN (1) MC (37) AT (37) GM (37) PV (24) LS (24) MD (24) SF (1) PF (4) EM (5) EPu (1) PO (2) CS (33) IP (33) PP (33) SF (1) PF (13) PV (13) GM (13) AT (1) PF (1) MT (4) EM (5) EPu (32) BA (33) LC (33) SN (3) PF (3) VA LEGEND: Perennial Hatch #1 Perennial Hatch #2 Perennial Hatch #3 Perennial Hatch #4 Perennial

#10 Trees Shrubs

Herbaceous

Plant Schedule Key: Quantity: Scientific Name: Herbacious Perennials: AA AT BA EP EM EPu GM HAc HM IP LC LP LPe LS MD PH PPa PV SN SCa SCe SF 97 50 85 42 8 9 67 59 5 46 131 20 20 110 20 46 50 Ageratina altissima Asclepias tuberosa Baptisia australis Echinacea

Hatch

Perennial Hatch

Perennial Hatch #7 Perennial Hatch #8 Perennial Hatch #9 Perennial Hatch

and Larger

Perennials

120 Monarda

Penstemon

Phlox paniculata Physostegia

103 55 45 111 SP Shrubs: CS IM ST PO PF VA Trees: CF MT MC PP 8 3 4 7 4 8 5 9 3 2 1

didyma

hirsutus

virginiana

Hgt.

0" Hgt. 3'

Pin Cherry 0"

Hgt.

#SP4 #SP4 #SP6 #SP4 #SP4 #SP4 #SP4 #SP4 #SP4 #SP4 #SP4 #SP5 #SP4 #SP5 #SP4 #SP5 #3 cont #5 cont. #5 cont. #10 cont. #7 cont. #5 cont. #5 cont. #5 cont. #10 cont. 1.5 - 2.0" Cal. B&B 1.5 - 2.0" Cal. 1.5 - 2.0" Cal. B&B B&B 5' - 6' Hgt.#15 pot

Size:Condition: Remarks:

pot

Diagonally planted; groups of 3 & 5; 14" O.C.

Design Implementation

Storm-water Drainage Plan:

Date: Spring 2021

Location: State College, Pennsylvania

Project Size: 5.2 Acres

The Pennsylvania State University Visitor Center applies grading concepts onto a real site with various challenges. The water from the parking lots is diverted into bio-rention systems that filter pollutants out of the water. As a result, the water released back into the Watershed is cleaned resulting in fewer environmental issues for residents and the wildlife. To facilitate visitor access around the building, a ramp and stairs were designed as required by ADA.

Tree Planting Construction Documents:

Date: Fall 2021

Location: University Park, PA

Project Size: 7.2 Acres

As part of the Millennium Science Complex project, a tree plaza was designed with both Strata-vault cells and Cornell University structural soil. These types of planting mediums enable the trees to grow in urban environments with hardscape material above the roots. In order for the pavers to be suspended over the root ball and flare, a custom paver grate and bolting system was designed for increased durability.

PROPERTY

BUILDING OUTLINE

EX. MAJOR CONTOUR

EX. MINOR CONTOUR

PROP. MAJOR CONTOUR

PROP. MINOR CONTOUR

RETAINING WALL

TOP WALL/BOTTOM WALL

HIGH POINT SWALE/ LOW POINT SWALE

DRAIN INLET

DRAINAGE DIRECTION

EXISTING ROADS

EXISTING VEGETATION

SITE FENCE

TOP FLOOR FINISH ELEV.

BOTTOM FLOOR ELEV.

SPOT ELEVATION

26 ADA ADA Bioretention DI /BC LPS 99.00 110 7.0% 4% 2.0% +TC: 111.50 98 109 108 107 100 101 102 103 104 105 106 99 98 96 95 94 93 92 91 90 89 88 87 111 97 105 104 101 100 105 107 104 103 102 101 100 99 111 109 108 110 106 109 108 HPS 110.00 Bioretention Stairs: 20 Landings: 105 99 100 101 102 103 104 105 105 104 102 101 100 99 98 2% 107.20+ TD TD LPS 106.00 CC 106.70 Bioretention TW 107.50 +BW 99.00 +TW 107.50 +BW 97.00 98 107 108 107 108 109 110 110 109 111 107 108 LP 106.31 106.31 LP: 106.00 106.00 107 107 +LP 106.00 RDI 107.25 111 113 114 110 111 110 111 BC: 111.00 TC: 111.90 +TC: 111.10 BC: 110.80 TC: 109.90 BC: 109.30 BC: 109.90 BC: 110.20 TC: 110.80 BC: 110.30 TC: 109.60 TC: 109.40 + TC: 110.00 BC: 109.60 TC: 109.80 TC: 109.70 TC: 109.60 TC: 109.70 BC: 108.70 BC: 108.80 BC: 108.70 TC: 109.10 TC: 108.80 BC: 108.40 TC: 109.90 BC: 109.40 TC: 109.00 BC: 108.50 BC: 108.50 BC: 108.20 TC: 108.60 BC: 108.10 TC: 108.40 BC 107.70 BC 106.90 BC 106.70 TC 107.30 BC 106.80 BC 107.20 TC 107.80 BC 107.60 TC 108.20 TC 107.90 BC 107.40 TC 107.80 BC 107.40 TC 108.10 BC 106.90 TC 107.00 TC 106.60 TC 106.70 BC 106.30 BC 106.30 TC 108.00 BC 106.30 BC 108.00 BC 108.00 BC 108.60 TC 109.30 BC 108.90 TC 109.80 BC 109.30 TC 109.70 BC 109.20 TC 108.50 BC 108.00 TC 108.40 TC 109.60 TC 109.80 TC 110.10 BC 111.00 TC 112.00 BC 110.40 TC 110.00 BC 109.50 TC 109.00 BC 108.90 TC 109.60 108.90 99.00 98.90 98.90 99.00 TW: 97.70 BW 97.30+ BW 97.60+ 107 HPR 107.50 TS 108.30+ +BW 97.00 BW 105.00 TW 102.00 BW 105.60 4.5% 2.0% 2% BW 108.20 TW 108.20 TW 109.20 BW 105.00 108 108 BW 109.10 +BW 97.70 BW 108.50 TW 107.50 BW 107.00 107.70 107.60 103.20 4% Pipe Bioretention 106.10+ DI/BC 109.20+ 108.40+ 108 HP 108.76 2.0% 2.0% 2.0% 2.0% 2.0% 2.0% Sheet Number Designer Course / Semester Sheet Title Revisions Penn State University Visitors Center A B C D 1 B C D 2 3 4 A 01.15.2023 PSU Visitors Center

LINE

TRENCH DRAIN

HPS LPS DI TFFE BFFE TW/BW + TD LEGEND

1"=80' N

CURB CUT DI/RDI

SCALE:

27" TYP

35 TYP

MULTI-LEADER TREE PLUMB AND TRUE.

SEE DETAIL: TREE GRATE INSTALLATION.

MULCH 2 - 3" W/ ALL NATURAL NON - DYED MULCH ON TOP OF ROOT BALL AWAY FROM COLLAR.

SEE DETAIL: TREE GRATE INSTALLATION FOR PAVER INSTALLATION.

ROOT BALL WITHOUT BURLAP. COLLAR SHOULD BE AT GRADE AND VISIBLE POSTINSTALLATION.

ROOT BALL IS SECURED USING DUCKBILL ROOT BALL ANCHORS. 2 CABLES PER TREE.

ROOT BALL IS INSTALLED ON 6" OF 3 4" CLEAN STONE.

CORNELL STRUCTURAL SOIL IS INSTALLED THROUGHOUT PLAZA AT 85% SPD IN 6" LIFTS.

EXISTING UNDISTURBED SUB-GRADE. NO COMPACTION IS NEEDED.

R 0'-9

12 "

C.U. STRUCTURAL SOIL.

1 2" DIA. HOLES FOR 12" GALVANIZED STEEL SPIKES TO SECURE PAVER GRATE TO SOIL.

LIP FOR TREE GRATE TO SIT ON POST INSTALLATION. SEE SHEET FOR STEELTREE GRATE FRAME SIZING.

ROOTBALL

DUCK BILL ROOT BALL ANCHOR; 1.5' AWAY FROM OUTSIDE DIA. OF TRUNK; REF. MANUFACTURER SPECS. FOR INSTALLATION

IRONSMITH 60" x 60" TREE GRATE. REF. MANUFACTURER SPECS. FOR INSTALLATION

10" X 2'-8" TECHO-BLOC HYDRA PERMEABLE PAVERS; RUNNING BOND W/ 7 16" PERMEABLE JOINTS.

TREE INSTALLATION NOTES:

-TREE TRUNK CALIPER SIZE TO MEET OR EXCEEDS ANSI Z60 STNDS.

-ROOTBALL TO MEET ANSI Z60 STNDS.

-ROOT FLARE SHOULD BE EXPOSED.

-UNCOVER 2/3 OF BURLAP FROM ROOT BALL

-REMOVE WIRE BASKET

-INSTALL CORNELL STRUCTURAL SOIL AROUND ROOT BALL

SAME INSTALLATION INSTRUCTIONS ON THE LEFT SIDE.

IRONSMITH 60" x 60" TREE GRATE. SEE SPEC SHEET FOR MODEL NUMBER. STEEL TREE GRATE FRAME. SEE SPEC SHEET FOR MODEL NUMBER.

30.0"

4.0"

TECHO - BLOC HYDRA PAVER.

6.0"

2" HIGH PERFORMANCE BASE 1 4 " CLEAN CHIP STONE. NON WOVEN GEOTEXTILE FABRIC.

12" GALVANIZED SCREW INSTALLED INTO C.U. SOIL.

TECHO - BLOC HYDRA PERMEABLE PAVERS W/ 7 16 GAP FOR PERMEABLE JOINTING MATERIAL. SEE PLAN FOR PATTERN INSTALLATION GUIDE.

PAVERS ARE INSTALLED ON 1" +/- OF HIGH PERFORMANCE BASE (HPB).

HIGH PERFORMANCE BASE (14" CRUSHED AND WASHED LIMESTONE) FILLS THE PAVER JOINTS. 1' OF 3 4" CLEAN STONE WITH NO FINES MUST BE COMPACTED IN 4" LIFTS WITH APPROPRIATE COMPACTOR. MUST BE 95% SPD.

NON WOVEN GEOTEXTILE FABRIC AS SPECIFIED BY LANDSCAPE ARCHITECT.

6" NDS PERFORATED PIPE AS SPECIFIED BY LANDSCAPE ARCHITECT.

NATIVE UNDISTURBED SOIL.

-COMPACT CU SOIL FIRMLY TO LIMIT MOVEMENT AND SETTLING

-2"-3" MULCH OVER TOP SOIL W/ 4" CLR. FROM ROOT FLARE.

-ARBORIST WILL PRUNE 3-5 YEARS AFTER PLANTING IN ACCORDANCE TO ANSI A300 SPEC..

-KEEP CABLE 1.5' AWAY FROM TREE TRUNK

C.U. SOIL AND TREE GRATE INSTALLATION NOTES:

-C.U. STRUCTURAL SOIL MUST BE INSTALLED IN 6" LIFTS AND COMPACTED TO 85% SPD.

-C.U. SHOULD BE INSTALLED AND COMPACTED AROUND THE ROOT BALL.

-TREE GRATE FRAME MUST BE INSTALLED ON 1 4 " CHIP STONE SETTING BED AND BE LEVEL TO FINISH GRADE OF PAVERS.

-TREE GRATE FRAME MUST BE INSTALLED WITH 12" GALVANIZED SCREWS INTO C.U. SOIL.

-MULCH MUST BE 2" LOWER THAN THE BOTTOM OF THE TREE GRATE.

-CONTRACTOR MUST FOLLOW ALL OTHER SPECIFICATIONS FROM IRON GRATE. SEE SPEC. SHEET.

67" TYP.

72.0" 60.0" 6.0" TYP 36.0" 30.0"

3 15 16 1.0' TYP. 17 3 4 " TYP.

Scale: 3 8 = 1' 0" 3

Scale: 1 2 = 1' 0"

1 Upper Plaza Typ. Tree Planting in Cornell Structural Soil Section Upper Plaza Typ. Tree Planting Tree Grate Enlargement

Scale: 1 4 = 1' 0"

Scale: 1 2 = 1' 0"

2 Upper Plaza Typ. Tree Planting in Cornell Structural Soil Section 4 Upper Plaza Permeable Paver Walkway Enlargement

Internships and Construction

James Doyle Design Associates Internship

Date: May 2022 - August 2022

Location: United States and U.K.

Project Size: Various

During the summer internship at JDDA, I had the opportunity to work on various projects that were in different phases. Through this experience, I was able to design details for fencing, gates, and hand rails. I was also given the opportunity to work with the other designers to create planting palettes and 3D renders to help clients visualize the design.

Construction Projects:

Date: May 2018 - Present

Location: New York and New Jersey

Project Size: Various

For over six years, I had the opportunity to work in the field to learn the installation process for various landscape features. These skills were later applied to construct my Eagle Scout project, the Alfred Baffa Pollinator Garden. As part of this project, I designed, managed, and installed all the features found on the site with help from the community.

Assorted Perennials 1 Geranium 'Brookside Hardy Geranium Hemerocallis 'Apricot Sparkle' Daylily 'Apricot Sparkle'

James Doyle Design Associates - Construction Documents

PROFESSIONALS PLOT DATE: 2022-8-4

Coreopsis verticillata Whorled Tickseed Deschampsia flexuosa Wavy Hairgrass Echinacea palida Pale Purple Coneflower Penstemon digitalis Beardtongue

Assorted Perennials Actea racemosa Black Cohosh Aster cordifolius Blue-wood Aster Dennstaedita punctilobula Hay Scented Fern Eupatorium perfoliatum Common Boneset Polystichum acrostichoides Christmas Fern

5.SEE JDDA NOTES AND SPECIFICATIONS SHEET FOR LANDSCAPE INSTALLATION SPECIFICATIONS REGARDING METHOD OF PLANTING, DEPTH OF SOIL, DISCREPANCIES ETC. 6.CONTRACTOR SHALL PROVIDE PLANTING SOIL SPECIFICATION, TO BE APPROVED, PRIOR TO SOIL ARRIVING ON SITE. 7.REFER TO REGULATIONS SET BY THE TOWN OF GREENWICH, ALL PLANTING REGULATIONS AND SPECIFICATIONS. 8.CONTRACTOR RESPONSIBLE FOR VERIFYING PLANTING MATERIALS AND QUANTITY. CONTRACTOR SHALL LAYOUT ALL PLANTING MATERIAL IN FIELD FOR REVIEW AND APPROVAL BY LANDSCAPE DESIGNER, PRIOR TO PLANTING. 9.CONTRACTOR SHALL INCLUDE (2X PER FIRST GROWING YEAR) SHEARING COSTS (BUXUS, TILIA, ILEX) INTO INSTALLATION COSTS. 10.CONTRACTOR RESPONSIBLE FOR VERIFYING THE SEED MATERIAL WITH LANDSCAPE DESIGNER PRIOR TO ORDERING. SEED VARIETIES MUST BE APPROVED BY LANDSCAPE DESIGNER. Achillea millefolium Common Yarrow Agastache foeniculum Anise Hyssop Aquilegia tuberosa Columbine Aster divaricatus White Wood Aster Bouteloua curtipendula Sideoats Grama

REVISIONS PHASE

Symphyotrichum novae-angliae New England Aster Tiarella cordifolia Heartleaf Foam Flower

6.CONTRACTORPRIORSOILSPECIFICATION, TO 7.REFERTO

8.CONTRACTORANDOFGREENWICH,SPECIFICATIONS. PLANTINGMATERIALS CONTRACTOR MATERIAL TOAPPROVALINBY PLANTING.

9.CONTRACTORSHALL TILIA,GROWINGYEAR)

10.CONTRACTORILEX)INTORESPONSIBLE THESEEDMATERIAL DESIGNERPRIORTO VARIETIESMUSTBE LANDSCAPEDESIGNER.

CIVIL ENGINEER & SURVEY COMPANY Kaaterskill Associates 517 Main St. Cairo, NY 12413 518-622-9667 ARCHITECT Douglas C. Wright Architects 1261 Broadway #400 New York, NY 10001 212-343-0034 L-5.10

CONSTRUCTION SET NOT FOR CONSTRUCTION

CHECKED BY: JD/JQ N

PLANTING PLAN- PERENNIALS

TITLE SHEET NO.

5'-0" MAX 3'-0" MIN.

AssortedPerennials

Boutelouacurtipendula SideoatsGrama

WOOD JOINT WHERE ACCESSORY OCCURS IN MIDDLE OF POST 3" x 3" CORTEN STEEL POST TYP. STEEL CABLE RAIL TERMINAL

ShadePerennials 10' 20'

Deschampsiaflexuosa WavyHairgrass

Echinaceapalida PalePurpleConeflower

Shade Perennials 3'-0" 3'-0"

Coreopsisverticillata WhorledTickseed

CABLE RAIL

3" MAX EQ. SPACING FINISH GRADE

2" 4" WOOD TOP RAIL WITH RADIUS TOP x 3" COR-TEN FLAT BAR BRASS FASTENER TYP. CORTEN TAB WELDED TO POST AND FASTENED TO FLAT BAR AND WOOD TOP RAIL RETAINING WALL SEE DETAIL (2) L-8.21 BRACKET BOLTED TO POST AND ATTACHED TO CONCRETE STEM WITH WEDGE ANCHORS

Geranium 'BrooksideHardyGeranium

Hemerocallis'ApricotSparkle' Daylily'ApricotSparkle' 2

CABLE RAILING - POST SECTION VIEW SCALE: CABLE RAILING ELEVATION VIEW 1" = 1'-0" 1

CABLE RAILING, SEE DETAIL (1) L-8.60

Tiarella cordifoliaHeartleafFoamFlower 0 SCALE: 1"=10'

3'-0" 3'-0"

Actea racemosa BlackCohosh Aster cordifoliusBlue-woodAster

Dennstaeditapunctilobula HayScentedFern

Polystichumacrostichoides ChristmasFern

Symphyotrichumnovae-angliae NewEnglandAster

RETAINING WALL RETAINING WALL

NOTES: 1.FENCING CONTRACTOR SHALL UP. 2.WOOD TO BE CLEAR WESTERN 3.STRUCTURAL ENGINEER SHALL CONCRETE STEM OR OTHER 4.CONTRACTOR SHALL CONFIRM LANDSCAPE DESIGNER BEFORE 5.CONFIRM ALL MEASUREMENTS FENCE INSTALLATION. 6.HARDWARE AND FASTENERS DESIGNER PRIOR TO CONSTRUCTION. SCALE: CABLE RAILING SOUTH ELEVATION 1/2" = 1'-0" 2

RETAINING WALL RETAINING WALL CABLE RAILING, SEE DETAIL (1) L-8.60

FINISHED GRADE INTERIOR STEEL STRUCTURE SPECIFIED BY FENCE CONTRACTOR (4) HINGE CORE DRILLS SPECIFIED BY FENCE CONTRACTOR FOOTING TO EXTEND PAST FROST DEPTH 4" 4" STEEL GATE POST INSTALLED BY FENCING CONTRACTOR 10" DIAMETER "SONOTUBE" FORM -USE THICK WALL 8 MIN.) FORM REMOVE "SONOTUBE" PRIOR TO CURING OF CONCRETE FT 4 FT x 4 FT REINFORCED 3500 PSI CONCRETE FOOTING # REBAR CAGE HORIZONTAL -12" ON CENTER BOTH WAYS VERTICAL 12 ON CENTER BOTH WAYS MASONRY TIE AT INTERSECTIONS 4'-0" 4'-0" 1'-0" (4) VERTICAL #5 REBAR CORE DRILL AND EPOXY IN GRANITE FOOTING TO BE LOCATED ON UNDISTURBED GRADE 6" CLEAR TYP 6" CLEAR TYP 15'-0" MAX 6" TYP. 3" FINISHED GRADE 2" TYP. 2" MAX. 6'-0' GATE POST HEIGHT 5'-3" + 18" SQ. RECLAIMED GRANITE POSTS (TYP) x 6" COR-TEN STEEL FLAT BAR SOLID WOOD GATE 6" 10" STILES TYP 4" 8" RAILS ROUTER OUT SLOTS IN SOLID WOOD TO RECEIVE COR-TEN STEEL FLAT BAR TYP. 6" 8" ALIGN COR-TEN FLAT BAR WITH CORNER OF GATE TYP. COR-TEN STEEL HIDDEN IN STILE AND WELDED TO GATE HINGE SPECIFIED BY FENCING CONTRACTOR FINISHED GRADE 6" TYP. 1'-0" TYP. 1'-5" TYP. DRIVEWAY STREET SIDE RESIDENCE SIDE CL CL NO.DATE SHEET & DESCRIPTION APP. 10 L-8.30 DRIVEWAY GATE AT MAIN DRIVEWAY DRAFT- COORDINATION SET Easterly- Horwitz 110 Lake Lillinonah Rd N Bridgewater, CT 06752 NOT FOR CONSTRUCTION DRAWN BY: KK ISSUE DATE: YEAR-MONTH-DAY James Doyle Design Associates, LLC STAMP TITLE SHEET NO. REVISIONS PHASE PROFESSIONALS PLOT DATE: 2022-8-4 A M E S D O Y E D E G N A S S O C A T E S N E R S C O N O F N A T U R E A N D A R T 5 G R E E N W H A V E G R E W C H C 3 0 203 869 2900 JDDA.COM CHECKED BY: JQ CIVIL ENGINEER & SURVEY COMPANY Arthur H. Howland & Associates, P.C. 50 Bridge St, New Milford, CT 06776 860-354-9346 STRUCTURAL ENGINEER CRAFT Engineering Studio 39 W 38th St, Ste. 6E, New York, NY 646-912-9867 ARCHITECT Workshop APD 39 W 38th St 7th Floor, New York, NY 212-273-9712 MEADOW CONSULTANT Larry Weaner Landscape Associates 2920 Mt. Carmel Ave., Glenside PA 19038 215-886-9740 NOTES AUTOMATED DRIVEWAY GATE: 1. DRIVEWAY GATE SHALL HAVE IN-GRADE AUTOMATIC GATE OPERATORS 2. CONFIRM ALL MEASUREMENTS IN FIELD WITH LANDSCAPE DESIGNER PRIOR TO CONSTRUCTION DRIVEWAY ACCESS SHALL BE A MINIMUM OF 14'-0" WIDE, WITHOUT OBSTRUCTIONS. CONTRACTOR SHALL VERIFY GATE OPENING & LEAF SIZE WITH LANDSCAPE DESIGNER 3. CONTRACTORS SHALL PROVIDE SHOP DRAWINGS FOR LANDSCAPE DESIGNER APPROVAL, FOOTINGS AND GATE MECHANICS 4. FENCE CONTRACTOR AND AUTO-GATE CONTRACTOR SHALL COORDINATE WITH EACH OTHER REGARDING FABRICATION AND INSTALLATION. ANY ISSUES IN SIZING SHALL BE BROUGHT IMMEDIATELY TO THE ATTENTION OF THE LANDSCAPE DESIGNER 5. BUILDER SHALL PROVIDE ELECTRICAL SERVICE AND COORDINATE PAVING SCHEDULE WITH AUTO-GATE CONTRACTOR 6. FENCING COMPONENTS SHALL COMPLY WITH ASTM STANDARDS AND ALL GUIDELINES SET BY THE AMERICAN LUMBER STANDARDS COMMITTEE 7. WOOD SHALL BE VERTICAL GRAIN CLEAR WESTERN RED CEDAR, KILN-DRIED, 12% MAXIMUM MOISTURE CONTENT. CONTRACTOR SHALL VERIFY MOISTURE CONTENT WITH LANDSCAPE DESIGNER PRIOR TO ASSEMBLY. 8. CONTRACTOR SHALL TEST MOISTURE CONTENT PRIOR TO ANY SURFACE APPLICATION 9. WOOD SHALL BE STAINED. CONTRACTOR SHALL PROVIDE SAMPLES ONSITE FOR CLIENT AND LANDSCAPE DESIGNER APPROVAL 10. ALL HARDWARE SHALL BE BRONZE. HARDWARE AND FINISHES SHALL BE REVIEWED WITH LANDSCAPE DESIGNER PRIOR TO CONSTRUCTION 11. ALL GRANITE SHALL BE APPROVED BY LANDSCAPE DESIGNER. GRANITE SHALL MATCH #/###### 12. ALL MATERIALS SHALL BE INSTALLED PER MANUFACTURES SPECIFICATIONS SCALE: SECTION - CONCRETE FOOTING & STRUCTURE 3/4" = 1'-0" 3 SCALE: ELEVATION ENTRANCE WOOD GATE WITH RECLAIMED GRANITE 3/4" 1'-0" 2 NOTES AUTOMATED DRIVEWAY GATE CONCRETE FOOTING: 1. BUILDER SHALL PROVIDE ELECTRICAL SERVICE AND COORDINATE PAVING SCHEDULE WITH AUTO-GATE CONTRACTOR 2. CONFIRM FOOTING LOCATIONS IN FIELD WITH LANDSCAPE DESIGNER PRIOR TO DRIVEWAY CONSTRUCTION 3. FENCE CONTRACTOR AND AUTO-GATE CONTRACTOR SHALL COORDINATE WITH EACH OTHER REGARDING FABRICATION AND INSTALLATION. ANY ISSUES IN SIZING SHALL BE BROUGHT IMMEDIATELY TO THE ATTENTION OF THE LANDSCAPE DESIGNER 4. TOP ELEVATIONS OF FOOTING TO BE REVIEWED ONSITE WITH THE LANDSCAPE DESIGNER 5.FOOTINGS TO BE ALIGNED AND CENTERED ON EITHER SIDE OF THE DRIVEWAY, AND NOT SKEWED 6. FOOTINGS TO BE FORMED ON UNDISTURBED GRADE 7. CIVIL ENGINEER TO ENSURE PROPER DRAINAGE, PITCHING SURFACE WATER AWAY FROM FOOTINGS SCALE: PLAN ENTRANCE WOOD GATE WITH RECLAIMED GRANITE 3/4" 1'-0" 1 FINISHED GRADE INTERIOR STEEL STRUCTURE SPECIFIED BY FENCE CONTRACTOR (4) HINGE CORE DRILLS SPECIFIED BY FENCE CONTRACTOR FOOTING TO EXTEND PAST FROST DEPTH 4" X 4" STEEL GATE POST INSTALLED BY FENCING CONTRACTOR 10" DIAMETER "SONOTUBE" FORM USE THICK WALL MIN.) FORM REMOVE "SONOTUBE" PRIOR TO CURING OF CONCRETE 4 FT x FT FT REINFORCED 3500 PSI CONCRETE FOOTING # 4 REBAR CAGE HORIZONTAL -12" ON CENTER BOTH WAYS VERTICAL 12 ON CENTER BOTH WAYS MASONRY TIE AT INTERSECTIONS 4'-0" 4'-0" 1'-0" (4) VERTICAL #5 REBAR CORE DRILL AND EPOXY IN GRANITE FOOTING TO BE LOCATED ON UNDISTURBED GRADE 6" CLEAR TYP 6" CLEAR TYP 15'-0" 2 1 2 MAX 6" TYP. 3" FINISHED GRADE 2" TYP. 2" MAX. 6'-0' GATE POST HEIGHT 5'-3" + 18" SQ. RECLAIMED GRANITE POSTS (TYP) 6" COR-TEN STEEL FLAT BAR SOLID WOOD GATE 6" x 10" STILES TYP 4" x 8" RAILS ROUTER OUT SLOTS IN SOLID WOOD TO RECEIVE COR-TEN STEEL FLAT BAR TYP. 6" x 8" ALIGN COR-TEN FLAT BAR WITH CORNER OF GATE TYP. COR-TEN STEEL HIDDEN IN STILE AND WELDED TO GATE HINGE SPECIFIED BY FENCING CONTRACTOR FINISHED GRADE 6" TYP. 1'-0" TYP. 1'-5" TYP. DRIVEWAY STREET SIDE RESIDENCE SIDE CL CL NO.DATE SHEET DESCRIPTION APP. 2 3 4 5 6 7 8 9 10 L-8.30 DRIVEWAY GATE AT MAIN DRIVEWAY DRAFT- COORDINATION SET Easterly- Horwitz 110 Lake Lillinonah Rd N Bridgewater, CT 06752 NOT FOR CONSTRUCTION DRAWN BY: KK ISSUE DATE: YEAR-MONTH-DAY James Doyle Design Associates, LLC STAMP TITLE SHEET NO. REVISIONS PHASE PROFESSIONALS PLOT DATE: 2022-8-4 J A M E S D O Y L E D E S G N A S S O C A T E S N T R E C T O N A U R E N A R T 1 G R E E N W C A V E G E N W C H T 0 6 203 869 2900 JDDA.COM CHECKED BY: JQ CIVIL ENGINEER & SURVEY COMPANY Arthur H. Howland & Associates, P.C. 50 Bridge St, New Milford, CT 06776 860-354-9346 STRUCTURAL ENGINEER CRAFT Engineering Studio 39 W 38th St, Ste. 6E, New York, NY 646-912-9867 ARCHITECT Workshop APD 39 W 38th St 7th Floor, New York, NY 212-273-9712 MEADOW CONSULTANT Larry Weaner Landscape Associates 2920 Mt. Carmel Ave., Glenside PA 19038 215-886-9740 NOTES AUTOMATED DRIVEWAY GATE: 1. DRIVEWAY GATE SHALL HAVE IN-GRADE AUTOMATIC GATE OPERATORS 2. CONFIRM ALL MEASUREMENTS IN FIELD WITH LANDSCAPE DESIGNER PRIOR TO CONSTRUCTION DRIVEWAY ACCESS SHALL BE A MINIMUM OF 14'-0" WIDE, WITHOUT OBSTRUCTIONS. CONTRACTOR SHALL VERIFY GATE OPENING & LEAF SIZE WITH LANDSCAPE DESIGNER 3. CONTRACTORS SHALL PROVIDE SHOP DRAWINGS FOR LANDSCAPE DESIGNER APPROVAL, FOOTINGS AND GATE MECHANICS 4. FENCE CONTRACTOR AND AUTO-GATE CONTRACTOR SHALL COORDINATE WITH EACH OTHER REGARDING FABRICATION AND INSTALLATION. ANY ISSUES IN SIZING SHALL BE BROUGHT IMMEDIATELY TO THE ATTENTION OF THE LANDSCAPE DESIGNER 5. BUILDER SHALL PROVIDE ELECTRICAL SERVICE AND COORDINATE PAVING SCHEDULE WITH AUTO-GATE CONTRACTOR 6. FENCING COMPONENTS SHALL COMPLY WITH ASTM STANDARDS AND ALL GUIDELINES SET BY THE AMERICAN LUMBER STANDARDS COMMITTEE 7. WOOD SHALL BE VERTICAL GRAIN CLEAR WESTERN RED CEDAR, KILN-DRIED, 12% MAXIMUM MOISTURE CONTENT. CONTRACTOR SHALL VERIFY MOISTURE CONTENT WITH LANDSCAPE DESIGNER PRIOR TO ASSEMBLY. 8. CONTRACTOR SHALL TEST MOISTURE CONTENT PRIOR TO ANY SURFACE APPLICATION 9. WOOD SHALL BE STAINED. CONTRACTOR SHALL PROVIDE SAMPLES ONSITE FOR CLIENT AND LANDSCAPE DESIGNER APPROVAL 10. ALL HARDWARE SHALL BE BRONZE. HARDWARE AND FINISHES SHALL BE REVIEWED WITH LANDSCAPE DESIGNER PRIOR TO CONSTRUCTION 11. ALL GRANITE SHALL BE APPROVED BY LANDSCAPE DESIGNER. GRANITE SHALL MATCH #/###### 12. ALL MATERIALS SHALL BE INSTALLED PER MANUFACTURES SPECIFICATIONS SCALE: SECTION CONCRETE FOOTING & STRUCTURE 3/4" 1'-0" 3 SCALE: ELEVATION ENTRANCE WOOD GATE WITH RECLAIMED GRANITE 3/4" = 1'-0" 2 NOTES AUTOMATED DRIVEWAY GATE CONCRETE FOOTING: 1. BUILDER SHALL PROVIDE ELECTRICAL SERVICE AND COORDINATE PAVING SCHEDULE WITH AUTO-GATE CONTRACTOR 2. CONFIRM FOOTING LOCATIONS IN FIELD WITH LANDSCAPE DESIGNER PRIOR TO DRIVEWAY CONSTRUCTION 3. FENCE CONTRACTOR AND AUTO-GATE CONTRACTOR SHALL COORDINATE WITH EACH OTHER REGARDING FABRICATION AND INSTALLATION. ANY ISSUES IN SIZING SHALL BE BROUGHT IMMEDIATELY TO THE ATTENTION OF THE LANDSCAPE DESIGNER 4. TOP ELEVATIONS OF FOOTING TO BE REVIEWED ONSITE WITH THE LANDSCAPE DESIGNER 5.FOOTINGS TO BE ALIGNED AND CENTERED ON EITHER SIDE OF THE DRIVEWAY, AND NOT SKEWED 6. FOOTINGS TO BE FORMED ON UNDISTURBED GRADE 7. CIVIL ENGINEER TO ENSURE PROPER DRAINAGE, PITCHING SURFACE WATER AWAY FROM FOOTINGS SCALE: PLAN - ENTRANCE WOOD GATE WITH RECLAIMED GRANITE 3/4" = 1'-0" 1 WIRE MESH MUST 18" BELOW TENSION WIRE IN LIEU OF GAUGE AND TYPE TO BE 3'-2" GATE POST HEIGHT 6" 1'-6" FOOTINGS TO FROST DEPTH TYP. OR TO SOLID ROCK 4" x 4" YELLOW CEDAR POSTS TYP. 2" 2'-6" 3'-0" 4" x 4" POST MIN WIDTH 3'-0" 1'-6" 2'-2" PLANTING AREAS 4" x 4" YELLOW CEDAR POST GARDEN AREA (1) CUSTOM GATE PANELS. VERIFY HEIGHTS AND LENGTHS IN L-8.30 AND IN FIELD 4000 PSI POURED CONCRETE FOOTING OR APPROVED EQUAL TO BE AT LEAST 6" BELOW GRADE AND EXTEND TO FROST DEPTH YELLOW CEDAR POST TO EXTEND INTO FOOTING POURED CONCRETE FOOTING TO EXTEND AT LEAST 2"-3" BELOW FROST DEPTH. FOOTING TO BE ON UNDISTURBED GRADE 2" MAX OPENING AT GRADE ASHLEY NORTON MD GATE LATCH WM PATINA, 985 LEVER 1 3/16" 5/16" ASHLEY NORTON HIN3535 WITH WM PATINA " STEEL ON RIGHT SIDE 1 4 STEEL ON TOP, BOTTOM AND RIGHT SIDES NOTES: 1.FENCING CONTRACTOR SHALL SUPPLY REQUIRED SHOP DRAWINGS AND A MOCK-UP 2.CONTRACTOR SHALL CONFIRM MAXIMUM AND MINIMUM PANEL LAYOUT WITH LANDSCAPE DESIGNER, BEFORE SHOP DRAWINGS ARE FINALIZED. 3.CONFIRM ALL MEASUREMENTS AND LAYOUT IN FIELD WITH JDDA PRIOR TO FENCE AND GATE INSTALLATION. 4.ALL FENCE HARDWARE AND POSTS SHALL BE REVIEWED AND APPROVED BY LANDSCAPE DESIGNER PRIOR TO CONSTRUCTION. CONTRACTOR SHALL PROVIDE LANDSCAPE DESIGNER WITH SPECIFICATIONS ON MATERIALS. 5.FENCE SHALL COMPLY TO ALL ASTM STANDARDS AND ALL GUIDELINES SET BY THE AMERICAN LUMBER STANDARDS COMMITTEE. 6.WOOD SHALL BE CLEAR STRAIGHT-GRAINED YELLOW CEDAR, KILN-DRIED, 12% MAXIMUM MOISTURE CONTENT, CONTRACTOR SHALL VERIFY MOISTURE CONTENT WITH LANDSCAPE DESIGNER PRIOR TO ASSEMBLY. CONTRACTOR SHALL TEST MOISTURE CONTENT PRIOR TO ANY SURFACE 2" 2" x 6" YELLOW CEDAR POST 1 4 OR x 2 STAINED STEEL FRAME MORTISED INTO WOOD 2" FINAL GRADE 2'-6" SCALE: GARDEN FENCE 1/2" = 1'-0" 2 SCALE: YELLOW CEDAR FENCE SINGLE GATE 1/2" = 1'-0" 1 GARDEN FENCE 0 SCALE:1"=10' 10' 20' 10 L-5.10 PLANTING CONSTRUCTION DRAWN ISSUE ©JamesDoyleDesignAssociates,LLC TITLE SHEETNO. PHASE PLOTDATE: N of3-5o.c.,groupsof3-5 4.ALL ALL 5.SEEHEALTHY SHEET SPECIFICATIONSETC.PLANTING,

Achillea millefoliumCommonYarrow

Aster

Agastachefoeniculum AniseHyssop Aquilegiatuberosa Columbine

divaricatus WhiteWood

Penstemondigitalis Beardtongue 1

AssortedPerennials

Eupatoriumperfoliatum CommonBoneset

NO.DATE SHEET & DESCRIPTION APP. 1 10
