WATERDOWNTAKE PIPEASPER PHE-DETAILS.
ASPERELECTRICAL CONSULTANT'S DETAIL ASPERELECTRICAL CONSULTANT'S DETAIL
PANELBOARD
RAWWATER TANK
12500LT. CAPACITY 6'6"+12"DEPTH
PROPOSEDNEWWALL
R1
METALDOORASPER INTERIORDETAIL
TREATED WATERTANK
10500LT. CAPACITY
6'6"+12"DEPTH
LOWHEIGHTWALL ASPERDETAIL
STAIRCASETOBE EXTENDEDTILLBEAM SHOWNLEVEL.
HPLSHEETCLADDING WITHCOVELIGHTAS VENDORDETAILS.
DRG.TITLE
STILTFLOORWORKINGPLAN
PROJECT
REVISIONSCHEDULE
REV.NODATE REVISION SCHEDULEOFOPENINGS
DOORS:
D:AKHILINTERNSHIP11.DWG
STATUS
SCALE:NTS
DATE:
DRGNO.:
DEALT:
D2=3'0"X9'0"SERVANTROOM
D3=2'9"X9'0"POWDERROOM
D4=2'6"X9'0"BATH,WC
W1=2'0"X5'0"4'0"SILL
W2=4'1"X6'6" D1=3'6"X9'0"LOBBY
W3=8'0"X6'6"2'6"SILL
VENTILATORS
V1=2'0"X4'0"5'-0"SILL
V2=2'2"X4'0"5'-0"SILL
WINDOWS: LEGEND: 9"THKWALL 6"BLOCKMASONRY
R.C.C.COLUMN
PHESHAFTCOVERED WITHMS/ALU.LOUVERS ASPERVENDOR'SSPECS.
MASONRYWALLAS PERDETAIL.
RCCWORKASPER STRUCTURALDETAILS
PROPOSEDNEWRCC/ MASONRYWALL
NOTE:
1.ANYDISCREPANCYINDETAILSOR MEASUREMENTOROTHERWISE SHALLBEBROUGHTTOTHENOTICE OFTHECONSULTANTBEFORE EXECUTIONOFTHESAME
2.LINTELHT.9'-0"FROMF.F.L.(FROM +2'6"FFL)UNLESSMENTIONED
3.SILLHT.2'6"FROMF.F.L.IFUNLESS MENTIONED 3.BEDROOMWINDOWSILLHT.2'-6" FROMF.F.L.IFUNLESSMENTIONED 4.CONCEALEDSERVICEDUCTSSHALL BECOVEREDWITHWALL&LOUVERS EXTERNALLYAFTERCOMPLETIONOF P.H.E.WORKS.
5.REFERRELEVANTARCHITECTURAL, STRUCTURAL,ANDOTHER CONSULTANTSDRAWINGWITHTHIS DRAWING. 6.STAIRCASECOLUMNTOBERAISED ACCORDINGTOTHESTAIRCASEDRG. 7.STILTFLOORROOFHEIGHTIS13'0" FROMF.F.L.TOF.F.L.(FROM+1'6"FFL)
SPECIFICATIONSFORCONSTRUCTION:
1.THICKNESSOFMORTARFORJOINTSOF BRICKORBLOCKSFORCONSTRUCTION OFWALLSOFANYTHICKNESSSHALL NOTEXCEED10MM.
2.PROPORTIONOFMORTARWHICHIS USEDTOCONSTRUCTWALLSMADEOF BRICKSORBLOCKSOFANYTHICKNESS SHALLBE1:4.
3.THICKNESSOFEXTERNALPLASTER SHALLNOTBELESSTHAN20MM.
4.PROPORTIONOFMORTARFOR EXTERNALPLASTERSHALLBE1:6.
5.THICKNESSOFINTERNALPLASTER SHALLNOTBELESSTHAN12MM.
6.PROPORTIONOFMORTARFORINTERNAL PLASTERSHALLBE1:4. 7.MINIMUMCURINGPERIODSHALLBE 15DAYSAFTERMINIMUMSETTINGTIME OF12HOURS.CURINGSHALLBEDONE ATSUCHINTERVALSWHEREIN CONSTANTWETNESSONSURFACE'SIS MAINTAINEDFORTHESAIDPERIODOF 15DAYS.
8.THEBRICKSORBLOCKSWHICHSHALL BEUSEDFORSAIDCONSTRUCTION SHALLBECOMPLETELYIMMERSEDIN WATERFORAMINIMUMPERIODOF48 HOURSBEFOREITSUSE.
NOTE:
110MMØPVCRAIN WATERDOWNTAKE PIPEASPER PHE-DETAILS.
HPLSHEETCLADDINGWITH COVELIGHTASVENDOR DETAILS.
GLASSRAILINGTOBE DETAILEDBYVENDOR
ISMC-200ORMSPLATE ASPERDETAIL..
GLAZINGASPER VENDORDETAILS
HPLSHEETCLADDING WITHCOVELIGHTAS VENDORDETAILS.
SLIDINGGATEANDTRACK ABOVETOBEDETAILEDBY FABRICATORORMETALIA COMPANY
NORTH-SIDE-ELEVATION
RCCOLUMNSASPER STRL.DETAILS.
CORNERWINDOWAS PERSPECIFICATION
RAILINGASPER INTERIORDETAILS
GLASSRAILINGASPER VENDORDETAILORAS PERAPPROVAL.
GLASSRAILINGAS PERVENDORDETAIL ORASPERAPPROVAL.
HPLSHEETCLADDING WITHCOVELIGHTAS VENDORDETAILS. ISMC-200ORMSPLATE ASPERDETAIL..
1.ANYDISCREPANCYINDETAILSORMEASUREMENTOROTHERWISESHALLBEBROUGHT TOTHENOTICEOFTHECONSULTANTBEFOREEXECUTIONOFTHESAME
2.LINTELHT.9'-0"FROMF.F.L.(FROM+2'6"FFL)UNLESSMENTIONED
3.SILLHT.2'6"FROMF.F.L.IFUNLESSMENTIONED
3.BEDROOMWINDOWSILLHT.2'-6"FROMF.F.L.IFUNLESSMENTIONED
4.CONCEALEDSERVICEDUCTSSHALLBECOVEREDWITHWALL&LOUVERSEXTERNALLY AFTERCOMPLETIONOFP.H.E.WORKS.
5.REFERRELEVANTARCHITECTURAL,STRUCTURAL,ANDOTHERCONSULTANTSDRAWING WITHTHISDRAWING.
6.STAIRCASECOLUMNTOBERAISEDACCORDINGTOTHESTAIRCASEDRG.
7.STILTFLOORROOFHEIGHTIS13'0"FROMF.F.L.TOF.F.L.(FROM+1'6"FFL)
SPECIFICATIONSFORCONSTRUCTION:
1.THICKNESSOFMORTARFORJOINTSOFBRICKORBLOCKSFORCONSTRUCTIONOFWALLSOFANY THICKNESSSHALLNOTEXCEED10MM.
2.PROPORTIONOFMORTARWHICHISUSEDTOCONSTRUCTWALLSMADEOFBRICKSORBLOCKSOFANY THICKNESSSHALLBE1:4.
3.THICKNESSOFEXTERNALPLASTERSHALLNOTBELESSTHAN20MM.
4.PROPORTIONOFMORTARFOREXTERNALPLASTERSHALLBE1:6.
5.THICKNESSOFINTERNALPLASTERSHALLNOTBELESSTHAN12MM.
6.PROPORTIONOFMORTARFORINTERNALPLASTERSHALLBE1:4.
7.MINIMUMCURINGPERIODSHALLBE15DAYSAFTERMINIMUMSETTINGTIMEOF12HOURS.CURINGSHALL BEDONEATSUCHINTERVALSWHEREINCONSTANTWETNESSONSURFACE'SISMAINTAINEDFORTHE SAIDPERIODOF15DAYS.
8.THEBRICKSORBLOCKSWHICHSHALLBEUSEDFORSAIDCONSTRUCTIONSHALLBECOMPLETELY IMMERSEDINWATERFORAMINIMUMPERIODOF48HOURSBEFOREITSUSE.
PERSTRL.DETAILS.
SECTIONATA-A
STAIRCASETOE ETENDEDTILLEAM SHOWNLEEL.
2.LINTELHT.-0ROM..L.ROM2LNLESSMENTIONED .SILLHT.2ROM..L.INLESSMENTIONED .EDROOMWINDOWSILLHT.2-ROM..L.INLESSMENTIONED 4.CONCEALEDSERICEDCTSSHALLECOEREDWITHWALLLOERSETERNALL ATERCOMPLETIONOP.H.E.WORKS. .REERRELEANTARCHITECTRALSTRCTRALANDOTHERCONSLTANTSDRAWING WITHTHISDRAWING. .STAIRCASECOLMNTOERAISEDACCORDINGTOTHESTAIRCASEDRG. .STILTLOORROOHEIGHTIS10ROM..L.TO..L.ROM1L
SPECIICATIONSORCONSTRCTION:
REISIONSCHEDLE
R1 0-11-202 2-0-202 STAIRCASEAREAREISION
R2 NORTHWESTSTAIRACASE WALLREISIONASPERSITE. R EATERNSIDESETACKANDCHANGES INMDROOMAREA
REDATE .NO REISION 0-08-202
1.THICKNESSOMORTARORJOINTSORICKORLOCKSORCONSTRCTIONOWALLSOAN THICKNESSSHALLNOTECEED10MM.
2.PROPORTIONOMORTARWHICHISSEDTOCONSTRCTWALLSMADEORICKSORLOCKSOAN THICKNESSSHALLE1:4. .THICKNESSOETERNALPLASTERSHALLNOTELESSTHAN20MM.
4.PROPORTIONOMORTARORETERNALPLASTERSHALLE1:. .THICKNESSOINTERNALPLASTERSHALLNOTELESSTHAN12MM. .PROPORTIONOMORTARORINTERNALPLASTERSHALLE1:4. .MINIMMCRINGPERIODSHALLE1DASATERMINIMMSETTINGTIMEO12HORS.CRINGSHALL EDONEATSCHINTERALSWHEREINCONSTANTWETNESSONSRACESISMAINTAINEDORTHE SAIDPERIODO1DAS.
8.THERICKSORLOCKSWHICHSHALLESEDORSAIDCONSTRCTIONSHALLECOMPLETEL IMMERSEDINWATERORAMINIMMPERIODO48HORSEOREITSSE.
WINDOWLINTELAND CHAJJAASPERDETAIL.
WINDOWSILLASPER DETAIL.
ROOEAMASPER STRL.DETAILS.
WINDOWLINTELAND CHAJJAASPERDETAIL.
WINDOWASPER
WINDOWSILLASPER DETAIL.
LIGHTWEIGHTLOCKS ILLING
WALLASPERDETAIL LITDOORASPER ENDORDETAILS.
COMPONDWALLAS PERDETAIL..
NOTE: 1.ANDISCREPANCINDETAILSORMEASREMENTOROTHERWISESHALLEROGHT TOTHENOTICEOTHECONSLTANTEOREEECTIONOTHESAME
2.LINTELHT.-0ROM.L.ROM2LNLESSMENTIONED
3.SILLHT.2ROM..L.INLESSMENTIONED 3.EDROOMWINDOWSILLHT.2-ROM..L.INLESSMENTIONED 4.CONCEALEDSERICEDCTSSHALLECOEREDWITHWALLLOERSETERNALL ATERCOMPLETIONOP.H.E.WORKS. .REERRELEANTARCHITECTRALSTRCTRALANDOTHERCONSLTANTSDRAWING WITHTHISDRAWING. .STAIRCASECOLMNTOERAISEDACCORDINGTOTHESTAIRCASEDRG. .STILTLOORROOHEIGHTIS130ROM..L.TO..L.ROM1L
GLASSROOAOEAS PERSTRL.GLAING CONSLTANTDETAILS
ROOEAMASPER STRL.DETAILS.
12MMMMMSO SECTIONAT11 2CCAS PERARICATOR DETAILS.
WINDOWASPER JOINERDETAILS.
THICKRCCCOPING THICKRCCWALLAS PERDETAIL.
ROOEAMASPERSTRL.
ALSECEILINGASPER INTERIORDETAILS
STRL.DETAILS
LITGLAINGASPER LITENDORDETAILS
STONECLADDINGAS PERAPPROAL.
LEDGEORARTIACTS WITHCOELIGHTAS PERINTERIORDETAILS.
RPPLANTEROAS PERINTERIOR LANDSCAPEDETAILS
RCCEAMASPER STRL.DETAILS
ALSECEILINGASPER INTERIORDETAILS
STONECLADDINGAS PERAPPROAL.
LEDGEORARTIACTS WITHCOELIGHTAS PERINTERIORDETAILS.
RPPLANTEROAS PERINTERIOR LANDSCAPEDETAILS
GRILLGATEASPER APPROAL.
SPECIICATIONSORCONSTRCTION:
1.THICKNESSOMORTARORJOINTSORICKORLOCKSORCONSTRCTIONOWALLSOANTHICKNESSSHALLNOT ECEED10MM.
2.PROPORTIONOMORTARWHICHISSEDTOCONSTRCTWALLSMADEORICKSORLOCKSOANTHICKNESSSHALL E1:4.
3.THICKNESSOETERNALPLASTERSHALLNOTELESSTHAN20MM. 4.PROPORTIONOMORTARORETERNALPLASTERSHALLE1: .THICKNESSOINTERNALPLASTERSHALLNOTELESSTHAN12MM. .PROPORTIONOMORTARORINTERNALPLASTERSHALLE1:4. .MINIMMCRINGPERIODSHALLE1DASATERMINIMMSETTINGTIMEO12HORS.CRINGSHALLEDONEAT SCHINTERALSWHEREINCONSTANTWETNESSONSRACESISMAINTAINEDORTHESAIDPERIODO1DAS. 8.THERICKSORLOCKSWHICHSHALLESEDORSAIDCONSTRCTIONSHALLECOMPLETELIMMERSEDINWATER ORAMINIMMPERIODO48HORSEOREITSSE.
DRG.TITLE
STILTLOORANDGRONDLOOREASTWESTSIDEPARTELEATIONSECTIONS.
PROJECT
MASSINGWALLASPER DETAIL
ROOEAMASPER
ROOEAMASPER STRL.DETAILS.
WINDOWLINTELAND CHAJJAASPERDETAIL.
WINDOWASPER JOINERDETAILS.
DETAIL.
WINDOWSILLASPER DETAIL.
10MMMSPLATEAT6CC ASPERARICATOR DETAILS
GLAINGASPERSTRL. GLAINGCONSLTANT DETAILS.
THIRDLOORL
SLAASPER STRL.DETAILS
HPLSHEETCLADDINGAS PERENDORDETAILS.
ALMINMPROILE LOERSASPER APPROAL.
WINDOWINELEATION ASPERSPECIICATION
MASSINGWALLAS PERELEATION DETAILS
HANDRAILASPER ENDORDETAILS.
SLAASPER STRL.DETAILS SECONDLOORL
ISMC-200WITHMSPLATE ASPERSTRL.DETAILS
CORNERWINDOWASPER SPECIICATION
GLAINGASPERSTRL. GLAINGCONSLTANT DETAILS.
INTERIORDETAILS
STRL.DETAILS
CHAJJAASPERDETAIL.
WINDOWASPER JOINERDETAILS.
WINDOWSILLASPER DETAIL.
STRL.DETAILS.
WINDOWLINTELAND CHAJJAASPERDETAIL.
WINDOWSILLASPER DETAIL.
GLASSROOAOEAS PERSTRL.GLAING CONSLTANTDETAILS
ROOEAMASPER STRL.DETAILS. 12MMMMMSO SECTIONAT11 2CCASPER ARICATORDETAILS.
2.LINTELHT.-0ROM..L.ROM26LNLESS MENTIONED .SILLHT.26ROM..L.INLESSMENTIONED .EDROOMWINDOWSILLHT.2-6ROM.L.I NLESSMENTIONED 4.CONCEALEDSERICEDCTSSHALLECOERED WITHWALLLOERSETERNALLATER COMPLETIONOP.H.E.WORKS. .REERRELEANTARCHITECTRALSTRCTRAL ANDOTHERCONSLTANTSDRAWINGWITHTHIS DRAWING. 6.STAIRCASECOLMNTOERAISEDACCORDINGTO THESTAIRCASEDRG. .STILTLOORROOHEIGHTIS10ROM.L.TO ..L.ROM16L
SPECIICATIONSORCONSTRCTION:
1.THICKNESSOMORTARORJOINTSORICKORLOCKS ORCONSTRCTIONOWALLSOANTHICKNESS SHALLNOTECEED10MM.
2.PROPORTIONOMORTARWHICHISSEDTOCONSTRCT WALLSMADEORICKSORLOCKSOANTHICKNESS SHALLE1:4. .THICKNESSOETERNALPLASTERSHALLNOTELESS THAN20MM. 4.PROPORTIONOMORTARORETERNALPLASTERSHALL E1:6. .THICKNESSOINTERNALPLASTERSHALLNOTELESS THAN12MM. 6.PROPORTIONOMORTARORINTERNALPLASTERSHALL E1:4. .MINIMMCRINGPERIODSHALLE1DASATER MINIMMSETTINGTIMEO12HORS.CRINGSHALLE DONEATSCHINTERALSWHEREINCONSTANT WETNESSONSRACESISMAINTAINEDORTHESAID PERIODO1DAS. 8.THERICKSORLOCKSWHICHSHALLESEDORSAID CONSTRCTIONSHALLECOMPLETELIMMERSEDIN WATERORAMINIMMPERIODO48HORSEOREITS SE.
SCALE:NTS
LEGEND
SECTIONAL ELEVATION A-A'
SECTIONAL ELEVATION B-B'
SITE COPY
COVE LIGHTAS PER SELECTION.
FALSE CEILING TO BE FINISHED WITH 12MM THK POP BACKING WITH 12MM THK PLYAS PER SELECTION.
WALLTO BE FINISHED WITH PUNNING WITH PAINTAS PER SELECTION.
COVE LIGHTAS PER SELECTION.
FALSE CEILING TO BE FINISHED WITH 12MM THK POP BACKING WITH 12MM THK PLYAS PER SELECTION.
WALLTO BE FINISHED WITH 12MM PUNNING WITH PAINT AS PER SELECTION.
17MM THICK DIFFUSER LIGHT COMPATABLE WITH TRIAC DIMMING & DALI DIMMING CONTROLLERAS PER SELECTION.
12MM THICK DIFFUSER LIGHT COMPATABLE WITH TRIAC DIMMING & DALI DIMMING CONTROLLERAS PER SELECTION.
DOOR HANDLE WITH CARD READER
ROOM DOOR FRONT FACIATO BE FINISHED WITH 12MM THK MANNLOUVERS BACKING WITH 50MM THKAS PER SELECTION.
CONCEALED DOOR CLOSER AS PER SELECTION.
12MM THICK DIFFUSER LIGHT COMPATABLE WITH TRIAC DIMMING & DALI DIMMING CONTROLLERAS PER SELECTION.
WALLTO BE FINISHED WITH 20MM THK DARK COLOUR MARBLE WITH EDGE PROFILEAS PER SELECTION.
+75MM FLOATING PANNELTO BE FINISHED WITH MDF WITH PAINT BACKING WITH 19MM PLYAS PER SELECTION.
350MM DEEP CEILING SUSPENDED SHELF REFER DETAIL.
GLASSWOOL INSULATIONAS PER ACOUSTICAL CONSULTANT.
20MM THK DARK COLOUR MARBLEAS PER SELECTION.
12MM PERFORATED MDF SHEET WITH BACKLIGHTAND HARDWOOD LIPPING TO BE FIXED USINGALLEN KEY.
DRY LANDSCAPE WITH 25MM THK GRAVEL/PEBBLE BEDAS PER LANDSCAPISTS DETAIL.
4MM THK MDF WITH 19MM THK PLY BACKINGAND PAINT FINISH.
25MM X 12MM THK HARDWOOD LIPPING TO FIX 12MM THK PERFORATED SHEET WITHALLEN KEY.
4MM THK MDF WITH 19MM THK PLY BACKINGAND PAINT FINISH.
COVE LIGHTAS PER SELECTION.
METAL EDGE PLATE WITH ROSE GOLD BRUSH FINISHAS PER SELECTION.
4MM THKACRYLIC SHEET FINISH WITH 12MM THK PLY BACKINGAS PERACOUSTICAL CONSULTANT.
12MM THK PARTICLE BOARD AS PER SELECTION.
SCHEDULE OF OPENINGS D5B = 3'6"X8'6" LINTEL 8'-6" FROM FFL
COVE LIGHTAS PER SELECTION.
4MM MDF WITH 12MM PLY BACKINGAND PAINT FINISHAS PER SELECTION.
6MM FABRIC/LEATHER FINISH WITH 16MM PLY BACKINGAS PER SELECTION.
410MM DEEP COUNTERTOPTO BE FINISHED WITH DARK COLOUR MARBLEAS PER SELECTION.
6MM FABRIC/LEATHER FINISH WITH 12MM PLY BACKINGAS PER SELECTION.
12MM PARTICLE BOARD AS PER SELECTION.
GLASSWOOL INSULATIONAS PERACOUSTICAL CONSULTANT.
25MM X 10MM X 1MM THK METAL EDGE WITH ROSE GOLD BRUSH FINISHAS PER SELECTION.
COVE LIGHTAS PER SELECTION.
12MM THK DARK COLOUR TOUGHENED GLASS WITH STAR EFFECTAND BACKLIGHT.
12MM THK TOUGHENED GLASS SHUTTERAS PER SELECTION.
4MM THKACRYLIC SHEET WITH 12MM PLY BACKINGAS PER SELECTION.
12MM THK PARTICLE BOARD AS PER SELECTION.
GENERAL NOTES:
1. ANY DISCREPANCY IN DETAILS OR MEASUREMENT OR OTHERWISE SHALL BE BROUGHT TO THE NOTICE OF THE CONSULTANT BEFORE EXECUTION
2. ALLTHE MATERIALS BROUGHT TO SITE FOR CONSTRUCTION PURPOSE SHOULD BEAS PER SPECIFICATIONS MENTIONED IN THE QUOTATION/ DRAWINGS AND APPROVAL FOR THE SAME TO BE OBTAINED FROM OWNER BEFORE EXECUTION
3. BEFORE COVERING THE FALSE CEILING ENSUREALL THE OTHER CO-ORDINATED SERVICES LIKE ELECTRICAL, HVAC, PLUMBING ETC., TO BE COMPLETED
4. ALL FALSE CEILING LEVELSARE MENTIONED FROM RESPECTIVE FINISHED FLOOR LEVELAND SLAB BOTTOM LEVELS UNLESS OTHERWISE SPECIFIED. KINDLY NOTE THAT THE SLAB LEVELSARE CHANGINGAT REGULAR INTERVALS.
5. REFER RELEVANTARCHITECTURAL, STRUCTURAL,AND OTHER CONSULTANTS DRAWING WITH THIS DRAWING.
6. ALL OTHER LIGHT FIXTURES, PENDANT LIGHTSAND CHANDELIER'S SHOWN IN THE DRAWINGS SHALL BE AS PER OWNER'S PURCHASE.
7. WALL PAINTAND OTHER WALL PANEL FINISHES TO BE MATCHED TO THE COLORAS PER SPECIFICATIONS MENTIONED IN THE DRAWING
8. IT IS CUSTOMER'S/CONTRACTOR'S RESPONSIBILITYTO LOCATE BUILDING LINESAND BENCH MARKS TO SITE.
9. IT IS CUSTOMER'S RESPONSIBILITYTO VERIFYAND ENSURE CORRECTNESS IN EXECUTION OFALLARCHITECTURAL AND INTERIOR WORKSAT SITEAS PER HAaID'S DESIGNSAND DRAWINGS.
61 MM DEEP CIRCULAR NICHE TO BE FINISHED WITH 12MM THK PLY BACKINGAND 4MM THKACRYLIC SHEET FINISHAS PER SELECTION.
17MM THICK DIFFUSER LIGHT COMPATABLE WITH TRIAC DIMMING & DALI DIMMING CONTROLLERAS PER SELECTION. 460MM DEEP OPEN SHELF TOPTO BE FINISHED WITH LIGHT COLOUR MARBLEAS PER SELECTION.
DOOR FRAMEAND SHUTTERAS PER ACOUSTICAL CONSULTANT.
460MM DEEP FLOATING PANELTO BE FINISHED WITH 4MMACRYLIC SHEET WITH 19MM PLY.
4MM THK MDF WITH 19MM THK PLY BACKING WITH PAINT FINISH AS PER SELECTION TO FIX THE SCREEN.
GLASSWOOL INSULATIONAS PER ACOUSTICAL CONSULTANT.
RECESSED TRIMLESS MAGNETIC TRACK LIGHTAS PER VENDOR SPECIFICATION
12MM POP FALSE CEILING TO BE FINISHED WITH EXPOSED CONCRETE FINISH.
GLASSWOOL INSULATIONAS PERACOUSTICAL CONSULTANT.
350MM DEEP CEILING SUSPENDED SHELF.
6MM FABRIC/LEATHER FINISH WITH 12MM PLY BACKINGAS PER SELECTION.
12MM PARTICLE BOARD AS PER SELECTION.
410MM DEEP COUNTERTOPTO BE FINISHED WITH DARK COLOUR MARBLE WITH ROUNDING EDGEAS PER SELECTION.
STORAGE SHELF OPENABLE SHUTTER TO BE FINISHED WITH 1MM THK LAMINATE WITH 19MM PLY BACKINGAS PER SELECTION.
ALUMINIUM PROFILE HANDLE AS PER VENDOR SELECTION.
DRAWER TO BE FINISHED WITH 1MM LAMINATE WITH 12MM PLY BACKINGAS PER SELECTION.
100MM DARK COLOUR MARBLE SKIRTINGAS PER SELECTION.
25 X 10 X 1MM THK METAL EDGE PLATE WITH ROSE GOLD BRUSH FINISHAS PER SELECTION.
12MM MDF WITH 12MM THK PLY BACKINGAND PAINT FINISH AS PER SELECTION.
GI SUPPORTS TO TAKE 12MM POP CEILINGAS PER SELECTION.
GLASSWOOL INSULATIONAS PERACOUSTICAL CONSULTANT.
6MM FABRIC/LEATHER FINISH WITH 12MM PLY BACKINGAS PER SELECTION.
12MM PARTICLE BOARD AS PER SELECTION.
CIRCULAR NICHE FOR MOVIE POSTERS.
PLAN @ 1360MM LVL FROM FFL
CIRCULAR NICHE FRONT FACIA TO BE FINISHED WITH 4MM MDF WITH 12MM PLY BACKINGAND PAINT FINISHAS PER SELECTION.
LIGHT COLOUR MARBLE WITH 4MM ROUNDING EDGEAS PER SELECTION.
PLAN @ 400MM LVL FROM FFL
COVE LIGHTAS PER SELECTION.
6MM FABRIC/LEATHER FINISH WITH 12MM PLY BACKINGAS PER SELECTION.
COVE LIGHTAS PER SELECTION.
20MM THK DARK COLOUR MARBLE SKIRTING WITH 5MM CHEMICALAND 12 MM PLY BACKINGAS PER SELECTION.
GENERAL NOTES:
1. ANY DISCREPANCY IN DETAILS OR MEASUREMENT OR OTHERWISE SHALL BE BROUGHT TO THE NOTICE OF THE CONSULTANT BEFORE EXECUTION
2. ALLTHE MATERIALS BROUGHT TO SITE FOR CONSTRUCTION PURPOSE SHOULD BEAS PER SPECIFICATIONS MENTIONED IN THE QUOTATION/ DRAWINGS AND APPROVAL FOR THE SAME TO BE OBTAINED FROM OWNER BEFORE EXECUTION
3. BEFORE COVERING THE FALSE CEILING ENSUREALL THE OTHER CO-ORDINATED SERVICES LIKE ELECTRICAL, HVAC, PLUMBING ETC., TO BE COMPLETED
4. ALL FALSE CEILING LEVELSARE MENTIONED FROM RESPECTIVE FINISHED FLOOR LEVELAND SLAB BOTTOM LEVELS UNLESS OTHERWISE SPECIFIED. KINDLY NOTE THAT THE SLAB LEVELSARE CHANGINGAT REGULAR INTERVALS.
5. REFER RELEVANTARCHITECTURAL, STRUCTURAL,AND OTHER CONSULTANTS DRAWING WITH THIS DRAWING.
6. ALL OTHER LIGHT FIXTURES, PENDANT LIGHTSAND CHANDELIER'S SHOWN IN THE DRAWINGS SHALL BE AS PER OWNER'S PURCHASE.
7. WALL PAINTAND OTHER WALL PANEL FINISHES TO BE MATCHED TO THE COLORAS PER SPECIFICATIONS MENTIONED IN THE DRAWING
8. IT IS CUSTOMER'S/CONTRACTOR'S RESPONSIBILITYTO LOCATE BUILDING LINESAND BENCH MARKS TO SITE.
9. IT IS CUSTOMER'S RESPONSIBILITYTO VERIFYAND ENSURE CORRECTNESS IN EXECUTION OFALLARCHITECTURAL AND INTERIOR WORKSAT SITEAS PER HAaID'S DESIGNSAND DRAWINGS.
12'-11"(12'-4½") X 20'-8"(19'-6")(12'-2")
HOME THEATER
LEATHER/FABRIC FINISH.
GLASS SHUTTER HINGEAS PER VENDOR SPECIFICATIONS.
PENDANT LIGHT INSIDE GLASS SHELFAS PER VENDOR SEELCTION.
12MM POP FALSE CEILING TO BE FINISHED WITH EXPOSED CONCRETE FINISH.
GLASSWOOL
CIRCULAR NICHE FRONT FACIA TO BE FINISHED WITH 4MM MDF WITH 12MM PLY BACKINGAND PAINT FINISHAS PER SELECTION.
6MM FABRIC/LEATHER FINISH WITH 12MM PLY BACKING AS PER SELECTION.
COVE LIGHTAS PER SELECTION.
600 X 600 X 10MM THK CARPET TILE WITH 19MM THK PLY BACKINGAS PER SELECTION.
LIGHT WEIGHT BLOCK FILLING.
20MM THK DARK COLOUR MARBLE SKIRTING WITH 19MM PLYAND 5MM CHEMICALAS PER SELECTION.
SCHEDULE OF OPENINGS D5B = 3'6"X8'6" LINTEL 8'-6" FROM FFL
GI SUPPORTS TO TAKE 12MM POP CEILINGAS PER SELECTION.
AC SUPPLY GRILLAS PER HVAC CONSULTANT.
460MM DEEP FLOATING PANEL SIDE TO BE FINISHED WITH 4MM ACRYLIC SHEET WITH 19MM PLY BACKINGAS PER SELECTION.
WALLTO BE FINISHED WITH 4MMACRYLIC SHEET WITH 12MM PLY BACKINGAND 12MM PARTICLE BOARDAND GLASSWOOL FILLINGAS PER SELECTION.
4MM MDF WITH 19MM PLY BACKING AND PAINT FINISHAS PER SELECTION.
GLASSWOOL INSULATIONAS PER ACOUSTICAL CONSULTANT.
SHELF TOPTO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE WITH 19MM PLY BACKINGAND 4MM ROUND EDGEAS PER SELECTION.
OPEN STORAGE SHELF TO BE FINISHED WITH 1MM THK LAMINATE ON BOTH SIDES WITH 19MM PLY BACKINGAS PER SELECTION.
20MM THK DARK COLOUR MARBLE SKIRTING WITH 19MM PLY BACKING AND 5MM CHEMICAL.
FLOWER VASEAS PER SELECTION.
GENERAL NOTES:
1. ANY DISCREPANCY IN DETAILS OR MEASUREMENT OR OTHERWISE SHALL BE BROUGHT TO THE NOTICE OF THE CONSULTANT BEFORE EXECUTION
2. ALLTHE MATERIALS BROUGHT TO SITE FOR CONSTRUCTION PURPOSE SHOULD BEAS PER SPECIFICATIONS MENTIONED IN THE QUOTATION/ DRAWINGS AND APPROVAL FOR THE SAME TO BE OBTAINED FROM OWNER BEFORE EXECUTION
3. BEFORE COVERING THE FALSE CEILING ENSUREALL THE OTHER CO-ORDINATED SERVICES LIKE ELECTRICAL, HVAC, PLUMBING ETC., TO BE COMPLETED
4. ALL FALSE CEILING LEVELSARE MENTIONED FROM RESPECTIVE FINISHED FLOOR LEVELAND SLAB BOTTOM LEVELS UNLESS OTHERWISE SPECIFIED. KINDLY NOTE THAT THE SLAB LEVELSARE CHANGINGAT REGULAR INTERVALS.
5. REFER RELEVANTARCHITECTURAL, STRUCTURAL,AND OTHER CONSULTANTS DRAWING WITH THIS DRAWING.
6. ALL OTHER LIGHT FIXTURES, PENDANT LIGHTSAND CHANDELIER'S SHOWN IN THE DRAWINGS SHALL BE AS PER OWNER'S PURCHASE.
7. WALL PAINTAND OTHER WALL PANEL FINISHES TO BE MATCHED TO THE COLORAS PER SPECIFICATIONS MENTIONED IN THE DRAWING
8. IT IS CUSTOMER'S/CONTRACTOR'S RESPONSIBILITYTO LOCATE BUILDING LINESAND BENCH MARKS TO SITE. 9. IT IS CUSTOMER'S RESPONSIBILITYTO VERIFYAND ENSURE CORRECTNESS IN EXECUTION OFALLARCHITECTURAL AND INTERIOR WORKSAT SITEAS PER HAaID'S DESIGNSAND DRAWINGS.
SHEET NO - 10 OF 15
REF IMAGE FOR GLASS HINGE
REF IMAGE FORACRYLIC SHEET
REF IMAGE FOR CARPET TILE
COVE
+100MM LVL FLOATING PANEL TO BE FINISHED WITH 3MM THK MDF WITH 19MM THK PLY BACKING AND PAINT FINISH AS PER SELECTION.
SHUTTER FRONT FACIA TO BE FINISHED WITH 19MM THK PLY WITH 4MM THK VENEER AND 1MM THK LAMINATE ON THE INSIDE.
STORAGE SHELF INSIDE TO BE FINISHED WITH 19MM THK PLY WITH 1MM THK LAMINATE AS PER SELECTION.
FLOATING PANEL TO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE WITH 19M THK PLY BACKING AS PER SELECTION.
+70MM LVL FLOATING PANEL TO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE WITH 19MM THK PLY BACKING AS PER SELECTION.
WALL TO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE AS PER SELECTION.
CONSOLE UNIT INSIDE TO BE FINISHED WITH 19MM THK PLY WITH 1MM THK LAMINATE AS PER SELECTION. SHUTTER TO BE PROVIDED WITH METAL PROFILE HANDLE AS PER VENDOR SELECTION.
SCHEDULE OF
SW1 = 5'4"X7'0" SILL LINTEL D = 3'6"X8'0" 1'-0"8'-0" FROM 2'-6" FFL FROM 2'-6" FFL 8'-0"
12MM THK MANNLOUVER WITH 19MM THK PLY BACKING TO SUPPORT MARBLE COUNTERTOP. EC
WALL TO BE FINISHED WITH 12MM THK MANNLOUVER WITH 12MM THK PLY BACKING AS PER SELECTION.
WALL TO BE FINISHED WITH LIGHT COLOUR MARBLE AS PER SEELCTION.
20MM THK DARK COLOUR MARBLE TABLETOP WITH 4 X 4MM EDGE GROOVE AS PER SELECTION.
DOOR AS PER JOINERY DETAILS.
WALL TO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE AS PER SELECTION.
CONSOLE UNIT SHUTTER TO BE FINISHED WITH 16MM THK PLY WITH 4MM THK VENEER IN THE FRONT AND 1MM THK LAMINATED ON THE INSIDE.
GENERAL NOTES:
1. ANY DISCREPANCY IN DETAILS OR MEASUREMENT OR OTHERWISE SHALL BE BROUGHT TO THE NOTICE OF THE CONSULTANT BEFORE EXECUTION
2. ALLTHE MATERIALS BROUGHT TO SITE FOR CONSTRUCTION PURPOSE SHOULD BEAS PER SPECIFICATIONS MENTIONED IN THE QUOTATION/ DRAWINGS AND APPROVAL FOR THE SAME TO BE OBTAINED FROM OWNER BEFORE EXECUTION
3. BEFORE COVERING THE FALSE CEILING ENSUREALL THE OTHER CO-ORDINATED SERVICES LIKE ELECTRICAL, HVAC, PLUMBING ETC., TO BE COMPLETED
4. ALL FALSE CEILING LEVELSARE MENTIONED FROM RESPECTIVE FINISHED FLOOR LEVELAND SLAB BOTTOM LEVELS UNLESS OTHERWISE SPECIFIED. KINDLY NOTE THAT THE SLAB LEVELSARE CHANGINGAT REGULAR INTERVALS.
5. REFER RELEVANTARCHITECTURAL, STRUCTURAL,AND OTHER CONSULTANTS DRAWING WITH THIS DRAWING.
6. ALL OTHER LIGHT FIXTURES, PENDANT LIGHTSAND CHANDELIER'S SHOWN IN THE DRAWINGS SHALL BE AS PER OWNER'S PURCHASE.
7. WALL PAINTAND OTHER WALL PANEL FINISHES TO BE MATCHED TO THE COLORAS PER SPECIFICATIONS MENTIONED IN THE DRAWING
8. IT IS CUSTOMER'S/CONTRACTOR'S RESPONSIBILITYTO LOCATE BUILDING LINESAND BENCH MARKS TO SITE.
9. IT IS CUSTOMER'S RESPONSIBILITYTO VERIFYAND ENSURE CORRECTNESS IN EXECUTION OFALLARCHITECTURAL AND INTERIOR WORKSAT SITEAS PER HAaID'S DESIGNSAND DRAWINGS.
12MM THK POP FALSE CEILING WITH 12MM THK PLY BACKING AND PAINT FINISH AS PER SELECTION.
12MM THK TOUGHENED GLASS AS PER SELECTION.
OPEN SHELF TO BE FINISHED WITH 4MM THK VENEER WITH 12MM THK PLY ON ALL SIDES AS PER SELECTION.
20MM X 4MM THK METAL EDGE TO BE FINISHED WITH ROSE GOLD BRUSH FINISH AS PER SELECTION.
TABLETOP TO BE FINISHED 20MM THK DARK COLOUR MARBLE WITH 4 X 4MM EDGE GROOVE AS PER SELECTION.
DRAWER INSIDE TO BE FINISHED WITH 12MM THK PLY WITH 1MM THK LAMINATE ON ALL SIDES AS PER SELECTION.
DRAWER FRONT FACIA TO BE FINISHED WITH 4MM THK VENEER WITH 19MM THK PLY BACK AND LAMINATE FINISH ON THE INSIDE AS PER SELECTION.
SHUTTER FRONT FACIA TO BE FINISHED WITH 19MM THK PLY WITH 4MM THK VENEER AND 1MM THK LAMINATE ON THE INSIDE.
= 2'9"X8'0"
SCHEDULE OF OPENINGS: DOORS: WINDOWS:
= 5'4"X7'0"
RECESSED TRIMLESS MAGNETIC TRACK LIGHT AS PER VENDOR SPECIFICATION.
FALSE CEILING TO BE FINISHED WITH 12MM THK MANNLOUVER WITH 12MM THK PLY AS PER SELECTION.
WALL TO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE AS PER SELECTION.
BLINDS AS PER SELECTION.
WALL TO BE FINISHED WITH 12MM THK MANNLOUVERS WITH 12MM THK PLY AS PER SELECTION.
ARTCRAFTS AS PER SELECTION.
COVE LIGHT AS PER SELECTION. FIXED DOUBLE GLAZED WINDOW AS PER VENDOR'S SPECIFICATION.
25MM X 4MM THK METAL EDGE TO BE FINISHED WITH ROSE GOLD BRUSH FINISH AS PER SELECTION.
+100MM LVL FLOATING PANEL TO BE FINISHED WITH 3MM THK MDF WITH 19MM THK PLY BACKING AND PAINT FINISH AS PER SELECTION.
100MM DARK COLOUR MARBLE SKIRTING AS PER SELECTION.
1. ANY DISCREPANCY IN DETAILS OR MEASUREMENT OR OTHERWISE SHALL BE BROUGHT TO THE NOTICE OF THE CONSULTANT BEFORE EXECUTION
2. ALLTHE MATERIALS BROUGHT TO SITE FOR CONSTRUCTION PURPOSE SHOULD BEAS PER SPECIFICATIONS MENTIONED IN THE QUOTATION/ DRAWINGS AND APPROVAL FOR THE SAME TO BE OBTAINED FROM OWNER BEFORE EXECUTION
3. BEFORE COVERING THE FALSE CEILING ENSUREALL THE OTHER CO-ORDINATED SERVICES LIKE ELECTRICAL, HVAC, PLUMBING ETC., TO BE COMPLETED
4. ALL FALSE CEILING LEVELSARE MENTIONED FROM RESPECTIVE FINISHED FLOOR LEVELAND SLAB BOTTOM LEVELS UNLESS OTHERWISE SPECIFIED. KINDLY NOTE THAT THE SLAB LEVELSARE CHANGINGAT REGULAR INTERVALS.
5. REFER RELEVANTARCHITECTURAL, STRUCTURAL,AND OTHER CONSULTANTS DRAWING WITH THIS DRAWING.
6. ALL OTHER LIGHT FIXTURES, PENDANT LIGHTSAND CHANDELIER'S SHOWN IN THE DRAWINGS SHALL BE AS PER OWNER'S PURCHASE.
7. WALL PAINTAND OTHER WALL PANEL FINISHES TO BE MATCHED TO THE COLORAS PER SPECIFICATIONS MENTIONED IN THE DRAWING
8. IT IS CUSTOMER'S/CONTRACTOR'S RESPONSIBILITYTO LOCATE BUILDING LINESAND BENCH MARKS TO SITE.
9. IT IS CUSTOMER'S RESPONSIBILITYTO VERIFYAND ENSURE CORRECTNESS IN EXECUTION OFALLARCHITECTURAL AND INTERIOR WORKSAT SITEAS PER HAaID'S DESIGNSAND DRAWINGS.
SHEET NO - 10 OF 14
POP FALSE CEILING WITH PAINT FINISHAS PER SELECTION
25MM METAL PLATE WITH ROSE GOLD BRUSH FINISHAS PER SELECTION
114MMTHK FLOATING PANELTO BE FINISHED WITH OIKOS PAINTAS PER SELECTION
CURTAINAS PER SELECTION
WINDOWAS PER JOINERY DETAIL 75MM WIDE WITH PROFILE EDGE AS PER THE DETAIL
SIDE TABLE TOPTO BE FINISHED WITH 20MM THK MARBLE(SMARALD GREY)ASAPPROVAL
FURNITURE AS PER SELECTION
MDF WITH OIKOS
DETAIL-C
METAL INSERT WITH ROSE GOLD BRUSH FINISHAS PER SELECTION
19MM THK PLY OPENABLE SHUTTER WITH LAQUERED FINISHAS PER SELECTION
INTERNALWARDROBE TO BE FINISHED WITH LAMINATEAS PER SELECTION
114MMTHK FLOATING PANELTO BE FINISHED WITH OIKOS PAINTAS PER SELECTION
METAL INSERT WITH ROSE GOLD BRUSH FINISHAS PER SELECTION
PERFORATED METAL SHEET AS PER SELECTION
SIDE TABLE FRONT FACIA TO BE FINISHED WITH 12MM THK MANNLOUVERSAS PER SELECTION
SIDE TABLE TOPTO BE FINISHED WITH 20MM THK SMARALD GREY MARBLEAS APPROVAL
REFERANCE IMAGE FOR HEAD BOARD
114MM THK PANELING TO BE FINISHED WITH PERFORATED METALAS PER SELECTION
MDF WITH PAINTAS PER SELECTION
PER SELECTION
12MM THK PLY BACKINGAS PER SELECTION
100MM Ø MEDALLIANAS PER SELECTION
LETHER/FABRIC PANELINGAS PER SELECTION
134MM THK PLY BOXING TO BE FINISHED WITH PAINTAS PER SELECTION
19MM THK PLYAS PER SELECTION
100MM HT MARBLE SKIRTING AS PER THE DETAIL
POP FALSE CEILING WITH PAINT FINISHAS PER SELECTION
169MM THK FLOATING PANEL TO BE FINISHED WITH OIKOS PAINTAS PER SELECTION
METAL EDGE PROFILE WITH GOLD/ROSE GOLD BRUSH FINISHAS PER SELECTION
150MM DEEP OPEN SHELF FRONT FACIATO BE FINISHED WITH LAQUEREDAS PER SELECTION
METAL EDGE PROFILE WITH GOLD/ROSE GOLD BRUSH FINISHAS PER SELECTION
LETHER/FABRIC (TO MATCH WITH FURNITUREAS PER SELECTION
TV LEDGE TOPTO BE FINISHED WITH SMARALD MARBLEAS PERAPPROVAL
MEDALLIANAS PER SELECTION
169MM THK PANELING TO BE FINISHED WITH 12MM THK MANNLOUVERSAS PER SELECTION
DRAWER SHUTTER TO BE FINISHED WITH LAQUERED AS PER SELECTION
169MM THK PANELING TO BE FINISHED WITH 12MM THK MANNLOUVERSAS PER SELECTION
THK MARBLE SKIRTIGAS PERTHE DETAIL
DETAIL-D
4MM MDF WITH PAINT FINISHAS PER SELECTION
4X4MM GROOVE WITH PAINT FINISHAS PER SELECTION
METAL EDGE PROFILEAS PER SELECTION
150MM DEEP OPEN SHELF WITH CIRCULAR PROFILE TO BE FINISHED WITH VENEERAS PER SELECTION
150MM DEEP OPEN SHELF FRONT FACIATO BE FINISHEDWITH LAQUREDAS PER SELECTION
INTERNAL DRAWER TO BE FINISHED WITH LAMINATEAS PER SELECTION FRAME WORKAS PER SELECTION
19MM THK PLY BACKING FOR MARBLE WITH LAMINATE FINISH(TO BE MATCH WITH MARBLE)AS PER SELECTION
20MM THK SMARALD MARBLE AS PERAPPROVAL
12MM THK MANNLOUVERS WITH 12MM THK PLY BACKING AS PER SELECTION
DRAWER TO BE FINISHED WITH LAQUEREDAS PER SELECTION
DETAIL-E
MDF WITH PAINTAS PER SELECTION
12MM THK MANNLOUVERS WITH 12MM THK PLY BACKING AS PER SELECTION
100MM HT MARBLE SKIRTING AS PER THE DETAIL
12MM THK PLYAS PER SELECTION
DETAIL-D
592MM DEEP STORAGE SHELF WITH OPENABLE SHUTTER TO BE FINISHED WITH 1MM THK LAMINATE WITH 19MM
COMPOUND WALLWITH PAINT FINISHAS PER SELECTION.
WALLTO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLE WITH 19MM THK PLY BACKINGAS PER SELECTION.
655MM DEEP STORAGE WITH OPENABLE SHUTTER TO BE FINISHED WITH 18MM THK PROFERATED SHEET WITH METAL EDGE PROFILEALONG WITH 'G' PROFILE HANDLEAS PER SELECTION.
PHE LINES COVERED WITHALU. LOUVERSAS PER PHE DETAIL.
371MM DEEP STORAGE SHELF WITH OPENABLE SHUTTER TO BE FINISHED WITH 4MM THK VENEER WITH 19MM THK PLY BACKINGAND 1MM THK LAMINATE FINISH INSIDEAND PROVIDED WITH 'G' PROFILE HANDLEAS PER SELECTION.
WALLTO BE FINISHED WITH 20MM THK LIGHT COLOUR MARBLEAS PER SELECTION.
12MM X 70MM WOODEN LIPPINGAS PER SELECTION.
12MM THK MANNLOUVERS WITH 12MM THK PLY BACKINGAS PER SELECTION.
FUNDER-MAX CLADDINGAS PER VENDOR'S SPECIFICATION.
GLASS DOORAS PER VENDOR'S SPECIFICATION.
SECTIONAL ELEVATION -A
SECTIONAL ELEVATION - B
