The Riverfront site is located close to the Atal Bridge along the Sabarmati River front.
The main goal of the Riverfront site is to conduct research on exploration of new materials, new technology, and new concepts relevant to the area of architecture. Architects, assistant architects, interior designers, art students, interns, senior architects, etc. will mostly take advantage of the well designed building.
The building structure is designed as a brick structure with parallel wall structures. Bricks are easily found in local markets on the coast for affordable prices and are used to construct the exterior part of the building, because they are suitable with Ahmedabad citi’s climate.
There will be a variety of spaces, including a multipurpose hall, an exhibition hall, a digital lab, a lab for the environment, workstations, the director’s cabin, etc. During the time of public event, around 600 people can fit in multi-purpose hall.
1. ENTRY
2. RECEPTION AREA
3. WORK STATION
4. CABIN
5. DISCUSSION ROOM 08
LEGEND AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 INSTITUTIONAL STUDIO |ARCHITECTURE INCUBATION CENTER | 2023
6. PANTRY
7. TOILET
8. CANTEEN
9. EXHIBITION HALL
10. SERVICE ROOM
16. A.V ROOM
17. BOOK SHOPE
18. TRAINING HALL
19. DIRECTOR CABIN
20. COA CABIN
21. ENVIRONMENTAL LAB
22. DIGITAL FEB LAB
23. RECORDING ROOM
24. MULTI PURPOSE ROOM
AREA ROOM
11. WAITING OR SEATING
12. SEMINAR ROOM
13. CONFERENCE ROOM
14. LIBRARY
09
15. ARCHIVE ROOM
PHYSICAL MODEL
10 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 INSTITUTIONAL STUDIO |ARCHITECTURE INCUBATION CENTER | 2023
11
HOUSING STUDIO
Afzal Khan no Tekro
Sem :- IV
Year :- 2022
Site :- Ahmedabad,Gujarat
The studio offered In this semester targeted to develop an understanding of functioning and fabric of human habits in a community. The site has a mixed-used land system, surrounded by a strong and congested context with a lot of activities happening. The site was given in a busy area located next to the RaipurDarwaja towards the Kalupur Railways station in the city of Ahmedabad,Gujarat.
02
12 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 HOUSING STUDIO |AFZAL KHAN NO TEKRO| 2023
13
CONCEPTUAL PROCESS
One of my initial concern was to thoroughly understanding the lifestyle and daily routine. And also to know the issue they are facing and their expectation , and after knowing this and keeping this criteria in mind , the idea was to develop an environment where all their issue are tried to solve.
Connectivity
Rhythm
Residential
Light and Shadow
BALCONY TERRACE
Mosque or Dargah
Road LIVING ROOM
LIVING ROOM
ROOM
ROOM
ELEVATION ELEVATION SITE
NORTH ELEVATION
A
Comercial
BED
BED
14 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 HOUSING STUDIO |AFSAL KHAN NO TEKRO| 2023
SECTION BB' 3000 Level 2 9000 Level 4 12000 Level 5 18000 Level 7 SECTION BB' Level 1 6000 Level 4 15000 Level 7 21000 SECTION AA’ A’ Parking area BRTS bus stop Contex Community space Garden space KITCHEN TOILET BALCONY TERRACE KITCHEN TOILET BALCONY TERRACE 15
AVOID ISOLATION
LACK OF COMMUNITY SPACES ORIENTATION
PROPER DRAINAGE
ARCHITECTURAL CONCERN
BETTER STREET NETWORK
STAGGERING OF UNITS
FORMATION OF POSITIVE SPACES
CLIMATIC RESPONSE
CLUSTER INFORMATION
Housing society for the Economically weaker section (EWS) will be located next to Afzal Khan No Tekaro, Ahmedabad. In which slum area will be developed into one and two BHK flats. In the EWS project, there will be three different type of homes, with 30 and 45 sqm for lower-class residents. In 60 sqm, lower middle class individuals can reside.
There will be 430 units in the site. Lower middle class people can occupy the bottom floor section, which has a separate private entrance.
Two BHK plan with attached bathrooms will be located in the building’s lower portion. Also, kids will benefit from a welcoming lobby, a well-landscaped area, a playground, and private two-wheeler parking.
On the other hand, lower class people can take over the upper part of the building due to maintain privacy and separate community between two different lower cast.
Upper part of the building will have one BHK flat, kitchen, balcony and shared Bathroom. Furthermore, half of the community will have a benefit of private terrace.
sq.mtr unit cluster on ground 60 sq.mtr Exploded cluster view First 45 sq.mtr 45
Ground floor plan 60
SOCIAL CONCERN 16 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 HOUSING STUDIO |AFSAL KHAN NO TEKRO| 2023 Living room Bed room LIVING ROOM BED ROOM LIVING ROOM BED ROOM
floor plan
unit cluster sq.mtr Exploded cluster view
floor plan
sq.mtr cluster 30 sq.mtr Exploded cluster view 17 Kitchen Toilet Balconey ROOM KITCHEN TOILET BALCONY TERRACE BED ROOM KITCHEN TOILET BALCONY TERRACE BED ROOM KITCHEN TOILET BALCONY TERRACE
First
sq.mtr
Second
30
LIVING ROOM BED ROOM KITCHEN TOILET BALCONY TERRACE UNIT PLAN SCALE 1:50 60 SQ.M UNIT 45 SQ.M UNIT ISOMETRIC VIEW LIVING ROOM BED ROOM KITCHEN TOILET BALCONY TERRACE UNIT PLAN SCALE 1:50 45 SQ.M UNIT NO 2 28 &30 SQ.M UNIT ISOMETRIC VIEW 60 sq.mtr unit 45 sq.mtr unit Living room Bed room Kitchen Toilet Balconey 60 sq.mtr unit view 28&30 sq.mtr unit view 45 sq.mtr unit view 45 sq.mtr unit(2) view 45 sq.mtr unit 2 30 sq.mtr unit LIVING ROOM BED ROOM KITCHEN TOILET BALCONY TERRACE LIVING ROOM BED ROOM KITCHEN TOILET BALCONY TERRACE LIVING ROOM
KITCHEN TOILET BALCONY TERRACE LIVING ROOM
KITCHEN TOILET BALCONY TERRACE LIVING ROOM BED ROOM KITCHEN TOILET BALCONY TERRACE 18 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 HOUSING STUDIO |AFZAL KHAN NO TEKRO| 2023
BED ROOM
BED ROOM
Cluster exploration
Site model
19
CONTEXTUAL STUDIO COMMUNITY CENTRE 03
Sem :- II
Year :- 2021
Site :- Ahmedabad
The Design briff given to us has a l shaped ploat with 9 mt high wall saround it. we were ask to design community center and covid ward in that ploat. we werw asked to create a spacee where a local community can spend their leisure time togethre at some common space. it should have a seprate space for a clinic doctor’s cabin ,library and a community hall Ahmedabad,Gujarat.
AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 20 CONTEXTUAL STUDIO |COMMUNITY CENTER| 2023
21
LEGEND
1. COMMUNITY SPACE
2. PHARMACY
3. CLINIC WAITING AREA
4. DR. CABIN
5. LIBRARY
6. SEMI COVERED SPACE
7. PUBLIC TOILET(F)
8. PUBLIC TOILET(M)
GROUND FLOOR PLAN
SECTION AA’ 22 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 CONTEXTUAL STUDIO |COMMUNITY CENTER| 2023
LEGEND
1. COVID WARD
2. LIBRARY
3. OPEN TERRACE
FIRST FLOOR PLAN
SECTION BB’ 23
K J I H F E D C B A A' K' 470 2350 1500 230 1500 2350 470 2890 470 4570 470 6250 470 4570 470 6250 470 6250 470 2840 230 4520 470 4570 470 1075 4200 4200 3360 5040 6720 5040 6720 6720 3190 5040 12230 16330 30710 59270 I' J' 1190 700 800 470 800 930 W1 6 W1 5 W5 1 W6 1 W7 1 350 1500 1500 350 4870 230 230 V1 1 V1 2 V2 1 V2 2 B C 6 WORKSTATION DIRECTOR CABIN COA CABIN WORK STATION CONFERENCE ROOM 1 EXHIBITION HALL CABIN LIBRARY EXHIBITION HALL LIBRARY F H I J K K' +0000 +0000 +0000 +0000 +0000 +4070 +4070 +4070 +4070 +4070 +0850MM SILL LVL +0000 MM PLINTH LVL +2125 MM LINTEL LVL +3025 MM BEAM BOTTOM LVL +3995 MM SLAB TOP LVL +6120 MM LINTEL LVL +7320 MM BEAM BOTTOM LVL +7990MM SLAB TOP LVL -0600 MM GROUND LVL 9260 5 1 1 1 12 3 D3 +8065 +7990 +8065 +7990 GROUND FLOOR FIRST FLOOR SECOND FLOOR +0850MM SILL LVL +0000 MM PLINTH LVL +2125 MM LINTEL LVL +3025 MM BEAM BOTTOM LVL +3995 MM SLAB TOP LVL +6120 MM LINTEL LVL +7320 MM BEAM BOTTOM LVL +7990MM SLAB TOP LVL -0600 MM GROUND LVL +10490 MM STAIR CABIN TOP LVL STAIR CASE PASSAGE ENTRANCE PASSAGE DIRECTOR CABIN STAIR CASE PASSAGE ENTRANCE PASSAGE CABIN CORRIDOR CORRIDOR CORRIDOR CORRIDOR 1 2 3 4 5 6 7 +0000 +4070 +3995 +0000 +4070 +3995 +0000 +4070 +3995 +0000 +4070 +3995 +0000 +4070 +3995 +0000 +4070 +3995 +8065 +7990 +8065 +7990 +10490 +10490 W5 1 5 STAIR CABIN GROUND FLOOR FIRST FLOOR SECOND FLOOR 1 W3 W3 W3 4 W4 1 3 5 4 2' 7 1 2 2'' AV ROOM CANTEEN TRAINING HALL TOILET F. MULTIPURPOSE HALL TOILET F. MULTIPURPOSE HALL MULTIPURPOSE HALL PASSAGE PASSAGE COURTYARD COURTYARD COURTYARD COURTYARD +0850MM SILL LVL +0000 MM PLINTH LVL +2125 MM LINTEL LVL +3025 MM BEAM BOTTOM LVL +6120 MM LINTEL LVL +7320 MM BEAM BOTTOM LVL +7990MM SLAB TOP LVL -0600 MM GROUND LVL +0075 +0000 +0075 +0000 +0075 +0000 +0075 +0000 +0000 +0055 +0000 +4070 +4070 +4070 +4070 - 0600 - 0600 +8065 +7990 +8065 +7990 +8065 +7990 GROUND FLOOR FIRST FLOOR SECOND FLOOR 1 W4 1 5 W3 W3 W3 8 W4 2 W2 2 V1 1 V1 2 W1 1 W1 2 W2 1 W8 1 W2 2 W8 W8 4 +0075 +0000 +0075 +0000 +0075 +0000 +0075 +0000 +0075 +0000 +0075 +0000 +0075 +0000 +0850MM SILL LVL +0000 MM PLINTH LVL +3025 MM BEAM BOTTOM LVL +3995 MM SLAB TOP LVL +6120 MM LINTEL LVL +7320 MM BEAM BOTTOM LVL +7990MM SLAB TOP LVL +8660 MM PARAPET LVL -0600 MM GROUND LVL A B C D E F H J' I GROUND FLOOR FIRST FLOOR SECOND FLOOR AV ROOM RECORDING ROOM DISCUSSION ROOM 2 SERVICE ROOM STORAGE ROOM MULTIPURPOSE HALL SERVICE ROOM DIGITAL FAB LAB 2 ENVIRONMENTAL LAB 2 STORAGE ROOM STAIR CASE STAIR CASE STAIR CABIN STAIR CASE STAIR CASE STAIR CABIN +4070 +8065 +4070 +8065 +4070 +4070 +4070 +4070 +4070 +8065 +10490 +10490 +0075 +0000 W1 4 W1 9 W1 10 D2 8 K J I F C B A PASSAGE PASSAGE TRAINING HALL DOUBLE HEIGHT WAITING AREA DOUBLE HEIGHT ENTRY PASSAGE MULTIPURPOSE HALL PASSAGE GROUND FLOOR FIRST FLOOR SECOND FLOOR +0850MM SILL LVL +0000 MM PLINTH LVL +2125 MM LINTEL LVL +3025 MM BEAM BOTTOM LVL +3995 MM SLAB TOP LVL +6120 MM LINTEL LVL +7320 MM BEAM BOTTOM LVL +7990MM SLAB TOP LVL -0600 MM GROUND LVL OPEN SPACE +0075 +0000 +0075 +0000 +4070 +8065 +0075 +0000 +4070 +8065 +4070 +8065 - 0600SECTION A 1 SCALE : 1:20 SECTION B 2 SCALE : 1:20 SECTION C 3 SCALE : 1:20 SECTION D 4SCALE : 1:20 SECTION E 5 SCALE : 1:20 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 24 WORKING DRAWING |ACADEMICS| 2023
WORKING DRAWING SEM :- VI (ONGOING) 04
3 5 6 4 2' 7 1 AV ROOM 8880X7930 PASSAGE 48230X2890 PASSAGE 30965X4570 PASSAGE 18000X3010 8895X7930 CANTEEN 6860X7930 RECORDING ROOM 8880X6250 8895X6250 RECEPTION 9970X6250 DISCUSSION ROOM 2 WORKSTATION DISCUSSION ROOM 1 TRAINING HALL CONFERENCE ROOM 2 +0000 F1 C1 W1 - 0600 - 0600 5 7 8 10 11 12 13 14 15 16 17 18 +0000 +0000 F1 C1 W1 +0000 F1 C1 W1 +0000 F1 C1 W1 +0000 F1 C1 W1 +0075 +0000 S.B. +3845 F1 C1 W1 +0000 F1 C1 W1 +0000 F1 C1 W1 F1 C1 W1 F1 C1 W1 +0000 UP UP +0000 DOUBLE HEIGHT WAITING AREA +2135 +2100 +2135 +2100 K J I H F E D C B A A' 2 J' 2'' 3 5 6 4 2' 7 1 2 1075 230 5360 230 3010 1250 230 6630 230 1075 3010 1015 230 8895 230 1075 3010 1075 230 8880 230 1030 5530 6860 5390 9005 5510 5630 3370 6895 3010 9415 3010 11445 3010 11445 48230 470 7930 470 2890 470 4570 470 6250 470 4570 470 6250 470 6250 470 6250 470 4570 470 4570 470 8400 3360 5040 6720 5040 6720 6720 5040 1680 5040 12230 16330 20630 5040 5040 49190 10080 10025 2301015 1015 230 8895 2301075 3010 10180 2301030 4805 3360 13440 9005 5510 5630 3370 11270 11060 11445 14455 48230 DIRECTOR CABIN COA CABIN WORK STATION 8720X4570 6250X5360 4570X5360 6250X5360 6250X5360 F1 C1 W1 +0000 F1 C1 W1 +0000 C1 W1 CONFERENCE ROOM 1 13440X13090 +0000 DOUBLE HEIGHT ENTRY 6720X13090 8895X6250 8880X6250 TOILET M. TOILET F. 3850X5360 3850X5360 +0000 F2 C1 W2 +0000 F2 C1 W2 1' PASSAGE 38170X4085 1190 1935 470 2890 470 2890 470 2890 470 2890 470 2890 470 2890 470 2890 470 2890 470 1875 32350 4030 3000 4030 F1 C1 W1 +0000 F1 C1 W1 - 0600 - 0600 SERVICE ROOM STORAGE ROOM 5520X4570 5520X4570 +0000 F1 C1 W1 +0000 F1 C1 W1 D2 3 D1 1 D1 2 D1 3 D1 4 D1 5 D1 10 D1 6 D1 7 D1 8 D1 9 D2 1 D2 2 D2 4 D2 5 D2 6 D2 7 D3 2 D3 1 D4 1 D2 8 D2 9 W1 1 W1 2 W1 4 W1 3 W2 1 W3 1 W3 2 W3 3 W3 4 W4 1 W1 W1 W5 W6 W7 725 W7 2 W8 1 W8 2 890 890 2000 470 2000 890 890 2000 470 2000 355 3900 2235 300 3900 2235 300 470 1500 4750 470 470 1500 4750 1075 3070 1500 3120 1200 2880 1200 470 1250 5700 2220 5800 620 1500 1075 5520 1200 470 1200 8890 1200 470 1200 5050 470 980 750 980 750 2030 1570 230 2030 1570 230 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +3845 +0075 S.B. +7840 +0075 S.B. +7840 +0075 S.B. +3845 +0075 S.B. +3845 +0055 +0055 S.B. +3025 S.B. +3025 +0000 +0075 S.B. +3845 +0000 +0075 S.B. +3845 +0000 +0075 S.B. +3845 +0075 S.B. +3845 A B C D E A D E 25
AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 26 WORKING DRAWING |ACADEMICS| 2023
27
28 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 WORKING DRAWING |ACADEMICS| 2023 ‘
29
Year :- 2021
Site :- pol khadiyani pol Ahmedabad
Architectural construction documents is very crucial to the design and construction process. By documenting every aspect of the building process, the standard and quality of construction is sustained and it helps in adding immense value to the projects. Documenting the old traditional houses of ahemdabad gives trimendous knowledge about the climatic response, community devlopment and material interpretation in building.
05
RELETED STUDY PROGRAM POL HOUSE AHEMDABAD
30 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 RELETED STUDY PROGRAM |POL HOUSE| 2023
31
GROUND FLOOR PLAN FIRST FLOOR PLAN
D01 W01 KITCHEN AREA FFL: -50 MM OTLO OTLO N01 N02 N03 TOILET UP 2971 819 493 984 401 5030 715 1155 832 780 798 4310 500 597 1403 230 2730 930 685 200 679 150 1450 430 2420 1429 BED ROOM B' B A A' 115200140 406 70 579 80 280 115 550 85 785 90 540 120 320 80 580 80 442 115 831 1328 755 1135 620 460 5130 1219 1390 170 569 115 5651 2780 1406 746 446 170 155 701 135 3760 443 4335 BED ROOM B' B A A' 100 190 90 280 81 769 80 260 100 545 80 769 80 531 105 295 81 769 80 270 90 5546 1371 135 530 575 1479 4090 2290 600 1449 831 5170 139 620 540 1506 2791 STOREG B' B A A' 926
SECOND FLOOR PLAN SECTION AA’ 32 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 RELETED STUDY PROGRAM |POL HOUSE| 2023
ELEVATION AT A 215 91 67 57 57 57 67 91 91 67 57 57 57 52 91 80 120 80 70 460 100 620 100 310 1580 200 2090 223 701 1410 SECTION 100 200 95 485 60 390 90 100 110 90 2180 200 130 155 135 155 135 155 135 150 135 150 130 120 2020 135 85 555 545 85 1100 1270 ELEVATION AT B 2090 1 : 20 LEGEND CLIENT: PROJECT: Documentation of WHC All dimensions are in Millimeters unless NOTES wood Wall UNIVERSITY/FIRM: SCALE 2800 DOOR DETAILS 33
MISCELLANEOUS SKETCH | RENDER |PHOTOGRAPHY 06
Sem :- I TO VI
Year :- 2020 TO 23
Almost every architect has faced a significant design issue somewhere along the line. Having creative & resourceful problem solving skills is a must.
34 AJAY DHORAJIYA | ARCHITECTURE DESIGN PORTFOLIO | 2023 MISCELLANEOUS |RENDER,SKETCH,PHOTOGRAPHY| 2023
35
