ROUND HEATED
RTR01 – 12V model
LOW VOLTAGE 12 VOLT MODEL
MIRROR POLISHED AND BRUSHED SATIN
MANUFACTURED FROM 304 GRADE STAINLESS STEEL
COLOURED FINISHES MANUFACTURED FROM 201 GRADE STAINLESS STEEL
ALL TOWEL RAILS AVAILABLE WITH EITHER BOTTOM LEFT OR RIGHT OUTPUT
3M CABLE, NO PLUG, INCLUDES THE TRANSFORMER
CAN BE MOUNTED UPSIDE DOWN
10 YEAR WARRANTY FOR CONSTRUCTION / HEATING ELEMENT
COATING ON COLOURED RAILS ARE COVERED BY A 2 YEAR WARRANTY
FEATURES
• Round bar / Height 800mm / 7 evenly spaced bars / 85W (Black rail 110W)
• Low voltage 12V ladder
• Vertical bars 32mm diameter
• Horizontal bars 19mm diameter
• 112mm from wall
12v ladders are manufactured using individual elements so one of the vertical bars is not heated, however this does not affect the rails ability to warm/dry a towel as all horizontal bars are fully heated. Please note: Due to manufacturing constraints beyond our control, our coloured towel rails may have minor colour variances in different batches, so may be slightly different to the images and colour samples you may have seen.
12V-RTR01LEFT 600x800 Polished
12V-RTR01RIGHT 600x800 Polished
12V-BRU-RTR01LEFT 600x800 Brushed Satin
12V-BRU-RTR01RIGHT 600x800 Brushed Satin
12V-BRTR01LEFT 600x800 Matt Black
12V-BRTR01RIGHT 600x800 Matt Black
ThermaNiche ThermaSheet demisters
towel rails timers underfloor heating floor grates
PLEASE NOTE: NOT ALL PRODUCTS ARE AVAILABLE IN ALL FINISHES. IF NOT LISTED IN THE SPECIFICATIONS IT IS NOT CURRENTLY AVAILABLE.
CODE SIZE (MM) FINISH
600 568 112 80 35 90 90 40 120 620 800 Cable exits the back 35mm from bottom of rail. When ordering please specify left or right side as viewed from the FRONT
