The equipment used for wafer bonding typically includes a bonding chamber or tool, which provides a controlled environment for the bonding process. The bonding surfaces of the wafers are carefully cleaned and prepared to ensure a strong and uniform bond.
The wafers are then aligned and brought into contact with each other under controlled pressure and temperature conditions.
Wafer bonding equipment is commonly used in the manufacturing of advanced semiconductor devices such as micro-electro-mechanical systems (MEMS), power devices, and sensors. The bonding process enables the creation of highly integrated devices with multiple functionalities and improved performance characteristics.
The global Wafer Bonding Equipment market was valued at US$ 316.7 million in 2022 and is projected to reach US$ 461 million by 2029, at a CAGR of 5.5% during the forecast period. The influence of COVID-19 and the Russia-Ukraine War were considered while estimating market sizes. CAGR of
By Types:
Fully Automatic
Semi Automatic
