ADITYA RATHOD
10 - May - 2002
About me
I am currently a 3 rd year B.Arch student in The Maharaja Sayajirao University of Baroda, Vadodra. I view architecture as an experiencial medium which guides human behaviour in spaces. I view design through the lens of human acclimatation in spaces.
Contact details
aaditya.rathod.32@gmail.com @_aadi_1002_
Languages English Hindi Gujarati (mother tongue)
Skills Auto CAD Sketchup MS Office Adobe Photoshop Adobe Illustrator Adobe InDesign V-Ray Enscape Lumion
Model Making Hand drafting Sketching
Education
Gajera International School, Surat (2006 - 2017)
Swaminarayan Gurukul, Surat (2017 - 2019) The Maharaja Sayajirao University, Vadodara (2019 - )
Interests Cinema Current affairs Reading Music History Maps Research
Participation
Activiely participated in organising college’s annual event “REFLECTION - 2022”.
Work experience
Khanak Solar Solutions, Surat (freelance) (2019 - )
------
------
Contents Old age home + Orphanage 2 nd year / 1 st sem 4 - 11 12 - 19 20 - 29 30 - 35 Block printing artist’s house 1 st year / 2 nd sem Housing for Industrial workers 3 rd year / 1 st sem Miscellaneous
Old
home +
age
Orphanage 2 nd year / 1 st sem Site : Farmland, Surat Client : hypothetical User group : - Old age people - Orphans - Support staff
Brief : Designing integrated living spaces for both age groups and other spaces catering their daily needs.
Site
Abrama village, near Surat
Towards NH-8
Farmland Towards riverbank
Towards surat
Area : About site :
4,225 m2
Site is situated in the outskirts of Surat city, near abrama village on the northern bank of Tapi river.
Living block Admin Block Recreational space Parking Dining hall Elders pavilion Kids pavilion Recreational space Green patch Water body Creating courtyards in Living and Admin Block and entry in Admin block Private balcony Courtyard - Riverside link Adding vertical circulation leading to a viewing deck on 3rd floor
1. Kids room 2. Elders room 3. Dining area 4. Elders pavilion 5. Kids pavilion 6. Admin 7. Clinic 8. Laundry 9. Meditation area 10. Temple Ground floor plan 3 4 5 6 7 8 1 1 1 1 1 1 2 2 2 2 2 2 9 10 A A’ B B’ 0 1 3 6 12 Section AA’
11. Staff room 12. Guest room 1 st floor plan 1 1 1 1 1 1 2 2 2 2 2 2 A A’ B B’ 0 1 3 6 12 Section BB’
Block printing artist’s house
1 st year / 2 nd sem
Site : Hypothetical
Client : Block printing artist
User group : - Artist - Workers - Visitors
Brief : Designing the living and working space for a block printing artist after studying their living and working conditions in detail.
Market place
Site
Hypothetical
Area : About site :
Garden
Mix use structures
506.25 m2
Site is situated in the context as follows:
• North - Garden
• East - Road
• South - Market place
• West - River
Working block Living Block Buffer Display, dyeing, storage Living block Printing block Massing arranged to capture max sunlightSemi open dyeing area Obstruction-less entry area Private garden Ghat across the river bank Adding vertical circulation Spiral staircase Dog-legged staircase -
1. Display 2. Dyeing workshop 3. Store room 4. Private residence 5. Ghat 1 B B’ C’ C 2 3 4 5 Ground floor plan A A’ 0 1 3 6 12 Section AA’
5. Printing workshop 6. Drying area B B’ C’ C 1 st floor plan 6 7 A A’ 0 1 3 6 12 Section BB’
Display Printing workshop
Section CC’
Dyeing workshop Roadside View
Housing for Industrial workers
3 rd year / 1 st sem
Site : Farmland, Surat
Client : hypothetical
User group : - single workers - workers with family
Brief : Designing Different categories of living units and other support amenities for local & migrant industrial workers working in textile factories in the viscinity of the site.
Farmland
Agricultural godown
Site
Diamond nagar, Laskana, Surat
Row housing society
Towards industrial area
Towards industrial area
Area : About site :
MIG housing
9,900 m2
Site is a farmland located in Laskana, an industrial suburb area of Surat city. Site has newly developed housing, textile factories and diamond polishing units in it’s vicinity.
block Family workers block Double heighted gathering spaces at alternate levels Gathering spaces for families Vertical circulation Horizintal circulation Opeining the single workers block from corners club house and library in the family workers block Light wells For light and air ventilaton Removing mass and connecting with perifery Amphitheatre Playground-
Single workers
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 2 2 1 1 2 2 3 3 3 3 3 3 2 2 5 5 6 8 8 B’ B A’ A 8 8 8 7 5 5 5 5 4 4 4 Legend: Single workers block Family workers block 1. Unit for 4 workers 2. Unit for 8 workers -A 3. Lavatory Block 4. Gathering Space 5. Dual family units 6. Library 7. Club house 8. Gathering space 1st floor plan 0 1 3 6 12
Single
Unit for 4 workers
Ground floor
Unit for 8 workers - A Unit for 8 workers - B
Lavatory block
workers block 1 st , 3 rd, 5 th, 7 th floor 2 nd, 4 th, 6 th, 8 th floor
Family workers block
2 nd - 8 th floor
1 st floor
2 family worker units and a shared balcony
Library Club house
Ground floor
Single workers block passage Playground
Amphitheatre Courtyard
Section BB’
Section AA’
Plan
Bagh - i - fin, Kashan, Iran
Miscellaneous
History of Archiectue :
- Plan of Bagh-i-Fin, Kashan, Iran
- Isometric section: Sanchi Stupa, Sanchi
Basic Design :
- Enameling on MS plate
- Mind map (mapping the route from the college to your home)
Photography
section Sanchi Stupa, Sanchi
Isometric
Mind maping exercise Vadodara city ENAMELING
Photography
Thank you Aditya Rathod +91 9726668163 aaditya.rathod.32@gmail.com
