Chapter 2 2.1

From Eq. (2.18),

Gs ρw 2450 2.80 × 1000 ; e = 0.0571 = = 1+ e 0.925 1+ e

ρd =

From Eq. (2.6), Porosity, n =

2.2

e 0.0571 = = 0.054 1 + e 1 + 0.0571

From Eq. (2.13), the dry density ρd =

ρ 2060 = = 1786.6 kg/m3 1 + w 1 + 0.153

From Eq. (2.18), ρd = e=

Gs ρw 1+ e

Gs ρw 2.70 × 1000 −1 = − 1 = 0.511 ρd 1786.6

Once saturated, from Eq. (2.19), ρsat =

2.3

(Gs + e ) ( 2.70 + 0.511) × 1000 = 2125.1 kg/m 3 ρw = (1 + e) (1 + 0.511)

Let’s consider a 1-m2 area in plan. The initial volume of this soil is V = 1 × 0.5 = 0.5 m3. Volume of the solids is Vs. e = 0 .9 =

0.5 − Vs ; Vs = 0.2632 m3 Vs

Ws = 0.2632 × 2.68 × 9.81 = 6.919 kN The new volume after compaction = 1 × 0.455 = 0.455 m3 The dry unit weight, γd = From Eq. (2.12), γd =

6.919 = 15.21 kN/m3 0.455

Gs γw 1+ e

SOURCE: Browsegrades.net

1 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

e=

Gs γ w 2.68 × 9.81 −1 = − 1 = 0.729 γd 15.21

From Eq. (2.13), γ = (15.21)(1 + 0.20) = 18.25 kN/m 3

2.4

At the compacted road base, the weight of solids, Ws = 120,000 × 19.5 = 2,340,000 kN At the borrow pit, the dry unit weight, γd = Volume of the pit, V =

γ 17.5 = = 16.13 kN/m 3 1 + w 1 + 0.085

2,340,000 = 145,080 m3 16.13

The moisture content has to be increased from 8.5% (at the borrow pit) to 14.0% (at the road base). The quantity of water to add, 2,340,000 × (0.14 ‒ 0.085) = 128,700 kN Volume of water to be added =

2.5

γd =

γ 110.4 = = 99.9 lb/ft 3 1 + w 1 + 0.105

γd =

Gs γ w 2.65 × 62.4 ; e= − 1 = 0.655 1+ e 99.9

From Eq. (2.23), Dr =

2.6

2.7

128,700 = 13,119.3 m 3 9.81

0.870 − 0.655 × 100 = 60.6% 0.870 − 0.515

a. A-1-a

c. A-3

b. A-1-b

d. A-7-6

Soil A: % of gravel = 50, % of sand = 13, % of fines = 37 D10 = 0.035 mm, D30 = 0.061 mm, D60 = 9.8 mm Cu = 280; Cc = 0.02 LL = 58, PL = 34, PI = 24 plots below the A-line; hence, silt The soil can be described as poorly (gap) graded sandy silty gravel with a group symbol of GM.

SOURCE: Browsegrades.net

2 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

Soil B: % of gravel = 24, % of sand = 69, % of fines = 7 D10 = 0.17 mm, D30 = 0.82 mm, D60 = 2.6 mm Cu = 15.3; Cc = 1.5 LL = 42, PL = 22, PI = 20 plots above the A-line; hence, clay The soil can be described as well graded clayey gravelly sand with a group symbol of SW-SM. Soil C: % of gravel = 1, % of sand = 99, % of fines = 0 D10 = 0.7 mm, D30 = 1.2 mm, D60 = 1.6 mm Cu = 2.3; Cc = 1.3 The soil can be described as poorly (uniformly) graded sand with a group symbol of SP. Soil D: % of gravel = 0, % of sand = 12, % of fines = 88 LL = 75, PL = 31, PI = 44 plots above the A-line; hence, clay.

The soil can be described as sandy clay of high plasticity with a group symbol of CH.

2.8

The head loss from the reservoir to the ditch, ∆h = 38 − 28 = 10.0 m The length of the sand seam in the direction of the flow, L = 200 cos10 = 203.1 m The hydraulic gradient, i = 10.0 203.1 = 0.0492

By Darcy’s law [Eq. (2.35)], v = ( 2.6 × 10 −5 m/s)( 0.0492 ) = 0.128 × 10 −5 m/s The cross section of the sand seam through which the flow takes place is

1.0 × 500.0 = 500.0 m2 The flow rate = (0.128 × 10 −5 m/s)(500.0 m 2 ) = 64.0 × 10 −5 m 3/s Volume of water flowing into the ditch per day: = (64.0 × 10 −5 m 3/s)(24 )( 3600) = 55.3 m 3

2.9

For the flow net shown in Figure P2.9, Nf = 3 and Nd = 10 Total head loss from right to left, hmax = 5.0 m The flow rate is given by [Eq. (2.46)] q = khmax

 3 = (1.5 × 10−5 )(5.0)  = 2.25 × 10−5 m 3/s/m length Nd  10 

Nf

= ( 2.25 × 10− 5 )(50.0)( 24)( 3600 m 3/day) = 97.2 m 3 /day

SOURCE: Browsegrades.net

3 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

2.10

On top of the soft clay layer (i.e., at 10 m depth), initially: σ ′ = 1 × 17.0 + 9( 20 − 9.81) = 108.7 kN/m 2

After the water table is lowered, σ ′ = 3 × 17.0 + 7( 20 − 9.81) = 122.3 kN/m 2

By lowering the water table, the effective stress has increased by (122.3 – 108.7) = 13.6 kN/m2

2.11

The soil below the water table can be assumed to be fully saturated (i.e., S = 1).

e = wGs = 0.25 × 2.70 = 0.675 The saturated unit weight can be computed as

γsat =

(Gs + e)γw (2.70 + 0.675) × 9.81 = = 19.8 kN/m3 1+ e 1 + 0.675

At a depth of 5 m into the sandy clay, σ = 4 × 9.81 + 5 × 19.8 = 138.3 kN/m2 u = 9 × 9.81 = 88.3 kN/m2 σ ′ = σ − u = 138.3 − 88.3 = 50 kN/m2

2.12

Refer to the figure.

a. The compression index Cc is given by [Eq. (2.53)],

Cc =

e1 − e2 1.10 − 0.85 = = 0.441 log σ 2′ − log σ1′ log 240 − log 65 SOURCE: Browsegrades.net

4 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

b. Let the void ratio at 460 kN/m2 pressure be e3 .

 460  e1 − e3 = Cc (log 460 − log 65) = 0.441 × log  = 0.375  65  e3 = 1.10 − 0.375 = 0.725

2.13

a. The clay is below the water table and, hence, is saturated. The initial void ratio eo can be determined as eo = wG s = 0.225 × 2.72 = 0.612 The saturated unit weight is determined as

γsat =

(Gs + e)γw ( 2.72 + 0.612)(9.81) = 20.3 kN/m3 = 1+ e 1 + 0.612

The effective overburden stress at the middle of the clay is

σ o′ = 2 × 17.0 + 3( 20.2 − 9.81) + 1.5( 20.3 − 9.81) = 80.3 kN/m2 < 110.0 kN/m2 Since the preconsolidation pressure is greater than the current overburden pressure, the clay is overconsolidated. The overconsolidation ratio

OCR = 110.0 80.3 = 1.37 b. The 2-m-high compacted fill imposes a surcharge of 2 × 20 = 40 kN/m2 (i.e., ∆σ ′ = 40.0 kN/m2 , σo′ = 80.3 kN/m2 , and σ c′ = 110.0 kN/m2 ) Since σ o′ + ∆σ ′ > σ c′ , the consolidation settlement can be computed from Eq. (2.69) as Sp = =

 σ′  C H  σ ′ + ∆σ'  Cs H  log c  + c log o ′ ′ 1 + eo σ 1 + e σ o o c     0.06 × 3000  110.0  0.52 × 3000  80.3 + 40.0  log log +  1 + 0.612 1 + 0.612 110  80.3   

= 52.9 mm

2.14

For U = 75%, Tv = 0.477 (Table 2.12)

Tv =

cv t H dr2

From two-way (doubly drained) to one-way (singly drained), Hdr is doubled.

For the same U and, hence, the same Tv, this would increase the time fourfold.

Therefore, it will take 4t years.

SOURCE: Browsegrades.net

5 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

2.15

a. The clay layer with one-way drainage has Hc of 6.0 m. After one year,

Tv =

cvt 0.0014 × 365 × 24 × 3600 = = 0.123 ; settlement, Sc(t) = 160 mm H2 6002

From Table 2.12, U = 39.6%

U=

Sc ( t ) Sc (max)

; Sc (max) = 160 0.396 = 404 mm

When t = 2 years, Tv = 0.246.

From Table 2.12, U = 55.8%.

Consolidation settlement during the first two years is 0.558 × 404 = 225.4 mm b. The initial effective overburden stress at the middle of the clay is σo′ = 1.5 × 17.0 + 0.5(18.5 − 9.81) + 3.0(19.0 − 9.81) = 57.4 kN/m2

∆σ ′ = 3 × 19 = 57 kN/m2 Sc =

 σ o′ + ∆σ ′  Cc H  log 1 + eo σ o′  

404 =

2.16

Cc × 6000  57.4 + 57.0  log ; Cc = 0.41 1 + 0.810 57.4  

a. For the clay layer, assuming S = 100% below the water table, eo = 0.45 × 2.70 = 1.215

γsat =

(Gs + e)γw (2.70 + 1.215) × 9.81 = 17.3 kN/m3 = 1+ e 1 + 1.215

The initial effective overburden stress at the middle of the clay layer is

σo′ = 1 × 16 + 1(19.0 − 9.81) + 1.5(17.3 − 9.81) = 36.4 kN/m2 With OCR = 1.5, the preconsolidation pressure σ c′ = 1.5 × 36.4 = 54.6 kN/m2 When the fill is placed, it imposes a surcharge of ∆σ ′ = 20 × 1.5 = 30.0 kN/m2 From Eq. (2.69), Sc = =

 σ′  C H  σ ′ + ∆σ'  Cs H  log c  + c log o 1 + eo  σ o′  1 + eo  σ c′  0.08 × 3000  54.6  0.65 × 3000  66.4  log log +  = 93.9 mm 1 + 1.215 1 + 1.215  36.4   54.6  SOURCE: Browsegrades.net

6 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

b. Including the fill load and the warehouse load, ∆σ ′ = 30 + 40 = 70 kN/m2

Sc = =

 σ′  C H  σ ′ + ∆σ'  Cs H  log c  + c log o 1 + eo  σo′  1 + eo  σ c′  0.08 × 3000  54.6  0.65 × 3000  106.4  log log +  1 + 1.215 1 + 1.215  36.4   54.6 

= 274.2 mm Consolidation settlement due to the warehouse alone is 274.2 – 93.9 = 180.3 mm

2.17

The direct shear test data are plotted in the figure. From the failure envelope, c′ = 6.5 kN/m2 and ϕ' = tan‒1(0.4292) = 23.2°

2.18

a. σ3′ = 100 kN/m2 and ∆σ f = 260 kN/m2 Therefore, σ1′ = σ 3′ + ∆σ f = 360 kN/m 2

φ′  φ′    From Eq. (2.91), σ1′ = σ 3′ tan 2  45 +  + 2c′ tan  45 +  2 2   For normally consolidated clays, c′ = 0; hence,

φ′   360 = 100 tan 2  45 +  ; φ ′ = 34.4 ° 2 

SOURCE: Browsegrades.net

7 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

b. For the second specimen, σ3′ = 200 kN/m2

34.4   2 σ1′ = 200 tan 2  45 +  = 719.5 kN/m 2  

∆σ f = 719.5 − 200 = 519.5 kN / m 2

2.19

a. In normally consolidated clay, c′ = 0 For the first specimen (consolidated drained test), using Eq. (2.91),

φ′   260 + 150 = 410 = 150 tan 2  45 +  ; φ ′ = 27.7° 2  In the second specimen (consolidated undrained test), applying the same value of φ ′ in Eq. (2.91),

σ3 = 150 kN/m 2 and ∆σ f = 115 kN/m 2 σ1 = σ 3 + ∆σ f = 265 kN/m 2

σ3′ = 150 − u f and σ1′ = 265 − u f

φ′  27.7    σ1′ = σ 3′ tan 2  45 +  = σ 3′ tan 2  45 +  = 2.737σ 3′ 2 2    265 − u f = (150 − u f ) × 2.737; u f = 83.8 kN/m2

b. From Eq. (2.96), A f =

2.20

uf ∆σ f

=

83.8 = 0.73 115

At failure the pore water pressure is uf, σ3 = 100 kN/m2 and σ1 = 207 kN/m2.

σ3′ = 100 − u f and σ1′ = 207 − u f Substituting for σ3′ and σ1′ in Eq. (2.91),

φ′  φ′    σ1′ = σ 3′ tan 2  45 +  + 2c′ tan 45 +  2 2  

(207 − u f ) = (100 − u f )tan 2  45 + 262  + 2 × 10 tan 45 + 262  







uf = 51.9 kN/m2 SOURCE: Browsegrades.net

8 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

2.21

The following table can be prepared from the given data, and the Mohr circles are plotted as shown in the figure.

Sample No.

(kN/m )

1 2 3

100 200 350

σ3 2

(∆σ d ) f

(∆ud ) f

2

2

(kN/m ) 88.2 138.5 232.1

(kN/m ) 57.4 123.7 208.8

σ3′

σ1

σ1′

(kN/m )

(kN/m )

(kN/m2)

188.2 338.5 582.1

42.6 76.3 141.2

130.8 214.8 373.3

2

2

The failure envelope is drawn tangent to the Mohr circles in the figure and, from measurements, c′ = 10.0 kN/m2 and ϕ' = 24.7°

2.22

The unconfined compressive strength of the clay specimen qu = 2cu = 90 kN/m2 Cross sectional area of the specimen =

π 4

× 752 = 4417.9 mm2

Maximum load the specimen can carry = 90 × 4417.9 × 10−6 = 0.398 kN = 398 N Weight of one steel plate = 1.5 × 9.81 N = 7.358 N Therefore, number of plates that can be stacked on the specimen = 398 7.358 = 54 With qu = 90 kN/m2 (see Table 2.14), it is a medium clay (consistency).

2.23

a. From Figure P2.7, D10 = 0.7 mm, D15 = 0.9 mm, D30 = 1.2 mm, D50 = 1.4 mm, D60 = 1.6 mm, and D85 = 2.05 mm

D60 1.6 D302 1 .2 2 = = 2.3 ; Cc = = = 1.3 D10 × D60 0.7 × 1.6 D10 0.7 From Eq. (2.87), φ ′ = 26 + (10 × 0.8) + (0.4 × 2.3) + 1.6 log(1.4) = 35.2° Cu =

SOURCE: Browsegrades.net

9 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.

D   2.05  b. From Eq. (2.89), a = 2.101 + 0.097  85  = 2.101 + 0.097  = 2.322  0 .9   D15  From Eq. (2.90), b = 0.845 – 0.398a = 0.845 – 0.398×2.322 = ‒ 0.0792

From Eq. (2.88),

1  1   −1   = tan   = 36.8°  ae + b   2.322 × 0.61 − 0.0792 

φ ′ = tan −1 

SOURCE: Browsegrades.net

10 © 2019 Cengage Learning®. All Rights Reserved. May not be scanned, copied or duplicated, or posted to a publicly accessible website, in whole or in part.
