import numpy as np ''' We are going to use the diabetes dataset provided by sklearn https://scikit-learn.org/stable/datasets/toy_dataset.html#diabetes-dataset to train a 2 fully connected layer neural net. We are going to build the neural network from scratch. ''' class dlnet: def __init__(self, x, y, lr = 0.01, batch_size=64, momentum=0.5, use_dropout=True, dropout_prob=0.3): ''' This method initializes the class, it is implemented for you.

Args: x: data y: labels Yh: predicted labels dims: dimensions of different layers alpha: slope coefficient for leaky relu param: dictionary of different layers parameters ch: Cache dictionary to store forward parameters that are used in backpropagation loss: list to store loss values lr: learning rate sam: number of training samples we have momentum: coefficient for momentum-based update step change: dict of previous changes for each layer

''' self.X=x # features self.Y=y # ground truth labels

self.Yh=np.zeros((1,self.Y.shape[1])) # estimated labels self.dims = [10, 15, 1] # dimensions of different layers self.alpha = 0.05 self.use_dropout = use_dropout self.dropout_prob = dropout_prob self.param = {} # dictionary for different layer variables self.ch = {} # cache for holding variables during forward propagation to use them in back prop self.loss = [] # list to store loss values self.batch_y = [] # list of y batched numpy arrays self.iter = 0 # iterator to index into data for making a batch self.batch_size = batch_size # batch size self.lr=lr # learning rate self.sam = self.Y.shape[1] # number of training samples we have self._estimator_type = 'classifier' self.neural_net_type = "Leaky Relu -> Tanh" self.momentum = momentum # momentum factor self.change = {} # dictionary for previous changes for momentum

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

def nInit(self, param=None): ''' This method initializes the neural network variables, it is already implemented for you.

Check it and relate to the mathematical description above.

You are going to use these variables in forward and backward propagation. ''' if param is None: np.random.seed(1) self.param['theta1'] = np.random.randn(self.dims[1], self.dims[0]) / np.sqrt(self.dims[0]) self.param['b1'] = np.zeros((self.dims[1], 1)) self.param['theta2'] = np.random.randn(self.dims[2], self.dims[1]) / np.sqrt(self.dims[1]) self.param['b2'] = np.zeros((self.dims[2], 1)) else: self.param = param for layer in self.param: self.change[layer] = np.zeros_like(self.param[layer]) def Leaky_Relu(self,alpha, u): ''' In this method you are going to implement element wise Leaky_Relu.

Make sure that all operations here are element wise and can be applied to an input of any dimension.

Input: u of any dimension alpha: the slope coefficent of the negative part. return: Leaky_Relu(u) ''' # TODO: IMPLEMENT THIS METHOD #Copy of u lrelu = np.copy(u) #Compute leaky ReLu return np.maximum(lrelu, alpha*lrelu)

def Tanh(self, u): ''' In this method you are going to implement element wise Tanh.

Make sure that all operations here are element wise and can be applied to an input of any dimension.

Do NOT use np.tanh.

Input: u of any dimension return: Tanh(u) ''' # TODO: IMPLEMENT THIS METHOD #Copy of u tan = np.copy(u) #Compute tangent

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

return np.tanh(tan) def dL_Relu(self,alpha, u): ''' This method implements element wise differentiation of Leaky Relu, it is already implemented for you.

Input: u of any dimension alpha: the slope coefficent of the negative part. return: dL_Relu(u) ''' return np.where(u > 0, 1.0, alpha) def dTanh(self, u): ''' This method implements element wise differentiation of Tanh, it is already implemented for you.

Input: u of any dimension return: dTanh(u) ''' return 1 - np.square(np.tanh(u)) def nloss(self,y, yh): ''' In this method you are going to implement mean squared loss.

Refer to the description above and implement the appropriate mathematical equation.

Input: y 1xN: ground truth labels yh 1xN: neural network output return: MSE 1x1: loss value ''' # TODO: IMPLEMENT THIS METHOD #Compute mse mse=np.sum(np.power(y-yh,2)) #Compute average mse *= 1/(2*y.shape[1]) return mse @staticmethod def _dropout(u, prob): ''' This method implements the dropout layer. Refer to the description for implementation details.

Input: u D x N: input to dropout layer return: u_after_dropout D x N dropout_mask DxN ''' # TODO: IMPLEMENT THIS METHOD #Initalize dropout dropout_mask = [] for _ in range(u.shape[0]):

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

#Set every row with 1 or 0 aux = np.random.choice(2, u.shape[1], p = [prob,1-prob]) dropout_mask.append(aux) #Apply dropout to u u_after_dropout = np.multiply(dropout_mask,u) #Scale u u_after_dropout *= (1/(1-prob)) return u_after_dropout, dropout_mask

def forward(self, x, use_dropout=True): ''' Fill in the missing code lines, please refer to the description for more details.

Check nInit method and use variables from there as well as other implemented methods.

Refer to the description above and implement the appropriate mathematical equations.

Do not change the lines followed by #keep.

Input: x DxN: input to neural network use_dropout: True if using dropout in forward return: o2 1xN ''' # TODO: IMPLEMENT THIS METHOD self.ch['X'] = x #keep LINE

u1 = self.param['theta1']@self.ch['X']+self.param['b1'] # IMPLEMENT THIS o1 = self.Leaky_Relu(self.alpha, u1) # IMPLEMENT THIS LINE if use_dropout: o1, dropout_mask = self._dropout(o1,self.dropout_prob) # IMPLEMENT THIS

LINE #keep

LINE

self.ch['u1'], self.ch['mask'], self.ch['o1'] = u1, dropout_mask, o1 else: self.ch['u1'], self.ch['o1'] = u1, o1 #keep u2 = self.param['theta2']@self.ch['o1']+self.param['b2'] # IMPLEMENT THIS o2 = self.Tanh(u2) # IMPLEMENT THIS LINE self.ch['u2'], self.ch['o2'] = u2, o2 #keep return o2 #keep

def compute_gradients(self, y, yh, use_dropout=False): ''' Compute the gradients for each layer given the predicted outputs and ground truths.

The dropout mask you stored at forward may be helpful.

Input:

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

y: 1 x N numpy array, ground truth values yh: 1 x N numpy array, predicting outputs

arrays)

Output: dLoss: dictionary that maps layer names (strings) to gradients (numpy ''' # TODO: IMPLEMENT THIS METHOD dLoss_o2 = (yh-y)/y.shape[1]# IMPLEMENT THIS LINE dLoss_u2 = dLoss_o2 * self.dTanh(self.ch['u2'])

# IMPLEMENT THIS LINE

dLoss_theta2 = np.dot(dLoss_u2,self.ch['o1'].T) # IMPLEMENT THIS LINE dLoss_b2 = np.sum(dLoss_u2,axis=1) # IMPLEMENT THIS LINE dLoss_o1 = np.transpose(np.dot(dLoss_u2.T,self.param['theta2'])) # IMPLEMENT THIS LINE if use_dropout: dropout,_ = self._dropout(self.dL_Relu(self.alpha,self.ch['u1']),self.dropout_prob) dLoss_u1 = np.multiply(dLoss_o1,dropout) # IMPLEMENT THIS LINE else: dLoss_u1 = dLoss_o1 * self.dL_Relu(self.alpha,self.ch['u1']) # IMPLEMENT THIS LINE dLoss_theta1 = np.dot(dLoss_u1,self.ch['X'].T) # IMPLEMENT THIS LINE dLoss_b1 = np.sum(dLoss_u1,axis=1, keepdims = True)# IMPLEMENT THIS LINE dLoss = {'theta1': dLoss_theta1, 'b1': dLoss_b1, 'theta2': dLoss_theta2, 'b2': dLoss_b2} return dLoss def update_weights(self, dLoss, use_momentum=False): ''' Update weights of neural network based on learning rate given gradients for each layer.

Can also use momentum to smoothen descent.

arrays)

Input: dLoss: dictionary that maps layer names (strings) to gradients (numpy Return: None

HINT: both self.change and self.param need to be updated for use_momentum=True and only self.param needs to be updated when use_momentum=False ''' # TODO: IMPLEMENT THIS METHOD for layer in dLoss: if use_momentum: self.change[layer] = self.momentum * self.change[layer] + dLoss[layer]

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

self.param[layer] = self.param[layer] - self.lr * self.change[layer] else: self.param[layer] = self.param[layer] - self.lr * dLoss[layer] def backward(self, y, yh, use_dropout=True, use_momentum=False): ''' Fill in the missing code lines, please refer to the description for more details You will need to use cache variables, some of the implemented methods, and other variables as well Refer to the description above and implement the appropriate mathematical equations. do not change the lines followed by #keep.

Input: y 1xN: ground truth labels yh 1xN: neural network output Return: dLoss_theta2 (1x15), dLoss_b2 (1x1), dLoss_theta1 (15xD), dLoss_b1 (15x1) Hint: make calls to compute_gradients and update_weights ''' # TODO: IMPLEMENT THIS METHOD if use_dropout: dLoss = self.compute_gradients(y, yh, use_dropout) if not use_dropout: dLoss = self.compute_gradients(y, yh) if use_momentum: self.update_weights(dLoss, use_momentum) if not use_momentum: self.update_weights(dLoss) return dLoss['theta2'], dLoss['b2'], dLoss['theta1'], dLoss['b1'] def gradient_descent(self, x, y, iter = 60000, use_momentum=False, local_test=False): ''' This function is an implementation of the gradient descent algorithm.

Notes: 1. GD considers all examples in the dataset in one go and learns a gradient from them.

2. One iteration here is one round of forward and backward propagation on the complete dataset.

3. Append loss at multiples of 1000 i.e. at 0th, 1000th, 2000th .... iterations to self.loss Input: x DxN: input y 1xN: labels iter: scalar, number of epochs to iterate through ''' # TODO: IMPLEMENT THIS METHOD #Initialize self.nInit()

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

for i in range(0,iter): #Forward pass yh=self.forward(x) #Compute loss loss=self.nloss(y,yh) if not local_test: self.loss.append(loss) else: if i % 1000 == 0: #Save loss self.loss.append(loss) #Backward pass if use_momentum: self.backward(y, yh, self.use_dropout, use_momentum) if not use_momentum: self.backward(y, yh, self.use_dropout) #bonus for undergraduate students def batch_gradient_descent(self, x, y, iter = 60000, use_momentum=False, local_test=False): ''' This function is an implementation of the batch gradient descent algorithm Notes: 1. Batch GD loops over all mini batches in the dataset one by one and learns a gradient 2. One iteration here is one round of forward and backward propagation on one minibatch.

You will use self.iter and self.batch_size to index into x and y to get a batch. This batch will be fed into the forward and backward functions.

3. Append and printout loss at multiples of 1000 iterations i.e. at 0th, 1000th, 2000th .... iterations. **For LOCAL TEST append and print out loss at every iteration instead of every 1000th multiple.

4. Append the y batched numpy array to self.batch_y at every 1000 iterations i.e. at 0th, 1000th, 2000th .... iterations. We will use this to determine if batching is done correctly. **For LOCAL TEST append the y batched array at every iteration instead of every 1000th multiple 5. We expect a noisy plot since learning on a batch adds variance to the gradients learnt 6. Be sure that your batch size remains constant (see notebook for more detail).

Input: x DxN: input y 1xN: labels iter: scalar, number of BATCHES to iterate through

This study source was downloaded by 100000853497421 from CourseHero.com on 04-16-2023 18:01:50 GMT -05:00

https://www.coursehero.com/file/197273925/NNpy/

local_test: boolean, True if calling local test, default False for autograder and Q1.3 this variable can be used to switch between autograder and local test requirement for appending/printing out loss and y batch arrays ''' # TODO: IMPLEMENT THIS METHOD raise NotImplementedError def predict(self, x): ''' This function predicts new data points It is implemented for you Input: x DxN: inputs Return: y 1xN: predictions ''' Yh = self.forward(x, use_dropout=False) return Yh
