Massey Ferguson MF 29 29 XP COMBINES Parts Catalogue Manual

Page 1

MASSEY FERGUSON MF 29/29 XP COMBINES - 819725 819725 TABLE OF CONTENT 00 Ref00 Page00
MASSEY FERGUSON MF 29/29 XP COMBINES - 819725 819725
OF CONTENT 00 Ref00 Page00
TABLE
MASSEY FERGUSON MF 29/29 XP COMBINES - 819725 819725
00 Ref00 Page00
TABLE OF CONTENT
MF 29/29 XP COMBINES - 819725 2 2 3 1 4 5 9 35 6 34 7 33 32 8 30 29 28 10 27 11 31 12 13 36 14 37 38 26 25 39 20 16 24 17 23 18 15 22 19 21 40 41 41 49 42 50 51 48 43 44 52 53 46 45 47 Ref1-1 Page1-1

STRAW DIVIDER

ItemPart NumberQtyDescription Comments

1 D282304602 Divider

2 D414473002 Split Ring

3 D282518011 Point POS.2-7 D282518021 Point POS.2-7

4 D410876004 Locknut 5 D204004714 Washer 6 D400668004 Screw Metric

7 D282602262 Point D282509001 Divider (F1) POS.8-31 Right Hand D282509011 Divider (F0) POS.8-31 Left Hand

8 D282111261 Divider 9 D400637002 Screw 10 D204004712 Washer 11 D282304471 Plate 12 D204004092 Washer 13 D414087001 SPLIT PIN 14 D282304621 Rod 15 D282304571 Wing 16 D272003131 Angle 17 D410108001 Nut Metric 18 D404079001 Screw Metric 19 D272006401 Stop 20 D273003231 Locknut 21 D282305171 Support 22 D404050002 Screw Metric 23 D204004092 Washer 24 D410135002 Nut D282304671 Mounting POS.25-28 25 D404244001 HEXAGON SCREW 26 D282304681 Mounting 1 27 D282304711 Mounting 2 28 D410875001 Locknut 29 D400667002 Screw 30 D282505491 Plate 31 D272003001 Pin 32 D404077004 Screw 33 D282304651 Support Right Hand D282304661 Support Left Hand 34 D204004714 Washer 35 D410876004 Locknut 36 D410877002 Locknut 37 D204004262 Washer 38 D282304532 Plate 2 39 D400702002 Screw Metric D282304872 Wing POS.40-53 40 D282304801 Wing 41 D414106002 Splint 42 D282304821 Support 43 D272003641 Handle 44 D282304861 Pipe 45 D400213001 Screw 46 D282304882 Clutch 47 D282304731 Support 48 D404077002 Screw 49 D204005181 Spacer 50 D282304721 Bracket 51 D410876002 Locknut 52 D273003231 Locknut 53 D204004261 Washer

(F0) ON THE RIGHT (F1) ON THE LEFT

MASSEY FERGUSON MF 29/29 XP COMBINES
819725 819725
-
1-1
Ref1-1 Page1-1
MF 29/29 XP COMBINES - 819725 41 41 41 41 1 1 1 40 2 42 42 42 42 43 43 43 43 3 5 8 8 19 45 6 7 20 21 9 9 18 10 11 11 11 12 12 22 24 28 25 23 26 29 17 16 30 15 27 14 33 33 13 34 31 32 35 36 39 38 37 44 44 4 Ref1-2 Page1-2

KNIVES AND FINGERS

ItemPart NumberQtyDescription Comments

1 D41010800 Nut Metric

2 D2520089912 Clip 12'-3, 72 M D2520089914 Clip 14'-4, 34 M D2520089916 Clip 16'-4, 95 M

3 D28210349 Shim 4 D28210350 Shim 5 D28230292 Shim 6 D40551600 Bolt 7 D282605311 Finger

8 D4042580012 Screw D4040790014 Screw Metric D4042580016 Screw 9 D28230833 Nut

10 D4410290021 Finger 12'-3, 72 M D4410290025 Finger 14'-4, 34 M D4410290031 Finger 16'-4, 95 M

11 D40551600 Bolt 12 D441033002 Finger 13 D441044001 Finger 14 D40551500 Bolt 15 D404076001 Screw

16 D40407800 HEXAGON SCREW

17 D20400471 Washer 18 D282300101 Bar 16' D282300111 Bar 14' D282500171 Bar 12' 19 D410135002 Nut 20 D282308291 Guard 21 D400637002 Screw 22 D4904000012 Ear Lifter 1 12'-3, 72 M 22 D4904000014 Ear Lifter 1 14'-4, 34 M 22 D4904000016 Ear Lifter 1 16'-4, 95 M

23 D282302272 Lever D252010542 Knife 12' POS.24-36 D282300342 Blade 14' POS.24-36 D282300372 Knife 16' POS.24-36 24 D413783003 Rivet 25 D413778002 Rivet 26 D413782004 Rivet 27 D441200001 Knife Head POS.28-29 28 D410487001 Castle Nut 29 D441202001 Cap 30 D414060001 SPLIT PIN 31 D430049001 Foam 32 D282301201 Spacer 33 D41377500 Rivet 34 D441034001 Blade 35 D44100000 Section 36 D252010702 Knife Back 12'-3, 72 M D282300082 Knife Back 14'-4, 34 M D282300072 Knife Back 16'-4, 95 M

37 D282308421 Guard (S3) POS.38-39 37 D282308431 Guard (S3) POS.38-39 37 D282308441 Guard (S4) POS.38-39

37 D282308451 Guard (S4) POS.38-39 38 D265003172 Spring 39 D282308412 Spring 40 D4904020012 Ear Lifter 2 (3) 12'-3, 72 M

MASSEY FERGUSON MF 29/29 XP COMBINES
819725 819725
-
1-2
Ref1-2 Page1-2

KNIVES AND FINGERS

ItemPart NumberQtyDescription Comments

40 D4904020014 Ear Lifter 2 (3) 14'-4, 36 M

40 D4904020016 Ear Lifter 2 (3) 16'-4, 95 M

41 D40426100 Screw 42 D49040500 Roller TYPE 2+3 43 D41013600 Nut 44 D49040400 Spring TYPE 2+3

45 D4904030012 Ear Lifter (3) 12'-3, 72 M

45 D4904030014 Ear Lifter (3) 14'-4, 36 M

45 D4904030016 Ear Lifter (3) 16'-4, 95 M (S3) 12'-14' (S4) 16' (3)

OPTIONAL EQUIPMENT

MASSEY FERGUSON MF 29/29 XP COMBINES - 819725 819725
1-2
Ref1-2 Page1-2
MF 29/29 XP COMBINES - 819725 1 5 42 6 2 8 3 4 9 43 14 15 16 11 12 44 10 13 28 29 25 25 25 17 26 26 37 30 23 24 24 31 32 33 34 34 35 20 36 19 22 40 38 21 39 18 41 27 7 Ref1-3 Page1-3

KNIFE CRANK AND BELLE CRANK

ItemPart NumberQtyDescription Comments

1 D417073001 Bearing

2 D282111092 Shim

3 D419643002 V Belt

4 D410877004 Locknut

5 D282507041 Pulley

6 D417079001 Flange

7 D404108004 HEXAGON SCREW

8 D431552001 Gib Key 9 D282501691 Arm 10 D414091001 SPLIT PIN

11 D204004481 Washer

12 D410491001 Castle Nut D282302491 Pitman POS.13-21

13 D404022003 Screw Metric 14 D282200841 Lock Washer 15 D417061001 Bearing Ball 16 D282302471 Conrod 17 D282200931 Locknut 18 D441201001 Toggle POS.19-20 19 D441202001 Cap 20 D410487001 Castle Nut 21 D430051001 Greaser T.915607 22 D414090001 Pin 24 D404298004 HEXAGON SCREW 25 D204004261 Washer 26 D410877004 Locknut D282302311 Bellcrank POS.27-40 27 D410123002 HEXAGON SCREW 28 D282200871 Washer 29 D282506911 Bush 30 D282109131 Clamp 31 D282506901 Spacer 32 D454091001 Seal 33 D282506921 Ring 34 D416674002 Bearing Roller 35 D282302241 Crank 36 D404283002 HEXAGON SCREW 37 D282302271 Lever 38 D454090001 Seal 39 D282200861 Shaft M16 40 D430015001 Greaser 41 D282109131 Clamp 42 D417111001 Flange (T5) 43 D417122001 Flange (T5) 44 D416639001 Bearing Ball (T5) (T5)

ONLY FOR DRY LANDS

MASSEY FERGUSON MF 29/29 XP COMBINES
819725 819725
-
1-3
Ref1-3 Page1-3
MF 29/29 XP COMBINES - 819725 5 5 4 2 2 2 7 11 11 11 3 1 9 6 8 10 10 13 13 12 12 19 16 16 32 14 17 21 21 18 22 20 20 48 48 15 15 15 15 24 23 49 33 34 35 25 26 36 52 53 38 28 28 30 31 40 44 45 41 42 43 43 47 51 50 37 39 27 27 29 Ref1-4 Page1-4

FEEDER DRUM

ItemPart NumberQtyDescriptionComments

1 D282501111 Bracket

2 D2040040911 Washer

3 D404047001 Screw Metric

4 D4101070010 Nut Metric

5 D410108002 Nut Metric

6 D282110231 Bolt

7 D282513191 Plate +F.915608 Right Hand

7 D282201101 Plate T.915607

8 D426253001 Pin

9 D426164001 Pin D282503801 Shaft 12' POS.10-26

D282503811 Shaft 14' POS.10-26 D282503821 Shaft 16' POS.10-26

10 D417078002 Flange 11 D4040770012 Screw 12 D282514052 Plate (2) +F.914863

13 D282501072 Plate

14 D282501081 Crankshaft 12' D282501091 Shaft 14' D282502511 Crankshaft 16'

15 D426162004 Pin

16 D426099004 Pin

17 D426164001 Pin 18 D426253001 Pin 19 D282503851 Arm Right Hand 20 D2825058515 Support

21 D2828123615 Hair Pin 22 D282005471 Shaft 23 D282503841 Arm (S3) POS.24-26 23 D282300511 Arm (S4) POS-24-26 24 D282500961 Arm Left Hand (S3) 24 D282300501 Arm Left Hand (S4)

25

D433381001 Bearing (S3) D433387001 Bush (S4) 26 D433383001 Bush (S3) D433389001 Bush (S4)

27 D404076006 Screw 28 D282514052 Plate (2) +F.914863

29 D28250091 Drive Shaft12' POS.30-31 29 D282501011 Drive Shaft14' POS.30-31 29 D282502471 Drive Shaft16' POS.30-31

30 D431543001 Gib Key 31 D282505351 Flange 32 D282513631 Auger 14' POS.10-31 32 D282513651 Auger 16' POS.10-31 32 D282514101 Auger 12' POS.10-31 33 D2825056615 Finger 34 D2820015015 Support 35 D282513021 Cover +F.915608 D282001331 Cover T.915607 36 D2826031415 Toggle 37 D2820015115 Support 38 D4040240030 Screw Metric 39 D404022008 Screw Metric

MASSEY FERGUSON MF 29/29 XP COMBINES
819725
- 819725
1-4
Ref1-4 Page1-4

FEEDER DRUM

ItemPart NumberQtyDescriptionComments

40 D282108701 Plate (S3) 40 D282301031 Plate (S4) 41 D410108002 Nut Metric 42 D282108951 Bolt 43 D410107005 Nut Metric 44 D417078001 Flange (S3) 44 D417079001 Flange (S4) 45 D419835001 V Belt (R9) 45 D419835002 V Belt (R8) 45 D419836002 Belt (T5) 46 D282109021 Pulley C 450 (R9) 46 D282301981 Pulley 2C-450 (R8) 16' 46 D282508871 Pulley 2C-450 (R8) 12'-14' 47 D431552001 Gib Key (S3) 47 D431568001 Gib Key (S4) 48 D282513351 Spiral 12' (U2) +F.915608 48 D282513291 Spiral 14' (T7) +F.915608 48 D282513301 Spiral 16' (S4) +F.915608 49 D282513361 Spiral 12' (U2) F.915608 49 D282513321 Spiral 14' (T7) +F.915608 49 D282513331 Spiral 16' (S4) +F.915608 50 D282513031 Tube F.915608 50 D282501151 Cowl T.915607 51 D282513382 Shell 12' (U2) +F.915608 51 D282513372 Tube 14' (T7) +F.915608 51 D282513422 Shell 16' (S4) +F.915608 52 D282504122 Cover (S4) 53 D404022008 Screw Metric (R8) FOR TABLES WITH DOUBLE BELT (R9) FOR TABLES WITH SINGLE BELT (S3) 12'-14' (S4) 16' (T5) ONLY FOR DRY LANDS (T7) 14' (U2) 12' (2) NO. REFERS TO TABLE NUMBER

MASSEY FERGUSON MF 29/29 XP COMBINES - 819725 819725
1-4
Ref1-4 Page1-4
MF 29/29 XP COMBINES - 819725 1 12 12 7 17 6 6 6 5 5 5 2 9 8 13 13 3 11 11 4 4 10 14 15 15 18 18 21 22 19 16 20 20 23 23 24 25 25 29 32 48 48 30 31 36 34 34 33 33 35 37 50 39 45 49 38 40 44 42 42 41 41 46 47 43 26 27 28 Ref1-5 Page1-5

COUNTER SHAFT

ItemPart NumberQtyDescription Comments

1 D419894002 V Belt (S6) F.39526

1 D419892002 V Belt (S7) T.38925

2 D282508661 Pulley (2) F.911160

2 D282507181 Pulley (2) T.911159

3 D404109002 Screw

4 D417073002 Bearing

5 D204004266 Washer

6 D410877004 Locknut

7 D282500231 Guard 12'-3, 72 M D282304411 Guard 14'-4, 34 M D282401261 Guard 16'-4, 95 M

8 D204004532 Washer

9 D404024002 Screw Metric 10 D282304901 Bracket 11 D410134004 Nut 12 D431553002 Gib Key

13 D282508881

Countershaft Left Hand (R8) 12'-3, 72 M

13 D282508891 Countershaft (R8) 14'-4, 34 M

13 D282400381 Countershaft Left Hand (R9) 12'-3, 72 M

13 D282302011 Countershaft (R9) 14'-4, 34 M

13 D282302021 Countershaft 16'-4, 95 M

14 D282504401 Pulley 15 D419643002 V Belt 16 D404283002 HEXAGON SCREW 17 D282502331 Bolt 18 D416227002 Bearing Ball 19 D287400281 Spacer 20 D425137002 Circlip 21 D287006071 Roller 22 D282502341 Spacer 23 D410881002 Locknut 24 D282302661 Bolt 25 D410877002 Locknut 26 D282302671 Bolt 27 D426167001 TIGHENING PIN 28 D426256001 Pin 29 D282301941 Pulley (R8) 30 D419835002 V Belt (R8) D419836002 Belt (T5) 31 D282302451 Spacer (R8) D282302461 Idler (R8) POS.32-36

32 D282302391 Pulley (R8) 33 D425140002 Circlip (R8) 34 D416228002 (R8) 35 D282503701 Bolt (R8) 36 D282302441 Ring (R8) 37 D282400341 Pulley (R9) 38 D419835001 V Belt (R9) 39 D282502341 Spacer (R9) 40 D287006071 Roller (R9) 41 D425137002 Circlip (R9) 42 D416227002 Bearing Ball (R9) 43 D282502331 Bolt (R9) 44 D287400281 Spacer (R9) 45 D282501861 Housing 12' 3, 72 M 45 D282501871 Housing 14' 4, 34 M 45 D282502761 Housing 16'

MASSEY FERGUSON MF 29/29 XP COMBINES
819725
- 819725
1-5
Ref1-5 Page1-5

MF

COUNTER SHAFT

ItemPart NumberQtyDescription Comments 4, 95 M

D280509091 Parts Pack (T5) POS.46-50

46 D289504481 Plate (T5)

47 D406898004 Screw (T5) 48 D410136006 Nut (T5) 49 D404077002 Screw (T5)

50 D289504471 Support (T5) (R8)

FOR TABLES WITH DOUBLE BELT (R9)

FOR TABLES WITH SINGLE BELT (S6)

ALSO USED F.38926-T.39087 (S7)

ALSO USED F.39088-T.39137 (T5)

ONLY FOR DRY LANDS (2) NO. REFERS TO TABLE NUMBER

FERGUSON
MASSEY
29/29 XP COMBINES - 819725 819725
1-5
Ref1-5 Page1-5
MF 29/29 XP COMBINES - 819725 11 12 6 13 1 2 2 4 3 5 9 10 21 8 16 16 14 14 15 15 17 52 20 20 20 20 23 19 19 19 19 24 51 46 22 45 47 18 25 26 28 30 30 31 31 29 29 34 48 35 36 36 32 32 37 33 50 38 38 38 39 39 39 40 49 41 41 41 42 42 43 44 44 7 27 27 Ref1-6 Page1-6

GUARDING AND REDUCING EQUIPMENT

ItemPart NumberQtyDescription Comments

1 D404081004 HEXAGON SCREW

2 D204004168 Washer

3 D282506781 Bridle

4 D282508671 Pulley

5 D419252002 V Belt

6 D282506811 Pulley

7 D410876004 Locknut

8 D417073002 Bearing 9 D431553003 Gib Key

10 D282508881 Countershaft Left Hand (R8) 12'-3, 72 M

10 D282508891 Countershaft (R8) 14'-4, 34 M

10 D282400381 Countershaft Left Hand (R9) 12'-3, 72 M

10 D282302011 Countershaft (R9) 14'-4, 34 M

10 D282302021 Countershaft 16'-4, 95 M

11 D404022006 Screw Metric

12 D204004056 Washer

13 D282509271 Cover 12'-3, 72 M

14 D4101340011 Nut

15 D204004695 Washer

16 D404024005 Screw Metric

17 D282509261 Guard (U2)

18 D282506711 Guard (U2) D282506871 Guard (V7) 19 D2040042610 Washer 20 D4108770014 Locknut 21 D419894001 V Belt (S6) F.39526 21 D419892001 V Belt (S7) T.38925 22 D282508661 Pulley (2) F.911160 22 D282507181 Pulley (2) T.911159 23 D282506801 Pulley 24 D277002441 Spacer 25 D404112003 Setscrew D431049001 Key 26 D282508411 Countershaft 12'-3, 72 M D282506791 Countershaft (V7) 27 D417073002 Bearing 28 D282515181 Bracket Right Hand 29 D404114004 Screw Metric 30 D404050002 Screw Metric 31 D204004092 Washer 32 D410135002 Nut 33 D282508421 Stay (U2) 34 D282509181 Stay (V7) 35 D282509221 Bracket Left Hand (V7) 36 D282509192 Bracket 37 D282509231 Bracket Left Hand (U2) 38 D20400404 Washer 39 D40402400 Screw Metric 40 D282504351 Bracket 41 D410134004 Nut 42 D425555002 Circlip 43 D282504591 Guard 44 D434272002 Pin 45 D282515771 Cover (V7) F.916692 46 D434272002 Pin F.916692 47 D425555002 Circlip F.916692 48 D282502861 Guard (V7)

MASSEY FERGUSON MF 29/29 XP COMBINES - 819725 819725
1-6
Ref1-6 Page1-6

GUARDING AND REDUCING EQUIPMENT

ItemPart NumberQtyDescription Comments F.916692

49 D282502841 Bracket 50 D282504341 Guard 51 D282517221 Support

(R8)

FOR TABLES WITH DOUBLE BELT (R9)

FOR TABLES WITH SINGLE BELT (S6)

ALSO USED F.38926-T.39087 (S7)

ALSO USED F.39088-T.39137 (U2) 12' (V7) 14' - 16' (2) NO. REFERS TO TABLE NUMBER

MASSEY FERGUSON
819725
MF 29/29 XP COMBINES - 819725
1-6
Ref1-6 Page1-6
MF 29/29 XP COMBINES - 819725 1 2 31 30 29 4 12 3 32 5 13 10 15 7 16 8 11 9 14 17 18 27 19 26 25 24 24 20 21 22 23 28 6 Ref1-7 Page1-7

WEARING PLATES AND STONE STOP

ItemPart NumberQtyDescription Comments

1 D282505931 Stop 12' INCL.P.2-3

1 D282505941 Stop 14' INCL.P.2-3

1 D282505951 Stop 16' INCL.P.2-3

2 D405516003 Bolt

3 D204004713 Washer

4 D282501801 Guard Right Hand

5 D282501781 Plate

6 D282501791 Guard Left Hand

7 D4040240025 Screw Metric

8 D2040040425 Washer

9 D282501861 Housing 12' 3, 72 M

9 D282501871 Housing 14' 4, 34 M

9 D282502761 Housing 16' 4, 95 M

10 D282508851 Plate Right Hand

11 D282508861 Plate Left Hand

12 D4040240017 Screw Metric

13 D2040040434 Washer

14 D4101340025 Nut

15 D40405000 Screw Metric

16 D20400409 Washer

17 D282500201 Stripper Right Hand (U2)

17 D282301821 Stripper Left Hand (T7)

17 D282301841 Stripper Left Hand (S4)

18 D282300101 Bar 16' (S4)

18 D282300111 Bar 14' (T7)

18 D282500171 Bar 12' (U2)

19 D282500211 Stripper Left Hand (U2)

19 D282301831 Stripper Left Hand (T7)

19 D282301851 Stripper Left Hand (S4)

20 D40423700 HEXAGON SCREW

21 D20400409 Washer

22 D41087500 Locknut

23 D282503671 Wearplate Left Hand

24 D282503692 Wearplate 4' (U2)

24 D282503691 Wearplate 4' (T7)

24 D282503682 Wearplate 3' (V7)

24 D282503693 Wearplate 4' (S4)

25 D282503661 Wearplate Right Hand

26 D20400471 Washer 27 D40407800 HEXAGON SCREW

28 D28250838 Wearplate

29 D282513111 Retainer (S4) D282515731 Retainer (S3) F.916283

30 D204004094 Washer

31 D404049004 Screw Metric 32 D410135004 Nut (S3) 12'-14' (S4) 16'

MASSEY FERGUSON MF 29/29 XP COMBINES
819725
- 819725
1-7
Ref1-7 Page1-7

WEARING PLATES AND STONE STOP 1-7

ItemPart NumberQtyDescription Comments (T7) 14' (U2) 12' (V7) 14' - 16'

MASSEY FERGUSON
MF 29/29 XP COMBINES - 819725 819725
Ref1-7 Page1-7
MF 29/29 XP COMBINES - 819725 55 56 3 57 1 10 4 5 12 2 6 7 8 9 13 62 61 61 59 54 53 60 20 19 18 24 15 27 30 50 31 33 34 36 37 38 45 39 46 40 47 48 41 41 43 63 42 42 23 23 17 21 25 26 14 22 44 29 32 35 52 51 28 49 Ref1-8 Page1-8
Thank you very much for your reading. Please Click Here. Then Get COMPLETE MANUAL.NOWAITING NOTE: If there is no response to click on the link above, please download the PDF document first and then clickonit.

TABLE TRAILER 1

ItemPart NumberQtyDescription Comments D282511032 Wheel (E7) POS.1-3

1 D467041002 Tyre 2 D282511022 Rim 3 D467372002 Valve 4 D4102160010 Nut 5 D467239002 Cap 6 D410879002 Locknut 7 D416209002 Ball 8 D467240002 Hub 9 D4043820010 Bolt 10 D416230001 Bearing Ball 12 D415824002 Washer 13 D282510962 Bracket 14 D282516281 Table (45) 15 D282518291 Table +F.919888 17 D450052001 Socket 18 D204004003 Washer 19 D403516003 Screw Metric 20 D450053001 Socket 21 D45084600 Reflector 22 D282511101 Bar (E7) 23 D282507481 Support 24 D204004661 Washer 25 D282006091 Ball 26 D282503271 Lever 27 D410877001 Locknut 28 D282503561 Hub 29 D204004411 Washer 30 D287001361 Spring 31 D426167001 TIGHENING PIN 32 D414108001 Splint 33 D282503551 Pin 34 D282510791 Pipe 35 D410881001 Locknut 36 D204004371 Washer 37 D415971001 Bearing 39 D426120001 TIGHENING PIN 40 D282503371 Spindle 41 D410111002 HEXAGON SCREW 42 D204004592 Washer 43 D282503401 Pipe 44 D282503151 Shaft 45 D282503051 Spacer 46 D467217001 Wheel 47 D282503171 Bush 48 D282503051 Spacer 49 D459072002 Wedge 50 D459073002 Holder 51 D204004018 Washer 52 D407412008 Screw 53 D282507592 Pin 54 D414462002 Pin D282511122 Wheel (E8) POS.55-58 55 D467056002 Tyre 56 D282511112 Rim 57 D467088002 Tube 58 D467375002 Rim 59 D282516431 Plate (E7) 60 D404109004 Screw 61 D204004268 Washer 62 D410109004 Nut Metric 63 D282513101 Drawbar (E8) (E7) 7.00 X 12 (E8) 6.00E X 9 (45) ONLY FOR GERMANY, SCHWITZERLAND, AUSTRIA AND HOLLA ND
