Group 53 Thermoplastic hoses
484 Description Insert MP UNF links anti-vib
Dim. thread inch
Dim. hose inch
Material
Part no
3/8 x 24
1/4
AISI 316
660275-06-04
HIGH PRESSURE HOSE 50252 6/2WL TWIN HOSE Application Assembly Users Tube Reinforcement Cover Temperature Safety factor Marking Remarks
Hydraulics and water blast. Only in certified TESS-firms. Construction, Maritime / ship, Mechanical engineering, Oil and Gas, Subsea. Polyamide (PA) 2 layers of steel wire helical + 2 layers steel braid. Black and blue Polyurethane (PUR) -30째C - +60째C Waterblasting 1:2,5, hydraulics 1:4, gas 1:6. Producer-type WP-batch No. Very flexible hose. It shall only be used special coupling. Same ferrule and insert as 5025. The hose shall always be pressure tested.
I.D. mm
I.D. inch
O.D. mm
W.P. BAR SF 1:2,5
W.P. BAR SF 1:4
W.P. BAR SF 1:6
Burst pressure BAR
Min. bend radius mm
Weight per m kg
5,9
1/4
12,0
1200
750
500
3000
80
0,474
Part no 50252-04
HIGH PRESSURE HOSE 5023 10/2W Application Assembly Users Tube Reinforcement Cover Temperature Safety factor Marking Remarks
53
Hydraulics and water blast. Only in certified TESS-firms. Construction, Maritime/Ship, Mechanical engineering, Oil and gas, Subsea. Polyamide (PA) 2 layers of steel wire helical + 2 layers steel braid. Black polyurethane (PUR) -30째C - +60째C Waterblasting 1:2,5 Hydraulics 1:4. Gas 1:6. Producer-type WP-batch No. It shall only be used special coupling. The hose shall always be pressure tested.
I.D. mm
I.D. inch
O.D. mm
W.P. BAR SF 1:2,5
W.P. BAR SF 1:4
W.P. BAR SF 1:6
Burst pressure BAR
Min. bend radius mm
Weight per m kg
Part no
10,0
3/8
17,2
1104
690
460
2760
125
0,430
5023-06
Description
Dim. inch
Material
3/8
Steel
65023-06
AISI 316
665023-06
Part no
FERRULE Ferrule for 5023-06 Ferrule for 5023-06 Description
3/8 Dim. thread inch
Dim. hose inch
Material
Part no
INSERT BSP SWIVEL - Supplied without nut, which must be ordered separately. Insert BSP swivel
1/2
3/8
Steel
60201-08-06
Insert BSP swivel
1/2
3/8
AISI 316
660201-08-06
Nut BSP
1/2
-
Steel
601-08
Nut BSP
1/2
-
AISI 316
6601-08
3/8
3/8
Steel
60212-06-06
Insert MM swivel
22 x 1,5
3/8
Steel
60271-22-06
Nut MM hex 30
22 x 1.5
-
Steel
671-22
Insert NPTF male
3/8
3/8
Steel
60216-06-06
Insert NPTF male
3/8
3/8
AISI 316
660216-06-06
INSERT BSP MALE Insert BSP male INSERT MM SWIVEL
INSERT NPTF MALE
484
