M O T I O N S Y S T E M A P P L I C AT I O N S
The R.A Jones Autoprod CF-400 is an inline cup-filling machine available in five, six, or eight-lane configurations with production speeds to 900 cups per minute. One innovative feature on the machine is a sealed rotary drive mechanism for sanitary station movement. Another is its use of a long endless synchronous belt (in blue) instead of a chain drive.
belt
POWER TRANSMISSION-PART CONVEYING
PYRATHANE® BELTS With Lifetime Warranty Against Manufacturing Defects
LINE SHAFT CONVEYOR BELTS - Original Equipment & Connectable CUSTOM MADE IN INCH, METRIC & O-RING SIZES Round, Flat and Connectable Polyurethane Belts • Very Clean Operation • Eliminates Tensioning Devices • Exceptional Abrasion Resistance
Endless boosts precision of packaging machine LONG BELTING (usually with L or H trapezoidal tooth or HTD profiles) can exceed 500 feet in some cases. Such belts work for power transmission and axis synchronization — doing double duty as conveyors in many cases. Such belts complete with rack-and-pinion sets in machine tools and X-ray equipment as a viable drive for linear strokes.
SAMPLES AVAILABLE
Try our Pyrathane Belts
®
on your conveyor ...
the standard of the industry!
AN ISO 9001 CERTIFIED COMPANY
Consider one application of an endless belt — on the R.A Jones Autoprod CF-400 cup-filling machine for the food and beverage industry. It has a belt drive for pockets instead of a traditional chain design. The belt drive boosts precision while reducing maintenance and the number of adjustments needed to stations.
pyramidbelts.com • 641.792.2405 • sales@pyramidbelts.com 18 201702_Pyramid4x475_lineshaftR2.indd 1 belts & pulleys – Motion Control HB 08.18 V2.cut.LE.indd 18
DESIGN WORLD — MOTION
11 • 2018
