Control Engineering May June 2025

Career, salary survey: Economy, workforce, tariffs | 36, 40, 42

Machine vision | 27

Safety, cybersecurity | 30, 34

Digital twins | 44

We’re sensing big savings in your future… when you buy process sensors from AutomationDirect

Our process sensors give you high performance at prices that are easy on your budget.

NEW! Soliphant® Series

Level Switches

Starting at $676.00 (FTM20-AM23A)

Endress+Hauser Soliphant® FTM20 vibration rod point level switches detect fine- or coarse-grained, non-fluidized bulk solids in silos, hoppers, and bins. They can even detect solids underwater, such as sediment buildup in a tank.

• 8.86in. insertion length

• PNP N.O./N.C. selectable or DPDT relay outputs

• 1-1/4in. or 1-1/2in. male NPT process connections

• Select models offer CSA general purpose or FM hazardous location ratings

• IP66/67, NEMA 4X protection rating

Temperature Sensors

Starting at $23.00 (THMJ-B02L06-01)

Temperature sensors provide accurate and reliable feedback for temperature control and monitoring applications.

• Optris infrared pyrometers

• Temperature switches and transmitters

• Thermocouples, RTDs, and thermowells

• ProSense 10K3 series thermistors

• Digital temperature switches/transmitters

NEW! Tru o®TKM Series Paddle Wheel Flow Meters

Starting at $944.00 (TKM-15-P)

• 4 to 20 mA and pulse outputs

ICON Process Controls Truflo® TKM series paddle wheel liquid flow meters provide reliable, full-pipe liquid flow measurement with exceptional long-term performance. They deliver outstanding value and are constructed with a chemically resistant PVC body, ideal for corrosive liquid applications.

• Sensing ranges up to 357 GPM

• ShearPro® paddle wheel design features 78% less drag than older paddle designs

• ShearPro® through-pin design eliminates finger spread and lost paddles

• 1/2 to 2in. schedule 80 socket process connections

• NEMA 4X and IP66 protection rating

Pressure Sensors

Starting at $79.00 (LPPT25-20-0015H)

Rugged pressure switches and transmitters provide accurate and reliable feedback for pressure control and monitoring applications. Switches provide simple setpointtripped signals, while transmitters can provide gauge, absolute, or differential pressure analog readings. Hygienic models and models for potable water applications are also available.

Newest Addition:

AttaBox Heartland/Heartland

SL Hinged Screw Cover Enclosures

Attabox Heartland enclosures starting at $83.00

The hinged screw cover con guration of the AttaBox Heartland series enclosures provides the highest level of protection against water intrusion with a NEMA 6P rating. These enclosures feature opaque covers and can be padlocked for added security.

• Constructed of polycarbonate with UV inhibitors

• NEMA ratings 1, 3R, 4, 4X, 6P, and 12

• Variable-depth side-mount capability

AutomationDirect is continually expanding our offering of quality enclosures from the best

• Aluminum back panel and swing-out panel mounting options

• Thick, robust sidewall construction eliminates sidewall flexing

• Fully non-metallic hinge, does not penetrate inside enclosure

7 | May and June online article sampling of www.controleng.com, with links

8 | Automate 2025: Robots accelerate; new industrial AI tools. System integrators provide automation advice. Benefits, challenges of implementing automation. 10x proven benefits from software. 5 ways cobots, AMRs top humanoid robots. Redefining control with software-defined automation. Emerson Exchange 2025: Modernize, easily integrate industrial automation. And more.

15 | Think Again: Non-AI advice to stay ahead of AI for industrial automation

16 | PID spotlight, part 17: Heuristic tuning of integrating processes

20 | APC 2.0: Base-layer advanced process control

23 | Ways IIoT, AI empower smart manufacturing

27 | Machine vision: New 3D ultrasonic sensor reduces costs, improves mobile robot safety

30 | How IoT, edge computing and digital twins empower process safety

34 | Evolution of automation: AI, cybersecurity, industry-specific needs

36 | Results are in: Control Engineering Career and Salary Survey, 2025Benefits and salaries increased. Artificial intelligence and machine learning top the list of leading automation technologies.

40 | Use 2025 salary survey advice to help your automation career

42 | Ways manufacturers can recruit, train and retain a skilled workforce

44 | How to leverage digital twins for asset lifecycle optimization

Industry 4.0 sets high standards for the future of sustainable production. Our level and pressure instrumentation is designed to meet these demands, combining the essential features that enhance quality, efficiency, and flexibility in your processes –every single day.

Everything is possible. With VEGA.

vega.com

INNOVATIONS

53 | New Products for Engineers, www.controleng.com/products

Control Engineering Product of the Year-Link to the 2025 winners. I/O modules for PLC family; IP69 ultra-premium efficient motor; High power lithium cells for automation; Ultrasonic sensors with IO-Link; Drive system optimization; 64-bit Arm computers with quad-core processor; DCS upgrade; RFID read/write head; High capacity pump station; Control system software for machine control, simulation.

55 | Back to Basics: Single-Pair Ethernet breaks down the limits of connectivity

SPE offers Ethernet connectivity in one set of twisted-pair copper wires, with power. At 10 Mbit/s, SPE run up to 1,000 meters.

NEWSLETTERS ONLINE

Process Instrumentation & Sensors, May 6

• Understanding EPA requirements for CEMS design; Advanced contextualization and visualization adds value to data; Generative AI tool recognized for innovation in industrial operations; and more. System Integration, April 22

• Ask 11 questions to simplify system integration; Six strategic steps to make systems integration seamless; The dark side of the IT/OT integration equation; and more

Go to www.controleng.com/subscribe and select newsletters.
