PDE2600PNUK
Logic Processing
Parker Pneumatic Miniature high-speed valves in stand alone, stackable or combined modules, incorporating standard logic functions. The range also includes timers and impulse modules. • Complete range • Stand alone, stackable or combinable modules • Very fast response time • Flexible and highly maintainable system • DIN rail mounting • Ø 4mm connection
Operating information Working pressure Working temperature Flow (Qmax) ATEX approval:
For ATEX specific products contact Sales Office
3 to 8 bar -15 °C to 60 °C 180 l/min (PRD = 60 l/min) CE Ex II 2 GD c 85oC
For more information see www.parker.com/euro_pneumatic
Logic sequencer Step modules
Step module subbase
Set of head and tail modules and deviation modules B
B
R P A
Order code
Without sub base Pneumatic output
PSM-A10
Visual indication of pneumatic output and manual override
PSM-A12
With sub base Wihtout manual overide
PSM-B12
Subbase Additional interlock
Order code
PSB-A12 PSV-A12
Head & tail set Deviation standard Deviation for remote
A
Order code PSE-A12 PSD-A12 PSD-B12
Logic elements Line mounted elements
S
a
Logic Function
Combinable elements
S
&
1 b
a
a
b
S
S
& b
a
Subbase mounted elements
S
&
1 b a
Order code
Logic Function
AND OR
PLL-A11 PLK-A11
Clip on Din-rail
PZM-L199
AND OR NOT INPUT
b
S
S
&
& a
a
Order code
Logic Function
PLL-B12 PLK-B12 PLN-B12 PLE-B12
AND NOT inhibit standard NOT inhibit threshold OR YES regenerated
a
a
Order code PLL-C10 PLN-C10 PLN-D10 PLK-C10 PLJ-C10
3 port subbase to be ordered separately.
Logic relays Pressure switch To be used with 3 port subbase
S
S
1
Amplifier relays B
A
a
Memory relays
S
To be used with 4 port subbase
P
To be used with 4 port subbase
p
a
Order code
Order code
Order code
With subbase Without subbase
PRE-A12 PRE-A10
With subbase Without subbase
PRD-A12 PRD-A10
With subbase Without subbase
PLM-A12 PLM-A10
Sensor relays
S
a
Order code
With subbase Without subbase
PRF-A12 PRF-A10
523
Parker Hannifin Corporation Pneumatic Division - Europe
