Connectors
AMPHENOL ICC BERGSTAK® SECURE CONNECTORS The BergStak® secure connector contains one-time-use and multi-times-use solutions. Both solutions have unique shield design to protect signal transmission. The 3 row contact design with 1mm pitch improves board surface utilisation by 20%. The family can support high-speed data transmission up to 32Gb/s. • EMI Shielding protects signals • 3 row contact design with 37 position per row to achieve the space-saving solution • Dual-beam receptacle contacts ensure more reliable connection • Blind-mating feature benefits to mating process • Modular design to support maximum 3 sets using together on one board
Features
Applications
• EMI shielding
• Communications
• Excellent protection of signals, no possible to probe. Suitable for the applications which need signal security
• Data
• High speed performance up to 32Gb/s
VIEW PRODUCT DETAILS
BUY NOW
• Can be used in high-end computing and signal transfer applications in data communication telecommunication, computing, medical technology and industrial automation segments
> BBU > Server/storage • Industrial and instrumentation > Factory automation
• Dual-beam receptacle contacts • Provides high electrical reliability and withstands high level of vibration • Blind-mating feature
SHOP NOW
• Suit for those tasks where visual and tactile tools are compromised during mating process • Modular design
SHOP NOW
AMPHENOL ICC COOL EDGE 0.8MM HIGH SPEED HYBRID CONNECTORS SHOP NOW
The 0.8mm pitch Double Density Cool Edge connectors and cable assemblies offer a compact design with 2 rows of contacts. This highly configurable single piece connector can accommodate both high speed and low speed signal and power. This hybrid connector reduces more than half of the PCB footprint when compared to 1mm PCIe Cool Edge. It supports PCIe Gen. 5 and is designed for multiple add-in-card thicknesses. • Provide options for 1.6mm and 2.36mm AIC • Hybrid configuration with differential, single-ended and power pin options • High speeds of up to 32GT/s (or 56GT/s PAM4) capability • Saves much more space than most of the cardedge connectors in market • 76 to 428 contacts
VIEW PRODUCT DETAILS
Features and benefits
Applications
• 0.8mm pitch
• Communications
• 2A per pin for power application
> Baseband
• 0.5A per pin for signal application
> Commercial systems
• Support high density hybrid applications
> Networking
• Signal pins options from 76 to 428
> Radio units
• Support maximum 70 lanes per connector
> High-end computing system
• Hybrid configurations • Allows flexible power-signal combinations
BUY NOW
• Accommodates 1.6mm and 2.36mm thick mating boards • Supports most of the standard AIC applications
SHOP NOW
SHOP NOW
• Optimised contact design to meet 32Gb/s • Meets next generation signal speed requirements 4
> Server and storage systems • Data > Server and storage systems > High-end computing system
