Page 1

VDLS 1.0 SERIES CATALOG 2020


Contents Intro 4

About VDLS 1.0

5

Highlight

6

Miniature Lighting Solution

Product Families 7-13

VLS

14-16

VLE

17-20

VLG

Other Components 22-23

Lighting Strips & Drivers


About us

WHO WE ARE VONN offers exceptional LED lighting creations, representing a fusion between innovative solutions and aesthetic vision. We are proud to present you with a wide range of residential and commercial LED lighting products. Our commitment to form, technology and precision defines our brand; we love what we do, and we deeply value our leadership position within the lighting industry.

OUR INSPIRATION We believe that it is in the pursuit of perfect form that we uncover the undercurrent of magic inherent to brilliant artistic expression. As a distinguished watchmaker will say, “Behind accuracy, lies precision”. We very much follow the same principle. Emphasis on design and function absolutely cannot stand short of quality. Simply stated- we pursue perfection and beauty while maintaining functionality and precision. By its very nature, LED represents innovation. However, at VONN, we set the bar much higher. We see the prestige beholden to precision and we’ve aligned our brand to it. Learn more about how we are defining new standards for the lighting industry at our website: VONN.com Thank you for taking the time to learn more about us.

One Canal Park, 3323 NE 163rd St PH-706, North Miami Beach, FL 33160 (888) 604-8666


VDLS 1.0

series

VDLS 1.0 is VONN’s miniature lighting product with >1” aluminum extrusions. The small size of the system is specially designed to be used in furniture systems such as wardrobes, cabinets and bookcases as well as commercial spaces. The series’ water resistance also allows it to be used in bathrooms and other humid environments as auxiliary lighting to customize a space.


Highlight

Dot-free light source produces perfect, homogeneous light

Multiple emission angles: 45째 , 90째 , 0-180째 or 0-90째 adjustable; customize your light scheme to your personal needs

The super slim and compact design allows profiles to be places anywhere

Several optional diffusers available, with different shapes and lighting distributions

Combined wire and pendant cables reduce visual clutter and allow for ease of installation


Miniature lighting solution DIFFUSER

C type

P type

EXTENDER F type

K type

7 type

L type

T type

180° Extender X type

END CAP

MOUNTING ACCESSORIES With hole

0-180°

90°

45°

0-90°

CONTROLLER PROFILE TYPE Sensor

Touch Slim

Thin

Recessed Bipolar Dimmer

Corner

Surface

Without hole


VLS0709

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing

Diffuser Material

Polycarbonate

Transmittance

>55%

Recommended LED Strip*

VD6120-24V-4mm (216.5 Lm/ft) VD6120-12V-4mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

5.2mm 0.20''

7.6mm 0.30'' L=(N×50mm)+(2×2mm)+15mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.59'' ➀;N=1…49;

9mm 0.35''

Profile Material

DIMENSIONAL DIAGRAM

7.6mm 0.30''

• •

Super narrow and thin. Applicable to small spaces. Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Screw-less close-fitting end cap.

9mm 0.35''

• • •

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.25”×H0.5”

Diffuser × 1

L8’2.5”×W0.25”×H0.25”

End Cap × 2

VEC-LS0709FSS L0.25”×W0.25”×H0.25”

18 54

-60°

-30°

90

60°

30°

INSTALLATION ACCESSORIES Mounting Clip

VCP-03 L0.5”×W0.5”×H0.25”

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS0709

2- FINISH S- Silver W- White B- Black

3- MOUNTING S- Surface R- Recessed

4- END CAPS L- Holeless End Cap

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLS0812

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing

Diffuser Material

Polycarbonate

Transmittance

>55%

Recommended LED Strip*

VD6120-24V-4mm (216.5 Lm/ft) VD6120-12V-4mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

5.2mm 0.20''

0.31'' L=(N×50mm)+(2×2mm)+10mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.39'' ➀;N=1…49;

12mm 0.47''

Profile Material

DIMENSIONAL DIAGRAM

10.4mm 0.41''

• •

Super narrow and thin. Applicable to small spaces. Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes.

12mm 0.47''

• • •

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.5”×H0.5”

Diffuser × 1

L8’2.5”×W0.25”×H0.25”

End Cap × 2

VEC-LS0812FSS L0.5”×W0.5”×H0.5”

End Cap w/hole × 2

42

-60°

-30°

70

60°

30°

VEC-LS0812FSD L0.5”×W0.5”×H0.5”

INSTALLATION ACCESSORIES Mounting Clip

14

VCP-03 L0.75”×W0.5”×H0.25”

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS0812

2- FINISH S- Silver

3- MOUNTING S- Surface R- Recessed

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLS1607

• •

Super slim. Applicable to a variety of small spaces. AL6063-T5 aluminum profile with excellent heat dissipation performance. German-imported polycarbonate diffuser. Optional fixed clips allow adjustment of luminaire angle.

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>60%

Recommended LED Strip*

VD6300-24V-8mm (345.7 Lm/ft) VD6300-12V-8mm (320.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

10.7mm 0.42''

5mm 0.20''

16mm 0.63'' L=(N×20mm)+(2×2mm)+8mm ➀;N=1…124; L=(N×0.79'')+(2×0.08'')+0.31'' ➀;N=1…124;

7mm 0.28''

Profile Material

DIMENSIONAL DIAGRAM

7mm 0.28''

• •

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.5”×H0.25”

Diffuser × 1

L8’2.5”×W0.5”×H0.25”

End Cap × 2

VEC-LS1607FSS L0.25”×W0.75”×H0.25”

End Cap w/hole × 2

VEC-LS1607FSD L0.25”×W0.75”×H0.25”

60 180

-60°

-30°

INSTALLATION ACCESSORIES Mounting Clip

VCP-04 0.75””×0.5”×0.25”

45º Mounting Clip

VCP-05 0.75”×0.5”×0.5”

0-180º Adjustable Mounting Clip

VCP-06 1.25”×0.75”×1”

0-90º Adjustable Mounting Clip

VCP-21 1”×1”×0.5”

300

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS1607

2- FINISH S- Silver W- White B- Black

3- MOUNTING S- Surface R- Recessed

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLS1613

• •

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>60%

Recommended LED Strip*

VD6120-24V-4mm (216.5 Lm/ft) VD6120-12V-4mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

12.4mm 0.49''

16mm 0.63'' L=(N×50mm)+(2×2mm)+8mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.31'' ➀;N=1…49;

13mm 0.51''

Profile Material

DIMENSIONAL DIAGRAM

10mm 0.39''

• •

Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes. Optional fixed clips for full light angle adjustment. Specialized smart controller.

13mm 0.51''

• •

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.75”×0.5”

Diffuser × 1

L8’2.5”×W0.5”×H0.25”

End Cap × 2

VEC-LS1613FSS L0.25”×W0.75”×0.5”

End Cap w/hole × 2

VEC-LS1613FSD L0.25”×W0.75”×0.5”

30 90

-60°

-30°

INSTALLATION ACCESSORIES Mounting Clip

VCP-04 0.75””×0.5”×0.25”

45º Mounting Clip

VCP-05 0.75”×0.5”×0.5”

0-180º Adjustable Mounting Clip

VCP-06 1.25”×0.75”×1”

0-90º Adjustable Mounting Clip

VCP-21 1”×1”×0.5”

150

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS1613

2- FINISH S- Silver W- White B- Black

3- MOUNTING S- Surface R- Recessed

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLS1612L

• •

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>85%

Recommended LED Strip*

VD6120-24V-8mm (216.5 Lm/ft) VD6120-12V-8mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

16mm

18mm

Profile Material

DIMENSIONAL DIAGRAM

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

10mm

2500mm

18mm

• •

Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes. Optional fixed clips for full light angle adjustment. Specialized smart controller.

12mm

• •

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.75”×0.5”

Diffuser × 1

L8’2.5”×W0.5”×H0.25”

End Cap × 2

VEC-LS1612LSS L16×W7×H18mm

End Cap w/hole × 2

VEC-LS1612LSD L16×W7×H18mm

60 180

-60°

INSTALLATION ACCESSORIES Mounting Clip

VCP-04 0.75””×0.5”×0.25”

45º Mounting Clip

VCP-05 0.75”×0.5”×0.5”

0-180º Adjustable Mounting Clip

VCP-06 1.25”×0.75”×1”

0-90º Adjustable Mounting Clip

VCP-21 1”×1”×0.5”

-30°

300

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS1612L

2- FINISH S- Silver W- White B- Black

3- MOUNTING S- Surface R- Recessed

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLS1911K

• • •

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>85%

Recommended LED Strip*

VD6280-24V-10mm (459.7 Lm/ft)

Recommended Driver**

VBSD-V24-065S

16.1mm 0.63''

19.7mm 0.78'' L=(N×50mm)+(2×2mm)+8mm ➀;N=1…49;

19.7mm 0.78''

Profile Material

DIMENSIONAL DIAGRAM

13.1mm 0.52''

Three-sided lighting source. Dot-free LED produces soft & homogeneous light. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Optional end caps with or without holes. Free & flexible connection.

19.7mm 0.78''

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS

-/+180° -150°

Profile × 1

L8’2.5”×W0.75”×H0.5”

Diffuser × 1

L8’2.5”×W0.75”×H0.5”

End Cap × 2

VEC-LS1911KSS L0.75”×W0.75”×H0.25”

End Cap w/hole × 2

VEC-LS1911KSD L0.75”×W0.75”×H0.25”

-120°

120°

0 50

-90°

Mounting Clip

VCP-07 L1.5”×W0.5”×H0.25”

Pendant Cable (w/Junction Box)

VPY-SSXX 6’6.75”/13’1.5”

Pendant Cable

VPN-SXX 6’6.75”/13’1.5”

Pendant Cable (Wire + Line in 1)

VPN-EAX 6’6.75”/13’1.5”

STANDARD EXTENDERS 180°, L-type, 7-type, T-type, X-type

90°

150

-60°

-30°

INSTALLATION ACCESSORIES

150°

60°

250

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS1911K

2- FINISH S- Silver W- White B- Black

3- MOUNTING P- Pendant S- Surface R- Recessed

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

VEX-E1, VEX-E2, VEX-E3, VEX-E4, VEX-E5

vonn.com


VLS1911C

• • •

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>85%

Recommended LED Strip*

VD6280-24V-10mm (459.7 Lm/ft)

Recommended Driver**

VBSD-V24-065S

16.1mm 0.63''

19.7mm 0.78'' L=(N×50mm)+(2×2mm)+8mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.31'' ➀;N=1…49;

19.6mm 0.77''

Profile Material

DIMENSIONAL DIAGRAM

13.1mm 0.52''

Domed lighting source. Dot-free LED produces soft & homogeneous light. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Optional end caps with or without holes. Free & flexible connection.

19.6mm 0.77''

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS

-/+180° -150°

Profile × 1

L8’2.5”×W0.75”×H0.5”

Diffuser × 1

L8’2.5”×W0.75”×H0.5”

End Cap × 2

VEC-LS1911CSS L0.75”×W0.75”×H0.25”m

End Cap w/hole × 2

VEC-LS1911CSD L0.75”×W0.75”×H0.25”m

-120°

120°

0 60

-90°

Mounting Clip

VCP-07 L1.5”×W0.5”×H0.25”

Pendant Cable (w/Junction Box)

VPY-SSXX 6’6.75”/13’1.5”

Pendant Cable

VPN-SXX 6’6.75”/13’1.5”

Pendant Cable (Wire + Line in 1)

VPN-EAX 6’6.75”/13’1.5”

STANDARD EXTENDERS 180°, L-type, 7-type, T-type, X-type

90°

180

-60°

-30°

INSTALLATION ACCESSORIES

150°

300

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLS1911C

2- FINISH S- Silver W- White B- Black

3- MOUNTING P- Pendant S- Surface R- Recessed

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

VEX-E1, VEX-E2, VEX-E3, VEX-E4, VEX-E5

vonn.com


VLE1212

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>55%

Recommended LED Strip*

VD6120-24V-4mm (216.5 Lm/ft) VD6120-12V-4mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

5.2mm 0.20''

12mm 0.47'' L=(N×50mm)+(2×4mm)+10mm ➀;N=1…49; L=(N×1.97'')+(2×0.16'')+0.39'' ➀;N=1…49;

12mm 0.47''

Profile Material

DIMENSIONAL DIAGRAM

10.4mm 0.41''

• •

Super narrow. Applicable to a variety of small spaces. Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes.

12mm 0.47''

• • •

4mm 0.16''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.5”×H0.5”

Diffuser × 1

L8’2.5”×W0.25”×H0.25”

End Cap × 2

VEC-LE1212FSS L0.5”×W0.5”×H0.25”

End Cap w/hole × 2

VEC-LE1212FSD L0.5”×W0.5”×H0.25”

14 42

-60°

-30°

INSTALLATION ACCESSORIES Mounting Clip

VCP-11 L1”×W0.5”×H0.5”

70

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLE1212

2- FINISH S- Silver W- White B- Black

3- MOUNTING T- Recessed w/ Trim

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLE2507 Super-slim recessed design. Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat Dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes.

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>60%

Recommended LED Strip*

VD6300-24V-8mm (345.7 Lm/ft) VD6300-12V-8mm (320.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

10.7mm 0.42''

5mm 0.20''

25mm 0.98''

L=(N×20mm)+(2×6mm)+8mm ➀;N=1…124; L=(N×0.79'')+(2×0.24'')+0.31'' ➀;N=1…124;

7mm 0.28''

Profile Material

DIMENSIONAL DIAGRAM

7mm 0.28''

• • • • • •

6mm 0.24''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W1”×H0.25”

Diffuser × 1

L8’2.5”×W0.5”×H0.25”

End Cap × 2

VEC-LE2507FSS L1”×W0.25”×H0.5”

End Cap w/hole × 2

VEC-LE2507FSD L1”×W0.25”×H0.5”

60 180

-60°

-30°

300

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLE2507

2- FINISH S- Silver W- White B- Black

3- MOUNTING T- Recessed w/ Trim

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLE2513

BASIC PARAMETERS AL6063-T5

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>60%

Recommended LED Strip*

VD6120-24V-8mm (216.5 Lm/ft) VD6120-12V-8mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

12.4mm 0.49''

25mm 0.98'' L=(N×50mm)+(2×6mm)+8mm ➀;N=1…49; L=(N×1.97'')+(2×0.24'')+0.31'' ➀;N=1…49;

13mm 0.51''

Profile Material

DIMENSIONAL DIAGRAM

10mm 0.39''

• •

Dot-free LED produces soft & homogeneous lighting. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes. Easy and efficient installation with recessed clips.

13mm 0.51''

• •

6mm 0.24''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W1”×H0.5”

Diffuser × 1

L8’2.5”×W0.5”×H0.25”

End Cap × 2

VEC-LE2513FSS L1”×W0.5”×H0.5”

End Cap w/hole × 2

EC-LE2513FSD L1”×W0.5”×H0.5”

30 90

-60°

-30°

INSTALLATION ACCESSORIES Mounting Clip

VCP-12 L1”×W1”×H0.5”

150

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLE2513

2- FINISH S- Silver W- White B- Black

3- MOUNTING T- Recessed w/ Trim

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLG1616C

• • •

Right-angle design to fit corners. Domed lighting source. Dot-free LED produces soft & homogeneous light. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes.

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>70%

Recommended LED Strip*

VD6120-24V-8mm (216.5 Lm/ft) VD6120-12V-8mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

''

Surface Processing

m

AL6063-T5

m .9 3 10 0. 4

Profile Material

DIMENSIONAL DIAGRAM

8 0. m m 31 ''

BASIC PARAMETERS

16mm 0.63''

• •

16mm 0.63''

16mm 0.63''

L=(N×50mm)+(2×2mm)+10mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.39'' ➀;N=1…49;

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.5”×H0.5”

Diffuser × 1

L8’2.5”×W0.75”×H0.25”

End Cap × 2

VEC-LG1616CSS L0.5”×W0.5”×H0.25”

-/+180° -150°

-120°

120°

0 30

-90°

-30°

150

60°

30°

VEC-LG1616CSD L0.5”×W0.5”×H0.25”

INSTALLATION ACCESSORIES Mounting Clip

90°

90

-60°

End Cap w/hole × 2

150°

VCP-13 L0.5”×W0.5”×H0.5”

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLG1616C

2- FINISH S- Silver W- White B- Black

3- MOUNTING C- Corner Mounted

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLG1616K

• • •

Right-angle design to fit corners. Double-sided lighting source. Dot-free LED produces soft & homogeneous light. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Close-fitting, screw-less design. Optional end caps with or without holes.

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>70%

Recommended LED Strip*

VD6120-24V-8mm (216.5 Lm/ft) VD6120-12V-8mm (195.1 Lm/ft)

Recommended Driver**

VBSD-V24-065S

0.

AL6063-T5

16mm 0.63''

16mm 0.63''

L=(N×50mm)+(2×2mm)+10mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.39'' ➀;N=1…49;

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS Profile × 1

L8’2.5”×W0.5”×H0.5”

Diffuser × 1

L8’2.5”×W0.5”×H0.5”

End Cap × 2

VEC-LG1616KSS L0.5”×W0.5”×H0.25”

-/+180° -150°

120°

0 19

90°

57

-60°

-30°

95

60°

30°

VEC-LG1616KSD L0.5”×W0.5”×H0.25”

INSTALLATION ACCESSORIES Mounting Clip

150°

-120°

-90°

End Cap w/hole × 2

m m ' .4 1' 15 0.6

Profile Material

DIMENSIONAL DIAGRAM

8m 31 m ''

BASIC PARAMETERS

16mm 0.63''

• •

VCP-13 L0.5”×W0.5”×H0.5”

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLG1616K

2- FINISH S- Silver W- White B- Black

3- MOUNTING C- Corned Mounted

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE G- 12V Flexible Strip F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLG3030C

• • •

Right-angle design to fit corners. Domed lighting source. Dot-free LED produces soft & homogeneous light. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Optional end caps with or without holes.

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>85%

Recommended LED Strip*

VD6280-24V-10mm (459.7 Lm/ft)

Recommended Driver**

VBSD-V24-065S

30mm 1.18'' L=(N×50mm)+(2×2mm)+10mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.39'' ➀;N=1…49;

30mm 1.18''

AL6063-T5

m m ' . 3 8' 2 2 0. 8

Profile Material

DIMENSIONAL DIAGRAM

15 .1 0. m 59 m ''

BASIC PARAMETERS

30mm 1.18''

• •

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS

-/+180° -150°

Profile × 1

L8’2.5”×W1.25”×H1.25”

Diffuser × 1

L8’2.5”×W1.25”×H1.25”

End Cap × 2

VEC-LG3030CSS L1.25”×W1.25”×H0.25”

End Cap w/hole × 2

VEC-LG3030CSD L1.25”×W1.25”×H0.25”

-120°

120°

0 60

-90°

Mounting Clip

VCP-14 1.25”×1.25”×0.5”

90°

180

-60°

-30°

INSTALLATION ACCESSORIES

150°

300

60°

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLG3030C

2- FINISH S- Silver W- White B- Black

3- MOUNTING C- Corner Mounted

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


VLG3030K

• • •

Right-angle design to fit corners. Double-sided lighting source. Dot-free LED produces soft & homogeneous light. AL6063-T5 aluminum profile with excellent heat dissipation performance. PC diffuser imported from Germany. Optional end caps with or without holes.

Surface Processing

Anodizing, Spraying RAL9003, Spraying RAL9005

Diffuser Material

Polycarbonate

Transmittance

>85%

Recommended LED Strip*

VD6280-24V-10mm (459.7 Lm/ft)

Recommended Driver**

VBSD-V24-065S

30mm 1.18'' L=(N×50mm)+(2×2mm)+10mm ➀;N=1…49; L=(N×1.97'')+(2×0.08'')+0.39'' ➀;N=1…49;

30mm 1.18''

AL6063-T5

m m ' .4 4' 31 1 . 2

Profile Material

DIMENSIONAL DIAGRAM

15 .1 0. m 59 m ''

BASIC PARAMETERS

30mm 1.18''

• •

2mm 0.08''

*Purchase of LED Strip is optional. Vonn recommends this LED strip for optimal performance. For more information, please refer to lighting source table at the end of this catalog. **Drivers are not included with this product and must be purchased separately. Vonn recommends the VBSD-V24-065S driver for this series. Dimming capabilities are based on drivers. For more information, please see the Drivers catalog.

PHOTOMETRIC OF 1M LUMINAIRES

PROFILE COMPONENTS

-/+180° -150°

Profile × 1

L8’2.5”×W1.25”×H1.25”

Diffuser × 1

L8’2.5”×W1.25”×H1.25”

End Cap × 2

VEC-LG3030KSS L1.25”×W1.25”×H0.25”

End Cap w/hole × 2

VEC-LG3030KSD L1.25”×W1.25”×H0.25”

-120°

120°

0 40

-90°

Mounting Clip

VCP-14 1.25”×1.25”×0.5”

90°

120

-60°

-30°

INSTALLATION ACCESSORIES

150°

60°

200

30°

ORDERING CODE Please select your customization choices from the following options, and send to VONN for ordering.

1- SKU VLG3030K

2- FINISH S- Silver W- White B- Black

3- MOUNTING C- Corner Mounted

4- END CAPS L- Holeless End Cap H- Single End w/Hole D- Double End w/Hole

5- LENGTH 2- 2' 4- 4' 6- 6' 8- 8'

6- LIGHT SOURCE F- 24V Flexible Strip

7- COLOR TEMP SW- 2700K WW- 3000K NW- 4000K W- 6000K

8- DRIVER J- 0-10V D- 3-in-1 Dimming N- Non-Dimming

9- VOLTAGE U- 100-277V Y- 120V

vonn.com


Other components

LIGHTING SOURCE Model

LEDs/m

Cutting Unit

120

3/25mm

12

120

6/50mm

24

120

3/25mm

12

120

6/50mm

24

120

3/10mm

12

VD6300-24V-8mm (345.7 Lm/ft)

120

6/20mm

24

VD6280-24V-10mm (459.7 Lm/ft)

120

14/50mm

24

VD6120-12V-4mm (195.1 Lm/ft)


12V+

12V+

12 V-

12V -

VD6120-24V-4mm (216.5 Lm/ft)

VD6120-12V-8mm (195.1 Lm/ft)

12V+

12V+

12 V-

12V -

VD6120-24V-8mm (216.5 Lm/ft)

VD6300-12V-8mm (320.1 Lm/ft)

Entry Cable

Voltage (DC)

12 V-

12 V-

DRIVER: LED LINEAR 3-IN-1 Model

VBSD-V24-065S


Input Voltage

Input Current

Output Voltage

Output Current

100-277V AC 50/60Hz

0.8A Max

24V DC

2.7A Max

vonn.com


E: FLEXIBLE STRIP Wattage

CCT

CRI

Lumens

Size

Suitable Profiles

8.6

2700 3000 4000 6000

>90

640

16’4”×0.15”×0.05”

LS0709 LS0812 LE1212

8.6

2700 3000 4000 6000

>90

710

16’4”×0.15”×0.05”

LS0709 LS0812 LE1212

8.6

2700 3000 4000 6000

16’4”×0.3”×0.05”

LS1613 LE2513 LG1616C LG1616K LS1612L

8.6

2700 3000 4000 6000

>90

710

16’4”×0.3”×0.05”

LS1613 LE2513 LG1616C LG1616K LS1612L

13

2700 3000 4000 6000

>90

1050

16’4”×0.3”×0.05”

LS1607 LE2507

13

2700 3000 4000 6000

>90

1134

16’4”×0.3”×0.05”

LS1607 LE2507

13

2700 3000 4000 6000

16’4”×0.4”×0.05”

LS1911K LS1911C LG3030C LG3030K

>90

640

>90

1508

1 DIMMING POWER SUPPLY Output Power

65W

Power Factor

>0.95

Power Efficiency

88%

Size

Suitable Profiles

13.6” × 1.18” × 0.92”

VLS0709 VLS0812 VLS1607 VLS1613 VLS1911K VLS1911C VLE1212 VLE2507 VLE2513 VLG1616C VLG1616K VLG3030C VLG3030K

vonn.com


Profile for VonnLighting

VONN - VDLS 1.0 Series Catalog
