1” DRIVE TOOLS
FLANK DRIVE® IMPACT SOCKETS RH
MB
Deep, mm Dimension
30 32 33 38 70
SIMM303
SIMM303 SIMM323 SIMM333 SIMM383 SIMM703
A
, Dia., inches
Dimension
46.0 52.3 52.3 60.3 97.61
B
, Head Width, inches
Dimension
53.7 53.7 53.7 57.2 60.45
C
, Head Length, inches
Dimension
46.0 76.2 53.3 59.7 95.45
D
, Length, inches
Dimension
76.2 82.6 82.5 88.9 127
E
, Hex Depth, inches
19.1 22.4 22.4 25.4 43.69
MB
Shallow Thin Wall, mm Dimension
IMM553TW 55 IMM705TW* 70 *Conventional hex.
IMM553TW
A
, Dia., inches
Dimension
75.9 91.2
B
, Head Width, inches
Dimension
60.5 82.6
C
, Head Length, inches
53.8 67.5
Dimension
D
, Length, inches
88.9 114.3
Dimension
E
, Hex Depth, inches
34.8 44.3
IMM705TW
SPECIAL APPLICATION IMPACT SOCKETS RH
Single Square/Shallow, inches Dimension
IM724 3/4 IM726 13/16 IM728 7/8 IM730* 15/16 IM732 1 IM736 1-1/8 * Budd Wheel applications
IM724
A
, Dia., inches
Dimension
1-15/16 1-15/16 2-1/16 2-1/16 2-1/8 2-1/4
B
, Head Width, inches
Dimension
2-1/8 2-1/8 2-1/8 2-1/8 2-1/8 2-1/4
C
, Head Length, inches
31/32 31/32 31/32 15/16 1-3/32 1-3/32
Dimension
D
, Length, inches
2-1/8 2-1/8 2-1/8 2-1/8 2-1/4 2-1/4
Dimension
E
, Hex Depth, inches
21/32 21/32 21/32 5/8 25/32 25/32
MB
Double Square/Shallow, inches Dimension
1-1/4
IM740
A
, Dia., inches
2-3/8
Dimension
B
, Head Width, inches
Dimension
2-3/8
C
, Head Length, inches
1-1/8
Dimension
D
, Length, inches
2-3/8
Dimension
E
, Hex Depth, inches
13/16
IM740
1-1/2" DRIVE HANDLES MB
Sliding T-Handle, Industial (1-1/2") Stock No.
L55
250 Snapon.com 1.877.762.7664
L55
Dimension
A
, Dia., inches
2-7/8
Dimension
B
, Head Width, inches
4-1/16
Dimension
C
, Head Length, inches
36
Handle Stock No. L55-1
Sliding Head Only Stock No. L55-2
