10 REASONS SELF-BUILDERS SHOULD BUILD WITH AIRCRETE THERMAL BLOCKS Building with Aircrete blocks is on the rise in Ireland, and the outlook tells us demand will continue to grow both nationally and globally, with recently published research forecasting the continued surge of the autoclaved aerated concrete market: “Rising demand for sustainable building materials and eco-friendly nature of AAC material are key factors driving industry growth,” says Emergen Research.

1 SUPERIOR COMFORT There is no substitute for a comfortable home, and with self-builders usually planning to build their forever home, comfort is top of the priorities list for many.

2 REDUCED ENERGY BILLS Reduced energy usage means reduced energy bills – perfect for every self-builder! It’s all down to the unique properties of Aircrete and their superior thermal performance.

3 THERMAL PERFORMANCE Aircrete blocks offer superb thermal performance, insulating up to ten times better than dense concrete blocks. With the walls of the house traditionally the biggest source of heat loss, the blocks can significantly reduce this and easily achieve better U-Values whilst maintaining an optimal thermal mass.

The blocks’ thermal performance is undoubtedly one of its most appealing properties for self-builders.

4 ELIMINATES DAMP & MOULD RISK It’s unsightly and unhealthy, and quite frankly, damp and mould should not be a problem in modern homes, but unless you deal effectively with the potential cold spots in your new build, it can still be a risk. With Aircrete, the risk is eliminated.

5 SUPERIOR FIRE PERFORMANCE Aircrete blocks far outperform some of the other alternatives on the market when it comes to fire performance, with timber frame only providing 30 minutes fire resistance and Aircrete up to 4 hours for the 215mm block and 2 hours for the 100mm block.

6 FASTER HEATING RESPONSE Aircrete walls respond quicker when heating is turned on. So rooms heat faster and the heating is on for a shorter period with less energy usage.

7

9

SUSTAINABLE SOLUTION

INTERNATIONAL BEST PRACTICE

Made from up to 80% recycled materials, an A+ Green Guide rating and one of the first construction products to have an Environmental Product Declaration published by the Irish Green Building Council. But it’s not just the block that’s more sustainable, it’s the home you build. Aircrete’s superior performance means selfbuilders can build a much more energy efficient home, with passive house or net zero standards much easier to achieve.

Aircrete is tried and tested as a strong and durable construction material.

It’s been established for decades as the material of choice in wall construction in countries right across Europe and beyond, including Germany, Italy, France, the Netherlands, Poland and the UK.

10 COST EFFECTIVE

8 REDUCE HEAT LOSS THROUGH THERMAL BRIDGING Aircrete reduces heat loss through thermal bridging by up to 80%. As thermal bridging occurs at every junction where there is a break in the insulation fabric, it is one of the largest sources of heat loss and important to address correctly.

Aircrete built is not only better built, but also a very cost-effective way to achieve a superior home.

For example, the cost of upgrading from using Aircrete in all key junctions of a house to building the entire inner leaf with Aircrete is typically only a very small percentage of the overall build cost.

This is then offset quickly by the resulting energy savings, and well worth it for the added performance benefits. In many cases the net result can be cost neutral.

Visit SelfBuildWithMannok.com for more on building with Aircrete and our tailored self-build packages.
