3582 and 3583 Series Table 1. Specifications for 3582 Series and Type 3582i Valve Positioners (Continued)
Pressure Gauges
Maximum Valve Stem Travel
1-1/2 inch (40 mm) diameter with plastic case and brass connection ! triple scale (PSI, MPa, and bar) or ! dual scale (PSI and kg/cm2)
4-1/8 inches (105 mm); adjustable to obtain lesser travels with standard input signals Characterized Cams
Pressure Connections
See characterized cams section
1/4-inch NPT female Approximate Weight Electrical Connection for Type 3582i
3582 Series Units: 5-1/2 pounds (2.5 kg) Type 3582i: 8 pounds (3.6 kg)
1/2-14 NPT conduit connection
1. This term is defined in ISA Standard S51.1-1979. 2. Do not exceed any of the pressure or temperature limits in this instruction manual. Also, any applicable standard or code should not be exceeded. 3. Scfh—Standard cubic feet per hour (60 F and 14.7 psia); normal m3/hr—normal cubic meters per hour (0 C and 1.01325 bar, absolute).
11B5625-E SHT B / DOC 13B8758-C SHT 1 / DOC
! ! !
! ! !
Figure 2. Typical Nameplates
Type 3582A—Pneumatic valve positioner without bypass and without pressure gauges.
Type 582i—Electro-pneumatic converter with: supply and output pressure gauges, automotive tire valves, or pipe plugs. Used for conversion of a 4 to 20 milliampere input signal to a 3 to 15 psig (0.2 to 1.0 bar) input signal for the pneumatic valve positioner.
Type 3582C—Pneumatic valve positioner without bypass and with automotive tire valves instead of pressure gauges.
Type 3583—Pneumatic valve stem position transmitter with supply and output pressure gauges.
Type 3582D—Pneumatic valve positioner with bypass and with automotive tire valves instead of pressure gauges.
Type 3583C—Similar to the Type 3583 valve stem position transmitter except with automotive tire valves in place of pressure gauges.
Type 3582—Pneumatic valve positioner with bypass and instrument, supply, and output pressure gauges.
Type 3582G—Pneumatic valve positioner without bypass and with instrument, supply, and output pressure gauges. Type 3582NS—Pneumatic valve positioner for nuclear service applications with or without bypass and with automotive tire valves instead of pressure gauges. Type 3582i—Electro-pneumatic valve positioner without bypass; with Type 582i converter; and with: supply and output pressure gauges, automotive tire valves, or pipe plugs.
4
Specifications Specifications for the valve positioners are shown in table 1. Specifications for the valve stem position transmitters are shown in table 2. Refer to the unit nameplate to determine the type of positioner or transmitter, supply pressure, etc. A typical nameplate is shown in figure 2.
