Tracks & profiles Galvanised track 35 x 30 mm - 3 m long
80
11205 11210
Ditto - 4 m long Ditto - 6 m long
11505
Galvanised track 50 x 40 mm - 3 m long
150
11211 11510
Ditto - 4 m long Ditto - 6 m long
11805
Galvanised track 62 x 55 mm - 3 m long
300
11511 11810
see dimensions on p. 4
TUBULAR TRACKS Item Nr Description
Ditto - 4 m long. Ditto - 6 m long
12105
Galvanised track (High Limit of Elasticity steel) 85 x 70 mm - 3 m long
12110
500
11809
12112
Ditto - 4 m length. Ditto - 6 m length.
BR CURVES FOR TUBULAR TRACK 11390 11710 11990 12335
Curve for galvanised track 35 x 30 mm, Radius = 500 mm. Curve for galvanised track50 x 40 mm, Radius = 600 mm. Curve for galvanised track 62 x 55 mm, Radius = 800 mm. Curve for galvanised track 85 x 70 mm, Radius = 1000 mm.
GUIDING PROFILES 12703
Galvanised U profile 25 x 17 mm- 3 m long.
12705
Ditto - 4 m long.
12710
Ditto - 6 m long.
12605
Galvanised U profile 30 x 30 mm - 3 m long.
12610
Ditto - 4 m long.
12615
Ditto - 6 m long.
12930
Galvanised U profile 50 x 60 mm - 6 m long.
GUIDING CURVES 12650 12655 12660
Galvanised curve for U profile 30 x 30 mm, Radius = 600 mm. galvanised curve for U profile 30 x 30 mm, Radius = 800 mm. Galvanised curve for U profile 30 x 30 mm, Radius = 1000 mm.
OR
RAIL
80
150
300
500
Buffer
11255
11560
11875
12185
80-150/7R
300-500/7R
The capacities are indicated for a manual operation. In case of automatic operation, the capacity must be divided by 2. Check the dimensions and particularly the opening dimension. If this dimension is not correct, adjust the track by narrowing or widening its sides. Jointing two tracks can weaken an installation : it is essential to use jointing brackets (see on p.19-20) in order to insure perfect assembly, without track disalignement. Welding has to be excluded.
16
Before the use of the doors, it is recommended that the inside of the tracks be correctly cleaned and greased with bodied oil. To avoid any faulty sliding of the door, it is necessary to grease the inside of the tracks at least every 6 months.
