Medium/Heavy Forming
Typical He-Bolt Anchors These Dayton Superior anchors are effectively used in conjunction with the D40 He-Bolt to anchor cantilever forms. The B18 Single Flared Coil Loop Insert is recommended for 5' lifts, the B33 Double Flared Coil Loop Insert is recommended for 5' to 7-1/2' lifts and the B43 Triple Flared Coil Loop Insert is recommended for 7-1/2' to 10' lifts. • See B18 Single Flared Coil Loop Insert. B18 Single Flared Coil Loop Insert
B33 Double Flared Coil Loop Insert
B43 Triple Flared Coil Loop Insert
• See B33 Double Flared Coil Loop Insert. • See B43 Triple Flared Coil Loop Insert.
To Order: Specify: (1) quantity, (2) name, (3) bolt diameter, (4) length, (5) safe working load, (6) finish (plain or Electroplated). Example: 450 pcs. B18 Single Flared Coil Loop, 1" x 9" long, 9,500 lbs. SWL, plain.
Special He-Bolt Inserts Medium/Heavy Forming Products
Special inserts can be manufactured to meet your unusual forming requirements. Please contact a Dayton Superior Technical Service Department with your requirements. Several special inserts that have been developed are shown below.
B34-4 Four Strut
B7 Two Strut B22 Four Strut
Four Strut Draped Insert
D42 Bag Ties Dayton Superior Bag Ties (D42) are 16 gauge, annealed loop-ended wire ties used for tying rebar and other non-construction applications, such as bags and carpet rolls. D42 Bag Ties are available in 4", 5", 6", 7", 8", 10" and 12" lengths. Other lengths and gauges are available on special order. D42 Bag Ties are sold by the bag or pallet only. 4" through 8" lengths are packaged in coils of 1,000 pieces, five coils per bag (5,000 pcs.). 10" and 12" lengths are packaged 2,500 pieces per bag.
To Order: Specify: (1) quantity, (2) name.
D42 Bag Ties
Example: 5 bags (25,000 pcs.), D42 Bag Ties.
72
12/15
