SlabDrain - H100/CSD
System layout
Cross Sidewalk Drain (CSD) CSD is a cross sidewalk drainage system which has a polymer concrete curb unit, that is cast into the curb line, to allow water from the H100K-8 or H100KS-8 SlabDrain to discharge into the road. A down spout inlet, also manufactured from polymer concrete, allows rainwater down spouts to drain into the channel.
Removable grates
Constant depth channels Closing cap Bottom knockout H100-8/H100-10 - 4”
BUILDING
Closing cap 3.94” (100mm) 2.56” (65mm), or 3.35” (85mm)
3.15” (80mm), or 3.97” (100mm)
SIDEWALK
6.10” (155mm)
6.10” (155mm)
3.15” (80mm), or 3.97” (100mm)
3.54” (90mm)
1.37” (35mm)
7.87” (200mm)
39.37" (1 meter)
ROAD
3.95” (100mm)
H100-8/10 channel
Down spout inlet
H100K-8 channel
Curb outlet
A
D
H100-8 & H100-10 Parts list
Part
Invert Depth
Overall Depth
Volume
Weight
mm
Gallons
lbs
3.15
80
1.16
20.0
3.95
100
1.70
25.0
-
3.15
80
-
1.0
-
-
3.95
100
-
1.0
-
-
-
-
-
0.2
-
-
-
-
-
0.3
No.
inches
mm
inches
H100-8 constant depth channel - 39.37” (1m)
00985
2.56
65
H100-10 constant depth channel - 39.37” (1m)
00549
3.35
85
H100-8 polymer concrete closing cap
05935
-
H100-10 polymer concrete closing cap
05939
Debris strainer for 4” bottom KO
93488
Grate removal tool
01318
CSD Parts list
Part
Invert Depth
Overall Depth
Weight
No.
inches
mm
inches
mm
lbs
Curb outlet - type 6 profile
96924
3.5
90
7.87
200
12.7
Down spout inlet
96932
3.2
82
3.95
100
6.0
Notes: 1. For use with H100K-8 or H100KS-8 channels only - see page 102-103 for details.
Notes: 1. See page 32 for details on suitable QuickLok™ grates, max. load Class C (56,000lb - 280psi). 2. Use grate removal tool to remove grates (Part #01318). 3. Debris strainer details for 4” dia. outlet on page 103. Use with 494Q (97393) or 495Q (97385) grates for non-metallic, non-locking drainage option - see ACO Sport brochure.
Outlet flow rates Outlet Product A A
Bottom outlet - H100-8 Bottom outlet - H100-10
Size Invert GPM (Sch 40) in. 4” round 4” round
2.56 3.35
87 99
CFS 0.20 0.23
Note: These are pipe flow rates at specified outlet, NOT channel flow rates.
