AVAILABLE SKUs SAMSUNG XCOVER6 PRO SOLUTIONS
3
RAM-GDS-SKIN-SAM84 IntelliSkin® for Samsung Galaxy XCover6 Pro
RAM-SKIN-SAM84
RAM® Skin™ for Samsung Galaxy XCover6 Pro
RAM-HOL-SAM84CP-1U EZ-Roll’r™ Powered Dock for XCover6 Pro with OEM or RAM® Skin™
4
RAM-HOL-SAM84PU ® EZ-Roll’r™ Powered Dock for Samsung XCover6 Pro without Case
PRIMARY MARKETS
RAM-DOCK-6G-SAM84CPU
RAM® 6-Port Charging Dock for Samsung XCover6 Pro with OEM or RAM® Skin™
6
RAM-DOCK-6G-SAM84PU
RAM® 6-Port Charging Dock for Samsung XCover6 Pro without Case
1
2
5
PUBLIC SAFETY & FIELD SERVICE WAREHOUSING & MANUFACTURING CONSTRUCTION
Patented & Pats. Pend. rammount.com/ip
SAMSUNG XCOVER6 PRO SOLUTIONS
FEATURES
INTELLISKIN® FOR SAMSUNG GALAXY XCOVER6 PRO
Includes built-in belt clip adapter
GDS® Ecosystem™ Compatible
Compatible with complete GDS® Ecosystem™
Drop Protection
IntelliSkin® sleeves are MIL-STD-810G drop protection certified.
Docking Contacts
Molded ruggedized docking contacts on the exterior of the skin are designed for repetitive docking in field applications
RAM® EZ-ROLL’R™ POWERED DOCK FOR SAMSUNG XCOVER6 PRO WITH or WITHOUT SMART CASE
RAM® SKIN™ FOR SAMSUNG XCOVER6 PRO
Form-Fitting Design
RAM® EZ-Roll’r™ powered dock perfectly secures the Samsung Galaxy XCover6 Pro
Pogo Pins
When connected to a power source, two integrated pogo pins provides charging capabilities to the device
Buttons & Cameras Exposed
RAM® EZ-Roll’r™ powered dock leaves the device’s buttons & cameras exposed and usable
Modular Mounting with RAM® Compatibility
Mount your vehicle dock anywhere with any B or C sized components via the 2-Hole AMPS hole pattern located on the back of the mount
RAM® 6-PORT CHARGING DOCK FOR SAMSUNG XCOVER6 PRO WITH or WITHOUT CASE
6-Port Charging Dock
Charges up to six Samsung Galaxy XCover6 Pros simultaneously, two models available for fleets deployed with or without cases
Pogo Pins
When connected to a power source, integrated pogo pins provide power to the device
USB Type-A Male Pigtail
Includes a USB Type-A male pigtail for power
LED Indicators
Red and green LED lights indicate charging status. Red means the charging bay is ready to charge a device and green means the device is docked and charging
With
Without Case
Case
Built-In Belt Clip Adapter
Built-In Belt Clip Adapter
Patented & Pats. Pend. rammount.com/ip
Includes built-in belt clip adapter
SPECS SAMSUNG XCOVER6 PRO SOLUTIONS
SPECS RAM-GDS-SKIN-SAM84 RAM-SKIN-SAM84 RAM-HOL-SAM84CPRAM-HOL-SAM84PU RAM-DOCK-6G-SAM84CPU RAM-DOCK-6G-SAM84PU Hardware Included (1) Belt Clip (1) Belt Clip
Materials TPU TPU High Strength Composite High Strength Composite Output Voltage 5V @2A 5V @2A (per port) Power Output 10W 60W total Input Connector USB Type-A Male Wall power cord Input Cable Length 1.2 meters 1.5 meters Compliance Meets MIL-STD-810H Drop Test Standards Meets MIL-STD-810H Drop Test Standards Made from ABS/PC-V0, conforms to UL 94-V0 flammability tests Made from ABS/PC-V0, conforms to UL 94-V0 flammability tests Warranty 3 years Lifetime 3 years 3 years Case Compatibility RAM® Skin™ or Samsung Smart Case RAM® Skin™ or Samsung Smart Case Dimensions H: 7.53” W: 3.38” D: 0.63” H: 6.88” W: 3.36” D: 0.62” W H: 7.88” W: 3.63” D: 1.63” WO H: 7.75” W: 3.38” D: 1.38” W H: 2.03” W: 11.87” D: 4.07” WO H: 2.16” W: 11.87” D: 4.07” INTELLISKIN® RAM® EZ-ROLL’R™ POWERED DOCK WITH or WITHOUT CASE RAM® 6-PORT CHARGING DOCK WITH or WITHOUT CASE RAM® SKIN™ With Case With Case Without Case Without Case Patented & Pats. Pend. rammount.com/ip
(2) #8-32 X 5/8” Machine Screws (2) #8-32 Nylock Nuts
SAMSUNG XCOVER6 PRO SOLUTIONS
GDS® ECOSYSTEM™
COMPATIBLE CHARGERS FOR RAM® EZ-ROLL’R™ POWERED DOCK FOR SAMSUNG XCOVER6 PRO WITH OR WITHOUT SMART CASE
RAM-GDS-CHARGE-V7B1U
GDS® Modular 10-30V
Hardwire Charger with Female USB Type-A Connector
RAM-GDS-CHARGE-CIGC
GDS® Type-C and Type-A 2-Port Cigarette Charger
RAM-GDS-CHARGE-USBC2W
GDS® Type-C and Type-A 48W
Premium 2-Port Wall Charger
RAM-GDS-CHARGE-USB2QCCIG
GDS® 2-Port USB Cigarette Charger with Qualcomm® Quick Charge™
COMPATIBLE PRODUCTS FOR THE INTELLISKIN® FOR SAMSUNG GALAXY XCOVER6 PRO
RAM-GDS-CHARGE-USB2W
GDS® 2-Port USB Wall Charger
GDS® Intelligent 6-port USB Charger
RAM-GDS-DOCK-D7U
GDS® Desktop Dock with Power Delivery
RAM-GDS-DOCK-D7AU
GDS® Desktop Dock with Power Delivery & Peripheral Port
RAM-GDS-HS4U
GDS® Hand Strap for XCover6 Pro with IntelliSkin® or RAM® Skin™
RAM-GDS-DOCK-V3CPAU
GDS® Vehicle Dock for Samsung XCover6 Pro with IntelliSkin®
RAM-GDS-DOCK-V11CU
GDS® Vehicle Handheld PC Dock with USB Type-C for IntelliSkin® Products
RAM-GDS-AD3CMU
GDS® Snap-Con™ GDS® to Power Delivery USB Type-C Adapter
RAM-GDS-BRUSH-01U
IntelliSkin® Contact Brush
RAM-GDS-STU GDS® Wrist Strap
RAM-GDS-HS4MU
GDS® Magnetic Hand Strap for XCover6 Pro with IntelliSkin® or RAM® Skin™
Patented & Pats. Pend. rammount.com/ip
RAM-B-166U
RAM® Twist-Lock™ Suction Cup Double Ball Mount
SAMSUNG XCOVER6 PRO SOLUTIONS
COMPATIBLE RAM®
MOUNTS
RAP-B-378-238U
RAM® Flex Adhesive Double Ball Mount with Diamond Plate
RAP-B-299-4-238U
RAM® Stubby™ Cup Holder Mount with Diamond Plate
RAM-B-138U
RAM® Double Ball Drill-Down Mount with Diamond Plate
RAP-SB-180U
RAM® Lil Buddy™ Adhesive Dash Mount with Diamond Plate
RAM-B-408-112-15-A-238U
RAM® Torque™ Large Rail Base with Diamond Plate
RAM-B-149ZU
RAM® Handlebar U-Bolt Double Ball Mount
RAP-B-400-238U
RAM® Tough-Claw™
Small Clamp Mount with Diamond Plate
RAM-B-149ZU-A
RAM® Handlebar U-Bolt Double Ball Mount
Patented & Pats. Pend. rammount.com/ip
