ABOUT JE PISTONS

JE Pistons opened its doors for business in 1947 with one simple objective, to supply the racing community with the highest quality pistons and components available in the marketplace. Although times, Although people and equipment have changed over time, our objectives and goals have remained constant. Today, JE is the largest manufacturer of custom forged racing pistons in the world. Offering the shortest lead times in the industry and a 98% order fill rate, JE is the definitive source for all of your high performance needs.

The JE complex encompasses the most modern performance piston manufacturing equipment in the industry. JE’s implementation of the most advanced CNC machining technologies available emphasizes our commitment to deliver the highest quality pistons, pins, rings and components available today. Industry leading processes like Ultra Crown®‚ a digital three-dimensional piston crown machining process, and Ultra Groove®‚ a machining operation that provides unprecedented flatness of ring grooves (tolerances to within millionths of an inch), are some examples of that commitment.

Our fully staffed, climate controlled QC (Quality Control) department utilizes the latest equipment to ensure expectation exceeding, consistent quality. F.E.A. (Finite Element Analysis), which predicts the thermal and structural stresses a piston will experience before it goes into service, enables JE to test and race-simulate our product before it ever sees a racetrack. Furthermore, the lessons we learn through our involvement in racing series like NASCAR, IndyCar, NHRA and many others, translate directly into the high quality, precision custom and shelf parts that we offer to you, our customer.

Our investment in technology and equipment is an investment in our future as well as our customers’. We preserve that investment by remaining committed to the philosophy of our founders; JE Pistons will always provide superior parts. Developed through extensive research, employing the latest high-tech manufacturing procedures and quality control.

THE MOST FULLY FEATURED

Easily find our Ultra Series listings highlighted in gold =

FEATURING

ALIGNED GRAIN FLOW TECHNOLOGY

Ultra Series combines all our premium features and a revolutionary new forging technology into an off-the-shelf piston kit! This includes an Aligned Grain Flow Forging, a proprietary JE technology that aligns forging grain flow in critical areas to improve strength

• Designed for Power: Every feature on Ultra Series Pistons are optimized to perform flawlessly in high high-horsepower racing engines. This includes lateral gas ports, thicker ring lands, and dual pin oiling.

• Aligned Grain Flow Forging: Exclusively available on JE Ultra Series, these optimized 2618 alloy forgings offer added strength over traditional 2618 forgings.

• “Perfect Skirt” Coating: This patented skirt coating reduces friction and provides a tighter clearance that eliminates cold-start slap and false knock on computer-controlled engines.

• Thermal Barrier Crown Coating: This ceramic-based coating reflects heat into the combustion chamber, therefore reducing piston crown temperatures and improving exhaust gas scavenging.

• 9310 Alloy Wrist Pins: These high strength, premium thick wall wrist pins are manufactured by Trend Performance in the USA.

• Ultra Series technology has been expanded into Powersports with specially designed UTV and Sport Bike applications

NOTICE: Due to the nature of performance applications, all JE Products are sold without any expressed warranty or any implied warranty of merchantability or fitness for a particular purpose. JE Pistons shall not, under any circumstances, be liable for any special, incidental or consequential damages, including, but not limited to, damages or loss of other property or equipment, loss of profits or revenue, cost of purchased or replacement goods, or claims of customers of the purchaser which may arise and/or result from the sale, installation or use of these parts. JE Pistons reserves the right to make product improvements and changes without notice and without incurring liability with respect to similar products previously manufactured.

All parts shipped F.O.B. our location. All parts are not legal for sale on pollution controlled motor vehicles. All trademarks, names or logos are property of their respective companies.

WARNING

This product contains chemicals known to the State of California to cause cancer and reproductive harm. www.P65Warnings.ca.gov

WHAT’S NEW WHAT’S NEW

ULTRA SERIES 3.5L ECOBOOST

Engineered specifically for the increasingly popular EcoBoost platform and field proven through engine builders making four-digit horsepower, JE’s Ultra Series pistons for Gen I & Gen II 3.5L EcoBoost applications utilize our proprietary Aligned Grain Flow technology for a custom-level performance package available off the shelf.

• Piston crown designed and machined to retain optimal direct injection function, yet still achieve a 10.0:1 compression ratio

• Aligned Grain Flow forging process done in-house in the USA provides unmatched tensile strength characteristics, perfect for high-horsepower builds

• Thermal Barrier Ceramic crown coating reflects heat and protects piston crown from potential damages of excess combustion temperatures

• Perfect Skirt coating reduces operating friction and noise

• Lateral gas ports paired with 1.0mm x 1.2mm x 2.8mm ring package promote power through consistent ring seal

• Supplied with robust, 9310 steel, .210” wall wrist pins and available in standard, .015” overbore and .025” overbore bore size options

BMW / TOYOTA SUPRA B58B30

JE’s latest boost-ready pistons are ready for battle in Toyota Supra and BMW B58B30 engine platforms, available in standard and overbore sizes with a 10.5:1 compression ratio.

• Constructed of forged 2618 aluminum with Forged Side Relief design to optimize strength-to-weight ratio

• Equipped with skirt coating and double-broach pin oilers to help deliver reliable performance through reduced friction and improved wear resistance

• Accumulator grooves minimizes combustion pressures below the top ring for improved, consistent ring seal

• Included 1.2mm PVD top x 1.2mm Napier second x 2.0mm PVD oil ring package

• Offset wrist pin helps reduce piston knock and operating noise

20 & 24-DEGREE

BIG BLOCK

CHEVY

We purpose-built the new 20° and 24° BBC pistons for the drag strip, packing our most advanced, custom-level features into an off-the-shelf, competitively priced package. These slugs are designed to work with the majority of 20° and 24° BBC cylinder heads on the market, utilize a robust .043” steel top, .043” ductile iron Napier second, and 3mm oil ring pack, and are available in a range of bore sizes from 4.600” to 4.625”.

• Engineered, forged, and machined in-house in the USA using 2618-T6 aluminum

• Contact reduction grooves reduce operating friction and minimize pressure, promoting more power

• 3D undercrown milling for weight optimization

• Optimized dome design with fire slot for improved flame travel and combustion efficiency

13-DEGREE SMALL BLOCK CHEVY

Another addition to JE’s strong lineup of circle track pistons is our all-new, 13-degree small block Chevy design. We worked closely with engine builders to design a dome and valve pocket profile that fits almost all aftermarket 13° SBC cylinder heads on the market.

• Vertical gas ports help provide strong and consistent top ring seal

• Contact reduction grooves reduce operating friction and minimize pressure, promoting more power

• Power-adder accumulator groove traps excess gases to help prevent ring flutter, aiding in consistent ring seal and power delivery

• Double pin oiling with broaches maximizes wrist pin and pin bore lubrication, improving longevity through reduced friction

• Ultra-groove ring groove operation provides unmatched surface flatness, promoting consistent ring seal

• Specially designed dome and pocket profile to fit many aftermarket SBC 13° cylinder heads

ASCS 360 & LIGHTWEIGHT 2-BARREL FLAT TOP

Purpose-designed specifically for the demands of IMCA/USRA and ASCS racing, JE’s 2-Barrel Lightweight Flat Top and ASCS 360 piston lineups offer race-focused engineering and features with off-the-shelf availability.

• 2-Barrel features an extremely lightweight (383g) design with strut lightening holes for maximized off-the-corner acceleration and improved windage

• ASCS 360 features a specially designed skirt shape to reduce piston rock at TDC and BDC, improving ring seal

• Strong and durable .220” minimum valve pocket thickness and 14.2cc dome with .330” intake pocket design on ASCS 360 series accommodates many popular racing cylinder head chamber designs

• Both series equipped with contact reduction grooves, accumulator groove and double pin oiling for minimized combustion pressure to provide consistent ring seal and improved pin and pin bore longevity through reduced friction

• 2-Barrel and ASCS series designed for robust .043” x .043” x 3.0mm ring package

PISTON TERMINOLOGY

PISTON DECK

STD OIL DRAIN BACK HOLES

SPLIT OIL DRAIN BACK HOLES

SIDE RELIEF

WRIST PIN HOLE/ PIN DIA.

PICK LOCK GROOVE (AVAILABLE FOR WIRE LOCKS)

LOCK GROOVE SLIPPER THICKNESS

COMPRESSION HEIGHT/DISTANCE

DOME HEIGHT

TOP LAND

TOP RING GROOVE

SECOND LAND

SECOND RING GROOVE

THIRD LAND

OIL RING GROOVE

FORCED PIN OILER (CENTERED OR SPLIT) SINGLE OR DOUBLE

SKIRT

BOTTOM BAND

TANG

VALVE POCKET DEPTH MEASURED VERTICALLY FROM THE DECK TO THE DEEPEST PART OF THE VALVE RELIEF RADIUS

VALVE ANGLE

GAUGE POINT (.500” STD, .275” WHEN SPECIFIED)

PIN BORE CENTER

SHELF PISTON TERMINOLOGY

With over 300 individual forgings to choose from, JE is able to achieve specific piston design requirements while reducing overall weight.

HONED PIN BORES

RADIUSED VALVE RELIEFS

SMOOTH RADIUSED DOME AND DISH DESIGNS

PRECISION CNC

MACHINED RING GROOVES

2618 LOW-SILICON MATERIAL

SIDE RELIEF AVAILABLE FULLY MACHINED WITH LOWER SUPPORT BAND OR AS FORGED.

MACHINED OIL

DRAIN BACK HOLES ENGINEERED FOR SPECIFIC OIL CONTROL

SHELF PISTON TERMINOLOGY

DIAMOND TURNED SKIRTS

FSR (Forged Side Relief) forging designs feature a reduced skirt width and shorter wrist pin when compared to traditional “full round” style forgings. The narrow skirt helps minimize piston contact with the cylinder wall that can cause friction and power loss while the shortened wrist pins reduces the overall weight. Some FSR forgings feature internal and external bracing to provide a more rigid construction while minimizing overall weight. With thousands of race miles logged in the most demanding applications like NASCAR, NHRA Pro Stock and Indy Car, these pistons provide the ultimate combination of low-friction, lightweight design with increased stability and strength.

SPECIFICALLY DESIGNED LEFT AND RIGHT FORGINGS ALLOW PRECISE VALVE RELIEF LOCATIONS FURTHER REDUCING WEIGHT WHILE MAINTAINING SUPERIOR STRENGTH AND UNIFORM CROWN THICKNESS

JE FORGINGS FEATURE ENLARGED PIN BOSS AND RING BELT RADII TO ENSURE OPTIMUM STRENGTH IN CRITICAL AREAS

CUSTOM PISTONS

For decades, JE Pistons has manufactured custom pistons for thousands of applications. JE Piston’s in-house engineering and manufacturing centers can produce a custom piston for almost any 4-stroke engine. To order custom pistons, please use the Custom Piston Order Form located in the back of this catalog, or download one from our website at www.JEpistons.com. Custom pistons do not include pins, locks or rings. Please see the components section of this catalog to select the proper components for your custom order.

APPLICATIONS INCLUDE:

Alfa Romeo

AMC

Aston Martin

Audi

Austin Healey

Bentley

BMW

BSA

Buick

Cadillac Caterham Chevrolet Chrysler Citroen Cosworth Datsun

PISTON COATINGS

THERMAL BARRIER

CROWN COATING

Applied to the top of the piston and is designed to reflect heat into the combustion chamber, thereby increasing exhaust gas velocity and greatly improving scavenging potential. The .0015” thick coating can also assist in extending piston life by decreasing the rate of thermal transfer.

TUFF SKIRT ® COATING

JE Pistons’ trademark coating that is a lubricating, anti-friction/anti-wear coating applied to the piston skirt only. Unlike our standard Skirt Coating, Tuff Skirt will not wear and is designed to withstand many different types of endurance applications, similar to those commonly found in NASCAR. Buildup is .0005” per surface and finished diameter of skirt should include the coating buildup.

PERFECT SKIRT TM

Perfect Skirt is a proprietary and patented skirt coating only offered by JE Pistons. Perfect Skirt is three-times thicker than traditional skirt coatings to allow racing pistons to have tighter piston-to-wall clearances similar to OEM applications. This decreases piston noise on startup and reduces cylinder bore wear. Additionally, this is beneficial for late-model engines, reducing the possibility of false knock sensor readings. Perfect Skirt will continuously conform to the shape of your cylinder’s bore.

Mitsubishi

Porsche Radical

Renault

Rolls Royce

Saab

Skoda

Smart

Subaru

Toyota

Triumph Vauxhall

Volvo

Yamaha and more...

ANODIZED RING GROOVE COATING

Reduces wear and material transfer between the ring and groove. Shown to be very durable in maximum effort, high endurance applications. Appropriate manufacturing allowances apply.

KOOLKOTE

Is an aerospace quality hard anodize applied to all surfaces of the piston with a buildup of .001. This coating is designed for use in nitro-methane engines such as Top Fuel Drag Racing to endure the corrosive effects of this type of fuel. It will withstand greater temperatures and will not flake, chip or peel. This coating does alter the heat transfer and expansion characteristics of the piston. Consult the JE Pistons technical department for specific applications. Manufacturing allowances are required on all surfaces.

EN PLATING

Help reduce pitting and piston ring micro welding caused by detonation with JE’s Electroless Nickel plating. Unlike other metal plating that loses hardness and softens when exposed to heat, Electroless Nickel gets harder as it runs. The plating is applied to the piston domes, ring grooves, and wrist pin bore to provide a lower coefficient of friction, reduce ring blow-by, and increase detonation protection. In addition, Electroless Nickel reflects heat and allows domes to run up to 68 degrees cooler.

STANDARD CUSTOM PISTON FEATURES

• Fully CNC Machined Piston

• Precision Machined CNC Ring Grooves

• 2618 Low-Silicon or optional 4032 High Silicon material available on some applications

• Diamond Turned Skirts

• Radiused Valve Reliefs

• Single Forced Pin Oilers

• Pick Lock Grooves (for use with wire locks)

• Machined Side Reliefs on full round forgings

• Lock Grooves Machined for Carbon Steel Spiro Locks (other options available)

• Engineered for your application!

LATERAL GAS PORTS

ACCUMULATOR GROOVE

INTERNAL PLUNGE BOSS

CONTACT REDUCTION GROOVES

DOUBLE PIN OILERS

PIN FITTING

NOTCHED BOTTOM BAND TYPE SIDE RELIEF

ULTRA CROWN DOME / INVERTED DOME:

The Ultra Crown machining process allows incredibly precise dome to cylinder head tolerances. By mapping the exact shape of a piston or cylinder head, optimum compression and quench characteristics can be achieved.

3D UNDER CROWN MILLING: The Under Crown machining process allows for uniform deck thickness, therefore creating a lighter and more durable piston.

VERTICAL GAS PORTS: Vertical holes in the deck of the piston, allows combustion pressure to directly enter behind the top ring on the power stroke, thus pressurizing the area behind the top ring for greater ring to cylinder wall seal. During the rest of the cycle, the ring has normal tension for reduced friction. (Most commonly used for drag race applications).

LATERAL GAS PORTS: This process mills slots into the top of the top ring groove and provides a pathway for combustion pressure to get behind the top ring. This process helps to increase ring seal and is most common in circle track applications.

ULTRA GROOVE: Ultra Groove is a special ring groove machining process that provides near perfect groove flatness and surface finish. Tolerances are held to millionths of an inch.

PIN BOSS & WINDOW MILLING: In certain applications window milling will remove a significant amount of weight from the skirt of the piston while maintaining its strength and integrity. Spin Boss refers to machining on the bottom of the pin boss, which removes weight where it is not needed for strength.

PLUNGE BOSS & CHAMFER PIN BOSS:

Machining process that removes additional material for added weight savings.

CONTACT REDUCTION GROOVES: The purpose of machining these grooves is to reduce the amount of contact area against the cylinder wall when the piston “rocks over”. Contact reduction also serves to disrupt the flame travel into the crevice area thus helping to reduce detonation.

ACCUMULATOR GROOVES: An accumulator groove is machined into the land between the top and second ring. It provides additional volume where residual combustion gases that have “blown by” the top ring can collect. This additional volume helps to reduce pressure between the top & second ring, thus aiding in top ring seal and minimizing ring flutter.

DOUBLE PIN OILERS: Double Pin Oilers deliver twice the amount of oil to the wrist pin as compared to the standard single pin oiler.

PIN FITTING: The pin bore is precision honed to attain an exact pin clearance. Clearances typically range from .0003 to .0010 between the wrist pin and pin bore.

OIL SQUIRT NOTCH: Notching can be done on pistons for motors with oil squirters, or to avoid contact between pistons and/or pistons and crankshaft.

BOTTOM OILERS: This process machines one or two holes into the bottom of the pin boss to assist in splash pin lubrication.

TULIP VALVE POCKETS: Most commonly used on Hemi and motorcycle engines, this process leaves a raised area on plunged valve pockets to achieve maximum compression.

VERTICAL GAS PORTS

ULTRA DOME

SPIN BOSS

WINDOW MILL CHAMFER PIN BOSS BOTTOM OILERS

OIL SQUIRT NOTCH

3D UNDER CROWN MILLING

SMALL BLOCK CHEVROLET
