sconce LED
ADA
WALL MOUNTS
reflex 3-504-24 Shown with optional cover plate (included)
GENERAL SPECIFICATIONS: - Cold rolled steel housing and trim. - ETL approved for damp locations - confirms to UL standard 1598. Review available options to format your Oxygen part number.
3-504-XX FINISH
3-504-XX
REFLEX / LED
- Certified CAN/CSA STD C22.2 No. 250.0. - ADA Compliant. - Unit mounts to 2" x 3" junction box. - Supplied with 4.25" x 4.25" cover plate for mounting to 4" x 4" junction box. - Unit mounts to 4" x 4" junction box.
DIFFUSER
Frosted Glass
- Approved for vertical mounting.
FINISH
14 Polished Chrome, 24 Satin Nickel
- Approved for wall mount applications only.
LAMPING
2 x 7w MAX GU10 LED ONLY (lamps not included)
- Visit www.oxygenlighting.com for technical cut sheets.
DIMENSIONS
4"(w) x 20"(h) x 3.5"(ext)
DRIVER
NA
VOLTAGE
120V
- Oxygen reserves the right to modify designs at any time.
oxygenlighting.com
21
