FEATURE

Making Sense of Industrial Networks

Fieldbus and 4-20mA in the Age of IoT

This installment in our series on key industrial network technologies explains why fi eldbus and 4-20mA communications remain relevant despite the proliferation of Ethernet-based communications amid industry’s digital transformation.

By James R. Koelsch, Contributing Writer

What will be the fate of fi eldbus and 4-20mA network communications in the face of Ethernet’s growing use in industrial networking? This is a question that many are asking as industrial Ethernet rapidly replaces legacy technologies that once dominated industrial networks.

In the discrete manufacturing industries, for example, the transition from fi eldbus to industrial Ethernet is well underway. “It has been occurring rapidly over the last decade and doesn’t appear to be slowing,” reports Michael Bowne, executive director, PI North America (the organization supporting Profi bus and Profi net).

As evidence for his point about the increasing use of Ethernet, Bowne notes the annual node counts that PI conducts for Profi net and Profi bus devices used in factory automation. “There were 8.5 million Profi net (industrial Ethernet) devices installed in 2021—the largest annual fi gure yet,” he says. By contrast, 1.5 million Profi bus (fi eldbus) devices were installed. This amounts to nearly six Profi net devices installed for every one Profi bus device.

It wasn’t all that long ago when the opposite was true. “2016 was the fi rst year more Profi net devices were installed than Profi bus,” notes Bowne. “In 2007, one Profi net device was sold for every 15 Profi bus devices.”

Despite such advances in discrete manufacturing, the transition to Ethernet has been unfolding much more slowly in the process industries. Bowne reports that there the transition from fi eldbus and 4-20mA to industrial Ethernet is really just getting started.

A big reason for the slow start has been safety, a concern eased recently by the development of Ethernet-APL (advanced physical layer), a version of Ethernet designed for hazardous environments. “With Ethernet-APL, there is now an intrinsically safe physical layer for Ethernet to allow direct connection to instruments in potentially explosive areas,” explains Bowne. “Ethernet-APL is poised to be a signifi cant step change in the capabilities of process automation networks—a change that is long past due.”

Ethernet-APL is an extension of the specifi cation for single-pair Ethernet (SPE) based on 10BASET-1L. Not only does it support all Ethernet-based protocols, it also provides power and communications over IEC 61158-2 Type A cables that can be as long as 1,000 meters. For intrinsic ignition protection, Ethernet-APL devices follow electrical parameters defi ned in IEC TS 6007947, the two-wire intrinsically safe Ethernet (2-WISE) technical specifi cation.

Users in both the discrete and process industries, therefore, are able to benefi t from the greater speed and bandwidth o ered by industrial Ethernet. This greater speed and capacity can streamline both connectivity and the fl ow of ever more diagnostic and prognostic data. “When leveraged properly, this additional information can net signifi cant gains in throughput, quality, and cost reduction,” notes Steve Fales, director of marketing at the ODVA (the group supporting EtherNet/IP, DeviceNet, and the Common Industrial Protocol).

For these reasons, Fales and others see fi eldbus and 4-20mA communications giving way to industrial Ethernet in most new installations. “The scales will generally tip toward industrial Ethernet for a new discrete manufacturing line or an island of automation in a process facility,” says Fales.

In response, fi eldbus standards organizations have moved to Ethernet. “Serial topologies from numerous organizations have become Ethernet-based,” observes Arnold O ner, strategic marketing manager, automation infrastructure, at Phoenix Contact. He points to FieldComm Group’s addition of HART-IP, PI and Profi net (noted above), and ODVA’s increased focus on EtherNet/IP.

Replaced, but not erased

Does this mean that Ethernet devices will eventually replace fi eldbus and 4-20mA networks? “Yes, but it will take a while for suppliers and end users to synchronize the replacement of the existing technology because the installed base is so large,” predicts Tom Burke, director of global standards at the CC-Link Partner Association Americas. “There has been a lot of investment [in these

legacy technologies], so there has to be a significant return on investment to justify replacing it.”

“Even though the cost di erence between legacy and new technologies is nominal, it’s hard to justify ripping and replacing existing industrial automation devices,” adds Fales. Buying new devices to replace existing ones that are doing the job and then shutting down production long enough to make the switch doesn’t make a lot of economic sense, especially when capital budgets are limited.

In the process industries, another limiting factor is the newness of Ethernet-APL. Some time will need to pass before enough device manufacturers incorporate the new Ethernet-APL physical layer into their products. “A significant number of vendors must do this to create an ecosystem of products that allow end users to build plants and networks,” explains Bowne.

Another lifeline for fieldbus and 4-20mA communications has been the development of gateways and translators capable of sending data to Ethernet networks. These devices allow data to be extracted from legacy networks while enabling those data to be sent to the edge or the cloud for monitoring and analysis. “They help keep existing installations integrated into the broader control network and thereby enable these legacy networks to stay in service as long as vendors are willing to make spares for the devices,” says Fales.

O ner at Phoenix Contact thinks that automation vendors will continue supporting fieldbus and 4-20mA technology with spares and services for quite a while yet. “We still have applications using pneumatics that were replaced by the 4-20mA loop circuits made with transistors,” he notes.

Unleashing stranded data

Ironically, the evolution of automation technology could help extend the life of fieldbus and 4-20mA technologies. “They [legacy networks] will still find use as newer digital devices using Ethernet include their capability,” predicts O ner.

For such reasons, Ted Masters, president and CEO of the FieldComm Group, thinks that traditional fieldbus and 4-20mA will always have a place in industrial networks. “Even in this era of digitalization, end users are not ripping out field devices,” he says. “They are instead protecting their investments by finding ways to unleash the valuable data

The Phoenix Contact FL ComServer UNI 232/422/485 converts a legacy serial 232/422/485 interface to Ethernet. Source: Phoenix Contact

Digitalizing hazardous areas. Enabling connectivity. Enhancing mobility.

For more information, visit pepperl-fuchs.com

Smart-Ex® 02 smartphone for industrial & hazardous areas—suitable for use in Div. 1 and Zone 1/21

stranded within these devices.”

For Masters, the challenge is to do this in ways that support digitalization. Besides using gateways and translators, another method involves upgrading 4-20mA signals with the HART protocol. “Higher-speed digital approaches to access 4-20mA data can use technologies such as HART-IP and WirelessHART,” says Masters.

Because the HART protocol can be superimposed on existing 4-20mA wiring, no changes to the connectivity infrastructure are necessary. Moreover, many instruments and host systems already support HART natively, and those that don’t can add HART functionality with adapters and other devices. “This makes it easier and more cost-e ective to bridge this data to applications that are either on-premises or cloud-based to create value,” notes Masters.

Another way to help fieldbus and 4-20mA technology support digitalization is to simplify the integration of field devices. Because industrial networks continue to include a variety of physical layers addressing Ethernet as well as fieldbus and 4-20mA wiring, the FieldComm Group is collaborating with the FDT Group, PI, and the OPC Foundation to develop new field-device integration (FDI) technology.

FDI provides a common approach for integrating information from intelligent field devices into higher-level asset management and automation/ control systems for configuration, commissioning, diagnostics, calibration, and other tasks. To be open for use across di erent protocols and network types, it also includes part of the NAMUR Open Architecture model and supports new and existing automation protocols. “FDI technology has been a major milestone for simplifying access to field device data in a standard way, regardless of communication protocol,” notes Masters.

Best fit for the job

Another reason that fieldbus and 4-20mA communications will continue to be relevant for a long time to come is that they remain su cient for some jobs. One example is a simple weigh scale reporting only weight through fieldbus. In such cases, Ethernet’s ability to accommodate communications from multiple devices on one wire is unnecessary. “Simple point-to-point connections are more than su cient,” notes Burke. “They provide enough bandwidth for the devices to work.”

Typically, users wanting to extract more information from plant floor devices will send data to a PLC and store it in memory. In this way, the “PLC serves as a kind of data federation because it aggregates data from all these di erent devices,” says Burke.

Open standards have also helped with transferring fieldbus data to higher-level applications in the network. “In 1995, OPC basically solved the problem of being able to grab data from all these different devices and send it up to client applications, such as typical small-scale HMI systems or even Microsoft Excel,” explains Burke. User companies and industry consortia have since developed data models and naming conventions to access the data from the disparate devices on the network.

Such point-to-point architectures provide many manufacturing facilities the connectivity they need. “Therefore, as long as they can aggregate the data and plug into something to get the data out, they don’t see any significant value in replacing their current network,” says Burke.

AT11-22USA | |

All-in-one servo drive and motor

The compact AMI812x servo drive

One connection level covers all interfaces: directly on the servo drive without requiring upstream I/O

The AMI812x integrated servo drive: integrated servo drive for compact drive technology (up to 48 V DC) combines highly compact servomotor, output stage and fieldbus connection for all motion requirements in the power range up to 400 watts for single axes or with daisy-chain solutions on the machine supports machine concepts without control cabinets

IP65 protection degree possible with sealing ring option

Safe torque off (STO) safety over FSoE (Safety over EtherCAT) reduces installation and integrates seamlessly into safety solutions

Beckhoff offers a complete, compact control solution including a range of compact motion technologies for servo, stepper, DC motors and more

Scan to experience the benefits of compact integrated servo drives

Are you looking for packaging or processing solutions and you don’t know where to start?

You’re looking for...

The most reliable and complete online directory of packaging and processing technology suppliers in North America – designed from the buyer’s perspective.

Features include: • Plain-language lters so it’s easy to nd what you need. • Type-ahead keyword search. • Visual navigation by machine or desired package type. • Packaging-speci c lters that are tailored to each product category.

In fact, many of these facilities, especially the smaller ones, are wary of pursuing technologies driving digital transformation. One reason is that they don’t know how to assess the value of turning data into actionable information to justify retooling their existing installations. Another reason is that they often don’t have the technical expertise and understanding in-house. “Over time, though, people will start to understand the benefits of using [greater levels of ] information and leveraging historians in a lot of these small manufacturing installations,” says Burke.

Beyond these reasons, there are at least two kinds of use cases that will continue to favor fieldbus and 4-20mA communications. First is when the job requires a specific device that isn’t yet available with an industrial Ethernet interface. “While just about all device vendors in 2022 o er devices with both fieldbus and industrial Ethernet interface options, some still only have fieldbus or analog communications,” observes Bowne. Here, users wanting to connect these devices to Ethernet networks will need to deploy gateways to translate the data.

PI has taken this a step further with a proxy concept. “Proxies are like gateways in that they connect disparate networks,” explains Bowne. “But unlike gateways, the data mapping is defined in a specification.” Because the data are translated according to the proxy specification, the data always look the same, even if they are coming into Profinet from Profibus or some other legacy fieldbus. This concept permits both migrating to Profinet in a piecemeal fashion and installing a new Profinet network without losing access to data from legacy systems.

The second use case for continuing to install fieldbus or 4-20mA occurs in the process automation market when the application requires intrinsic safety. Here, a fieldbus usually remains the preferred solution. As Ethernet-APL becomes more widely available, however, Bowne expects it to slowly replace fieldbuses in such cases.

The Wago 750-366 EtherNet/IP fieldbus coupler detects all connected I/O modules and creates a local process image. Two Etherent interfaces and an integrated switch allow the fieldbus to be wired in a line topology, eliminating the need for additional network devices, such as switches or hubs. Source: Wago
