Enable ztC OPC UA on ztC

Setup Guide for Stratus ztC Edge 250i OPC UA Integration into AVEVA Intouch HMI

How to add and enable ztC OPC integration into AVEVA Intouch

2

Enable ztC Edge OPC UA in ztC Edge Web Console

Create OPC Connection in AVEVA Intouch

1. Open the “System Platform Management Console”.

2. Open the Operations Integration Server Manager 3. Select “Default Group” 4. Select “Local” 5. Select “Wonderware – Gateway” 6. Select “OI.GATEWAY” and the “Configuration”

www.stratus.com

3

7. Right click on “Configuration” and select “Add OPCUA Connection”

8. Give the OPCUA Connection a name 9. Server Node: “ztC System IP Address” 10. OPCUA Server: “opc.tcp://ztC systemIP:4840/ 11. Security Policy: None (Can be different depending what you select in the ztC console)

Once you test the connection and it is successful you should receive the indexes in the namespace

www.stratus.com

4

12. Right click on newly created OPCUA Connector for ztC and “Add OPCUA Group Connection”

www.stratus.com

5

13. Once the Group has been created you can no “Browse OPCUA Server” and add to list

14. Under the “name” column you can rename the tag to more suitable name 15.Under the “name” column you can rename the tag to more suitable name

www.stratus.com

6

OPC Graphic integration example below

www.stratus.com

7

Creating a ztC OPC UA Tag reference in Intouch HMI Window Maker

Step 1 Select “String” button under “Value Display”

Step 2 Insert a tag name in the “Expression” box Step 3 Select “Type” radio button and choose I/O Message as the type Step 4 Insert in the “Item” box the ztC OPCUA tag reference Step 5 Save your options and return to main page to create next one.

www.stratus.com

8

Once completed all your tag references to the ztC your display could look like below example:
