Wall Mounted Enclosures
Telequick mounting plate, UMPT Description:
Telequick mounting plate for UDP/UDPT enclosures.
Material:
2 mm perforated steel.
Pack quantity:
1 piece.
For enclosure
2
Mounting plate dimensions
H
W
h
w
500
500
390
390
UMPT5050
500
750
390
640
UMPT5075
750
500
640
390
UMPT7550
750
750
640
640
UMPT7575
750
1000
640
890
UMPT75100
750
1250
640
1140
UMPT75125
1000
500
890
390
UMPT100500
1000
750
890
640
UMPT10075
1000
1000
890
890
UMPT100100
1000
1250
890
1140
UMPT100125
1250
750
1140
640
UMPT12575
1250
1000
1140
890
UMPT125100
UMPT, Mounting plate, telequick, polyester,
Item no.
, Mounting plate, telequick, polyester, UMPT
Snap nuts for telequick plates, TN Description:
Nuts to be used in the telequick mounting plates.
Pack quantity:
50 pieces. Thread
Item no.
M4
TN04
M5
TN05
M6
TN06
TN, Nuts, snap for telequick mounting plates,
, Nuts, snap for telequick mounting plates, TN
Not suitable for AFS.
Depth adjustment kit, UPD Description:
To provide depth adjusment for the mounting plate and other accessories in steps of 12.5 mm.
Material:
Galvanized steel.
Delivery:
4 brackets, four depth profiles and mounting accessories. Item no. UPD01
UPD, Mounting plate, brackets, depth adjustment, polyester wall mounted UDP/UDPT,
, Mounting plate, brackets, depth adjustment, polyester wall mounted UDP/UDPT, UPD
