dtc range 2023

drawer system

Features

Smooth

Dragon Pro

TitaniumX

Magic Move

Economy Runners

Ball Bearing Runners

Wall/Slides

DWD

SWD

Slides Only

Finish

White

Silk White & Matt Black

White

Zinc Plated

White

Zinc Plated

Runners

Concealed Side Mount

Side Mount

Under Mount

Side Mount

Side Mount & Undermount

Extension

Full Extension

Single Extension

Full Extension

Single Extension

Full Extension

Mechanism

Soft Close / Push-to-Open option

Self Close (Soft close option)

Soft Close

Self Close (Soft close option)

Soft Close / Non-Soft close option

Height

68 83 115

80 95 127 178 238

86 118 150 214

Length

270-600mm

300-600mm

250-550mm

250-600mm

250-500mm

250-600mm

Load Capacity

40kg

30kg

40kg

20kg

45kg

wall

DWD

Double wall drawer

runners

SWD

Single wall drawer

Slide Only

mechanism

Soft-Closing

Push-to-Open

Side Mount

Mounted in a vertical position on the side of the drawer

Under Mount

Mounted in a horizontal position under the chassis of the drawer

extension

Self Close

Full Extension

Allows drawers to be opened completely

Single Extension

Only allows drawers to be opened partly— 3/4 opened

drawer system

Standard Drawer Silk White Finish 95 mm

127 mm

178 mm

238 mm

PTO (Slides Only)

300mm

B013004A

B023004A

B033004A

B043004A

B413004H

350mm

B013504A

B023504A

B033504A

B043504A

B413504H

400mm

B014004A

B024004A

B034004A

B044004A

B414004H

450mm

B014504A

B024504A

B034504A

B044504A

B414504H

Nominal Length

500mm

80 mm

B015004A

B025004A

B035004A

B045004A

B415004H

550mm

B05004A

B015504A

B025504A

B035504A

B045504A

B415504H

600mm

B016004A

B026004A

B036004A

B046004A

B416004H

*Synchronisation Rod(B0FH02) is needed for drawers with width of 600mm or wider for Push-to-Open mechanism to work.

DRAGONPRO

features

• • • • • • • • •

Double wall drawer

• •

Load capacity 40kg Matt black or silk white finish Full extension synchronised drawer Tool-free assembly and removal Soft-close drawer system Up/down adjustment ± 2 mm Left /right adjustment ± 1.5 mm Easy slide in and click back brackets No gallery rail — clean, one-piece, complete side Double wall drawer Push-to-open option available

Full Extension

Concealed Slides Side Mount

Soft Close

Push-to-Open (Optional)

advantages • • • • •

No need to construct drawer sides and tool-free assembly and removal makes building a drawer quick and easy Runners and slides are hidden and no gallery rails makes the drawer look cleaner Internal left/right adjustment Built-in soft closing mechanism Stylish colours — comes in matt black and silk white

drawer system

Standard Drawer Matt Black Finish

Nominal Length

80 mm

95 mm

127 mm

178 mm

238 mm

300mm

B013004AMB

350mm

B013504AMB

B023504AMB

B033504AMB

B043504AMB

400mm

B014004AMB

B024004AMB

B034004AMB

B044004AMB

450mm

B014504AMB

B024504AMB

B034504AMB

B044504AMB

B015004AMB

B025004AMB

B035004AMB

B045004AMB

B015504AMB

B025504AMB

B035504AMB

B045504AMB

500mm

B005004AMB

550mm

B043004AMB

dragonpro accessories Gallery Rail

Brackets

White Knock-In Square Gallery Rail Set

Inner Drawer Accessories

Front Fix Expanding Dowel Set

Front Panel 1100mm

M0104S350

350mm

B0101B

97/127mm High

B01021

White

M0104S400

400mm

B0301B

178/238mm High

B01021MB

Matt Black

M0104S450

450mm

M0104S500

500mm

M0104S550

550mm Inner Drawer Front Bracket Set

Inner Drawer Front Rail 1100mm

B01012

95mm White

M01078

White

B02012

127mm White

M01078MB

Matt Black

White Easy Fix Square Gallery Rail Set

B03012

178mm White

M0104H350

350mm

B01012MB

95mm Matt Black

M0104H400

400mm

B02012MB

127mm Matt Black

M0104H450

450mm

B03012MB

178mm Matt Black

M0104H500

500mm

M0104H550

550mm

Marking Jigs

Marking Jig Rear Variable Bracket Set

Matt Black Knock-In Square Gallery Rail Set M0104S350MB

350mm

M0104S400MB

400mm

M0104S450MB

450mm

M0104S500MB

500mm

B0103J

White

B0103JMB

Matt Black

B0101A

97/127mm High

B0301A

178/238mm High

Synchronisation Rod

PTO Synch Rod B0FH02 Extra Cover Caps

Stabiliser Set

B01081

TBJS01

Inside 178/238mm high

TBJS02

Inside 95/127mm and outside all drawers

TBJS01MB

Inside 178/238mm high matt black

TBJS02MB

Inside 95/127mm and outside all drawers matt black

White

1100mm Grey

* Synchronisation rod is not applicable in 300mm drawers.

drawer system

features

Double wall drawer

Full Extension

SMOOTH

Concealed Slides Side Mount

Soft Close

Push-to-Open (Optional)

• • • • • • •

advantages • • • • • • •

•

Optimal soft closing operation Load capacity 40kg White finish Full extension synchronised drawer Tool-free assembly and removal of drawer Double wall drawer Up/down adjustment ± 2 mm (access from left and right profile) Left /right adjustment ± 1.5 mm (access from right profile only)

Tool-free front and gallery rail fixings come standard Runners and slides are concealed, giving the drawer a cleaner look Side adjustment is accessed from the right profile only Built-in soft closing mechanism Fully synchronised soft close drawer and no knocking noise 2D adjustment on the standard drawer (side and height) 3D adjustment on pot drawers (side, height, and tilt adjustment through the gallery rail)

drawer system

Soft Closing Nominal Length

Profile 68 mm Set A

83 mm

Push-to-Open

Medium

High Pot Drawer

Profile

115 mm

135 mm

199 mm

83 mm

Set B

Set D

Set A

270mm

B01270A

B02270A

300mm

B01300A

B02300A

350mm

B01350A

B02350A

B01350B

B01350D

B513504A

400mm

B513004A

B01400A

B02400A

B01400B

B01400D

B514004A

450mm

B004504A

B01450A

B02450A

B01450B

B01450D

B514504A

500mm

B005004A

B01500A

B02500A

B01500B

B01500D

B515004A

550mm

B01550A

B02550A

B01550B

B01550D

B515504A

600mm

B01600A

B02600A

Use Set B components

Use Set D components

Set A - Comes complete drawer with easy fix front brackets Set B - Set A (83mm) plus easy fix gallery rails & medium back brackets Set D - Set A (83mm) plus easy fix gallery rails & high back brackets. 115mm - Optional medium pot drawer will require additional 167mm back bracket and easy fix gallery rail. *Synchronisation Rod(M0FH02) is needed for drawers with width of 600mm or wider for Push-to-Open mechanism to work.

smooth accessories Drawer Accessories

White Knock-In Inner Gallery Rail Set

White Easy Fix Gallery Rail Set

M01041350

350mm

M0104V300

M01041400

400mm

M0104V350

300mm 350mm

M01041450

450mm

M0104V400

400mm

M01041500

500mm

M0104V450

450mm

M01041550

550mm

M0104V500

500mm

M01041600

600mm

M0104V550

550mm

M0104V600

600mm

Synchronisation Rod M0FH02

PTO rod 1100mm

Stabiliser B01081

Rear Variable Brackets B0103J

Rear fixing bracket

Drawer Front Stabilizer M01082

Fastener

drawer system

smooth accessories Gallery Rails

Brackets

Side Wing

White Knock-In Square Gallery Rail Set

Rear Bracket Set - White

B Drawer H64 Single Wall Side Set

M0104S350

350mm

M0104S400

400mm

M0104S450

450mm

M0104S500

500mm

M0104S550

550mm

B01031

H83 Std - A

B01032

H135 Med Pot - B

B01033

H199 High Pot 2xRail-D

B01039

H199 High Pot Rail-D

B02031

H115 Std - A

B02032

H167 Med Pot-115profile

M01051450

450mm

M01051500

500mm

M01051550

550mm

Inset Drawer

White Front Panel M01021

H83 1100mm

Inset Drawer Handle M01022

Rail Fixing Bracket Set Screw-on fixing bracket. Suits knock-in gallery rails only.

MGH08

D Drawer H128 Single Wall Side Set Inset Front Bracket Set - White

M01052300

M01012

H83 Std

M01052350

350mm

M01013

H135 Med Pot

M01052400

400mm

M01014

H199 High Pot Rail

M01052450

450mm

M01052500

500mm

M02010

H115 Std

300mm

M01052550

550mm

M01052600

600mm

M0104H350

350mm 400mm

M0104H450

450mm

M0104H500

500mm

M0104H550

550mm

Extra Cover Caps

B01 White Set MJS01

Regular

1100mm White Front Rail M01043

High inset

Sink/ Vanity

White Easy Fix Square Gallery Rail Set

M0104H400

For high inset drawer

Front Fixing Bracket Set M0101B

Expanding Dowel

M01019

Easy Fix Dowel

M01011

Screw-On

Sinks/ Vanity Drawer Wall D Drawer H128 Double Wall Side Set M01053350

350mm

M01053400

400mm

M01053450

450mm

M01053500

500mm

M01053550

550mm

M01053600

600mm

M0103M

U-Shaped

Marking Jigs

Marking Jigs ML3

Gallery rail

M0101A

Front fix bracket

drawer system

TITANIUMX • • • • • • • • •

Load capacity 30kg Self-closing Double stop positions 2-D front panel adjustment Up/down adjustment ±2mm Left/right adjustment ±2mm White finish Quiet drawer system Soft close option is available

features

advantages •

Single Wall Drawer

Single Extension

Side Mount

Self Close

• • •

Soft Close (Optional)

No need to construct drawer sides which makes building a drawer quicker and easier Thin walls create more space for storage Economical walled drawer system Universal front brackets

With Pins

Without Pins

Nominal Length

86 mm

250mm

DTC86250WP

300mm

DTC86300WP

350mm

DTC86350WP

DTC118350WP

DTC150350WP

DTC214350WP

DTC86350W

400mm

DTC86400WP

DTC118400WP

DTC150400WP

DTC214400WP

450mm

DTC86450WP

DTC118450WP

DTC150450WP

DTC214450WP

500mm

DTC86500WP

DTC118500WP

DTC150500WP

DTC214500WP

550mm

DTC86550WP

DTC118550WP

118 mm

150 mm

214 mm

86 mm

118 mm

150 mm

214 mm

DTC118350W

DTC150350W

DTC214350W

DTC86400W

DTC118400W

DTC150400W

DTC214400W

DTC86450W

DTC118450W

DTC150450W

DTC214450W

DTC86500W

DTC118500W

DTC150500W

DTC214500W

DTC118250W DTC118300W

DTC150550W

drawer accessories Gallery Rail

Bracket

Marking Jigs

Front Marking Jig Screw-on White Single Wall Rail Set

Easy Fix White Single Wall Rail Set

DTCRAIL35W

350mm

DTCRAIL35WV

350mm

DTCRAIL40W

400mm

DTCRAIL40WV

400mm

DTCRAIL45W

450mm

DTCRAIL45WV

450mm

DTCRAIL50W

500mm

DTCRAIL50WV

500mm

DTCRAIL55W

550mm

DTCRAIL55WV

550mm

Single Side Metal Bracket DTCFBKTEXPDL

Exp Dowel

DTCFBKTKI

Knock-In

DTCFBKTSO

Screw-On

Sold per each Two per drawer required

DTCDFMJIG

Single wall drawer

Soft-close Adapters

DTCSYLENTD

For single wall drawer

DTCSYLENTR

For single extension runner

Suits 350mm and above lengths Sold in pairs

premium slide system

features

MAGIC MOVE • • • • • • • • • • •

Full extension, fully synchronized runner 40kg load capacity Zinc plated finish The drawer system self-locks once positioned on the slide Soft closing Bottom mounting Includes 3D front brackets with runners 3D adjustment Up/down adjustment ±2.5mm Left/right adjustment ±1.5mm Depth adjustment ±3mm

Nominal Length

Magic Move

250mm

DTCTS10250H

300mm

DTCTS10300H

350mm

DTCTS10350H

400mm

DTCTS10400H

450mm

DTCTS10450H

500mm

DTCTS10500H

550mm

DTCTS10550H

600mm

DTCTS10600H

Slide Only

Full Extension

Under Mount

advantages • • • •

3D adjustable for a better retro-fitting of drawers Soft closing without additional parts Fully concealed runner No rebate is required to accommodate the runner

slide system

Economy Runners

Ball Bearing

Nominal Length

Single Extension

Full Extension

250mm

DRECO250

300mm

DRECO300

DRBB300MMBM

DRBB300MMN

DRBB300SCSM

350mm

DRECO350

DRBB350MMBM

DRBB350MMN

DRBB350SCSM

400mm

DRECO400

DRBB400MMBM

DRBB400MMN

DRBB400SCSM

450mm

DRECO450

DRBB450MMBM

DRBB450MMN

DRBB450SCSM

500mm

DRECO500

Bottom Mount

Side Mount -

Soft Closing

DRBB250MMN

DRBB500MMBM

DRBB500MMN

DRBB500SCSM

550mm

DRBB550MMBM

DRBB550MMN

DRBB550SCSM

600mm

DRBB600MMBM

DRBB600MMN

DRBB600SCSM

ECONOMY RUNNERS

BALL BEARING B/M

BALL BEARING S/M

• • • • • • •

• • •

Single extension 20kg load capacity Roll out prevention White finish Economy Bottom mounting Self-closing

• • •

Full extension 45kg load capacity Steel ball bearing rollers for longer roller life System 32 drilling Hold-in cushion positive out stop Bottom mounting

Accessories • DTCSYLENTR — Soft closing adapter

features

Slide Only

Single Extension

features

Under Mount

Slide Only

advantages •

Economical choice

• • • •

Full extension 45kg load capacity Steel ball bearing rollers for longer roller life Soft closing option System 32 drilling Hold-in cushion positive out stop Side mounting

Full Extension

features

Under Mount

Slide Only

advantages • •

High loading capacity Easy removal from runner

Full Extension

Side Mount

Soft Close (Optional)

advantages • • •

High loading capacity Soft closing without add-ons Easy removal from runner

cutlery trays

drawer accessories 4-bay Width: 356mm Depth: 473.5mm Height: 55m

7-bay Width: 356mm Depth: 473.5mm Height: 55m

Suits 500mm deep Dragon Pro drawer

DTCCUTDP500A01

DTCCUTDP500A03

The ultra-slim design and sensible organization components yield maximum storage space

Width 285mm

Width 370mm

Width 460mm

Depth 480mm Height 65mm Configuration 3 x (85 x 310mm) 1x (85 x 170mm) 1x (85 x 255mm) 1 x ( 85 x 85mm) 2 x spring loaded spacers*

Depth 480mm Height 65mm Configuration 4 x (85 x 310mm) 2 x (85 x 255mm) 1 x (85 x 170mm) 2 x spring loaded spacers*

Depth 480mm Height 65mm Configuration 5 x (85 x 310mm) 2 x (85 x 255mm) 2 x (85 x 170mm) 2 x spring loaded spacers*

*Keeps modules stable and adds another full length compartment where required

DTCCUTLERY500 Stainless Steel Modular

DTCCUTLERY600 Stainless Steel Modular

Suits 500mm deep drawer

CUTLERY600A W - 530-460mm x D - 485-415mm H - 50mm ABS White

CUTLERY600S W - 530-490mm x D - 485-445mm x H - 60mm ABS White

CUTLERY700A W - 630-590mm x D - 485-420mm x H - 50mm ABS White

CUTLERY800S W - 730-685 x D - 485-420mm x H - 50mm ABS White

DTCCUTLERY700 Stainless Steel Modular Suits 500mm deep drawer

CUTLERY900S W - 830-780mm x D - 485-415mm x H - 50mm ABS White

spice/bottle drawer

NARROW SPICE / BOTTLE DRAWER When a kitchen design requires a narrow cabinet to be placed, a narrow spice drawer configuration makes the most of the small space and optimises convenience and storage capacity.

features

Full Extension

Soft Close

Under Mount

advantages • • • • • •

•

Suit 150mm cabinet width Concealed, full extension runners 40kg load capacity Soft closing Silent system guarantees smooth run without noise 3D adjustment (side, height and tilt) > Left/right adjustment ± 1.5 mm > Up/down adjustment ± 2 mm > Tilt adjustment +1.5, -2.5mm Grey matt finish

spice/bottle drawer drawers and dividers HQ450A150Z01 Pure pro spice/bottle 150mm Drawer Grey Matt Suits 150mm module 450mm Deep

HQ10074450-85

HQ10075450-85

Pure Pro Spice/Bottle Divider low Grey matt Suits HQ450A150Z01 Top drawer

Pure Pro Spice/Bottle Divider high Grey matt Suits HQ450A150Z01 Bottom drawer

NL: 450mm Width: 85mm 4 dividers plus base

pivot star hinge

Hinge

Overlay

Mounting

Drill Pattern

110°

Full Overlay / Half Overlay / Inset

Screw-On / Knock-in / Q-turn

B-45/9.5 / H-52/5.5

160°

Full Overlay

Q-turn / Knock-in

B-45/9.5 / H-52/5.5

90° Blind panel

Knock-in

B-45/9.5 / H-52/5.5

45° Corner door hinge

Knock-in

B-45/9.5 / H-52/5.5

135° Bi-fold

Q-turn / Knock-in

B-45/9.5 / H-52/5.5

overlay

Full Overlay

Half Overlay

Inset

mounting Screw-On

Knock-in

ASSESSMENT CRITERIA Aesthetics / Design Quality, Practical Use The PIVOT-STAR is an innovative technology hinge characterized by its fast-adjustable soft-close design. The door closing speed can be adjusted to suit different door sizes and / or user preferences by turning the speed setting screw from “-” to ”+”. This speedadjustability feature makes the PIVOT-STAR stand out from other hinges that only allow users to activate or deactivate the soft-close function.

Q-turn

pivot star hinge

Integrated Soft Close Hinge

Overlay

Mounting

Drill Pattern

110°

Full Overlay / Half Overlay / Inset

Screw-On / Knock-in / Q-turn

B-45/9.5 / H-52/5.5

160°

Full Overlay

Screw-On / Knock-in / Q-turn

B-45/9.5 / H-52/5.5

90° Blind panel

Knock-in / Q-turn

B-45/9.5 / H-52/5.5

45° Corner door hinge

Knock-in / Q-turn

B-45/9.5 / H-52/5.5

95° Thick hinge

Full Overlay

Q-turn

B-45/9.5 / H-52/5.5

soft close Number of hinges for each door Soft Closing Adjustment

L = distance between hinges

“-” Reducing door closing time “+” Increasing door closing time

The number of hinges needed for each door depends on the width of the door, the height of the door, and the type of material the door is made of. It varies in particular practices. The hinge installation proposal listed above is only for your reference. The experiment is suggested in an uncertain situation. “L” volume shall be large considering stability.

drill pattern

B Drill Pattern 45/9.5

H Drill Pattern 52/5.5

pivot star hinge

110° hinge Environmentally friendly

Fine tuning

Cyanide free electroplating suitable for schools and hospitals

Side, depth and height(cam)adjustable for a better presentation of the doors

Unlimited soft-close adjustment

Highly slam resistant

Controlled adjustment with only a twist of a screw

Without rebound effect

Availability

Full Overlay

Half Overlay

Inset

Knock-In

Screw-On

Q-Turn

H 52/5.5

B 45/9.5

Soft Close

Full Overlay

Hinge DTCC81A676 Full overlay |

Integrated Soft Close Hinge DTCC81A676F

Screw-On

Full overlay |

DTCC81A675N Full overlay |

Knock-In

DTCC81A677M Full overlay |

Knock-In

DTCC81A675T8

Half Overlay

Full overlay |

Q-Turn

DTCC81B675T8 Half overlay |

Q-Turn

DTCC81B677M Half overlay |

Knock-In

DTCC81C675T8 Inset

Q-Turn

DTCC81C677M Inset

Inset

Knock-In

B 45/9.5

H 52/5.5

B 45/9.5

H 52/5.5

B 45/9.5

H 52/5.5

Screw-On

DTCC81A675NF Full overlay |

Knock-In

DTCC81A677MF Full overlay |

Knock-In

DTCC81A675T8F Full overlay |

Q-Turn

DTCC81A677T0F Full overlay |

Q-Turn

DTCC81B676F Half overlay |

Q-Turn

DTCC81B677T0F Half overlay |

B 45/9.5

H 52/5.5

B 45/9.5

H 52/5.5

Screw-On

DTCC81B675T8F Half overlay |

Q-Turn

B 45/9.5

H 52/5.5

DTCC81C676F • • • • • •

110° opening angle 11.5mm hinge cup depth 35mm hinge cup diametre 16-26mm door thickness 3-6mm drilling distance(K) on the door Shallow cup depth

• • • • •

Side adjustment +2mm/-4mm Depth adjustment +3mm /-1mm Cam adjustment up/down +2mm /-2mm 26mm thick doors with standard hinge Easily fine-tuned soft close adjustment for small doors

Inset

Screw-On

DTCC81C675T8F Inset

Q-Turn

DTCC81C677T0F Inset

Q-Turn

B 45/9.5

H 52/5.5

pivot star hinge

Plate Height Calculation

Versatile application

Shallow cup depth can be used on doors from 13mm up to 26mm thick as standard 110 degree

Plate height = 12(constant) + DBE (K)- D (Overlay required)

Clean minimalist look Slim modern design

Space needed to open the door

2mm Plate = 12 + 5 – 15

K=3

0.7

0.9

1.2

1.5

1.8

2.2

2.6

3.2

3.8

4.5

5.3

K=4

0.7

0.9

1.1

1.4

1.8

2.1

2.5

3.0

3.5

4.4

4.9

K=5

0.6

0.9

1.1

1.4

1.7

2.0

2.4

2.9

3.4

3.9

4.6

K=6

0.6

0.8

1.1

1.3

1.6

2.0

2.4

2.8

3.2

3.8

4.4

T= Door thickness K= Cup hole drilling distance from door edge

Space needed to open the door K=3

0.0

0.1

K=4

0.0

0.2

0.4

0.7

0.9

1.1

K=5

0.0

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

K=6

0.9

1.2

1.4

1.6

1.8

2.0

2.2

2.4

2.6

2.8

3.0

The above values are calculated on the assumption that the doors have square edges. They are reduced if the doors have radiussed edges.

Projection of the door

Ø 35mm hinge cup types

Use these formulas to determine the type of hinge arm, drilling distance(K=5mm), and the height of the mounting plate (H=2mm) for each door application. Projection of the door from the cabinet side at the max opening. The figures are based on a straight arm hinge, H=0mm mounting plate and drilling distance (K)=3mm.

B Drill Pattern 45/9.5

H Drill Pattern 52/5.5

pivot star hinge

160° hinge Availability

Knock-In

Screw-On

Q-Turn

Hinge

DTCC81A605N

DTCC81A605NF

DTCC81A607M

DTCC81A607MF

DTCC81A605T8

DTCC81A605T8F

Q-Turn

Screw-On

| B 45/9.5

Knock-In

Soft Close

Integrated Soft Close Hinge DTCC81A606F

Knock-In

160° opening angle 11.8mm hinge cup depth 35mm hinge cup diametre 16-28mm door thickness 3-6mm drilling distance on the door

B 45/9.5

DTCC81A606 Screw-On

• • • • •

H 52/5.5

Knock-In

H 52/5.5

Knock-In

B 45/9.5

Q-Turn

B 45/9.5

| H 52/5.5

B 45/9.5

DTCC81A607T0F Q-Turn

H 52/5.5

Ø 35mm hinge cup types

The door combined with a mounting plate H=0, opens at 90° with a 1.0mm protrusion allowing objects to move from inside of the cabinet.

Ø 35mm hinge cup types

Use these formulas to determine the type of hinge arm, drilling distance(K=5mm), and the height of the mounting plate (H=2mm) for each door application.

H Drill Pattern 52/5.5 8

B Drill Pattern 45/9.5

pivot star hinge

90° blind panel hinge Availability

Hinge DTCC81G675N Knock-In

Knock-In

• • • • •

Q-Turn

H 52/5.5

B 45/9.5

DTCC81G677M

Soft Close

Knock-In

110° opening angle 11.5mm hinge cup depth 35mm hinge cup diametre 16-26mm door thickness 3-6mm drilling distance on the door

H 52/5.5

Integrated Soft Close Hinge DTCC81G677MF Knock-In

H 52/5.5

DTCC81G675T8F Q-Turn

Space needed to open the door

B 45/9.5

K=3

0.7

0.9

1.2

1.5

1.8

2.2

2.6

3.2

3.8

4.5

5.3

K=4

0.7

0.9

1.1

1.4

1.8

2.1

2.5

3.0

3.5

4.4

4.9

K=5

0.6

0.9

1.1

1.4

1.7

2.0

2.4

2.9

3.4

3.9

4.6

K=6

0.6

0.8

1.1

1.3

1.6

2.0

2.4

2.8

3.2

3.8

4.4

T= Door thickness K= Cup hole drilling distance from door edge

Space needed to open the door K=3

0.0

0.1

K=4

0.0

0.2

0.4

0.7

0.9

1.1

K=5

0.0

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

K=6

0.9

1.2

1.4

1.6

1.8

2.0

2.2

2.4

2.6

2.8

3.0

The above values are calculated on the assumption that the doors have square edges. They are reduced if the doors have radiussed edges.

Adjustment range of D -3 +2

Ø 35mm hinge cup types B Drill Pattern 45/9.5

Use these formulas to determine the type of hinge arm, drilling distance(K=5mm), and the height of the mounting plate (H=2mm) for each door application.

H Drill Pattern 52/5.5

Adjustment range of L -0.5 +3

pivot star hinge

95° thick door hinge Availability

Integrated Soft Close Hinge DTCC81A615T8F Q-Turn

Soft Close

• • •

Q-Turn

H 52/5.5

K=3

B 45/9.5

DTCC81A617T0F

B 45/9.5

Q-Turn

95° opening angle 11.5mm hinge cup depth 35mm hinge cup diametre

Space needed to open the door

• • •

H 52/5.5

19-35mm door thickness 3-9mm drilling distance on the door Soft close only

32 - 35

0.1

0.2

0.3

0.4

0.5

0.7

0.9

1.3

2.2

3.2

4.1

5.0

6.0

7.0 - 10

K=4

0.1

0.2

0.3

0.4

0.5

0.7

0.8

1.0

1.6

2.5

3.5

4.4

5.3

6.3 - 9.1

K=5

0.1

0.2

0.3

0.4

0.5

0.7

0.8

1.0

1.2

2.0

2.9

3.7

4.7

5.6 - 8.4

K=6

0.1

0.2

0.3

0.4

0.5

0.6

0.8

1.0

1.2

1.4

2.3

3.2

4.1

5.0 - 7.8

K=7

0.1

0.2

0.3

0.4

0.5

0.6

0.8

1.0

1.2

1.4

1.8

2.7

3.6

4.4 - 7.0

K=8

0.1

0.2

0.3

0.4

0.5

0.6

0.8

1.0

1.1

1.4

1.6

2.2

3.1

3.9 - 6.5

K=9

0.1

0.2

0.3

0.4

0.5

0.6

0.8

0.9

1.1

1.3

1.6

1.8

2.6

3.4 - 6.0

T= Door thickness K= Cup hole drilling distance from door edge

Space needed to open the door

32 - 35

K=3

0.0

0.0 - 0.0

K=4

0.0

0.0 - 0.0

K=5

0.0

0.2

0.3

0.4

0.5 - 0.7

K=6

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.0

1.2

1.3

1.4

1.5 - 1.7

K=7

1.3

1.4

1.5

1.6

1.7

1.8

1.9

2.0

2.2

2.3

2.4

2.5 - 2.7

K=8

0.1

0.2

0.3

0.4

0.5

0.6

0.8

1.0

1.1

1.4

1.6

2.2

3.1

3.5 - 3.7

K=9

2.3

0.2

0.3

0.4

0.5

0.6

0.8

0.9

1.1

1.3

1.6

1.8

2.6

4.5 - 4.7

The above values are calculated on the assumption that the doors have square edges. They are reduced if the doors have radiussed edges.

Projection of the door

Ø 35mm hinge cup types B Drill Pattern 45/9.5

Projection of the door from the cabinet side at the max opening. The figures are based on a straight arm hinge, H=0mm mounting plate and drilling distance (K)=3mm.

Use these formulas to determine the type of hinge arm, drilling distance(K=5mm), and the height of the mounting plate (H=2mm) for each door application.

H Drill Pattern 52/5.5

pivot star hinge

135° bi-fold corner hinge Availability

Hinge DTCC81H675T8 Q-Turn

Q-Turn

• • •

Knock-In

H 52/5.5

55° opening angle 11.5mm hinge cup depth 35mm hinge cup diametre

Kitchen bi-fold door application

B 45/9.5

DTCC81H677M

B 45/9.5

Knock-In

• •

H 52/5.5

14-26mm door thickness 3-7mm drilling distance on the door

Ø 35mm hinge cup types

B Drill Pattern 45/9.5

H Drill Pattern 52/5.5

Use these formulas to determine the type of hinge arm, drilling distance(K) and the height of the mounting plate (H) for each door application.

110° stainless steel hinge Availability

Hinge DTCSS80A476F

Screw-On

Soft Close

• • • • • • • •

110° Full overlay Soft Closing Screw-on 304 grade stainless steel Incorporated hinge plate Hinge and plate as pictured Suitable for outdoors and alfrescos 11.5mm cup depth

pivot star hinge

45° corner door hinge Availability

Hinge DTCC81E675N Knock-In

Knock-In

• • • • •

Q-Turn

H 52/5.5

B 45/9.5

DTCC81E677M

Soft Close

Knock-In

110° opening angle 11.5mm hinge cup depth 35mm hinge cup diametre 16-26mm door thickness 3-6mm drilling distance on the door

H 52/5.5

Integrated Soft Close Hinge DTCC81E677MF Knock-In

H 52/5.5

DTCC81E675T8F Q-Turn

Space needed to open the door

B 45/9.5

K=3

0.7

0.9

1.2

1.5

1.8

2.2

2.6

3.2

3.8

4.5

5.3

K=4

0.7

0.9

1.1

1.4

1.8

2.1

2.5

3.0

3.5

4.4

4.9

K=5

0.6

0.9

1.1

1.4

1.7

2.0

2.4

2.9

3.4

3.9

4.6

K=6

0.6

0.8

1.1

1.3

1.6

2.0

2.4

2.8

3.2

3.8

4.4

T= Door thickness K= Cup hole drilling distance from door edge

Space needed to open the door K=3

0.0

0.1

K=4

0.0

0.2

0.4

0.7

0.9

1.1

K=5

0.0

0.2

0.4

0.6

0.8

1.0

1.2

1.4

1.6

1.8

2.0

K=6

0.9

1.2

1.4

1.6

1.8

2.0

2.2

2.4

2.6

2.8

3.0

The above values are calculated on the assumption that the doors have square edges. They are reduced if the doors have radiussed edges.

Adjustment range of L -0.5 +3

Adjustment range of D +2 -4

Ø 35mm hinge cup types B Drill Pattern 45/9.5

Use these formulas to determine the type of hinge arm, drilling distance(K=5mm), and the height of the mounting plate (H=2mm) for each door application.

H Drill Pattern 52/5.5

pivot star hinge plates

wing hinge plate Screw-On Cam Hinge Plate DTC81T00TQ

DTC81T01TQ

DTC81T20TQ

DTC81T21TQ

DTC81T40TQ

DTC81T41TQ

Plate height - 0mm Plate height - 2mm Plate height - 4mm

• • • •

Cam adjustable plates adjust the height to +2/-2mm Available in 3 different fixings — Screw-On, Euro Screw Fix & Expanding Dowel Plates come in the standard size of 2mm and are also available in 0, 4, 9, and 18mm A standard of 2mm can only occur with a 5mm DBE (Distance Before the Edge)

Expanding Dowel Cam Hinge Plate

Euro Screw Fix Cam Hinge Plate

Plate height - 0mm Plate height - 2mm Plate height - 4mm

Euro Screw Fix Non Cam Hinge Plate

DTC81T02TQ

DTC81H02AQ

DTC81T22TQ

DTC81H22AQ

DTC81T42TQ

DTC81H42AQ

Plate height - 0mm Plate height - 2mm Plate height - 4mm

DTC81H92AQ

Plate height - 9mm

DTC81H182AQ

Plate height - 18mm

Screw-On Non Cam Hinge Plate DTC81H20AQ

Plate height - 2mm

inline hinge plate • • • •

The inline cam plate is only height adjustment- +2/-2 Available in knock-in only Plates come in the standard size of 2mm and is also available in 0mm & 4mm A standard of 2mm can only occur with a 5mm DBE (Distance Before the Edge)

Knock-In Cam Hinge Plate DTC81H0MYQ

Plate height - 0mm

DTC81H2MYQ

Plate height - 2mm

DTC81H4MYQ

Plate height - 4mm

Angle Reduction Clips Plate Height Calculation • •

Plate height = 12(constant) + DBE (K)-D (Overlay required) 2mm Plate = 12 + 5 – 15

DTC120S160 suits 160° reduce to 120°

DTC86S80

suits 110° reduce to 85°

dtc down stays dtc down stays

white

black

Features • • • • • • • •

Down Stay

Cabinet height: 200-480mm Door weight up to 14kg Horizontal or vertical mounting Adjustable opening speed and angle Soft-opening Medium and strong power factor options Available in white and black finish Can be used with flat hinge or 110ª euro hinge (sold separately)

DTCDQ00AM02A

MEDIUM POWER WHITE

DTCDQ00AH02A

STRONG POWER WHITE

DTCDQ00AM02C

MEDIUM POWER BLACK

DTCDQ00AH02C

STRONG POWER BLACK

Kit Includes

MEDIUM

HP (MM)

LIFT MECHANISM SET X1

200-230 230-270

STRONG

LIFT MECHANISM SET X2

LIFT MECHANISM SET X1

LIFT MECHANISM SET X2

4.3-5.8

4.9 - 6.9

3.7-5.6

6.8 - 9.2

4.4 - 6.2

270-330

3.8-5

7.4-9

4 - 5.2

8.6-11

330-380

3.3-4.9

7.2-8.8

3.7-5.1

8-11.2

380-430

2.9-3.9

6.1-8.7

3.3-4.5

7.5-11

430-460

2.9-3.7

5.9-8.3

3.3-4.5

7.5-10.5

460-480

2.9-3.7

5.5-7.5

3.4-4.1

7-9.5

dtc down stay installation door weight tables DTCDQ00PB F053139677

FLAT HINGE NICKEL, 18-20MM BOARD BLACK, 16-21MM BOARD

MEDIUM HP (MM)

LIFT MECHANISM SET X1

200-230 230-270

STRONG

LIFT MECHANISM SET X2

LIFT MECHANISM SET X1

LIFT MECHANISM SET X2

4.2-6.2

4.8-6.8

3.6-5.2

6.8 - 9.6

4.4-6

270-330

3-4.6

6.4-8.8

3.6-5.2

7-10.2

330-380

3.2-4.3

6.5-8.5

3.7-4.9

6.9-10.1

380-430

3.1-3.9

5.7-7.3

3.7-4.5

6.9-8

430-460

2.7-3.9

5.9-8.3

3.7-4.7

7.1-9.5

460-480

2.8-3.8

5.3-7.7

3.6-4.4

6.8-8.9

MEDIUM

STRONG

HP (MM)

LIFT MECHANISM SET X1

LIFT MECHANISM SET X2

LIFT MECHANISM SET X1

LIFT MECHANISM SET X2

200-230

6.3-8.5

7.5-9.3

230-270

4.5-5.6

9.2-12

6.8-8.6

270-330

3.7-5.1

7.7-10.1

5.4-7.1

10.5-13.7

330-380

3.2-4.3

6.6-9.3

4.6-6.1

9.1-11.3

380-430

3-4

6.6-8.2

4.4-5.4

8.4-10.2

430-460

2.8-3.6

5.4-7.6

4.2-5.2

7.4-9.4

460-480

2.8-3.6

5.4-7.6

4-5.2

7.2-9.4

DTCDQ00PB F053139677

FLAT HINGE NICKEL, 18-20MM BOARD BLACK, 16-21MM BOARD

MEDIUM HP (MM)

LIFT MECHANISM SET X1

200-230

5.3-7.3

230-270

4.2-6

STRONG

LIFT MECHANISM SET X2

LIFT MECHANISM SET X1

LIFT MECHANISM SET X2

8-11

9.6-12.8

6.6-8.6

270-330

3.8-5.1

7.9-11.1

5.7-7.3

11.3-14.5

330-380

3.3-4.5

7.3-8.5

4.9-6.3

9.7-11.7

380-430

3.2-4.2

6.2-8.2

4.4-5.4

8.6-10.6

430-460

3-3.8

6.2-7.8

4-5.2

7.8-10.2

460-480

2.8-4

5.6-7.8

3.8-5

7.6-10

top stays & latches top stays Features • Opening angle 107° • Door thickness 16-28mm • Suitable for doors 250-700mm high • Cabinet width up to 1200mm • 3D door adjustments: • Height +/-2mm • Depth +/-2mm • Side +/-2mm • Easy to open, and stays at any desired positions • Tool free assembly and removal • Hovering adjustment only • Available in 2 colours (standard supply in white) • Available in push-to-open options which includes push-to-open latches

Top Stay DTCSQ02BL03A

1.92-3.12kg 250-400mm 480-1250

Load

Height

Power- Light

DTCSQ02BM03A

Load

Power- Medium

Height

DTCSQ02BH03A

Load

Power- Strong

Height

DTCSF00AH02A

Load

3.84-4.7kg 250-500mm LF 960-2350 6.4-7.2kg 250-500mm LF 1600-3600 8-12.85kg 400-700mm 3200-9000

white

Height

Power- Extra Strong

(standard)

DTCSQ2FBM03A

Load

Power- Medium - PTO

Height

DTCSQ2FBC03A

Load

4.24-4.9kg 250-500mm LF 1060-2450

Power- Extra Strong - PTO

7.42-8.33kg 350-600mm 2600-5000

Height LF

Power Factor LF = Cabinet height KH(mm) x door weight(kg)

Cover Caps (Optional) DTCSQJS03B

Grey

DTCSFJS01B

Grey

Grey to suit only Extra strong DTCSF00AH02A

Reducer (if required) ~

DTCSQW100

100 degree reducer

DTCSQW75

75 degree reducer

DTCSFW75

75 degree reducer to suit DTCSF00AH02A

top stays & latches top stays

latches

DTCMS-A011A

Magnetic push latch. 10mm drill hole adjustable head M=Push Length

• • • • • • • • • •

Provides 3D adjustments (height, side & depth). Upper:+/-2mm Lower: +2/-1mm Suitable for cabinet height 650-1040mm high Weight capacity up to 19.8kg White (Standard colour) Adjustable soft-closing speed Hovering adjustment Stays at a desired position Easy to open Easy installation, door clips on & off without tools Door thickness 16-28mm

DTCMS-B03A

Magnetic push, cross plate, adjustable head M=Push Length

Bi-Fold Top Stay DTCST04AH02A

Load

DTCST05AH02A

Load

DTCST06AH02A

Load

DTCST07AH02A

Load

DTCST08AH02A

Load

11.5-19.8kg Height650 - 729mm 10.5-18.1kg Height730 - 799mm

9.5-16.5kg Height800 - 879mm 8.7-15.1kg Height880 - 959mm

8.0-13.9kg Height960 - 1040mm

DTCMS-B01A

Magnetic push, inline plate, adjustable head M=Push Length

limited lifetime warranty on all dtc products

To make a warranty claim, proof of purchase or equivalent documentation along with the defective product and a written explanation of the defect must be supplied for warranty claims to be considered. Warranty claims can be provided by pre-paid postage to our distributor in Australia. Nikpol PTY LTD 6-12 Fairchild Street, HEATHERTON VIC 3202 Please allow up to 4 weeks for a response to any warranty claim.

Visit Nikpol’s website for more information about warranty claims. www.nikpol.com.au

Nikpol Pty. Ltd. DTC brochure 2023 For the full product range and availability please refer to nikpol.com.au. The photos and images in this brochure are as close to the real product as possible, but from time to time, camera angles and printing can distort these images. For all warranties, care information and other technical information, please see visit our website. Printed September 2023 Tel Web Email

1300 645 765 www.nikpol.com.au sales@nikpol.com.au

Head Office (VIC) 6-12 Fairchild Street Heatherton VIC 3202 @nikpolptyltd

QLD 19 William Farrior Place Eagle Farm QLD 4009 @nikpolaustralia

#nikpol

NSW 2/5 Bessemer Street, Blacktown NSW 2148 /company/nikpol/

@nikpolptyltd
