9
Clipper
®
Wire Hook System
Maintenance Lacers
The advantages of lacer installation and Clipper® Roller Lacing Technology™ are what set Clipper wire hook systems apart from all other light-duty fasteners.
Roller Lacer® Available in four widths: 24”, 36”, 48”, and 60” (600, 900, 1200, 1500 mm). Ideal for users with wide belts requiring on-site installation.
All three maintenance lacers – the Roller Lacer® Gold Class™ , the Roller Lacer and the Microlacer® – utilize Roller Lacing Technology. Clipper Roller Lacing Technology works fast to significantly minimize downtime, without sacrificing precision.
• Handle-actuated belt clamp system • Sturdy aluminum construction for on-site installation • Storage compartment for extra face strips and lacer pins • Continuous lacing feature for lacing belts wider than the tool’s width
Roller Lacer® Belt Width in. mm
Ordering Number
24
600
RL-24
36
900
RL-36
48
1200
RL-48
60
1500
RL-60
Face Strips sold separately
Roller Lacer® Face Strips Belt Width in. mm
Hook Size UCM36, 36
Hook Size UX1, 1
Hook Size U2-U3, 2-4
Hook Size U4-U7, 4½-7
24
600
FSMAN36-24
FSMAN1-24
FSMAN2-24
FSMAN4-1/2-24
36
900
FSMAN36-36
FSMAN1-36
FSMAN2-36
FSMAN4-1/2-36
48
1200
FSMAN36-48
FSMAN1-48
FSMAN2-48
FSMAN4-1/2-48
60
1500
FSMAN36-60
FSMAN1-60
FSMAN2-60
FSMAN4-1/2-60
Includes one Lacer Pin
Microlacer® Proven, reliable choice for belts 14” (350 mm) wide and less. Can also be used on wider belts with infrequent lacing requirements. • Belts are secured by tightening belt clamp knobs • Sturdy construction • Compact and lightweight • Economical • Continuous lacing feature for lacing belts wider than the tool’s width
Clipper® Roller Lacing Technology™
Microlacer® Belt Width in. mm 14
Ordering Number
350
MICROLACER
Face Strips sold separately
Microlacer® Face Strips Hook Size
Ordering Number
UCM36, 36
FSMAN36-MICRO
UX1, 1
FSMAN1-MICRO
U2-U3, 2-4
FSMAN2-MICRO
U4-U7, 41/2-7
FSMAN4-1/2-MICRO
Includes one Lacer Pin
www.flexco.com
One person can install splices on-site and the process is easy to learn. The lacers are lightweight, portable, and easy-to-carry. Sturdy aircraft aluminum construction can handle rigorous use.
