LOW/MEDIUM PRESSURE
4202 Paint Spray Tubing
4202-04504 4202-08504 4202-12624
NOMINAL I.D.
in 1/8 1/4 3/8
mm 3.2 6.4 9.5
NOMINAL O.D.
in .275 350 .499
mm 7.0 8.9 12.7
NOMINAL WALL THICKNESS
in .050 .050 .062
MINIMUM BEND RADIUS
mm 1.3 1.3 1.6
in 1.50 2.50 3.00
*WORKING PRESSURE @75°F (23.9°C)
mm 38.1 63.5 76.2
psi 475 275 200
bar 32.8 19.0 13.8
MIN. BURST PRESSURE @75°F (23.9°C)
psi 2,000 1,100 900
bar 137.9 75.9 62.1
WEIGHT LB KG
AVAILABLE LENGTH
100 ft 100 m 1.23 1.8 2.15 3.2 3.86 5.7
feet 500 500 500
TWIN LINE HOSE
r
PART NUMBER
Construction
Temperature Range
• Low pressure air-operated paint spray systems
• Nylon single wall design • Non-staining, non-swelling core tube
• -40°F to 150°F (-40°C to 55°C)
TRUCK HOSE
Applications
• Translucent design for easy inspection of paint flow • Flexible and lightweight • Excellent resistance to paint and cleaning solvents • Available lengths are continuous
AIR, WATER & TUBING
* Recommended Working Pressure Note: Always use accepted cleaning practices to clean finished hose assembly before use.
Features
HIGH PRESSURE
CONSTANT PRESSURE HOSE
Tubing
TUBING
• Corrosion resistant plated brass and aluminium fittings • Contoured nut eliminates need for ferrule; helps eliminate leaks • With or without spring guard to prevent kinking • Easy to assemble, completely reusable
4202-0450
1/8”
1/8 NPT Male 1/4 NPSM
4401-4440 4401-5480
4202-0850
1/4“
1/8 Male Pipe Special 1/8 Male Pipe w/Spring Guard 1/4 NPSM Special 1/4 NPSM w/Spring Guard 9/16 x 20 Straight Mechanical Special 9/16 x 20 w/Spring Guard 3/8NPSM Special 3/8 NPSM w/Spring Guard
4401-4840 4401-6840‡ 4401-5880 4401-7880 4401-5818‡ 4401-7818‡ 4401-5812 4401-7812
4202-1262
3/8“
9/16 x 20 Straight Mechanical 3/8 NPSM
4401-51218‡ 4401-51212
‡ Run-to-order hose. Contact your Eaton representative for details.
PART NUMBER
HOSE ASSEMBLY EQUIPMENT
FITTING DESCRIPTION
ACCESSORIES
NOMINAL I.D.
Available at www.EatonProducts.com EATON Synflex Hose and Fittings Technical Catalog E-HOOV-MC001-E1 March 2008
21
TECHNICAL DATA
Features
HOSE FITTINGS
SPECIALTY HOSE
4401 Paint Spray Tubing Fittings
