Brass Products Push>Connect Plus
Note: For additional technical questions, contact Technical Support at 1-888-258-0222. Eaton is proud to announce three design changes to Push>Connect products. The introduction of a low profile, sure-seal design for male NPTF threaded fittings is here. Also, an improved collet design will allow use with all types of tubing from Nylon to 90A durometer Polyurethane, including Polyethylene, and PVC tubing. Lastly, the male swivel design provides greater strength and stability. Below is a summary of features and benefits for the newly named Push>Connect Plus.
Swivel Male “Y”
F M
A
L
Perfect thread seal: A captured Teflon® ring around the base of the hex shoulder, seals similar to a reusable (SAE type) seal eliminates thread sealant and loose particles associated with thread sealant.
Super-quick Installations: New short thread length means fewer turns and super-quick installations.
Lower Profile: Push>Connect Plus has a lower profile for those tight places. A shorter thread design eliminates exposed threads where dirt and bacteria can collect (ideal for food processing and hygienic applications).
Universal Thread: Use with NPT, BSPP, and BSPT ports. The new part will have a ‘P’ in the part number to signify the new design. An example of this change is previous #1169x4S becomes #1169Px4S. Current Push>Connect parts with 10-32UNF threads and ending in ‘A’ (eg.1168x2A) will continue with the current thread design.
More Versatility: The new brass collet is designed for use with all types of tubing from Nylon to 90A durometer Polyurethane, including Polyethylene, and PVC tubing. Tube Male O.D. Pipe
Catalog Number Thread
F H
M L
1/8 5/32 1/4
1108Px2S 1108Px2.5S 1108Px4S
0.83 0.83 0.96
0.39 0.39 0.49
1/8 1/8 1/8
0.20 0.20 0.20
1.28 1.28 1.40
H
SW
D
Male Connector H
L SW
D SW1 C
AG F
Tube O.D. A
Male Pipe Thread D
Catalog Number F G H L
SW SW1 (mm) (mm)
1/8 1/8 1/8 5/32 5/32 5/32 1/4 1/4 1/4 1/4 5/16 5/16 5/16 3/8 3/8 3/8 3/8 1/2 1/2 1/2
10-32* 1/8 1/4 10-32* 1/8 1/4 10-32* 1/8 1/4 3/8 1/8 1/4 3/8 1/8 1/4 3/8 1/2 3/8 1/4 1/2
1168Px2A 1168Px2 1168Px2x4 1168x2.5A 1168Px2.5 1168Px2.5x4 1168x4A 1168Px4 1168Px4x4 1168Px4x6 1168Px5 1168Px5x4 1168Px5x6 1168Px6x2 1168Px6 1168Px6x6 1168Px6x8 1168Px8 1168Px8x4 1168Px8x8
9 12 14 9 12 14 12 12 14 19 14 14 19 17 17 19 22 19 19 22
Available at www.EatonProducts.com *UNF Thread 70
Improved Swivel Design: Strength and stability have been engineered into the new male swivel.
EATON Brass Products Master Catalog E-BRFI-MC001-E3 February 2008
0.346 0.346 0.346 0.346 0.346 0.346 0.460 0.460 0.460 0.460 0.539 0.539 0.539 0.610 0.610 0.610 0.610 0.720 0.720 0.720
0.411 0.551 0.629 0.411 0.551 0.629 0.551 0.551 0.629 0.866 0.629 0.629 0.866 0.776 0.776 0.866 1.004 0.866 0.866 1.004
0.177 0.200 0.255 0.177 0.200 0.255 0.177 0.200 0.255 0.294 0.200 0.255 0.294 0.200 0.255 0.294 0.335 0.294 0.255 0.335
0.846 0.728 0.807 0.807 0.728 0.807 0.905 0.807 0.846 0.885 0.945 0.945 0.924 1.082 1.102 0.945 0.984 1.161 1.161 1.062
2.0 2.5 2.5 2.0 2.5 2.5 2.0 4.0 4.0 4.0 5.0 6.0 6.0 5.0 7.0 7.0 7.0 10.0 7.0 10.0
