VACUUM PRODUCT PUMP HEADER PULLEYS
V-BELT CRANKSHAFT PULLEY • • • •
Ideal for driving alternators and/or vacuum pumps at optimum speed Fits any 1" dia. crank-driven mandrel with 1/8" x 1/8" keyway CNC machined from billet aluminum with hard-coat anodized finish May be used with Moroso Vacuum Pumps Nos. 22640, 22641, 22642, 22644, 22840, 22842, 22843 and Vacuum Pump Pulley No. 64885
PART # 23520 23523
DESCRIPTION 2.5" V-Belt Crankshaft Pulley 4" V-Belt Crankshaft Pulley
No. 23523
No. 23520
VACUUM PUMP V-BELT PULLEY
PART # 64885
DESCRIPTION Vacuum Pump V-Belt Pulley
No. 64885
Drive Kits on pgs. 118-120
VACUUM PUMP PULLEY, OFFSET V-Belt • Allows Moroso Vacuum Pumps to be installed in cars with minimal drive mandrel space • Hard coat anodized • Offset 7/8", 5" diameter pulley uses stock (3-bolt) mounting pattern with 1.16" bolt circle • Use with Moroso Vacuum Pump Nos. 22640, 22641, 22642, 22644, 22840, 22842 and 22843 PART # 64887
DESCRIPTION Vacuum Pump Pulley, Offset
No. 64887
VACUUM PUMP PULLEY Gilmer Type, 28 Tooth • Fits Moroso Racing Vacuum Pumps or similar “smog” pumps that use OE-style, 3-bolt mounting pattern; accepts standard gilmer belts with 3/4" width or less • Precision machined from aircraft-quality aluminum with hard-coat anodized finish for extended service life and features direct, bolt-on installation • Use with Moroso 3- or 4-Vane Racing Vacuum Pump Nos. 22640, 22641, 22642, 22643, 22644, 22840, 22842, 22843 and interchangeable drive components PART # 64886
DESCRIPTION Vacuum Pump Pulley, Gilmer Type, 28 Tooth
PART # 97172
VACUUM PUMPS & ACCESSORIES
• Fits Moroso Racing Vacuum Pumps or similar “smog” pumps that use OE-style, 3-bolt mounting pattern • Precision machined from the highest grade aircraft aluminum and hard-coat anodized for extended service life • Deep V-groove ensures belt retention under all racing conditions • Machined with six holes to reduce weight • 5" diameter pulley uses stock (3-bolt) mounting pattern with 1.16" bolt circle • Use with Moroso Vacuum Pump Nos. 22640, 22641, 22642, 22644, 22840, 22842 and 22843
No. 64886
AVAILABLE OPTIONS Crankshaft Pulley
VACUUM PUMP PULLEY Gilmer Type, 36 Tooth • Fits Moroso Racing Vacuum Pumps or similar “smog” pumps that use OE-style, 3-bolt mounting pattern; accepts standard Gilmer belts with 1/2" width or less • Precision machined from aircraft-quality aluminum and features direct, bolt-on installation • Use with Moroso 3- or 4-Vane Vacuum Pump Nos. 22640, 22641, 22642, 22643, 22644, 22840, 22842 and interchangeable drive components PART # 64888
DESCRIPTION Vacuum Pump Pulley, Gilmer Type, 36 Tooth
PART # 97172
AVAILABLE OPTIONS Crankshaft Pulley
No. 64888
