MOROSO’S PREMIER CIRCLE TRACK DISTRIBUTORS OUR BEST SPEAKS FOR ITSELF! In most catalogs a manufacturer will showcase their top-of-the-line product, whether sold in larger numbers or not. Unfortunately, we can’t show you our Premier Distributors because of proprietary agreements. We can tell you how extaordinarily well our distributors perform—in Circle Track’s top racing series—by both the leader and the majority of the top ten series cars. In addition to racing, Moroso distributors are also utilized on one of the largest fleet of delivery vehicles in the United States. Even though you might not be racing 500 miles or picking up 500 packages a day, Moroso’s line of distributors give our customers the same performance, quality and reliability that racing and industry leaders have come to depend on.
CIRCLE TRACK DISTRIBUTOR REPLACEMENT PARTS For Moroso Multiphase, Premier Billet and Durabillet Distributors DESCRIPTION Adapter Ring Cap Cap (w/o Wire Retainer) Pick Up (Short Lead) Pick Up (Long Lead) Retainer Rotor
MULTIPHASE
PREMIER BLUE BELL 97851 97852 97850 97862 97863 97853 97848
97851 97852 97850 97862 97863 97853 97848
DURABILLET BLACK BELL 97854 97855 97856 97862 97863 97853 97848
IGNITION SYSTEM
DURAFIRE DISTRIBUTORS
COMPLETE BOLT-IN REPLACEMENTS FOR HEI CHEVROLET V8 ENGINES Now there’s no need to build your own high-output distributor that you can tune for noncomputerized HEI Chevy V8’s. The ignition experts at Moroso have done it for you! Moroso’s new DuraFire Distributors come equipped with everything needed to customize the ignition timing curve for your particular street/strip application. It features several high-output components including Moroso’s ProCoil that provides more complete combustion for easier starts, smoother idle, improved acceleration and more horsepower! Included: High-Output Module, Mechanical Advance Curve Kit, HEI Cap & Rotor, High-Output
ProCoil & Cover, option of Adjustable Vacuum Advance PART # 72230* 72231* PART # 97857 72355
DESCRIPTION DuraFire Distributor, G.M. HEI, V8, with Vacuum Advance DuraFire Distributor, G.M. HEI, V8, w/out Vacuum Advance D REPLACEMENT PARTS (continued on next page) Ignition Module, G.M. HEI ProCoil Ignition Coils (see page 308)
No. 72231
B
CHECK OUT THE FEATURES
302
A. One-piece aluminum housing is cleanly machined for neat appearance; steel shaft and gear provide concentric operation B. HEI Distributor Cap and Rotor are precision molded from advanced polymers with solid brass contacts and low-resistance center coil brush C. Mechanical Advance Curve Kit with extra springs allow you to recurve your distributor for full advance at optimum RPM; precision stamped weights, welded pins and center plates with smooth edges eliminate erratic timing F D. Moroso’s ProCoil combines low oxygen, high-conductivity magnet wire, high-silicon core material, and non-porous epoxy impregnation to produce extremely high current and extended duration for increased spark energy E. High-Output Module delivers high spark output and extended reliability F. Adjustable Vacuum Advance (available on No. 72230) allows you to dial in as much spark advance as conditions permit; built-in stop prevents the adjustment screw from backing out *Not legal for sale or use on pollution-controlled vehicles
Phone: 203.453.6571 Fax: 203.453.6906
C E A
