ELECTRONIC SWITCH PANEL PANEL MOUNT, SWITCH PANEL
• High-tech rocker-style multi-color L.E.D. switches that are dust and water resistant and feature a wide-profile for use with racing gloves • Five on/off switches with momentary start switch, 3.125" H x 7.875" L x 2.50" D • Right Angle 9 Pin Sub D Connector • Aluminum Faceplate features Moroso logo and are black anodized to withstand years of constant use • Includes switch decal package to indicate start, ignition, fuel, fan, lights, nitrous and other uses
No. 76025 PART # DESCRIPTION 76025 Electronic Switch Panel, Panel Mount Switches
ROLL BAR MOUNT, SWITCH PANEL
• High-tech rocker-style multi-color L.E.D. switches that are dust and water resistant and feature a wide-profile for use with racing gloves • Five on/off switches with momentary start switch • Right Angle 9 Pin Sub D Connector • Aluminum Faceplate features Moroso logo and are black anodized to withstand years of constant use • All housed in a 3.625" H x 8.375" L x 2.75" D black pod that attaches to a roll bar by hose clamps • Includes switch decal package to indicate start, ignition, fuel, fan, lights, nitrous and other uses
No. 76050 (includes Roll Bar Mount)
PART # DESCRIPTION 76050 Electronic Switch Panel, Roll Bar Mount Switches
ELECTRICAL SWITCH PANEL
Available Up-Gradable Software:
346
To purchase view online at www.moroso.com or, through a live support line, 203-458-0546, Mon-Fri, 8:15 -5:00pm E.S.T.
Level 2 Software: • Expanded Monitoring, Sensor Calibration Capability, Ability to Turn On or Off Circuits • Ability to monitor 2 Oil Pressure Sensors • Monitor Oil Pressure Levels with the ability to shut off 3 selectable circuits at selectable time (.2 - 1 second) if Oil pressure Drops below set points • Monitors Fuel Pressure with the ability to shut off 3 selectable circuits if Fuel pressure Drops below set points. • Ability to calibrate sensors by the user. • Separate Custom Circuit for monitoring and controlling Nitrous Oxide systems • Monitor Water Temperature so Circuits can be turned "ON" or "OFF" at user defined settings, such as Electric Water Pump, Main Fan, and Auxiliary Fan PART # DESCRIPTION 76100 Electronic Switch Panel, Level 2 Software Upgrade 76125 Electronic Switch Panel, Level 3 Software Upgrade
Phone: 203.453.6571 Fax: 203.453.6906
Level 3 Software: • Data Acquisition (Requires Level 2 Software) • 50 per second / 20 per second / 10 per second user selected sample rates • Stores data in date coded files in vehicle folder when downloaded • ZOOM feature - Drag over Area on manually enter start and finish times • 3 User defined and stored Data View Options • Displays 6 external input and 10 Circuits - On/Off on screen • Manual stepping on screen while displaying all recorded values in Legend • Ability to read input from magnetic sensors on drive shaft to calculate tire slippage
Level 4 Software: Available soon
