FRAME RAILS AND COMPONENTS
CROSSMEMBER KIT LADDER BAR • Convenient kit includes components needed to install a Ladder Bar Crossmember on a Pro Street or Drag Race car • Kit includes: 2" x 3" x 60" Dropped Crossmember, four Ladder Bar Crossmember Brackets and all hardware • 60" length and full 3.5” drop-center profile makes this sturdy mandrel bent Crossmember an ideal front attachment point on virtually any chassis design • The ladder bar mounting holes are stamped on a 33" radius to allow quicker adjustments when used with Competition Engineering’s Ladder Bars • Made in USA PART # C3059
DESCRIPTION Crossmember Kit - Ladder Bar
No. C3059
COMPETITION ENGINEERING
2" X 3" DROPPED CROSSMEMBER Makes fabricating a rear frame on a Pro Street or Drag Race car easier and more professional • Sturdy 2" x 3" x .083" steel is mandrel formed on computer-controlled equipment, providing uniform wall thickness and exact profile dimensions • 60" length and full 3.5" drop-center profile makes this crossmember an ideal front attachment point on virtually any chassis design • Use with Competition Engineering’s Formed Rear Frame Rails Nos. C3060, C3062 or any other suitable frame rail kit PART # C3061 PART # C3060 C3062 C3409
No. C3061
DESCRIPTION Dropped Crossmember, 2” X 3” AVAILABLE OPTIONS Universal 4-Link Frame Rails Universal Ladder Bar Frame Rails Ladder Bar Brackets
ALUMINUM & STEEL REAR FENDERWELLS • 24-gauge steel or .032" aluminum • Pittsburgh locking seam for easy assembly • Two widths to accommodate a variety of tire sizes • Available in five diameters • Bead rolled reinforcing ribs for strength
No. C3006
REAR FENDERWELLS CHART STEEL C3002 C3006 C3008 C3010
ALUMINUM C3004 C3005 C3007 C3009 C3011
LENGTH 43" (L) 46" (L) 36" (L) 38" (L) 40" (L)
DIMENSIONS HEIGHT x 21.5" (H) x x 23" (H) x x 18" (H) x x 19" (H) x x 20" (H) x
WIDTH 27.25" (W) 27.25" (W) 23.25" (W) 23.25" (W) 23.25" (W)
356 Phone: 203.453.5200 Fax: 203.453.6906
