NEW PRODUCTS NEW PRODUCTS
UNIVERSAL COOLANT EXPANSION TANK, WITH SIGHT TUBE • Designed for several applications where a small volume remote tank is necessary • Sight Tube is constructed out of high quality tubing, allows the user to check the fluid level for years to come • Fabricated aluminum with integral mounting bracket • 1-1⁄4 quart capacity • One 1⁄2" NPT female fitting on bottom of the tank and one 3⁄8" NPT female fitting on the side •B illet radiator filler neck accepts Moroso Racing Radiator Caps and standard size radiator caps, has a barbed fitting for overflow hose
No. 63773
PART # DESCRIPTION 63773 Coolant Expansion Tank, Universal with Sight Tube
4-5/8"
6-9/16"
3"
5-5/8"
5-5/8"
UNIVERSAL COOLANT EXPANSION & RECOVERY TANK SYSTEM Until now to follow the rules of most sanctioning bodies a remote recovery tank would have to be plumbed off the overflow hose. No need with this dual tank system which has a 1-1⁄4" quart expansion tank with an attached 1 quart recovery tank. An added bonus is that the recovery tank has a built-in siphon tube which draws the overflowed coolant back into the expansion tank as the coolant cools down. The end result is savings in complexity, weight, clutter, cost, maintenance and forgetting to install a recovery tank off the expansion tank. • Tank system is fabricated out of aluminum with integral mounting bracket • E xpansion Tank section features; -1-1⁄4 quart capacity -One 1⁄2" NPT female fitting on bottom of the tank and one 3⁄8" NPT female fitting on the side -Billet radiator filler neck accepts Moroso Racing Radiator Caps and standard size radiator caps • Recovery Tank section features; -1 quart capacity - Internal Siphon Tube which allows the coolant to recirculate from the recovery tank back into the expansion tank 1⁄4" NPT female fitting on bottom of the tank PART # 63772
No. 63772 3-3/4"
DESCRIPTION Coolant Expansion & Recovery Tank System, Universal
7-1/2" 3-3/4"
8-7/16"
3"
6-13/16"
8-1/2"
18
Phone: 203.453.6571 • Fax: 203.453.6906 • Tech Support: 203.458.0542 • 203.458.0546
2-1/2"
